Exmark Phazer 4500-461 Manual de usuario

For Serial Nos.

790,000 & Higher

Part No. 4500-461 Rev. A

PHAZER™

-1-

-2-

READ OPERATOR’S MANUAL BEFORE

OPERATING OR SERVICING EXMARK EQUIPMENT

TABLE OF CONTENTS

Description Page

34” Deck Group ............................................................3-4

Decal Group ..................................................................13

Electrical Diagram..........................................................15

Electrical Group .............................................................14

Electrical Logic Schematic .............................................16

Engine Group ................................................................11

Frame Group ................................................................5-6

Fuel Group.....................................................................10

Motion Control Group ......................................................7

Park Brake Group ............................................................8

Seat Group ......................................................................9

Transaxle Group............................................................12

34” DECK GROUP

-3-

Item Part No. Description Qty.

1 1-303508 Decal, Discharge Warning......................1

2 1-303520 Decal, Trivantage................................... 1

3 1-403005 Decal, Danger........................................2

4 1-413113 Bushing, Idler.........................................1

5 1-513034 Sleeve, Bearing......................................2

6 1-603384 Bushing, Idler Pivot ................................1

7 1-613098 Idler, Flat................................................2

8 52-2860 Washer .................................................. 2

9 63-8410 Washer .................................................. 2

10 98-5954 Decal-Danger......................................... 4

11 103-1077 Decal, Bolt Torque .................................1

12 103-3330 Spring, Extension ................................... 1

13 103-3898 Flat, Strut ............................................... 2

14 103-3900 Spacer, Strut..........................................6

15 103-9948 Bushing, Idler.........................................1

16 104-8301 Nut, Nyloc 3/8-16 Flg .............................8

17 109-0381 Brace, Deck Linkage.............................. 1

18 109-2462 Decal, Commercial 34............................ 1

19 109-2465 Decal, Belt Routing ................................ 1

Item Part No. Description Qty.

20 109-3086-01 Cover, RH Spindle ................................. 1

21 109-3100 Nut, Cage 5/16....................................... 4

22 109-3891 Asm, Idler Arm W/Bearings.................... 1

23 3256-4 Washer, 3/8 Std..................................... 2

24■109-9467 Asm, Deck W/Decals ............................. 1

25 109-5150 Chute, Discharge................................... 1

26 109-6886 Spring, Torsion ...................................... 1

27 109-9441-01 Cover, Left Spindle ................................ 1

28 109-9461 Pin, Chute.............................................. 1

29 302-40 Zerk, 90° 1/4-28..................................... 1

30 323-8 Screw, HH 3/8-16 x 1 1/2....................... 2

31 323-9 Screw, HH 3/8-16 x 1 3/4....................... 2

32 3231-11 Bolt, Carriage 3/8-16 x 3 1/2 .................. 1

33 3231-21 Bolt, Carriage 3/8-16 x 3/4 ..................... 1

34 3231-7 Bolt, Carriage 3/8-16 x 2 1/4 .................. 1

35 3231-9 Bolt, Carriage 3/8-16 x 2 3/4 .................. 1

36 3234-47 Screw, HH FLG 5/16-18 x 3/4 ................ 4

37 3256-27 Washer, 5/8 SAE ................................... 2

38▲109-9473 Asm, Deck Complete ............................. 1

Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).

VIncludes all item shown on pages 3 & 4. Does not include struts or strut hardware.

■Includes items 25, 26, & 28.

34” DECK GROUP (cont)

-4-

Item Part No. Description Qty.

1 1-513208 Washer, Spring Disc 5/8.........................2

2 1-633447 Chain, Deck Lift...................................... 4

3 1-807268 Key, Machine 1/4 x 3/16 x 1 ................... 2

4 103-1026 Screw, HH 5/8-11 x 1 Gr 8 ..................... 2

5+103-1330 Guard, Bearing Top................................2

6 103-1898 Screw, HH 7/16-20 x 1-5/8 Sp................8

7 103-2535 Spacer, Guard Bottom ...........................2

8+103-2788 Spindle...................................................2

9 103-2802 Washer, Spring Disc 3/4.........................2

10 109-3522 Asm, Cutter Housing Complete .............. 2

11 103-9366 Belt, Blade .............................................1

12 103-9792 Asm, Chain Deck ...................................1

13 103-9817 Asm, Chain Deck ...................................3

Item Part No. Description Qty.

