EXCELLPRECISION CO.,LTD.

Weighing ZSME300000036

Weighing

Scale

User Manual

EXCELLPRECISION CO.,LTD.

Weighing ZSME300000036

Preparation beforeOperation

1. Avoid operatingthescale inthelocationswherethereistoomuch temperaturechanges

and airflow, forexample, the place undersunlightoraircondition.

2. Use the independent powersocket to avoidthe interrupt of otherelectronic product.

3. When turning on the scale, do not place any object on the platter.

4. When operating the scale,placethe object on thecenterofthe platter.Fortheaccuracy

of weighing, do not place the object overthe range of the platter.

5. When thelowpowerindication()lights up, the scaleneeds to be recharged.

Display Description

HIGH :Upperlimit. To warn the object isoverthe setting upperlimit value. And it

means the weight excessivelyis high

OK :Value between upperand lowerlimit. To warn the weight of object isin the

normalsetting range.

LOW :Lowerlimit. To warn the object isunderthe set upperlimit. And it means the

weight is not enough.

kg :Unit kilogram”

lb :Unit pound”

à0ß:Zero”indication

Net:Net Weight”indication

:LowPower”indication

61:(STABLE) Stable”indication

62:(PT) PreTare”mode

63:(M+) Accumulation”mode

EXCELLPRECISION CO.,LTD.

Weighing ZSME300000036

Keyboard Description

UNITS

UNITS”⇒Press thekey to select the weighing unit kg”or lb.”

1. ESC ”ESC”⇒Return function.

2. PRESET: Preset function forweight.

3. M+:Accumulationfunction forweight.

4. TARE/ :”TARE”⇒tare function; ””⇒to move the cursorleftward.

5. PRETARE:Pre-tare function.

6. RECALL:To recallthevalue of accumulation, tare, and pre-tare.

7. CE:To clearthevalue of accumulation, tare, and pre-tare.

8. ZERO/→: ”ZERO”⇒to re-zero weightvalue; ”→”⇒to move the cursorrightward.

PRINT PRINT”⇒printing.

9. ENTER

ENTER”⇒confirmation key.

10.BL/↑: ”BL”⇒backlight setting; ”↑”⇒to add numberormove the menu upward.

HOLD HOLD ⇒printing summation

11.

SAMPLE

SAMPLE”⇒sampling function.

12. G/N/ :”G/N”⇒net and grossweight switch function; ””⇒to deduct number

ormove the cursordownward.

13. ON :To turn on the scale.

14. OFF :To turn off the scale.

EXCELLPRECISION CO.,LTD.

Weighing ZSME300000036

Function & Operation

BacklightFunction

Press BL/↑to select3 backlight modes incycle:

.,.,.

.⇒Auto backlight mode. When the weight ismorethan 10d, or

pressing keys, thebacklight willlightup. Afterre-zeroing (the

weight less than 10d)for5 seconds, the backlightwillbe off.

.⇒Backlight always lights up.

.⇒Backlight off.

WeighingFunction

(1).UnitSelection

UNITS

1. Afterturning on the scale, press

displayindications kg”or lb”.ESC

Key to select theunit kg”or lb.”Thescreenwill

2. Afterturningoff thescale,thescalewill memorize theweighingunit.Whenturning

on the scalenext time, the weighing unit used previously willbe recalleddirectly.

(2).Check-weighingFunction

1. Lowerlimit”, Upperlimit”, and Buzzer”Presetting.

Press BL/↑, G/N/↓, TARE/ , ZERO/→,

to input the pre-set value. Description as below:

TARE/ :To move leftward.

ZERO/→:Tomove rightward.

BL/↑:To deduct the numberby 1.

G/N/↓:Toadd the numberby 1.

ENTER : Confirmationkey.

ESC : Return key.

ENTER

UNITS

ESC

EXCELLPRECISION CO.,LTD.

Weighing ZSME300000036

Example:

LowerLimit”Presetting (lowerlimit >10d, d=division)ex.: lowerlimit = 20kg.

Press PRESET key, the screen displaysïð.

Press ZERO/→once, the screen displays ïð.

Press BL/↑twice, thescreen displays ïð.

Meanwhile, ifpressing ENTER key, the screen willdisplay 0”instead of ” ”.

UpperLimit”Presetting (upperlimit ≥lowerlimit)ex.: upperlimit = 25 kg.

Press ENTER once,the screen displaysïð. .

Press ZERO/→once, the screen displays ïð. .

Press BL/↑twice, thescreen displays ïð. .

Press ZERO/→once, the screen displays ïð. .

Press BL/↑5 times, the screen displays ïð. .

Meanwhile, ifpressing ENTER key, the screen willdisplay 0”instead of ” ”.

Buzzer”Presetting (referto Note 1)ex.: buzzer= 22.

