USERGUIDE



IntegratingSoundLevelMeter

andDatalogger



Model407780A



www. .com information@itm.com1.800.561.8187

407780A‐EU‐ENv1.34/14

Introduction



ThankyouforselectingtheExtechInstrumentsModel407780A.Thisdeviceisshippedfullytested

andcalibratedand,withproperuse,willprovideyearsofreliableservice.Pleasevisitourwebsite

(www.extech.com)tocheckforthelatestversionofthisUserGuide,ProductUpdates,and

CustomerSupport.



Features

TheSoundLevelMetercomplieswiththerequirementsofIEC61672‐1:2003standardfora

Class2instrument.

Theinstrumentcontainsseveralfeatureswhichpermitsoundlevelmeasurementsundera

varietyofconditions.

Featuresinclude:

Fivemeasurementranges

Fast,SlowandImpulsetimeweightingsettings

AandCfrequencyweightingsettings

Storageofupto32000measurementrecords

USBserialportfordownloadingrecordstoacomputerorrealtimeanalysis

AC/DCsignaloutputsareavailablefromasinglestandard3.5mmcoaxialsocketsuitable

forusewithafrequencyanalyzer,levelrecorder,FFTanalyzer,graphicrecorder,etc.

Leq,SEL,SPLMAX,SPLMIN,PH(PeakHold),L05,L10,L50,L90,andL95,tenmeasured

parametersaremonitoredduringmeasurement

Presetmeasurementtime

Soundlevelalarmoutputconnector



www. .com information@itm.com1.800.561.8187

407780A‐EU‐ENv1.34/14

InstrumentCare

Donotattempttoremovethemeshcoverfromthemicrophoneasthiswillcause

damageandaffecttheaccuracyoftheinstrument.

Protecttheinstrumentfromimpact.Donotdropitorsubjectittoroughhandling.

Transportitinthesuppliedcarryingcase.

Protecttheinstrumentfromwater,dust,extremetemperatures,highhumidityand

directsunlightduringstorageanduse.

Protecttheinstrumentfromairwithhighsaltorsulphurcontent,gasesandstored

chemicals,asthismaydamagethedelicatemicrophoneandsensitiveelectronics.

Alwaysswitchtheinstrumentoffafteruse.Removethebatteriesfromtheinstrumentif

itisnottobeusedforalongperiodoftime.Donotleaveexhaustedbatteriesinthe

instrument,astheymayleakandcausedamage.

Cleantheinstrumentonlybywipingitwithasoft,dryclothor,whennecessary,withacloth

lightlymoistenedwithwater.Donotusesolvents,abrasives,alcoholorcleaningagents.

www. .com information@itm.com1.800.561.8187

407780A‐EU‐ENv1.34/14

MeterDescription



1. 1/2‐inchmicrophone

2. LCDdisplay

3. Powerbutton

4. Leq/SEL/SPLselectbutton

5. RUN/Pausebutton

6. UP/DOWNrangesettingbuttons.

7. A/CFrequencyweightingselectswitch

8. FAST/SLOW/IMPULSEtimeweighting

selectswitch.

FAST:125ms,SLOW:1second,

IMPULSE:35mswithslowdecay

9. MAXbutton

10. RECORD/ERASEbutton

11. Realtimeclockbutton

12. Integrationtimebutton

13. Alarmoutput

14. AC/DCoutput

15. CAL(calibration)adjustment

16. Externalpowerinput

USBinput(locatedonbottom,not

shown)

Tripodmountingscrew(locatedonrear,notshown)

Batterycover(locatedonrear,notshown)



www. .com information@itm.com1.800.561.8187

407780A‐EU‐ENv1.34/14

DisplayDescription



1. Soundlevelrangeindicator(5ranges):30–90dB,40–100dB,50–110dB,60–120dBand70–

130dB

2. Bargraphrepresentsthecurrentsoundlevel(1dBresolution).

3. Date/timeandelapsedtimeindicator:year‐month‐dayorhour:minute:second.

Duringintegratingthisindicatordisplaystheelapsedtimeinseconds.

WhenviewingthePeakHoldvaluethisindicatordisplaysPH.

