EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

EXE Connections and Configurations

The following steps should be observed when setting up the EXE.

Power Supply Connection:

The power supply comes with an external power switch mounted on a 1RU panel.

There is one switch for the power supplies at the top of the frame and one switch for the supplies at the

bottom of the frame. When the switch is in the Off position all the power modules will be shutdown,

and when the switch is returned to the On position it will cause the power modules to power back up.

Each switch has a mating cable, with four alarm connectors. The alarm connectors are required for the

power tray to current share and therefore must be plugged into the back of each operating power supply

tray.

First, connect an Ethernet cable from the Control Network to the front of the PSU unit. Use a web

browser to open the Power Supply Unit (PSU) web interface, login with username Admin and password

exeadmin. By default each PSU’s IP is set to 192.168.0.230.

EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

On the Main page verify that the System Voltage is set to 48V.

On the Modules page verify that all Rectifiers in a Shelf have similar current consumptions.

EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

Compare the PSU currents of different shelves that power the top half of the frame and the bottom half

of the frame (if applicable). The shelves that are current sharing should have similar current

consumptions; if they do not then check the current sharing cable that interconnects the PSU shelves.

EXE NCS-A Connections:

1. Connect the NCS-A to the EXE frame according to wiring diagram, use instructions below as

reference:

a. Connect the NCS’s Control port using a 1GE RJ-45 SFP to a switch or directly to the

controlling PC so that the NCS User Interface may be accessed.

b. Connect the NCS’s FC CFG A port using a 1GE RJ-45 SFP to EXE-FC A on FC Cfg1 using

another 1GE RJ-45 SFP.

c. Connect the NCS’s FC CFG B port using a 1GE RJ-45 SFP to EXE-FC B on FC Cfg1 using

another 1GE RJ-45 SFP.

d. Connect the NCS’s 10GE SFP1 port to EXE-FC A on Ctrl 1.

e. Connect the NCS’s 10GE SFP2 port to EXE-FC B on Ctrl 1.

f. Repeat steps a-e with the second NCS except this time using FC Cfg2 on both FC’s, and

Ctrl 2 on both FCs for the 10Gb fibers (as shown in the reference diagram above).

g. Connect reference input to Ref1 on both FC’s.

Special Note:

The connections listed above require specific SFP types:

a. On EXE-NCS-A , 10GE ports use MO-10GE-SFP-10KM

EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

b. On EXE-FC , 10GE ports use SFP10G-TR13-A

c. On EXE-FC , 1GE ports use SFPTR-RJ45-SER-AV

Map of NCS ports to physical ports:

Control



eth0

FC CFG A



eth2

FC CFG B



eth3

SC1



eth4

SC2



eth5

10GE SFP-1



eth7

10GE SFP-2



eth6

EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

EXE NCS-A Settings

EXE-NCS-A Network Configuration

The EXE-NCS-A network can be set from either the Host webpage or command line interface. This

step is required if the customer wants to use a different IP address, Netmask or Gateway than the

pre-set settings.

1. To configure Host’s IP address from web interface:

a. Use web browser to open the Host webpage, in the address bar enter the preset host IP

address

b. Change IP Address, Subnet Mask and Gateway (if required) of the NCS Host.

c. Select the Apply button.

2. To configure Host’s IP address from command line:

a. Connect a monitor and keyboard to the NCS unit. Login to NCS Host with the username:

root, password: evertz.

b. Set the IP address, netmask and gateway with the command below; retry until no error

messages are returned (Most errors are due to typing mistakes):

netsetup --force config ip_address netmask gateway || echo

error

EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

Example:

NCS-0# netsetup --force config 172.16.227.51 255.255.0.0 172.16.1.1

|| echo error

c. Verify if the network is configured as expected using the following commands:

ifconfig | grep ip_address

ip route | grep default

Example:

NCS-0# ifconfig | grep 172.16.12.90

inet addr:172.16.12.90 Bcast:0.0.0.0 Mask:255.255.0.0

NCS-0# ip route | grep default

default via 172.16.227.1 dev breth0

Finally reboot the system for the changes to take effect; enter reboot in the NCS host terminal.

EXE-NCS-A host will automatically assign an IP address for the Guest by using the Host’s IP + 1.