Press ENTER once,the screen displaysïð.

Press BL/↑twice, thescreen displaysïð.

Press ZERO/→once, the screen displays ïð.

Press BL/↑twice, thescreen displays ïð.

Press ENTER once,the screen displays . .

EXCELLPRECISION CO.,LTD.

Weighing ZSME300000036

4SinglePoint Presetting

Lowerlimitonly

Method (I)

Afterfinished presetting lowerlimit, the screen displaysïð.. Press

PRESET onceagain.Ifthe screendisplays . , the singlepoint

presetting”is completed.

Method (II)

Afterfinishedpresettinglowerlimit, upperlimitandbuzzer,press PRESET once.

When the screen displaysïð., press RECALL twice again. At

thistimethe screen displays presettingupperlimit, press CE once. If the screen

displays . , the single point presetting”iscompleted.

Upperlimitonly

Afterfinished presetting, press PRESET once. When the screen displays

ïð., press RECALL once. Atthistimethe screendisplays

presetting lowerlimit, press CE once.Thenthe screen displays presettingupper

limit, press ESC or RECALL to exit. If thescreen displays . , the

single pointpresetting”iscompleted.

EXCELLPRECISION CO.,LTD.

Weighing ZSME300000036

Note1

ΧΧ

A⇒0 = Buzzerbeeps when being stable; LCD indication lights up.

1=Buzzerbeepswhen being stable; LCD indicationlightsupwithoutstable

determination.

2 = Buzzerbeepsand LCD indication lights up without stable determination.

B⇒0 = No buzzerbeep.

1=When it’sOK(the value higherthan lowerlimitand lowerthanupperlimit,)

the buzzerbeeps.

2= When thevalue is lowerthan orequal with lowerlimit, orhigherthanupper

limit, the buzzerbeeps.

4SinglePoint Presetting (lowerlimit only),the buzzeris fixed as:

When the value ishigherthan lowerlimit, the buzzerbeeps and

LOWindication willbe off.

Buzzerbeeps and LCD indicationlights up without stabledetermination.

4SinglePoint Presetting (upperlimit only),the buzzeris fixed as:

Whenthe value is higherthanupperlimit, the buzzerbeeps

and HIGHindication willbe on.

Buzzerbeeps and LCD indicationlights up without stabledetermination.

EXCELLPRECISION CO.,LTD.

Weighing ZSME300000036

4LCD Indication:

ïLOWðïOKðïHIGHð

ïïïïïïðððððð

10d LowerLimitUpperLimit

UNITS

♦Afterentering

intothe presetting mode, ifintended to abort, press

ESC key.

2. Setting Value Recall

Press PRESET and then RECALL ⇒torecall lowerlimit”

Press RECALL ⇒to recall upperlimit”

Press RECALL ⇒to recall buzzer”

Press RECALL again ⇒to recoverthe originalmode.

3. Setting Value Clear

Press PRESET , RECALL and then CE ⇒to clear lowerlimit”

Press CE again ⇒to clear upperlimit &buzzer”

EXCELLPRECISION CO.,LTD.

Weighing ZSME300000036

(3).Accumulation Function

1. Weight Accumulation

Place the object on theplatter,afterthe weight display is stable, press M+ key

to save thepresent weightvalue into memory.Meanwhile, the screen displays

totalcount accumulation”and then totalweight accumulation”,and the

accumulation (M+)indication 6”willbeflashing. After3 seconds, thescreen will

displaythe weight on platter,and the accumulation (M+)indication 6”lights up.

If the weightisunstableafterpressing M+ key, the screen will display ”.

4The scale can be continuous toaccumulate the next weight without re-zeroing.

Whenthe changes of weight on the platterishigherthan ±10d, press M+

key, afterbeing stable, it’s capable to save theweight into memory.

4Accumulation count isup to 9999, but display digitis up to 6.

2. Accumulation Clearing

♦Press RECALL and then CE to clearallthe accumulation.

♦Accumulation willbecleared automaticallyafterturning off.

3. AccumulationRecall

Whilepressing RECALL key,the screen willdisplay totalcount accumulation”,

and then totalweight accumulation”.It willbeback to theoriginalmode after

accumulation (M+)light 6”flashing for3 seconds. If no accumulation, it willbe back

to the originalmode afterthe screendisplays totalcount accumulation”.

(4).ZeroFunction

If zerodrifthappens during operating the scale, which means no objectson platter,

but the screen displays tiny weight value, press ZERO/→to re-zero. Meanwhile,

the screen willdisplay thezero(à0ß)indication.

(5).Net/ GrossSwitch

If ithas tareorpre-tareat present, press G/N/↓and the screen displays the gross

value. Meanwhile,allthe keys areno function, and press G/N/↓to returndisplaying

net weight value.
