Expobar Office automatic Manual de servicio

OFFICE EB-61 LEVA &

BARISTA MINORE

OFFICE AUTOMATIC

PLEASE READ THIS HANDBOOK CAREFULLY BEFORE START UP.

1. Identification of External Components

3 2

WIDE 240 m.

HIGH 225 mm

DEPTH 420 m

5 1

WIDE 240 mm

HIGH 225 mm

DEPTH 420 m

WIDE 260 mm

HIGH 225 mm

DEPTH 450 m

3.1 7

3.1

ig. 1

1 MAIN SWITCH

2 HOT WATER TAP

3 BREWING PUSH BUTTON

3.1 ELECTRONIC SWITCHBOARD

(CONTROL MODEL)

3.2 BREWING LEVER

4 STEAM TAP

5 BREWING GROUP UNIT

6 STEAM PIPE

7 DRIP TRAY

8 HOT WATER PIPE

9 ELEMENT PILOT

10 BOILER PRESSURE READER

(MANOMETER)

2. General Features

• Stainless steel body.

• Switch panel with 4 automatic dosing levels or lever operated.

• Automatic boiler refill from either mains water or tank.

• Water and steam tap.

• Professional brewing group with direct pre-infusion chamber.

• Cleaning valve.

• 1200W element.

• Water softener incorporated.

• Copper boiler with heat exchanger.

• Water reservoir.

• Vibrating motor-pump built-in.

3. Supplied

Coffee Dosage Spoon

ilter Basket

Spring

ilter

holder

ilter Membrane

Coffee Tamper

1Cup Filter

asket

ig. 2

2 Cups Filter

aske

4. Installation

• THIS MACHINE IS SUITABLE FOR DOMESTIC USE

The machine should be installed on a flat and safe surface.

-Electrical Installation:

Please observe the following requirements:

a) It is necessary to earth the machine. Do not connect to a two-pin plug.

b) Do not connect the machine to a circuit containing other high drain devices. You

will trip the circuit breaker.

c) Avoid using an extension lead, adaptors, multiple wall sockets or multi box at the

connection of coffee machine to the electricity supply.

-Water Installation:

• If your machine was supplied with mains water connection it should connected to the

water mains via a 3/8 male fitting. It is strongly recommended that you use a water

softener if lime is an issue.

• If you are going to use the machine with the water reservoir:

a) Remove the upper lid from the coffee machine.

b) Take out the water reservoir.

c) Fill the water reservoir with lime free water.

Disclaimer:

The manufacture is not responsible for injuries or damages to persons and/or animals,

nor damages to equipment, caused by a wrong installation of the coffee machine.

5. Start-up

Steps to follow:

1)If the machine is connected to the water network please open the gate valve (tap at the

wall).

2)If the machine is going to work with water tank:

i) Lift the top lid of the coffee machine, remove the water tank.

ii) Fill the water tank , do not close the tank until the first coffee comes through. It is

advisable to use only de-scaled water, in order to avoid scale related problems.

iii) Connect the machine to the mains and switch it on. The boiler will start filling

automatically; when the machine has finished the initial filling process ,it will

start the heating process, indicated by a red light.

3)When the red light switches off, it will indicate that the machine has heated up to the

proper boiler temperature for brewing. This is also indicated on the dial guage on the

front panel showing a reading of approximately 1.

All the Office models are provided with an element protector system. In case of lack of

water in the machine, the element will be automatically disconnected, stopping the heating

process in order to avoid any damage on the machine.

6. Correct fitting of the Filter Holder in the Brewing Group

INCORRECT

FITTING

CORRECT

POSITION

ig. 4

8. Brewing Coffee

1. Take the filter holder from the machine.

2. Fill the filter basket with the right amount of freshly ground coffee.

3. Press the coffee with the tamper.

4. Place the filter holder into the brewing group (see above for correct position).

5. Place the cup under the coffee outlet and press the appropriate brewing button or

operate the lever.

Note: The switch panel on the automatic model is already programmed with 4

standard doses and a continuous pour button. The first 4 buttons (those with pictures

of cups) are volumetric controlled and automatically switch off at a predetermined

point, the 5th one is for continuous coffee, and should be pressed again to stop.

THE FILTER HOLDER SHOULD BE ALWAYS PLACED ON THE BREWING

GROUP, in order to keep it on the right temperature to obtain the best coffee.

ssembled 2 cups

Filter holder

ssembled 1 cup

Filter holder

1 cup filter

basket

2 cups filter

basket

ig. 6

9. Drip tray Removal

Remove the grill placed on the drip tray. Lift the tray up slightly at the front, and pull forward

to remove it from the machine. Empty contents and wash the tray out. PERIODICALLY

CHECK THE LEVEL IN THE DRIP TRAY. Do not operate the machine without the drip

tray. The Leva model drip tray pulls directly to the front.

ig.

10. Switch Panel

10.1 Switch Panel Features

The switch panel is capable of the following functions:

• Volumetric control of 4 different coffee dosages per group.

• Boiler refilling.