For example: Host IP is 10.10.10.10 Guest IP will be 10.10.10.11

EXE-NCS-A Host

1. Login to the EXE-NCS host webpage with username root, password evertz. This will bring up the Host

page displaying the firmware version installed on the host and all host settings.

The parameters on this page are defined as:

a. Version: Displays the firmware version that is installed on the Host.

b. NCS Index: Displays the state of control for the NCS

o0 : means the NCS is set up as main control.

o1 : means the NCS is set up as redundant control.

*Note: The NCS’s cannot have same NCS Index.

EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

c. Time Server: The IP address of the Time Server being used to synchronize the NCS Host

clock with an NTP server.

2. The Second page is the Guest page.

The parameters on this page are defined as:

a. Guest Settings: Displays the image that is currently used for the Guest. Select Start/Stop

under the Action label; this will start/stop the guest image. NOTE: Stop both NCS Guest’s

before making any firmware changes to avoid sync issues.

Only start the Guest when all settings have been applied.

Always start the Guests one NCS at a time.

EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

Always start the Guest of NCS0 first (Main NCS).

EXE frame will power on after Guest started.

b. Image Settings: Displays a list of pre-loaded Guest images. Choose the appropriate

image number under the label Image corresponding to the Guest of choice. If the

desired image isn’t loaded on the list, click Choose File, and select the image file then

select Create.

c. Card Settings: These allow the user to enable/disable blades in the frame.

Blades that are not present in EXE frame need to be Disabled.

Blades can be disabled by clicking on the box and choosing Null.

Blades can only be enabled/disabled when the Guest is stopped.

d. When all settings and configurations are done:

a. Power on EXE frame and wait for 5 minutes

b. Ensure all blades boot up.

c. Ensure both NCS’s sync up (i.e. Display Peer Controller: Online)

d. Ensure all previously enabled ports return to Up.

Troubleshooting EXE System issues

1. EXE frame can’t boot

There are some reasons that may cause the EXE frame to be unable to boot up properly. The most

common reason is because there is no link between the NCS’ and the FC’s. The following steps will

describe how to troubleshoot this problem:

a. Go to the Host webpage and ensure the Guest is started.

b. Verify the connections from Guest

i. SSH into the NCS guest with username: root, password: evertz.

ii. Type command checklinks.

oIf all links are connected properly, it will return “All links are

okay”.

oIf links have problem, NCS guest will show some messages as below:

Link down On NCS0

- "exe-NCS-0:eth7" connected to "exe-FC-01:fm0-01-F01-P01(fm0-01)" (Link between

Ctr1(fm0-01-F01-P01(fm0-01)) port on FC01 and 10GE-SFP1(eth7) on NCS0 is down)

- "exe-NCS-0:eth6" connected to "exe-FC-02:fm0-01-F02-P01(fm0-01)" (Link between

Ctr1 (fm0-01-F02-P01(fm0-01)) port on FC02 and 10GE-SFP2(eth6) on NCS0 is down)

- "exe-NCS-0:eth2" connected to "exe-FC-01:eth0" (Link between FC Cfg1 (eth0) port on

FC01 and FC CfgA (eth2) on NCS0 is down)

- "exe-NCS-0:eth3" connected to "exe-FC-02:eth0” (Link between FC Cfg1 (eth0) port on

FC02 and FC CfgB (eth3) on NCS0 is down)

EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

Link down On NCS1

-"exe-NCS-1:eth7" connected to "exe-FC-01:fm0-02-F01-P02(fm0-02)" (Link between

Ctr2(fm0-02-F01-P02(fm0-02)) port on FC01 and 10GE-SFP1(eth7) on NCS1 is down)

- "exe-NCS-1:eth6" connected to "exe-FC-02:fm0-02-F02-P02(fm0-02)" (Link between

Ctr2(fm0-02-F02-P02(fm0-02)) port on FC02 and 10GE-SFP2(eth6) on NCS1 is down)

- "exe-NCS-1:eth2" connected to "exe-FC-01:eth1" (Link between FC Cfg2 (eth1) port on

FC01 and FC CfgA (eth2) on NCS1 is down)

- "exe-NCS-1:eth3" connected to "exe-FC-02:eth1" (Link between FC Cfg2 (eth1) port on

FC02 and FC CfgB (eth3) on NCS1 is down)

Cable is swapped

-"exe-NCS-0:eth2" connected to "exe-FC-01:eth0" + "exe-NCS-0:eth2" connected to "exe-