WhenviewingthepercentilevaluesthisindicatordisplaysL:05,L:10,L:50,L:90orL:95.

4. Leq:Equivalentcontinuoussoundlevelreading

5. SEL:Soundexposurelevelreading

6. SPL:Time‐weightedsoundlevelreadingSoundPressureLevel

7. Low‐batteryindication

8. MAX:WhendisplayedflashingitindicatesthattheMaximumtime‐weightedsoundlevel

readingisshown.WhenitisdisplayedsoliditindicatesthattheMaximumsoundlevel

readingisdisplayed.

9. MIN:Minimumsoundlevelreading.

10. REC:IndicatesthatDatarecordingisinprocess

11. Soundlevelreading(0.1dBresolution):30.0–130.0dB

12. FULL:Indicatesthattherecordingmemorybankhasbeenfilled

www. .com information@itm.com1.800.561.8187

407780A‐EU‐ENv1.34/14

13. dB:Soundlevelunit(decibel)

14. A,C:AorCfrequencyweightingindicator.

15. IMP:Impulsetimeweightingindicator

16. OVER:Over‐rangeindicatorappearsflashingwhenover‐rangemeasurementshavebeen

includedinthesoundlevelmeasurementdatarecordingsession.

17. SLOW:Slowtimeweightingindicator

18. FAST:Fasttimeweightingindicator

19. :Indicatesthatintegratingsoundlevelmeasurementshavebeenstopped.

20. :Indicatesthatintegratingsoundlevelmeasurementsarepaused.

21. :Startandcontinuousintegratingmeasurementindicator.

22. UNDER:Under‐rangeindicatorappearsflashingwhenunder‐rangemeasurementshave

beenincludedinthesoundlevelmeasurementdatarecordingsession.



www. .com information@itm.com1.800.561.8187

407780A‐EU‐ENv1.34/14

Operation

Themeterhastwomodesofoperation,SoundLevelMetermodeandIntegratingSoundLevel

Metermode.

SoundLevelMetermeasurements

1. Pressthe buttontoswitchthemeterON.Theinitialstatedependsontheconditionsset

whenthemeterwaslastswitchedoff.

2. PresstheA/Cbuttontoselectthedesiredfrequencyweighting.

3. PresstheFAST/SLOW/IMPULSEbuttontoselectthedesiredresponsetime.

Note:Refertolocalstandardstoselecttheproperweightingandresponsetimeforthe

measurementstobeperformed.Requirementsvaryaccordingtocountryandtypeoftest.

OSHArequiresSlowandAweightformanyoftheirworkplacetests.

4. Usethe▲▼buttonstoselectthedesireddBrange.Chooseasettinginwhichthebar

graphindicationregistersapproximatelyinthemiddleoftherange.IftheOVERindicator

appearsduringameasurement,theupperlimitoftheselectedrangehasbeenexceeded.

Increasetherangesettinguntilthesymbolremainsoffduringmeasurements.Similarly,if

theUNDERindicatorappears,reducetherangesettinguntilthesymbolremainsoff.Both

indicatorsarenon‐latchingandwillclearwhenthecorrectrangeisselected.

5. Holdtheinstrumentcomfortablyinhand(awayfromthebody)orpositionitonatripod.

Pointthemicrophonetowardthenoisesource,thesoundpressurelevelwillbedisplayed

onthemeter’sLCDdisplay

6. Thenumericlevelindicationonthedisplayshowsthecurrentlymeasuredsoundlevel.The

readingisupdatedoncepersecond.

7. PresstheMAXbuttontodisplaythemaximumsoundlevelencounteredduringa

measurementperiod;theMAXindicatorwillblinkappearonthedisplay.PresstheMAX

buttonagaintoexitthismode

8. PressDATE/TIMEtochangefromcurrenttimehour:minute:seconddisplaytocurrent

dateyear–month‐daydisplay.Thedisplaywillreverttothecurrenttimedisplayafter2

seconds.



www. .com information@itm.com1.800.561.8187

407780A‐EU‐ENv1.34/14

IntegratingSoundLevelMetermeasurements

Theintegratingsoundlevelmodewillmeasurethesoundlevelovertimeandcalculatethe

followingresults:

