7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

Revision 1.3

TABLE OF CONTENTS

1. OVERVIEW.......................................................................................................................................... 1

2. INSTALLATION................................................................................................................................... 3

2.1. CARE AND HANDLING OF OPTICAL FIBER............................................................................ 4

2.1.1. Safety.............................................................................................................................. 4

2.1.2. Assembly......................................................................................................................... 4

2.1.3. Labeling........................................................................................................................... 5

2.1.4. Handling and Connecting Fibers..................................................................................... 5

3. SPECIFICATIONS............................................................................................................................... 6

3.1. OPTICAL INPUT......................................................................................................................... 6

3.2. COAXIAL INPUT ........................................................................................................................ 6

3.3. OPTICAL OUTPUT..................................................................................................................... 6

3.4. SERIAL VIDEO OUTPUTS:........................................................................................................ 7

3.5. ELECTRICAL ............................................................................................................................. 7

3.6. PHYSICAL.................................................................................................................................. 7

3.7. COMPLIANCE ................................................................................................................................8

4. STATUS INDICATORS AND DISPLAYS ........................................................................................... 9

4.1. STATUS INDICATOR LEDS..................................................................................................... 10

4.2. DOT-MATRIX DISPLAY........................................................................................................... 11

4.2.1. Displaying the Optical Power........................................................................................ 11

4.2.2. Displaying the Video Standard...................................................................................... 11

4.2.3. Displaying the EDH Errors ............................................................................................ 12

5. JUMPERS AND LOCAL CONTROLS .............................................................................................. 13

5.1. SELECTING THE INPUT SOURCE.......................................................................................... 13

5.2. SELECTING THE RECLOCKING MODE................................................................................. 13

5.3. SELECTING THE RECLOCKING RATE.................................................................................. 13

5.4. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED

BY THE GLOBAL FRAME STATUS ........................................................................................ 14

5.5. SELECTING WHETHER MODULE WILL BE CONTROLLED FROM THE

LOCAL CONTROLS OR THROUGH THE VISTALINK

INTERFACE ...................................... 14

7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

Revision 1.3

5.6. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES.............................................. 14

6. VISTALINK

REMOTE MONITORING/CONTROL........................................................................... 15

6.1. WHAT IS VISTALINK

?............................................................................................................. 15

6.2. VISTALINK

MONITORED PARAMETERS .............................................................................. 16

6.3. VISTALINK

CONTROLLED PARAMETERS ........................................................................... 17

6.4. VISTALINK

TRAPS.................................................................................................................. 17

Figures

Figure 1-1: 7707OO Block Diagram......................................................................................................................2

Figure 2-1: 7707OO Rear Panel...........................................................................................................................3

Figure 2-2: Reproduction of Laser Certification and Identification Label..............................................................5

Figure 4-1: 7707OO Status Indicator and Jumper Locations ...............................................................................9

Tables

Table 6-1: VistaLINK

Monitored Parameters.....................................................................................................16

Table 6-2: VistaLINK

Controlled Parameters....................................................................................................17

Table 6-3: VistaLINK

Traps...............................................................................................................................17

7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

Revision 1.3

REVISION HISTORY

REVISION DESCRIPTION DATE

1.0 Original Version Jan 05

1.1 Updated safety section and added assembly and labeling sections Aug 05

1.2 Updated VistaLINK

description and fixed format Jun 08

1.3 Updated features & specs Nov 08

Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for

the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of

Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered

by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.

Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is

granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.

Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,

please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or

specifications.

7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

Revision 1.3

WARNING

Never look directly into an optical fiber. Non-reversible damage to the eye can

occur in a matter of milliseconds.

Do not hook up the 7707OO DWDM cards directly with a short fiber optic

cable. The 7707OO DWDM cards produce +7dBm of power which will damage

the receiver if connected directly.

7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

Revision 1.3 7707OO-1

1. OVERVIEW

The 7707OO is a VistaLINK

enabled, optical to optical converter for any bi-level encoded signal @ rates

from 19.39Mb/s to 540Mb/s. As such it can be used for SMPTE 259M (143-360Mb/s), SMPTE 344M

(540Mb/s), DVB-ASI (270Mb/s) and SMPTE 310M (19.4Mb/s) signals. Monitoring and control of card

status and parameters is provided locally at the card edge, and remotely via VistaLINK

. The 7707OO

accepts one fiber input and provides two reclocked coaxial outputs and one optical output. A coaxial SDI

input can be used as a fallback source, in case of optical link failure or can be selected as the primary

input.

The 7707OO is available in different versions to meet a variety of applications. All versions accept

1310 nm to 1610 nm optical input signals on multi-mode or single-mode fiber and translate the signal to

another wavelength as indicated below. (See specifications for complete information).

