Extron electronics Quantum Elite Series Manual de usuario

User Guide

Quantum Elite and

Quantum Connect

Quantum®Processors

Videowall Processing Systems

68-2010-01 Rev. E

12 19

PRELIMINARY

Safety Instructions

Safety Instructions • English

WARNING:This symbol, , when used on the product, is intended to

alert the user of the presence of uninsulated dangerous voltage within the

product’s enclosure that may present a risk of electric shock.

ATTENTION: This symbol, , when used on the product, is intended

to alert the user of important operating and maintenance (servicing)

instructions in the literature provided with the equipment.

For information on safety guidelines, regulatory compliances, EMI/EMF

compatibility, accessibility, and related topics, see the Extron Safety and

Regulatory Compliance Guide, part number 68-290-01, on the Extron

website, www.extron.com.

Sicherheitsanweisungen • Deutsch

WARNUNG: Dieses Symbol auf dem Produkt soll den Benutzer darauf

aufmerksam machen, dass im Inneren des Gehäuses dieses Produktes

gefährliche Spannungen herrschen, die nicht isoliert sind und die einen

elektrischen Schlag verursachen können.

VORSICHT: Dieses Symbol auf dem Produkt soll dem Benutzer in

der im Lieferumfang enthaltenen Dokumentation besonders wichtige

Hinweise zur Bedienung und Wartung (Instandhaltung) geben.

Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,

EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie in

den Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer

68-290-01) auf der Extron-Website, www.extron.com.

Instrucciones de seguridad • Español

ADVERTENCIA: Este símbolo, , cuando se utiliza en el producto,

avisa al usuario de la presencia de voltaje peligroso sin aislar dentro del

producto, lo que puede representar un riesgo de descarga eléctrica.

ATENCIÓN: Este símbolo, , cuando se utiliza en el producto, avisa

al usuario de la presencia de importantes instrucciones de uso y

mantenimiento recogidas en la documentación proporcionada con el

equipo.

Para obtener información sobre directrices de seguridad, cumplimiento

de normativas, compatibilidad electromagnética, accesibilidad y temas

relacionados, consulte la Guía de cumplimiento de normativas y seguridad

de Extron, referencia 68-290-01, en el sitio Web de Extron, www.extron.com.

Instructions de sécurité • Français

AVERTISSEMENT : Ce pictogramme, , lorsqu’il est utilisé sur le

produit, signale à l’utilisateur la présence à l’intérieur du boîtier du

produit d’une tension électrique dangereuse susceptible de provoquer

un choc électrique.

ATTENTION : Ce pictogramme, , lorsqu’il est utilisé sur le produit,

signale à l’utilisateur des instructions d’utilisation ou de maintenance

importantes qui se trouvent dans la documentation fournie avec le

matériel.

Pour en savoir plus sur les règles de sécurité, la conformité à la

réglementation, la compatibilité EMI/EMF, l’accessibilité, et autres sujets

connexes, lisez les informations de sécurité et de conformité Extron, réf.

68-290-01, sur le site Extron, www.extron.com.

Istruzioni di sicurezza • Italiano

AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad

avvertire l’utente della presenza di tensione non isolata pericolosa

all’interno del contenitore del prodotto che può costituire un rischio di

scosse elettriche.

ATTENTZIONE: Il simbolo, , se usato sul prodotto, serve ad avvertire

l’utente della presenza di importanti istruzioni di funzionamento e

manutenzione nella documentazione fornita con l’apparecchio.

Per informazioni su parametri di sicurezza, conformità alle normative,

compatibilità EMI/EMF, accessibilità e argomenti simili, fare riferimento

alla Guida alla conformità normativa e di sicurezza di Extron, cod. articolo

68-290-01, sul sito web di Extron, www.extron.com.



Trademarks

All trademarks mentioned in this guide are the properties of their respective owners.

The following registered trademarks (®), registered service marks (SM), and trademarks (TM) are the property of RGBSystems, Inc. or

ExtronElectronics (see the current list of trademarks on the Terms of Use page at www.extron.com):

Registered Trademarks (®)

Extron, Cable Cubby, ControlScript, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, Flat Field, FlexOS, Glitch Free. Global

Configurator, GlobalScripter, GlobalViewer, Hideaway, HyperLane, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink,

MediaPort, NetPA, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, ShareLink, Show Me, SoundField, SpeedMount, SpeedSwitch,

StudioStation, SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VideoLounge, VN-Matrix, VoiceLift, WallVault, WindoWall, XPA, XTP,

XTPSystems, and ZipClip

Registered Service Mark(SM) : S3 Service Support Solutions

Trademarks (™)

AAP, AFL (Accu-RATEFrameLock), ADSP(Advanced Digital Sync Processing), Auto-Image, AVEdge, CableCover, CDRS(ClassD

Ripple Suppression), Codec Connect, DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator,

DSPConfigurator, DSVP(Digital Sync Validation Processing), eLink, EQIP, Everlast, FastBite, Flex55, FOX, FOXBOX, IP Intercom

HelpDesk, MAAP, MicroDigital, Opti-Torque, PendantConnect, ProDSP, QS-FPC(QuickSwitch Front Panel Controller), RoomAgent,

Scope-Trigger, SIS, SimpleInstructionSet, Skew-Free, SpeedNav, Triple-Action Switching, True4K, Vector 4K , WebShare, XTRA, and

ZipCaddy

FCC Class A Notice

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause interference. This interference must be corrected at the expense of the user.