14+103-9953 Sheave, Blade Drive .............................. 2

15 104-8300 Nut, Nyloc 5/16-18 Flg ........................... 2

16 104-8301 Nut, Nyloc 3/8-16 Flg ............................. 12

17 109-2548 Blade, 17.5 Standard ............................. 2

109-2551 Blade, Low lift ........................................ 2

■109-3129 Blade, Mulch.......................................... 2

109-2549 Blade, Solid ........................................... 2

18 109-2610-01 Baffle, Discharge ................................... 1

19 323-7 Screw, HH 3/8-16 x 1 1/4....................... 12

203217-46 Nut, Hex 3/4-16 Heavy........................... 2

21 3230-23 Bolt, Carriage 5/16-18 x 3/4, short neck 2

22 32128-37 Nut, Whizlock 7/16-14............................ 16

23 103-8280 Kit, Cutter Housing................................. 2

Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).

Anti-scalp kit P/N AS34 is available for this unit.

Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize) between the spindles & bearings

and spindles & sheaves and under top bearing guard. DO NOT use a copper or nickel based anti-seize.

QRequires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK343.

+Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on nut.

FRAME GROUP

-5-

Item

Part No.

Description

Qty.

1 32144-70 Screw, HWH 5/16-18 x 3/4 TF................3

2 1-513658 Bumper ..................................................5

3 93-8069 Decal, Hot Surface ................................. 1

4 1-513747 Decal, Battery ........................................ 1

5 3230-16 Bolt, Carriage 5/16-18 x 7/8 ...................4

6 109-3125 Asm, Frame W/Decals ...........................1

7 116-0201-03 Guard, Muffler ........................................1

8 103-9381-01 Plate, Floor ............................................1

9 104-8300 Nut, Nyloc 5/16-18 Flg ........................... 18

10 114-0543 Asm, Rear Guard W/Decal.....................1

11 109-0375 Grip, Brake Lever................................... 1

12 109-2356 Decal, Motion Control............................. 2

13 109-2421-03 Bracket, LH Fuel Tank ........................... 1

14 109-2422-03 Bracket, RH Fuel Tank...........................1

Item

Part No.

Description

Qty.

15 109-2429-03 Bracket, Rear Fuel Tank ........................ 2

16 109-2466 Decal, Phazer........................................ 1

17 109-2467 Decal, Drive Wheel Release .................. 2

18 109-2490 Decal, Danger Slope.............................. 1

19 109-2494 Decal, Console ...................................... 1

20 109-2539 Decal, Relay .......................................... 1

21 109-2605 Stop, Motion Control.............................. 2

22 109-2862 Decal, Rotating Devices......................... 1

23 302-19 Zerk, 1/4-28 Str...................................... 5

24 109-2992 Decal, Pump Belt Routing...................... 1

25 32151-48 E-Ring ................................................... 1

26 3230-23 Bolt, Carriage 5/16-18 x 3/4 ................... 13

27 3234-7 Screw, HH FLG 5/16-18 x 5/8 ................ 3

Exmark black touch up spray paint – gloss black.

FRAME GROUP (cont.)

-6-

Item

Part No.

Description

Qty.

1 283-6 Pin, Clevis 5/16 x 1 1/4 ..........................1

2 1-543509 Cone, Bearing Tapered Roller................4

3 1-543511 Seal, Grease.......................................... 2

4 1-543508 Cup, Bearing Tapered Roller ................. 4

5 1-633508 Washer, Spring Disc ..............................6

6 1-633585 Bearing, Cone Tapered Roller................4

7 1-811010 Plug .......................................................2

8 103-0063 Seal, Double Lip..................................... 4

9 103-2768 Guard, Seal............................................ 4

10103-3051 Spacer, Nut............................................ 4

11 103-3157 Axle, Caster ...........................................2

12 103-4882 Cap, Grease ..........................................2

13 103-8618-01 Wld, Caster Fork .................................... 2

14 112-3810 Asm, Wheel And Bearings .....................2

15 103-9932 Link, Deck Control..................................1

16 103-9933 Nut, Shoulder .........................................2

17 103-9934 Bushing..................................................1

18 104-7201 Nut, Nyloc 1/4-20 Flg .............................2

19 104-8300 Nut, Nyloc 5/16-18 Flg ........................... 3

20 104-8301 Nut, Nyloc 3/8-16 Flg .............................1

Item

Part No.

Description

Qty.