7707OO13 1310 nm FP Suitable for distances > 60 km @ 270 Mb/s

7707OO15 1550 nm DFB Suitable for distances > 100 km @ 270 Mb/s

There are several versions with built in isolators specifically suited to coarse wave division multiplexing

(CWDM) applications. The CWDM versions are suitable for distances > 100 km @ 270 Mb/s

7707OO27 1270 nm DFB

7707OO29 1290 nm DFB

7707OO31 1310 nm DFB

7707OO33 1330 nm DFB

7707OO35 1350 nm DFB

7707OO37 1370 nm DFB

7707OO43 1430 nm DFB

7707OO45 1450 nm DFB

7707OO47 1470 nm DFB

7707OO49 1490 nm DFB

7707OO51 1510 nm DFB

7707OO53 1530 nm DFB

7707OO55 1550 nm DFB

7707OO57 1570 nm DFB

7707OO59 1590 nm DFB

7707OO61 1610 nm DFB

There are several versions with built in isolators specifically suited to dense wave division multiplexing

(DWDM) applications. The DWDM versions are suitable for distances >120 km @ 270 Mb/s (for DWDM

applications contact factory).

7707OODyyy DWDM DFB laser output, yyy – ITU channel number

The 7707OO occupies one card slot and can be housed in either a 1RU frame, which will hold up to three

modules, or a 3 RU frame, which will hold up to 15 modules.

7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

7707OO-2 Revision 1.3

Features:

•Can be used as optical regenerator/repeater, E to O converter, to E converter, O to O wavelength

converter

•Auto-rate selection, reclocking and indication for all SMPTE 259M

•standards from 143-540Mb/s

•Supports additional standards of SMPTE 305M(SDTi), SMPTE 310M(19.4Mb/s) and M2S or DVB-

ASI(270Mb/s)

•Can also support Datacom/Telecom rates up to 540Mb/s

•Coaxial or optical input (jumper selectable)

•Supports single-mode and multi-mode fiber optic cable

•Optical output wavelengths of 1310nm, 1550nm and up to sixteen CWDM wavelengths (ITU-T

G.694.2 compliant)

•DWDM wavelengths (ITU-T G.694.1 compliant) also available

•Independent isolated output drivers to ensure no cross channel

•loading effects and to maintain polarity from input to output for

•DVB-ASI applications

•Comprehensive signal and card status monitoring via four digit card

•edge display or remotely through SNMP and VistaLINK -enabled capability

•Detection and display of optical input power, video format and EDH errors

•Fully hot-swappable from front of frame

•Two BNC serial digital output

Figure 1-1: 7707OO Block Diagram

RECLOCKING

SMPTE 259M

SMPTE 305M

SMPTE 310M

SMPTE 344M

DVB-ASI

CONTROL/

INDICATION

VistaLINK

Interface

LOCAL

CONTROL

LOCAL

INDICATIO

Optical

Input 2

Serial

BNC

Outputs

OPTICAL

RECEIVER

CABLE

DRIVER

Optical

Output

OPTICA

DRIVE

Redundant

SDI Input ADAPTIV

EQUALIZATION

7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

Revision 1.3 7707OO-3

2. INSTALLATION

The 7707OO comes with a companion rear plate that has two BNC connectors and two SC/PC (shown),

ST/PC or FC/PC optical connector. For information on mounting the rear plate and inserting the module

into the frame see the 7700FR chapter section 3.

SDI INPUT

SDI OUTPUT

7707OO

Figure 2-1: 7707OO Rear Panel

7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

7707OO-4 Revision 1.3

OPTICAL INPUT: Input for SDI optical signals. Available in SC/PC, ST/PC, FC/PC female

connectors. Accepts SMPTE 259M, SMPTE 344M, DVB-ASI,

SMPTE 305M(SDTi) or SMPTE 310M optical signals and provides auto-rate

selection and reclocking for rates from 143Mb/s to 540Mb/s. A non-reclocking

mode is also selectable via card edge jumpers, or through the VistaLINK

interface. This wide range input accepts optical wavelengths of 1270nm to

1610nm, accommodating standard, CWDM or DWDM transmission schemes.

COAXIAL SDI INPUT: This input provides a second Serial Video input. When the SOURCE jumper is

set to the AUTO mode, the module will switch to the coaxial input in case of

optical link failure. In addition either input may also be selected as the sole

signal source. The coaxial input is non-reclocked. (See section 5.1 for more

information on setting the SOURCE jumper).

OPTICAL OUTPUT: There is one SC/PC (shown), ST/PC or FC/PC female connector with the video

output converted to an optical signal as specified in section 3.2. The optical

output laser is enabled only while a valid input signal is detected indicated by

the SIGNAL VALID LED.