ATTENTION:

• The Twisted Pair Extension technology works with unshielded twisted pair (UTP)

or shielded twisted pair (STP) cables; but to ensure FCC Class A and CE

compliance, STP cables and STP Connectors are required.

• La technologie extension paires torsadées fonctionne avec les câbles paires

torsadées blindées(UTP) ou non blindées(STP). Afin de s’assurer de la

compatibilité entre FCC ClasseA et CE, les câbles STP et les connecteurs STP

sont nécessaires.

NOTES:

• (This 1st paragraph is for TP ONLY, delete for all others products) This unit was

tested with shielded I/O cables on the peripheral devices. Shielded cables must be

used to ensure compliance with FCC emissions limits.

• (if only this paragraph is used, reformat to single NOTE format.) For more

information on safety guidelines, regulatory compliances, EMI/EMF compatibility,

accessibility, and related topics, see the Extron Safety and Regulatory

Compliance Guide on the Extron website.

VCCI-A Notice

この装置は、クラスＡ情報技術装置です。この装置を家庭環境で使用すると、電波妨害を引き

起こすことがあります。その場合には使用者が適切な対策を講ずるよう要求されることがあります。

ＶＣＣI－Ａ

Battery Notice

This product contains a battery. Do not open the unit to replace the battery. If the

battery needs replacing, return the entire unit to Extron (for the correct address, see the

Extron Warranty section on the last page of this guide).

CAUTION: Risk of explosion. Do not replace the battery with an incorrect type. Dispose

of used batteries according to the instructions.

ATTENTION : Risque d’explosion. Ne pas remplacer la pile par le mauvais type de pile.

Débarrassez-vous des piles usagées selon le mode d’emploi.

Conventions Used in this Guide

Notifications

The following notifications are used in this guide:

WARNING: Potential risk of severe injury or death.

AVERTISSEMENT : Risque potentiel de blessure grave ou de mort.

CAUTION: Risk of minor personal injury.

ATTENTION : Risque de blessuremineure.

ATTENTION:

• Risk of property damage.

• Risque de dommages matériels.

NOTE: A note draws attention to important information.

TIP: A tip provides a suggestion to make working with the application easier.

Software Commands

Commands are written in the fonts shown here:

^AR Merge Scene,,0p1 scene 1,1 ^B 51 ^W^C.0

[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]

E X! *X1&*X2)*X2#*X2! CE}

NOTE: For commands and examples of computer or device responses used in this

guide, the character “0” is the number zero and “O” is the capital letter “o.”

Computer responses and directory paths that do not have variables are written in the font

shown here:

Reply from 208.132.180.48: bytes=32 times=2ms TTL=32

C:\Program Files\Extron

Variables are written in slanted form as shown here:

ping xxx.xxx.xxx.xxx —t

SOH R Data STX Command ETB ETX

Selectable items, such as menu names, menu options, buttons, tabs, and field names are

written in the font shown here:

From the File menu, select New.

Click the OK button.

Specifications Availability

Product specifications are available on the Extron website, www.extron.com.

Extron Glossary of Terms

A glossary of terms is available at http://www.extron.com/technology/glossary.aspx.