21 116-0199 Bar, Height Adjust.................................. 1

22 109-3544 Asm, Height Adjust W/Decal .................. 1

23 109-2416 Spring, Extension................................... 1

24 109-2463 Decal, Deck Height ................................ 1

25 109-2620 Pawl, Height Control .............................. 1

26 109-2628 Cable..................................................... 1

27 109-3323 Asm, Height Pin W/Lanyard ................... 1

28 321-5 Screw, HH 1/4-20 x 7/8.......................... 2

29 323-6 Screw, HH 3/8-16 x 1............................. 2

30 325-20 Screw, HH 1/2-13 x 6............................. 2

31 3230-23 Bolt, Carriage 5/16-18 x 3/4 ................... 2

32 3256-23 Washer, 5/16 SAE ................................. 1

33 1-303334 Washer, Spring Disc 5/16 ...................... 2

34 63-8410 Washer .................................................. 5

35 3289-19 Screw, Flat HD 3/8-16 x 1 3/4 ................ 1

36 1-806003 Hairpin, Cotter ....................................... 1

37 3296-45 Nut, Nyloc 1/2-13 Thin ........................... 2

38 3296-51 Nut, Nyloc 3/4-10................................... 2

39 3274-104 Screw, Button Head 5/16-18 x 1 ............ 1

Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).

Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on spacer nut Item #10.

MOTION CONTROL GROUP

-7-

Item

Part No.

Description

Qty.

1 1-543017 Balljoint .................................................. 2

2 3296-4 Nut, Esna 5/16-24 ..................................2

3 1-633181 Plate, Tapped......................................... 2

4 1-633257 Grip, Control Lever................................. 2

5 1-809057 Screw, SH 5/16-18 x 3/4 .......................4

6 65-7410 Switch ....................................................2

7 98-5975 Washer, Spring Disc 3/8.........................4

8 103-9367 Asm, Lever Control (RH) W/Grip ............ 1

9 103-9368 Asm, Lever Control (LH) W/Grip.............1

10 103-9373 Trunnion.................................................2

11 103-9407 Rod, Steering ......................................... 2

12 103-9411 Wld, Steering Control (RH)..................... 1

13 103-9413 Wld, Steering Control (LH) ..................... 1

14 103-9414 Post, Lever Mount .................................. 2

15 103-9928 Bearing ..................................................4

16 104-7201 Nut, Nyloc 1/4-20 Flg .............................4

17 104-8300 Nut, Nyloc 5/16-18 Flg ........................... 4

Item

Part No.

Description

Qty.

18 104-8301 Nut, Nyloc 3/8-16 Flg ............................. 2

19 109-2339 Damper, Motion Control......................... 2

20 109-2423 Shaft, Control Pivot................................ 2

21 109-2428 Bracket, Damper Mount ......................... 2

22 1-633545 Spacer ................................................... 4

23 322-6 Screw, HH 5/16-18 x 1 1/4 ..................... 2

24 323-6 Screw, HH 3/8-16 x 1............................. 4

25 323-9 Screw, HH 3/8-16 x 1 3/4....................... 2

26 3220-2 Nut, Jam 5/16-24 ................................... 6

27 3229-4 Bolt, Carriage 1/4-20 x 1 1/2 .................. 4

28 3234-7 Screw, HH FLG 5/16-18 x 5/8 ................ 4

29 3256-24 Washer, 3/8 SAE ................................... 2

30 32128-20 Nut, Whizlock 5/16-18............................ 4

31 3272-10 Pin, Cotter 1/8 x 3/4 ............................... 2

32 3290-500 Screw, PPH #10-24 x 5/8....................... 4

33 32128-33 Nut, Whizlock 1/4-20.............................. 4

PARK BRAKE GROUP

-8-

Item

Part No.

Description

Qty.

1 3256-3 Washer, 5/16 Std ................................... 2

2 32120-19 E-Ring.................................................... 1

3 103-9408 Bar, Equalizer ........................................1

4 103-9409 Bracket ,Brake Pivot...............................1

5 104-8300 Nut, Nyloc 5/16-18 Flg ...........................2

6 109-5376 Wld, Brake Bellcrank..............................1

7 103-9925 Spring, Brake .........................................1

8 103-9926 Nut, Square............................................1

9 32120-35 E-Ring.................................................... 1

10 114-0548 Wld, Brake Clevis...................................1

Item

Part No.

Description

Qty.

