Extron electronics SW2 ARxi Manual de usuario

1-2 SW2 ARxixi

xixi

xi and SW4 ARxixi

xixi

xi Switchers • Specifications

Video

Gain ............................................... Unity

Bandwidth .................................... 350 MHz (-3dB)

Switching speed ........................... 5 mS (max.)

Video input

Number/signal type ................... 2 (SW 2 ARxi) or 4 (SW 4 ARxi) RGBS, RGsB, RsGsBs, component video, S-video,

NTSC/PAL/SECAM composite video

Connectors .................................... 2 (SW 2 ARxi) or 4 (SW 4 ARxi) x 4 BNC female

Minimum/maximum levels ...... Analog ....... 0.3V to 1.5V p-p with no offset

Impedance .................................... 75 ohms

Horizontal frequency .................. 15 kHz to 145 kHz

Vertical frequency ....................... 30 Hz to 170 Hz

Return loss .................................... -30dB @ 5 MHz

Video output

Number/signal type ................... 1 RGBS, RGsB, RsGsBs, component video, S-video, NTSC/PAL/SECAM

composite video

Connectors .................................... 4 BNC female

Minimum/maximum levels ...... Analog ....... 0.3V to 1.5V p-p

Impedance .................................... 75 ohms

Sync

Input type ..................................... Analog RGBS, RGsB, RsGsBs

Output type .................................. RGBS, RGsB, RsGsBs

Standards ...................................... NTSC, PAL, SECAM

Input level ..................................... 1V to 5V p-p

Output level .................................. 5V p-p

Input impedance .......................... 510 ohms

Output impedance ...................... 75 ohms

Polarity .......................................... Positive and negative

Control/remote — switcher

Contact closure ............................ 1 25-pin D female connector

Extron remote key pad control .. 1 25-pin D female connector ........... use with the Extron KP-10

IR controller module ................... 1 25-pin D female connector ........... use with the Extron IR-101

General

Power............................................. 100VAC to 240VAC, 50/60 Hz, 10 watts, internal, auto-switchable

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing

Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing

Rack mount ................................... Yes (2U high, ½-rack width), with optional shelf, part #60-030-01

Enclosure type .............................. Metal

Enclosure dimensions ................. 3.4" H x 8.4" W x 6.25" D

8.5 cm H x 21 cm W x 16 cm D

(Depth excludes connectors.)

Shipping weight ........................... 5 lbs (2.3 kg)

Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)

Approvals ..................................... UL, CUL, CE

MTBF ............................................. 30,000 hours

Warranty ....................................... 2 years parts and labor

Specifications are subject to change without notice.

(7.2-052101-D3)

Specifications — SW2 ARxixi

xixi

xi and SW4 ARxixi

xixi

xi Switchers