viiQuantum Videowall Processing Systems • Contents

Contents

Introduction............................................................ 3

About this Guide................................................. 3

About the Quantum Videowall Processors.......... 3

Models ........................................................... 4

Features ............................................................. 4

Functional Overview ........................................... 7

RAPT Bus for Source Transfer ........................ 7

Display Architecture ........................................ 9

Scenario Examples ....................................... 10

Application Diagrams........................................ 16

Installation and Maintenance .......................... 20

Installation Steps .............................................. 20

Rear Panel Features ......................................... 22

Quantum Elite 615 Rear Panel ...................... 22

Quantum Elite 408 and Quantum Connect

Rear Panels ................................................. 24

Card Connections and Functions...................... 26

Control Card................................................. 26

Input Cards................................................... 28

Output Cards................................................ 41

Input and Output Card Arrangements........... 47

Keyboard, Mouse, Monitor, USB, and

Media Cards................................................ 48

Ethernet Connections ....................................... 53

Front Panel Features......................................... 54

Quantum Elite 615 Front Panels ................... 54

Quantum Elite 408 and Quantum Connect

Front Panels ................................................ 57

Maintenance..................................................... 59

Cleaning Ventilation Grilles and Filters ........... 59

Removing and Replacing Components......... 59

Operation.............................................................. 61

Powering On and Off ........................................ 61

Using the Control Panel.................................... 63

Starting the Control Panel............................. 63

Control Panel Buttons................................... 64

Loading Image Files (Quantum Elite

Models Only) ............................................... 64

Changing Network Settings .......................... 65

Updating Firmware ....................................... 65

Shutting Down Using the Control Panel ........ 68

Committing the Current Settings to Flash

Memory....................................................... 68

Accessing the Quantum Control Software ........ 69

Computer System Requirements.................. 69

Installing the Software .................................. 69

Starting the Software .................................... 70

QC 101 Controller............................................... 71

Overview of the QC 101 ................................... 71

Installation and Connections............................. 72

QC 101 Rear Panel Connections .................. 72

Installation Overview ..................................... 73

Connectivity Options..................................... 73

Connecting for RS-232 Control ........................ 74

Conﬁguring the QC 101.................................... 75

Setting the QC 101 IP Address..................... 75

Configuring the RS-232 Connection ............. 78

Front Panel Indicators....................................... 79

Quantum Videowall Processing Systems • Contents viii

Reference Information ...................................... 80

Mounting ......................................................... 80

UL Guidelines for Rack Mounting.................. 80

Rack Mounting the Quantum Processor ....... 81

Mounting the QC 101 ................................... 82

Network Setup ................................................. 83

What is an IP Address?................................. 83

Choosing IP Addresses ................................ 83

Subnet Mask ................................................ 84

Pinging for the IP Address ............................ 84

Subnetting, a Primer..................................... 85

Quantum Series Videowall Processing Systems • Introduction 1

Introduction

This section gives an overview of the Extron Quantum Videowall Processors, describes

significant features of the series, and provides sample application diagrams. The following

topics are covered:

• About this Guide

• About the Quantum Videowall Processors

• Features

• Functional Overview

• Application Diagrams

About this Guide

This guide discusses how to install, configure, and operate the Quantum Elite and

Quantum Connect videowall processors.

Throughout this guide, the terms “Quantum” and “processor” are used interchangeably to

refer to both Quantum Elite models and the Quantum Connect.

About the Quantum Videowall Processors

The Quantum Elite 615, Quantum Elite 408, the Quantum Connect 82, and the Quantum

Connect 84 are multi-window scalable and expandable videowall processors that can

be configured for a variety of input, output, and window capabilities. These processors

feature high performance video scaling technology that produces very high quality images.

The Elite models can be populated at the factory with any combination of DVI-I or HDMI

output cards, each of which supports up to 128 video graphic source windows, and with

input cards for composite or S-video, RGB or HD component video, HDMI, DVI, and SDI

(including 3G-SDI, HD-SDI, and SD-SDI) sources. The two Quantum Connect models are

available with only HDMI input and output cards.

NOTES:

• Input capacity is based on an input-output card configuration with one slot

occupied by an output card.

• Output capacity is based on an input-output card configuration with one slot

occupied by an input card.

You can preprogram or create a variety of display scenarios as needed using the

Quantum Elite or the Quantum Connect control software interfaces for setup and system

operation. Many source signals can be shown at small sizes, a few at large sizes, or

many combinations of both. The Quantum high performance image scaling technology

accurately preserves the original image quality at all window sizes.

Quantum Series Videowall Processing Systems • Introduction 2

Models

Quantum Elite

• The Quantum Elite 615 has a 6U high, 15-slot card frame. It has a maximum input

capacity of 28 single-link DVI-D, 28 HDMI, 28 SDI, 28 RGB or HD component video,

or 168 composite or S-video. Maximum output capacity is 28 DVI-I or HDMI. Multiple

Quantum Elite 615 card cages can be used to create very large display arrays.

• The Quantum Elite 408 has a 4U high, 8-slot card frame with a maximum input

capacity of 14 single-link DVI-D, 14 HDMI, 14 SDI, 14 RGB or HD component video,

or 84 composite or S-video. Maximum output capacity is 14 DVI-I or HDMI.

Additional DVI, HDMI, SDI, or RGB source signals can be streamed over an IP network to

the Elite processors using the Extron QGE 100 IP encoder.

Quantum Connect

The Quantum Connect 82 and 84 models have 4U high, eight-slot card frames with four

HDMI input cards (eight HDMI inputs).

The Quantum Connect is ideal for small to medium videowalls with 2 to 14 screens. Two models

are available:

• Connect 82 is configured with one HDMI output card (two HDMI outputs per card).

• Connect 84 is configured with two HDMI output cards (four HDMI outputs per card).

NOTE: The Connect models do not support the following features that are provided

on the Elite models:

•Input and output cards other than HDMI

•Customized conﬁgurations to order

•QGE 100 source types

•Picture and image ﬁle source types

•Window borders or text

•Clock and timer source types

•Multiple processor systems

•Edge-blended displays

Features

• Card frame videowall processing system — The Quantum processor allows

for various combinations of input and output cards to match specific source and

videowall configurations. It is a fully modular system, allowing each unit to be

individually configured to best suit the end user application.

• Input configurations — The Quantum processor can be configured with various

combinations of inputs within the available card slots.

All models:

• HDMI input: The dual HDMI/DVI input card accepts two HDMI or DVI sources

at resolutions up to 1920x1200 and HDTV 1080 @ 60 Hz, as well as custom

resolutions.

NOTE: Appropriate HDMI to DVI cables or adapters are required for DVI

signal input on this card.
