User’s Guide

400A AC/DC Clamp Meter

Model MA220

MA220-EU-EN V1.5 7/09

Introduction

Thank you for selecting the Extech MA220 AC/DC Clamp Meter. This meter measures

AC/DC Current, AC/DC Voltage, Resistance, Capacitance, Frequency, Duty Cycle,

Temperature, Diode Test, and Continuity. This professional meter, with proper care, will

provide years of safe reliable service.

Safety

International Safety Symbols

This symbol, adjacent to another symbol or terminal, indicates the user must

refer to the manual for further information.

This symbol, adjacent to a terminal, indicates that, under normal use,

hazardous voltages may be present

Double insulation

SAFETY NOTES

Do not exceed the maximum allowable input range of any function

Do not apply voltage to meter when resistance function is selected.

Set the function switch OFF when the meter is not in use.

Remove the battery if meter is to be stored for longer than 60 days.

WARNINGS

Set function switch to the appropriate position before measuring.

When measuring volts do not switch to current/resistance modes.

Do not measure current on a circuit whose voltage exceeds 240V.

When changing ranges using the selector switch always disconnect the test leads

from the circuit under test.

Do not exceed the maximum rated input limits.

OVERVOLTAGE CATEGORY III

This meter meets the IEC 610-1-95 standard for OVERVOLTAGE CATEGORY III. Cat III

meters are protected against overvoltage transients in fixed installation at the distribution

level. Examples include switches in the fixed installation and some equipment for industrial

use with permanent connection to the fixed installation.

MA220-EU-EN V1.5 7/09

Specifications

Function

Range

Accuracy (of

reading)

DC Current 40.00 ADC 0-20.00 ADC ± (2.5% + 6 digits)

20.00-40.00 ADC ± (3% + 6 digits)

400.0 ADC 0-300.0 ADC ± (2.5% + 6 digits)

300.0-400.0 ADC ± (3.5% + 6 digits)

AC Current 40.00 AAC 0-20.00 AAC ± (3% + 10 digits)

20.00-40.00 AAC ± (5% + 10 digits)

400.0 AAC 0-300.0 AAC ± (3% + 10 digits)

300.0-400.0 AAC ± (5% + 10 digits)

DC Voltage

± (0.8% + 3

digits)

.000V

± (1.5% + 3 digits)40.00V

400.0V

600V ± (2.0% + 3 digits)

AC Voltage 400.0mV ± (1% + 10 digits)

4.000V ± (2% + 5 digits)40.00V

400.0V

600V ± (2% + 5 digits)

Resistance



± (1.0% + 4 digits)

4.000k± (1.5% + 2 digits)

40.00k



4.000 M± (2.5% + 3 digits)

40.00M± (3.5% + 5 digits)

Capacitance 40.00nF ± (5% + 30 digits)

400.0nF ± (3% + 5 digits)

4.000µF ± (3.5% + 5 digits)

40.00µF

100.0µF ± (5% + 5 digits)

Frequency

5.000Hz

± (1.5% + 5

digits)

50.00Hz ± (1.2% + 2 digits)

Sensitivity: 5~5KHz:

10Vrms min.

5KHz~150KHz:

40Vrms min.

500.0Hz

5.000KHz

50.00KHz

150.0KHz

Duty Cycle 0.5% to 99.0% ± (1.2% + 2 digits)

Pulse Width: 100µs-100ms, Frequency: 5Hz to 150KHz

Temperature -50.0 to 400.0°C -50.0 to -20.0°C ± 7°C

-20.0 to 400.0°C ± (3% + 5 °C)

400 to 1000°C 400 to 1000°C

-58.0 to 400.0°F -58.0 to 0°F ± 14°F

0 to 400.0°F ± (2.5% + 6 digits)

400 to 1832°F 400 to 1832°F ± (3% + 7°F)

MA220-EU-EN V1.5 7/09

Jaw size 23mm (0.9") approx.

Display 4000 count LCD

Continuity Audible tone < 150approx.

Diode Test Open circuit voltage < 1.5VDC;

Test current 0.3mA (typical)

AC V bandwidth 50Hz to 400Hz

AC A bandwidth 50/60Hz

Low battery indication “ ” is displayed

Overrange indication “OL” is displayed

Auto Power OFF After 30 minutes

Measurement rate 2 per second, nominal

Input Impedance 7.8MΩ (V DC and V AC)

Operating Temperature 5ºC to 40ºC (41ºF to 104ºF)

Storage Temperature -20oC to 60oC (-4oF to 140oF)

Operating Humidity Max 80% up to 31ºC (87ºF) decreasing linearly to 50% at 45ºC

(113ºF)

Storage Humidity <80%

Operating Altitude 2000meters (6560ft.) operating

Batteries (2) 1.5V AAA batteries

Weight 200g (0.44lb)

Size 200x50x35mm (7.87” x 1.97” x 1.38”)

Safety For indoor use and in accordance with the requirements for

double insulation to IEC1010-1 (1995): EN61010-1 (1995)

Overvoltage Category III, Pollution Degree 2.