FC-01:eth1"

1GE link is swapped on FC01. Currently, FC Cfg2 (eth1) on FC01 is connected to FC

CfgA (eth2) on NCS0 instead of connected to FC CfgA (eth2) on NCS1

-"exe-NCS-0:eth7" connected to "exe-FC-01:fm0-01-F01-P01(fm0-01)" + "exe-NCS-

0:eth7" connected to "exe-FC-01:fm0-02-F01-P02(fm0-02)"

10GE link is swapped on FC01. Currently, Ctr2 (fm0-02-F01-P02(fm0-02)) port on

FC01 is connected to 10GE-SFP1(eth7) on NCS0 instead of connected to 10GE-

SFP1(eth7) on NCS1

Peering link is disconnected

-"exe-NCS-0:eth4" connected to "exe-NCS-1:eth4"

The first Peer link between NCS0 and NCS1 is disconnected

-"exe-NCS-0:eth5" connected to "exe-NCS-1:eth5"

The second Peer link between NCS0 and NCS1 is disconnected

c. Check LED lights from the back of NCS for 1GE links and 10GE links. Reseat the SFP from

the FC’s side if any of them are not lit up. The link should be recovered after reseating.

NOTE: The LED lights for the 10GE links are located between 10GE SFPs. The top 2 LED lights

are associated with the 10GE SFP2 port. The bottom 2 LED lights are associated with the

10GE SFP1 port.

2. Port down

There are some reasons that may cause the EXE port to remain Down.

a. The Port is set to Down on the Guest Webpage:

i. Go to the Port tab on the Guest webpage, make sure Operation is set to Up.

b. The Port is set to the wrong speed:

i. Go to the Port tab on the Guest webpage, make sure Speed is set to the proper

speed (1GE/10GE).

EXE Bandwidth Limiting Script

Date Revised: Jan-12-16 Revision 1.0

c. Ports set to wrong type

i. Go to Port tab on Guest webpage, ensure Transceiver Type is set to the right

cable type. There are 2 types of cable.

oOptical: Use for fiber cables.

oDAC: Use for copper cables.

ii. If you need to set series of port at one time, follow these steps:

oSSH to guest.

oType cfgsh

oType set portConfigTransceiverType <port range> <type>

Example:

set portConfigTransceiverType 10..40 dac

set portConfigTransceiverType 100..240 optical

d. Link is down on the other side (end-device)

i. Ensure the link is UP on other device which is connected to EXE port.

e. Bad SFP

i. Go to Port tab on Guest webpage and check “TX power level” and “RX power

level”.

oTx[dBm] should read no less than -8.2, and no greater than +0.5

oRx[dBm] should read no less than -10, and no greater than +0.5

ii. If Tx power is -16, -20 or -40, it is means it is a bad SFP.

3. EXE not swiching in VBI - Verify reference (Genlock) status

a. From guest SSH to FC by using command:

ossh fc01 (For the top FC)

ossh fc02 (For the bottom FC)

b. Change directory to /evertz/factory/fc folder and run ./ref script

FC-01# cd /evertz/factory/fc

FC-01# ./ref

oRef1: 15.7331655129 kHz (15890)

oRef2: not detected (32768)

i. The ./ref utility reports the detected line rate:

oNTSC is 27000000/1716 = 15.734 kHz

oPAL is 27000000/1728 = 15.625 kHz

oHD formats have higher frequency line rates.

Otros manuales de Hardware de red de evertz

evertz

evertz 9590 Manual de usuario

evertz

evertz MAGNUM Manual de usuario

evertz

evertz EMR-TDM16-DLY Manual de usuario

evertz

evertz HD9525LG Manual de usuario

evertz

evertz 3405 Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 8010TM Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 9531 Manual de usuario

evertz

evertz 3406FR-HDBNC Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 5600ACO2 Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz TR-3200E Manual de usuario

evertz

evertz 7700 7780ASI-IP2 Manual de usuario

evertz

evertz HD9626DSK Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 7800 Manual de usuario

evertz

evertz TR-4800E Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 7700 Series Manual de usuario

evertz

evertz 7700 Series Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario

Lanner

Lanner NCA-1525 Manual de usuario

evertz EXE Manual de usuario

Manuales populares de Hardware de red de otras marcas