11 109-0223 Link, Over Center................................... 2

12 109-5370 Wld, Brake Link...................................... 1

13 3256-23 Washer, 5/16 SAE ................................. 2

14 109-2861 Spring, Extension................................... 1

15 283-6 Pin, Clevis 5/16 X 1 1/4.......................... 2

16 283-75 Pin, Clevis 5/16 X 3/4............................ 1

17 322-12 Screw, HH 5/16-18 x 2 1/2..................... 2

18 3272-10 Pin, Cotter 1/8 x 3/4 ............................... 3

19 1-633545 Spacer ................................................... 1

SEAT GROUP

-9-

Item

Part No.

Description

Qty.

1 27-0410 Screw, Shoulder 5/16-18 x 1 Sp............. 2

2 63-8410 Washer .................................................. 4

3 82-2190 Switch ....................................................1

4 103-3999 Decal, Exmark Logo............................... 1

5 103-9376 Bumper, Seat......................................... 2

6 104-8300 Nut, Nyloc 5/16-18 Flg ........................... 4

7 109-3128 Asm, Seat W/Decals .............................. 1

8 109-2427-03 Bar, Seat Stop........................................ 1

Item

Part No.

Description

Qty.

9 116-0950 Decal, Service Aid ................................. 1

10 109-2607-03 Bracket, Seat ......................................... 1

11 109-2608 Spacer ................................................... 4

12 108-6163 Kit, Armrest............................................ 1

13 32144-4 Screw, HWH 1/2-20 x 1/2 Taptite........... 2

14 322-10 Screw, HH 5/16-18 x 2........................... 4

15 1-653036 Washer .................................................. 4

Exmark black touch up spray paint – gloss black.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cortacésped de Exmark

Exmark

Exmark QUEST QZS708GEM50200 Manual de usuario

Exmark

Exmark Vantage VT20KA484 Manual de usuario

Exmark

Exmark Turf tracer HP Manual de usuario

Exmark

Exmark ECSKA21 Manual

Exmark

Exmark Laser Z XP Manual de usuario

Exmark

Exmark LAZER Z DS Series Manual de usuario

Exmark

Exmark exmark 30" Manual de usuario

Exmark

Exmark Ultra Vac Lazer Z HP Manual de usuario

Exmark

Exmark Phazer Manual

Exmark

Exmark PIONEER S-SERIES Operators Manual de usuario

Exmark

Exmark 135-2532 Manual de usuario

Exmark

Exmark Ultravac Bagger 126-8680 Manual de usuario

Exmark

Exmark Turf Tracer HP 4500-358 Manual de usuario

Exmark

Exmark FrontRunner Air-Cooled Manual de usuario

Exmark

Exmark LAZER Z Manual de usuario

Exmark

Exmark ULTRAVAC BAGGER 126-6954 Manual de usuario

Exmark

Exmark Turf tracer Manual de usuario

Exmark

Exmark 4500-370 Manual de usuario

Exmark

Exmark Lazer Z HP Manual de usuario

Exmark

Exmark Turf Ranger FMD604 Manual de usuario

Exmark

Exmark Metro 21 Series Manual de usuario

Exmark

Exmark Quest 4500-451 Manual de usuario

Exmark

Exmark Lazer XS 4500-380 Manual de usuario

Exmark

Exmark Metro 26 Manual de usuario

Manuales populares de Cortacésped de otras marcas

RHINO

RHINO 1958 Manual de usuario

Wolf Garten

Wolf Garten Compact plus 40 B Manual de usuario

Cub Cadet

Cub Cadet LTX 1045 Manual de usuario

Craftsman

Craftsman 917.378461 Manual de usuario

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manual de usuario

Challenge

Challenge CH18V2 Instrucciones de operación

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manual de usuario

DEWEZE

DEWEZE ATM-725 Manual de operación

Weed Eater

Weed Eater 180083 Manual de usuario

Husqvarna

Husqvarna Poulan Pro PP185A42 Manual de usuario

Better Outdoor Products

Better Outdoor Products Quick Series Manual de usuario

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manual de funcionamiento

MTD

MTD 795, 792, 791, 790 Manual de usuario

Toro

Toro Groundsmaster 3505-D Manual de usuario

Dennis

Dennis FT 610 Manual de usuario

AIRFORCE

AIRFORCE F-15 Gen 3 Manual de usuario

MTD

MTD 126-220-000 Manual de usuario

Toro

Toro 74806 Manual de usuario