MA220-EU-EN V1.5 7/09

Meter Description

1. Conductor jaws

2. Jaw opening trigger

3. Function select switch

4. LCD Display

5. ZERO button

6. Data Hold and Backlight Button

7. Mode select button

8. Range select button

9. Hz/%/Duty Cycle button

10. COM input jack

11. V/Temp jack

12. Battery cover (rear)

AC AC (alternating current)

DC DC (direct currrent)

Minus sign

AUTO AutoRange mode

ZERO ZERO mode

•))) Audible Continuity

HOLD Data Hold mode

Low Battery icon

Diode test mode

mmilli

VVolts

AAmps

Kkilo

MMega

ΩOhms

°F Degrees Fahrenheit

°C Degrees Centigrade

MA220-EU-EN V1.5 7/09

Operation

Notice: Read and understand all WARNING and CAUTION statements listed in the

safety section of this operation manual prior to using this meter. Set the function select

switch to the OFF position when the meter is not in use.

DC/AC Current Measurements

Warning: Disconnect the test leads from the meter before making

current clamp measurements.

1. Set the Function switch to the 400ADC, 40ADC, 400AAC or

40AAC range. If the range of the measured is not known, select

the higher range first then move to the lower range if necessary.

2. For DC current measurement, press the ZERO key to null the

meter display.

3. Press the trigger to open jaw. Fully enclose one conductor to be

measured.

4. The clamp meter LCD will display the reading.

DC/AC Voltage Measurements

1. Set the rotary function switch to the Volts/Hz/% position.

2. Insert the black test lead banana plug into the negative (COM) jack and the red test lead

banana plug into the positive (V/Temp) jack

3. Select AC or DC with the MODE button

4. Connect the test leads to the circuit under test

5. Read the voltage on the display. The display will indicate the proper decimal point and

value.

Resistance Measurements

1. Set the function switch to the •))) CAP position.

2. Insert the black test lead banana plug into the negative (COM) jack

Insert the red test lead banana plug into the positive (VTempjack.

3. Touch the test probe tips across the circuit or part under test. It is best to disconnect one

side of the part under test so the rest of the circuit will not interfere with the resistance

reading.

4. Read the resistance on the display. The display will indicate the proper decimal point and

value.

Continuity Check

1. Set the function switch to the •))) CAP position.

2. Push the mode button to indicate •))) on the display.

3. Insert the black lead banana plug into the negative (COM) jack

Insert the red test lead banana plug into the positive (V) jack.

4. Touch the test probe tips to the circuit or wire you wish to check.

5. If the resistance is less than approximately 150, the audible signal will sound. If the

circuit is open, the display will indicate “OL.”.

MA220-EU-EN V1.5 7/09

Diode Test

1. Turn the rotary switch to the •))) CAP position.

2. Insert the black test lead banana plug into the negative (COM) jack and the red test lead

banana plug into the positive (V jack.

3. Push the mode button to indicate on the display.

4. Touch the test probes to the diode under test. Typically for a normal diode, forward

voltage will indicate 0.4V to 0.7V. Reverse voltage will indicate “OL”. Shorted devices will

indicate near 0V and an open device will indicate “OL” in both polarities.

Capacitance Measurements

Warning: To avoid electrical shock, disconnect power to the unit under test and

discharge all capacitors before taking any capacitance measurements. Remove the

batteries and unplug the line cords.

1. Set the function switch to the •))) CAP position.

2. Push the mode button to indicate nF on the display.

3. Insert the black lead banana plug into the negative (COM) jack and

insert the red test lead banana plug into the positive (VTemp) jack.

4. Press the ZERO key to null the meter display.

5. Touch the test probe tips to the capacitor you wish to check.

6. Read the capacitance value on the display.

Frequency or % Duty Cycle Measurements

1. Turn the rotary switch to the Volts Hz % position.

2. Insert the black test lead banana plug into the negative (COM) jack and the red test lead

banana plug into the positive (V jack.

3. Select Hz or % with the HZ/% button.

4. Touch the test probe tips to the circuit under test.

5. Read the frequency on the display.

Temperature Measurements

1. Turn the rotary switch to the Temp position.

2. Insert the Temperature Probe into the negative (COM) and the (VTempjacks, making

sure to observe correct polarity.

3. Select °C or °F with the MODE button.

4. Touch the temperature probe head to the part whose temperature you wish to measure.

Keep the probe touching the part under test until the reading stabilizes.

5. Read the temperature on the display.

Warning: To avoid electrical shock, be sure the thermocouple has been removed before

changing to another measurement function.