LeqEquivalentcontinuoussoundlevelmeasurement

SELSoundexposurelevelmeasurement

SPLMAXMaximumsoundlevelmeasurement

SPLMIN Minimumsoundlevel)measurement

(PH) PeakHoldsoundlevelmeasurement

Percentile Soundlevel(L05,L10,L50,L90andL95)measurement

Whenusingthismeterinamodeotherthanthesoundlevelmeasurementmode,allprocessing

functionsprovidedbythemeterareperformedsimultaneously.Forexample,whenequivalent

continuoussoundlevelmeasurementisselectedtheexposurelevelandpercentilelevelarealso

determined.

1. Pressthe buttontoswitchONthemeter.

2. PresstheA/Cbuttontoselectthedesiredfrequencyweighting.

3. PresstheFAST/SLOW/IMPULSEbuttontoselectthedesiredresponsetime.

4. Usethe▲▼buttonstoselectthedesireddBrange.Chooseasettinginwhichthebar

graphindicationregistersnearthemiddleoftherange.IftheOVERorUNDERindicators

switchONfrequently,changethelevelrangesetting.

5. Settingtheintegratingmeasurementtime.(DefaultorManual)

Defaulttimes:

a. PresstheINTEGTIMEbuttononcetoselectadefaultintegratingtime.

b. Usethe▼▲buttonstoselectthemeasurementtime.

c. Theselectionwillcyclethrough:1sec,3sec,10sec,30sec,1min,5min,8min,10min

15min,30min,1hour,8hours,24hours.

d. After5secondsofinactivitythemeterwillstorethedisplayedselectionandreturnto

thenormalmode.

Manuallysettime:

a. PressandholdINTEGTIMEfor3secondstomanuallysettheintegrationtime.

b. Aflashingcursorindicatesthecurrentlyselectedparameter(seconds).

c. Usethe▼▲buttonstosetdesiredsecond.

d. PresstheINTEGTIMEbuttontomovetothenextparameter(minutes),repeatthis

procedureuntilthedesiredminutesandhourshavebeenset.PresstheINTEGTIME

buttontostorethesettingandtoexitthismode.Themaximummeasurementtime

settingis100hours.



www. .com information@itm.com1.800.561.8187

407780A‐EU‐ENv1.34/14

6. Pressthe►ǁbuttontostartthemeasurement,the►symbolandtheelapsed

measurementtimeisdisplayed.

Whenthemeasurementtimehaselapsed,themeasurementautomaticallyterminates

andthesymbolisdisplayed.

Duringmeasurements,the►ǁbuttoncanbeusedtopauseandresumeatest.

Duringpause,thepausesymbolǁisdisplayed.

Toterminatethemeasurement,pressandholdthe►ǁbuttonfor2seconds.

Ifanunderoroverrangeconditionoccursatleastonceduringmeasurement,theOVER

orUNDERindicatorappearstoindicatethattherecordeddatacontainsover‐rangeor

under‐rangedata.

Duringthisproceduremostofthebuttons,suchastheA/Cbuttonandlevelrange

buttons,areinoperative.Onlythe►ǁbuttonandtheLeqSELSPLbuttonscanbeused.

Allothersettingsmustbemadebeforestartingthemeasurement.

Pauseintervalsarenotincludedinthemeasurementtime.



7. Whenthemeasurementiscompleted,pausedorinprogress,presstheLeqSELSPLbutton

tocyclethroughanddisplaythefollowingmeasurementresults.

Leq:Equivalentcontinuoussoundlevelwithstartmeasurementtime.

SEL:Soundexposurelevelwithterminatemeasurementtime.

SPLMAX:Maximumsoundlevelwithtime.

SPLMIN:Minimumsoundlevelwithtime.

PH:PeakHoldsoundlevel

L:055%percentilesoundlevel

L:1010%percentilesoundlevel

L:5050%percentilesoundlevel

L:9090%percentilesoundlevel

L:9595%percentilesoundlevel

SPLINSTCurrentsoundlevelwithcurrenttime.

IfOVERisflashing,therecordeddatacontainsover‐rangemeasurements.

IfUNDERisflashing,therecordeddatacontainsunder‐rangemeasurements.