• System supervision through alarms.

• Serial connection RS-232 with data reading from the control panel to PC.

• Brewing group auto-cleaning (if activated).

10.2 Switch Panel Setting

To programme the switch panel, press and hold the symbol “*” for aprox. 5 seconds

until the green LEDs on the switchboard light up; at this moment press the symbol of the

coffee selection you want to programme (1 single, 1 large, 2 singles, 2 larges). You will see

all the green LEDs switched off, except the option you have selected and the “*” LED. Press

the same symbol again when the quantity in the cup reaches your desired level, it will be

memorized and the LED on this selection will then disappear to show that setting has been

successful. Repeat the above process for all the coffee selections.

This process should be carried out with fresh coffee in the filter holder each time.

To re-programme any dose (all the selections are independent) simply repeat the above

process on the button to be reprogrammed. Once done, any remaining buttons are unaffected

and will retain their original setting.

Example of 1 short coffee setting:

Take the filter holder from the machine and fill it with the coffee, then place it into the

brewing group. Place a cup under the coffee spout and press and hold the “*” button until all

the green LEDs on the switch panel light up then immediately press the short coffee. The

green LEDs will then disappear except the short coffee one and the “*” button. The coffee

will start to run into the cup. Once the quantity in your cup reaches your desired level press

the short button again. The LED on this selection will turn off to show that the setting has

been successful.

lectronic switch panel

ig. 8

1 short coffee

2 large coffees

Continuous pour

1 large coffee

2 short coffees

10.3 Switch Panel Alarms

• If the boiler takes greater than two minutes to refill, the LEDs will start blinking.

You should switch the machine off and then on again (using the main switch) to

reset it.

• If the coffee is ground to fine or packed to firmly the water flow will be severely

restricted and the LED will light. Switch the brewing button off, wait for the

pressure to be discharged from the valve, remove the handle. Adjust the grind

and try again.

• 5 minutes is the maximum safety time for any dosage.

11. Heating up Liquids

a) Place the steam pipe over the tray and discharge the water from inside the pipe.

b) Close the steam tap.

c) Insert the steam pipe into the liquid to be heated up.

d) Open the steam tap. It will start heating up the liquid (with the steam tap open do not

remove the steam pipe from the liquid, it could be dangerous). Close the steam tap before

taking out the steam pipe.

e) Once the process has finished, place the steam pipe over the tray, and open the tap again

to clean the pipe of product residue. Close the tap and clean the pipe with a damp cloth.

12. Hot Water Supply

Place the cup/recipient to be filled up under the hot water outlet. Open the hot water tap until

obtaining the desirable amount of hot water.

13. Coffee Machine Cleaning

Switch the machine off. The outside of the machine can be cleaned with a damp cloth and a

non-abrasive household detergent.

14. Water Softener/filter Cleaning

a) Fill the water reservoir.

b) Dissolve 300 grams of table salt inside the water reservoir.

c) Insert the water softener filter inside the water reservoir.

d) Siphon the water reservoir through the water softener filter as indicated below.

Once the water reservoir is empty, fill it again with non-salt water and repeat the

process in order to clean the water softener filter.

rain the water from the

reservoir this way

eservoir filled with

salty water

Water softener filter

Tube

ig. 9

15. Brewing Group & Coffee Filter Cleaning

a) Remove the filter holder from the machine.

b) Place the filter membrane on the coffee filter.

c) Insert special cleaning compound (available for commercial coffee companies) into the

filter holder according to manufacturers recommendations. Use only special detergent

for brewing group cleaning.

d) Place the filer holder in the brewing group and operate the star button for 5 seconds.

Repeat 5 times. For the Lever models: raise and lower for 5-second intervals. Repeat 5

times.

e) Clean the filter holder of cleaning compound by washing under the brew group and

repeat the process without compound. This will flush away any residue.

f) It will be necessary to soak the filter holder in the head-cleaning compound from time to

time to remove caked on coffee oils.

g) Once the cleaning cycle has finished, dismantle the filter holder and wash thoroughly..

DO NOT MANIPULATE THE FILTER HOLDER DURING THE CLEANING

CYCLE

It is recommended that you clean the brewing group once a week.

Filter membrane

eter

ent

Filter membrane

Filter basket

Filter membrane

Filter basket

ig. 10

16. Cleaning the Shower Screen and Head Seal

After a period (say 6 months in domestic use and weekly cleaning) the shower screen will

become clogged with coffee oils that need to be removed. Proceed as follows:

• Dislodge the shower screen with its neoprene seal from the group head. This may be

accomplished by levering the screen downwards using the handle of a teaspoon. Lever

your way around until the unit drops out.

• Separate the seal from the screen and soak the screen in head cleaning compound until

clean. If this fails to adequately clean the item it will need to be replaced. Replace it

with any brand item designed for an E-61 group head.

• If the neoprene ‘O’ ring (head seal) is hard it too needs replacing. Any 6mm thick

(standard size) head seal for an E-61 group head will be satisfactory.