Auto/Manual Ranging

The meter turns on in Autoranging mode. Press the RANGE button to enter manual

ranging. Each press of the range button will step to the next range as indicated by the units

and decimal point location. Press and hold the RANGE button for two seconds to return to

Autoranging mode.

Note: Manual ranging does not function in AC Current or Diode and Continuity check

functions. In Temperature function, it will change the resolution from 0.1° to 1°.

MA220-EU-EN V1.5 7/09

Data Hold

To freeze the LCD meter reading, press the HOLD button. While data hold is active, the

HOLD display icon appears on the LCD. Press the HOLD button again to return to normal

operation.

Backlight

Press and hold the HOLD button for >2 seconds to turn the backlight on/off.

Note: The HOLD feature will activate when the backlight is turned on. Press the HOLD

button again to exit the Hold feature.

Zero Button

Zeros Capacitance and DC Current measurements. Also allows the user to offset the

meter by using the displayed value as the zero reference value. Press the ZERO key

momentarily to activate and to exit Zero mode.

Maintenance

WARNING: To avoid electrical shock, disconnect the meter from any circuit, remove the

test leads from the input terminals and turn OFF the meter before opening the case. Do

not operate with open case.

Cleaning and Storage

Periodically wipe the case with a damp cloth and mild detergent; do not use abrasives or

solvents. If the meter is not to be used for periods of longer than 60 days, remove the

batteries and store them separately

Battery Replacement

1. Remove the two rear Phillips head screws

2. Open the battery compartment

3. Replace the two 1.5V AAA batteries.

4. Re-assemble the meter

You, as the end user, are legally bound (Battery ordinance) to return all used

batteries and accumulators; disposal in the household garbage is prohibited!

You can hand over your used batteries / accumulators at collection points in

your community or wherever batteries / accumulators are sold!

Disposal: Follow the valid legal stipulations in respect of the disposal of the

device at the end of its lifecycle

Otros manuales para MA220

Tabla de contenidos

Otros manuales de Multímetro de Extech Instruments

Extech Instruments

Extech Instruments Extech 470 Manual de usuario

Extech Instruments

Extech Instruments EX530 Manual de usuario

Extech Instruments

Extech Instruments BT100 Manual de usuario

Extech Instruments

Extech Instruments MultiMaster MM560 Manual de usuario

Extech Instruments

Extech Instruments EX230 Manual de usuario

Extech Instruments

Extech Instruments RC200 Manual de usuario

Extech Instruments

Extech Instruments EX505 Manual de usuario

Extech Instruments

Extech Instruments Extech 470 Manual de usuario

Extech Instruments

Extech Instruments MultiTec MT310 Manual de usuario

Extech Instruments

Extech Instruments LT40 Manual de usuario

Extech Instruments

Extech Instruments EX430-NIST Manual de usuario

Extech Instruments

Extech Instruments MG300 Manual de usuario

Extech Instruments

Extech Instruments MultiMaster MM560A Manual de usuario

Extech Instruments

Extech Instruments EX542 Manual de usuario

Extech Instruments

Extech Instruments MN26 Manual de usuario

Extech Instruments

Extech Instruments DM220 Manual de usuario

Extech Instruments

Extech Instruments ExStik EC500 Manual de usuario

Extech Instruments

Extech Instruments EX710 Manual de usuario

Extech Instruments

Extech Instruments EX520-S Manual de usuario

Extech Instruments

Extech Instruments EX205T Manual de usuario

Extech Instruments

Extech Instruments 412355A Oyster Series Manual de usuario

Extech Instruments

Extech Instruments EX810 Manual de usuario

Extech Instruments

Extech Instruments 407910 Manual de usuario

Extech Instruments

Extech Instruments MiniTec Series Manual de usuario

Manuales populares de Multímetro de otras marcas

Agilent Technologies

Agilent Technologies 34420A Manual de usuario

Fluke

Fluke 83 Manual de usuario

Hameg

Hameg HM 8012 Manual de usuario

Mastech

Mastech MY70 Manual de usuario

Steren

Steren MUL-300 Manual de usuario

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Manual de usuario

PeakTech

PeakTech 4000 Manual de uso y cuidado

YOKOGAWA

YOKOGAWA 90050B Manual de usuario

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Manual de usuario

Fluke

Fluke 8846A Manual de operación y mantenimiento

Tempo Communications

Tempo Communications MM200 Manual de usuario

Elenco Electronics

Elenco Electronics CM-1555 Manual de usuario

Mastech

Mastech MS8238C Manual de usuario

SDAR

SDAR 830A, 830B, 830D, 830C Manual de usuario

RS PRO

RS PRO RS-9519BT Manual de usuario

BGS technic

BGS technic 8890 Manual de usuario

Amprobe

Amprobe Hexagon 60 Manual de usuario