8. Pressandholdthe►ǁbuttonfor2secondstoexitthismeasurementmode,clearthe

measuredresult,andtoreturntothenormalsoundlevelmeasurementmode.



www. .com information@itm.com1.800.561.8187

407780A‐EU‐ENv1.34/14

SettingtheCurrentTimeandDate

Dateandtimeinformationisstoredwitheachstoredrecordblock.Therefore,itisimportantto

ensurethatthisinformationiscorrect.

1. PresstoswitchOFFthemeter.

2. PressandholdtheDATETIMEbuttonandthenpressthe buttontoswitchONthemeter

toenterthedateandtimesettingmode.

3. Aflashingcursorindicatesthecurrentlyselectedparameter(seconds),usethe▲▼buttons

tosetthecurrentsecond.

4. PresstheDATETIMEbuttontomovetothenextparameter(minutes)andusethe

▲▼buttonstosetthecurrentminute.

5. Repeatstep4tosetthecurrenthour,day,month,andyear.

6. PressDATETIMEtostorethenewdateandtime,andtoexitthismode.



RecordingData

IntheIntegratingSoundLevelMetermodethemetercanrecordandstoremeasurementdata.

Memorycapacityis32000recordswhichcanbestoredinupto255blocks.Recordingcanstart

whenintegrationbeginsoratapresettime.Thestoreddatacannotbeviewedonthemeter’s

display;itmustbedownloadedusingthesuppliedPCsoftware.

1. Settingthedatasamplingrate.

a) Pressthe buttontoswitchOFFthemeter.

b) PressandholdtheINTEGTIMEbuttonandthenswitchthemeterON,theIntrsymbol

andthesamplerateinsecondswillbedisplayed.

c) Usethe▲▼buttonstosetthesamplingrate(1to255seconds).

d) PressINTEGTIMEtostorethesettingandexitthismode.

2. Settheintegratingfunctionsasdescribedpreviously.

3. PresstheRECORDERASEbuttontoprepareforrecording.TheRECsymbolwillappearonthe

display.

4. Pressthe►‖button.ThemeasurementswillstartandtheRECsymbolwillbegintoflash,

indicatingthatdataarebeingstored.

5. Ifintegrationispaused,recordingwillalsopause.

6. Whenthememoryisfilled(32000datapointsor255blocksused),theRECFULLsymbolwill

bedisplayed.



www. .com information@itm.com1.800.561.8187

Tabla de contenidos

Otros manuales de Instrumento de medición de Extech Instruments

Extech Instruments

Extech Instruments RH520B Manual de usuario

Extech Instruments

Extech Instruments RT32 Manual de usuario

Extech Instruments

Extech Instruments CLT600 Manual de usuario

Extech Instruments

Extech Instruments 380942 Manual de usuario

Extech Instruments

Extech Instruments HD350 Manual de usuario

Extech Instruments

Extech Instruments SL355 Manual de usuario

Extech Instruments

Extech Instruments 401027 Manual de usuario

Extech Instruments

Extech Instruments RF20 Manual de usuario

Extech Instruments

Extech Instruments EN150 Manual de usuario

Extech Instruments

Extech Instruments ExStik PH100 Manual de usuario

Extech Instruments

Extech Instruments PH220 Manual de usuario

Extech Instruments

Extech Instruments 451181 Manual de usuario

Extech Instruments

Extech Instruments VT30-E Manual de usuario

Extech Instruments

Extech Instruments 401025 Manual de usuario

Extech Instruments

Extech Instruments 407123 Manual de usuario

Extech Instruments

Extech Instruments RPM33 Manual de usuario

Extech Instruments

Extech Instruments RH350 Manual de usuario

Extech Instruments

Extech Instruments 407026 Manual de usuario

Extech Instruments

Extech Instruments 461880 Manual de usuario

Extech Instruments

Extech Instruments CO240 Manual de usuario

Extech Instruments

Extech Instruments 461895 Manual de usuario

Extech Instruments

Extech Instruments TKG100 Manual de usuario

Extech Instruments

Extech Instruments 407119 Manual de usuario

Extech Instruments

Extech Instruments VB500 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