• Reassemble the seal to the shower screen ensuring the chamfered edge of the seal is

next to the open end of the shower screen. Failure to do this will make it difficult to

insert the unit in the group head.

• Insert the combined unit (open side uppermost) into the group head. Force the

neoprene seal up into the group head until it can go no further and seats evenly all the

way around. Use the handle of the teaspoon. Now insert the filter holder and pull to

the right until it is correctly located.

nside of the brewing group view

Common place for coffee particles

Shower screen

ig. 11

18. FAQ’s

It is important to differentiate between mechanical issues relating to the machine and issues

relating to the brewing of coffee. One is a machine issue and the other is a coffee issue. Here

are some frequently asked questions and their suggest solutions:

Symptom: Coffee pours too slowly.

Cause: Coffee stream should be as thick as a mouses tail.

Remedy: If thinner, coarsen up the grind. Use less force with the tamper.

Symptom: Coffee pours too fast.

Cause: Coffee stream should be as thick as a rats tail.

Remedy: If thicker, fine up the grind. Try tamping more firmly. Is the filter basket

completely full?

Symptom: No crema on coffee.

Cause: Handle not full. Coffee ground too course. Water too hot. Coffee not fresh.

Coffee not freshly ground.

Symptom: Crema thin and will not heal.

Cause: Over extracted.

Remedy Coarsen up the grind.

Symptom: Coffee tastes bitter.

Cause: Water too hot. Over extracted.

Symptom: Coffee tastes burnt.

Cause: Group head dirty/handle dirty.

Remedy: Replace shower screen and shampoo filter basket & holder.

Symptom: Water runs over top of handle.

Cause: Head seal damaged.

Remedy: Replace head seal.

Symptom: Slow water flow from group.

Cause: Shower screen clogged

Remedy: Replace shower screen.

Symptom: Water under machine.

Cause: Drip tray full. Something else?

Remedy: Empty drip tray or call technician.

Symptom: No steam from wand.

Cause: Nozzle blocked.

Remedy: Remove nozzle and clear holes.

Symptom: Excessive water in grounds.

Cause: Filter basket not full. Coffee ground too fine.

Remedy: Fill filter basket completely. Coarsen grind.

Symptom: Pump lacks pressure.

Cause: Poor water supply. Pump defective.

Remedy: Call technician.

A service to the customers of

Expobar (NZ) Ltd

208 Featherston St

Palmerston North

Phone 06 3593301

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cafetera de Expobar

Expobar

Expobar ELEN Manual de usuario

Expobar

Expobar BRILLIANCE Guía de instalación

Expobar

Expobar diamant Manual de usuario

Expobar

Expobar Diamant Pro Manual de usuario

Expobar

Expobar G-10 Manual de usuario

Expobar

Expobar BREWTUS III Manual del propietario

Expobar

Expobar Markus MINI Manual de usuario

Expobar

Expobar BREWTUS IV Manual del propietario

Expobar

Expobar QUARTZ Manual de usuario

Expobar

Expobar Office Manual de usuario

Expobar

Expobar MINI 1GR CONTROL/PULSER Manual de usuario

Expobar

Expobar New Elegance Manual de usuario

Expobar

Expobar Megacrem MINI Manual de usuario

Expobar

Expobar BRILLIANCE Manual de usuario

Expobar

Expobar QUARTZ Manual de usuario

Expobar

Expobar New Elegance Manual de usuario

Expobar

Expobar New Elegance 1GR Manual de usuario

Expobar

Expobar ONYX Manual de usuario

Expobar

Expobar QUARTZ CLASSIC Manual de usuario

Expobar

Expobar G10 1 GROUP Manual de usuario

Expobar

Expobar CARAT 1GR Manual de usuario

Expobar

Expobar ELEN Manual de usuario

Expobar

Expobar Diamant Pro Manual de usuario

Expobar

Expobar Crema Compact Manual de usuario

Manuales populares de Cafetera de otras marcas

Taurus

Taurus Livorno 6 Manual de usuario

Delta-q

Delta-q QUICK Manual de usuario

Bunn

Bunn LCA-1 Guía de solución de problemas

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instrucciones de instalación

Saeco

Saeco Vienna Plus Sup 018M Manual de usuario

DeLonghi

DeLonghi DC300 Manual de usuario

INCAPTO

INCAPTO BXCO1470E Manual de usuario

Bosch

Bosch TASSIMO finesse TAS16B Series Manual de usuario

Exido

Exido 245-072 Manual de usuario

Animo

Animo OptiVend Choco Manual de usuario

Siemens

Siemens TQ505DF Series Manual de usuario

DeLonghi

DeLonghi ECI341 Manual de usuario

Krups

Krups KT406511 Manual de usuario

Cimbali

Cimbali M32 Classic Manual de usuario

Philips

Philips HL3844N Manual de usuario

Bosch

Bosch TES 515 SERIES Manual de usuario

Tekmatix

Tekmatix TMFM - 65 Manual de usuario

Scarlett

Scarlett SC-CM33005 Manual de usuario