SDI OUTPUT: The 7707OO provides two reclocked serial digital video outputs for signal

distribution. Both outputs maintain the same polarity as the input and are DVB-

ASI compliant.

2.1. CARE AND HANDLING OF OPTICAL FIBER

2.1.1. Safety

CLASS 1 LASER PRODUCT

Background colour: yellow

Triangular band: black

Symbol: black

2.1.2. Assembly

Assembly or repair of the laser sub-module is done only at Evertz facility and performed only by qualified

Evertz technical personnel.

7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

Revision 1.3 7707OO-5

2.1.3. Labeling

Certification and Identification labels are combined into one label. As there is inadequate space on the

product to place the label, it is reproduced here in the manuals.

There is no date of manufacture on this label as it can be traced by bar code label placed on the Printed

circuit board of each Evertz plug-in module.

•The Model number is one of: 7707OO13, 7707OO15

7707OOxx, (xx = 27, 29, 31, 33, 35, 37, 43, 45, 47, 49, 51, 53, 55, 57, 59, 61)

7707OODyyy (Dyyy represents ITU Grid Channel: D200, D210, D220, D230, D240, D250, D260,

D270, D280, D290, D300, D310, D320, D330, D340, D350, D360, D370, D380, D390, D400,

D410, D420, D430, D440, D450, D460, D470, D480, D490, D500, D510, D520, D530, D540,

D550, D570, D580, D590, D600)

Figure 2-2: Reproduction of Laser Certification and Identification Label

2.1.4. Handling and Connecting Fibers

Never touch the end face of an optical fiber. Always keep dust caps on optical fiber

connectors when not connected and always remember to properly clean the optical end

face of a connector before making a connection.

The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore

care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz

recommends that you maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that will

decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with

cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in the

frame that does not have a suitable I/O module. For further information regarding care and handling of the

fiber optic cable see section 3 of the Fiber Optics System Design section of this manual binder.

7700 MultiFrame Manual

7707OO Optical Regenerator/Wavelength Converter, 19.4Mb/s to 1.485Gb/s, VistaLINK®

7707OO-6 Revision 1.3

3. SPECIFICATIONS

3.1. OPTICAL INPUT

Standards: SMPTE 297M

Reclocked: SMPTE 259M A, B, C, D, SMPTE 344M, SMPTE 305M, DVB-ASI, M2S

Non-Reclocked: Any bi-level signal type at rates of 19.4Mb/s – 540Mb/s including

SMPTE 310M (19.4 Mb/s)

Connector: Female SC/PC, ST/PC or FC/PC

Wavelength: 1270nm -1610nm

Optical Sensitivity: -31dBm @ 270Mb/s

Max. Input Power: 0dBm

Fiber Size: 62 µm core / 125 µm overall

3.2. COAXIAL INPUT

Normal: SMPTE 259M (143 to 540Mb/s) or DVB/ASI

Jumper Selectable: SMPTE 310M (19.4Mb/s)

Connector: 1 BNC per IEC 61169-8 Annex A

Impedance: 75Ω(nominal)

Equalization: Automatic to 275m(min) @ 270Mb/s with Belden 8281 cable

Return Loss: > 15dB to 540Mb/s

3.3. OPTICAL OUTPUT

Standards: same as optical input

Number of Outputs: 1 reclocked

Connector: SC/PC, ST/PC or FC/PC female housing

Return Loss: < 14 dB

Rise and Fall Time: 400-700 ps

Jitter: < 0.15UI (Reclocked)

< 0.20UI (Non-reclocked)

Fiber Size: 9 µm core / 125 µm overall

Otros manuales para 7700 Series

127

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de red de evertz

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 3700FR Series Manual de usuario

evertz

evertz 7800 Manual de usuario

evertz

evertz 9580 Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 5010-GPSII Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 9625LG Manual de usuario

evertz

evertz 8010TM Manual de usuario

evertz

evertz EQT Series Guía del usuario

evertz

evertz 9625DSK-LGA Manual de usuario

evertz

evertz 5700ACO Manual de usuario

evertz

evertz S623 Manual de usuario

evertz

evertz 3405 Manual de usuario

evertz

evertz 7700 7780ASI-IP2 Manual de usuario

evertz

evertz MAGNUM-ROUTER-SS Manual de usuario

evertz

evertz MetaCast 2 Manual de usuario

evertz

evertz 8025 Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 3406FR-HDBNC Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz TR-4800E Manual de usuario

evertz

evertz 7720AE Series Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario

Lanner

Lanner NCA-1525 Manual de usuario
