Eton SOUND 110 Manual de usuario

SOUND 110

AM/FM Digital Retro Style

OWNER’S MANUAL

Need Help? Contact Us.

Etón Corporation, 1015 Corporation Way, Palo Alto, CA 94303, USA.

1-800-872-2228 (U.S.); 1-800-637-1648 (Canada); 650-903-3866

(worldwide); M-F, 8:30-4:00, Pacic Standard Time;

www.etoncorp.com.

WARNING

• Do not expose this appliance to rain or moisture.

• Do not submerge or expose for extended period to water.

• Protect from high humidity and rain.

• Only operate within specied temperature range (0 °C to 40 °C).

• Unplug immediately if liquid has been spilled or objects have fallen into the

apparatus.

• Clean only with a dry cloth. Do not use detergents or chemical solvents as this

might damage the nish.

• Do not remove cover [or back].

• Refer servicing to qualied service personnel.

Disposal

According to the European Directive 2002/96/EC all

electrical and electronic products must be collected

separately by a local collection system.

Please act according to your local rules and do not dispose of your

old products with your normal household waste.

ENVIRONMENT

SOUND 110 OWNER’S MANUAL

• Main unit

• Left and right speaker unit

• AC adapter

• Remote control

• AM antenna

• FM antenna

• Owner’s manual

This radio has a battery back-up system on the rear of the radio to

ensure continuous operation of the memory presets, clock and alarm

in the event of power failure. The switch from AC to battery power

is automatic. However under battery power the clock display will not

illuminate, even though the clock will maintain the current time and

will store the alarm time in its memory. The system operates on 2 AA

batteries.

Make sure that the batteries are installed correctly. Wrong polarity

may damage the unit. It is suggested to use alkaline batteries for the

sake of better performance. Do not mix old and new batteries. Do

not mix carbon-zinc, alkaline or rechargeable batteries. Remove the

batteries if the unit is not going to be used for a long period. Leaking

batteries may cause damage to the unit and will void the warranty.

Plug one of the speakers into the LEFT SPEAKER OUT jack on the

back of the radio and the other one into the RIGHT SPEAKER OUT

jack. It doesn’t matter which one you plug into the left or right. Plug

the FM antenna into its socket. Plug the AM antenna into its socket.

BATTERY BACKUP

SETTING UP YOUR SYSTEM

SOUND 110 OWNER’S MANUAL

WHAT YOUR ETÓN SOUND 110 INCLUDES

Plug the AC adapter into the mains and then into the radio’s AC

14VAC socket.

The remote uses a CR/DL2025 battery. Insert it into the battery

holder with the writing facing opposite to the writing on the remote.

Replace the battery when it no longer works. Pull out the plastic tab

to activate the remote.

Press the STANDBY button on the radio or on the remote.

Press the MODE button on the radio or the remote to select UDISK,

SD/MMC, AUX or TUNER.

Use the VOL buttons on the remote or the volume knob on the

unit.

Use the MODE button to select TUNER, then select AM/FM with the

remote’s AM/FM button or the BAND button or the BAND button

on the unit. Tune using the tuning buttons on the radio or the

remote. A quick, short press tunes individual frequencies; a longer

press of 1 second engages auto tuning, which tunes only to stations

of strong signal strength.

PREPARING THE REMOTE FOR USE

SOUND 110 OWNER’S MANUAL

TURNING THE RADIO ON

SELECTING PLAY MODES

ADJUSTING VOLUME

PLAYING AM OR FM

SETTING UP YOUR SYSTEM continued

You may store 10 AM and 20 FM stations. To store a station:

Tune to it rst, then press PROGRAM on the remote; then use the

numeric keypad to enter the two-digit memory number that you wish

it to be stored in or scroll to that number with the remote’s PS/F but-

tons ; then press PROGRAM. By two-digit number we mean 01,

02 ….. 20. ‘PS’ stands for preset; ‘F’ stands for folder.

To scroll through what you’ve stored into memory, press the remote’s

PS/F buttons. ‘PS’ stands for preset; ‘F’ stands for folder. To

directly enter the memory that you wish to go to, press the memory’s

number, e.g. 01, 02, ….. 18, 19, 20.

Press the MODE button on the radio or the remote until UDISK or

SD/MMC appears. Plug in your USB or SD/MMC card. Play automati-

cally begins.

To advance folders, press the remote’s advance folder buttons,

PS/F . ‘F’ stands for folder. To advance tracks, press the button.

To go back to the beginning of a track, press the button. To go

back to the previous track, press the button twice. To advance

or go back within tracks keep the buttons pressed. To pause

play, press the button. To start play again, press it again. Press the

stop button to stop play. During play, folder, track, play time, song

name, artist and album name ash in the display.

While playing from a USB or SD/MMC card, you may select the follow-

ing play modes with the remote; they show in the upper portion of

PLAYING FROM A USB OR SD/MMC CARD

SOUND 110 OWNER’S MANUAL

RETRIEVING STATIONS STORED IN MEMORY

STORING AM OR FM FREQUENCIES

the display: RANDOM, INTRO and REPEAT.

A. RANDOM plays the songs randomly.

B. INTRO plays each song for 10 seconds.

C. REPEAT: four repeat modes are possible by pressing the REPEAT

button sequentially. REPEAT ALL or REPEAT FOLDER can be used

with INTRO and RANDOM.

1. To play one song over and over, press the REPEAT button until

an open rectangle with arrow appears in the upper left corner of

the display. RANDOM and INTRO do not work.

2. To play a segment of a song, press the REPEAT button until

A appears where you want the segment to start, then press

REPEAT again causing B to appear where you wish to end the

segment. A and B appear in the upper left corner of the display.

Any 90-second segment can be repeated. RANDOM and INTRO

do not work.

3. Press the REPEAT button until ALL appears in the upper left

corner of the display to repeat all songs. RANDOM and/or INTRO

may be turned on.

4. Press the REPEAT button until FOLDER appears in the upper

left corner of the display to repeat a folder. RANDOM and/or

INTRO may be turned on.

5. Press REPEAT until all repeat symbols disappear. Play is normal.

This is a 12-hour clock, showing AM and PM.

1. Press the button on the remote for about 3 seconds or until

the hour ashes.

PLAYING FROM A USB OR SD/MMC CARD

continued

SOUND 110 OWNER’S MANUAL

SETTING THE CLOCK

2. Press the buttons to set the hour and press when

nished. The minutes start ashing.

3. Press the buttons to set the minutes and press when

nished.

1. Press the button on the remote for about 3 seconds or until

the hour ashes.

2. Press the buttons to set the hour and press when

nished. The minutes start ashing.

3. Press the buttons to set the minutes and press when

nished.

Press the remote’s or the ALARM button to sequentially to select

ALARM ON/OFF or BUZZER. When the alarm is on, an asterisk (*)

appears in the display to the left of the clock. The BUZZER will alarm

for 25 minutes; the TUNER, USB or SD will alarm for 59 minutes. Set

the desired volume level for the alarm before turning the radio to

standby.

After the alarm turns on you can press the SNOOZE button on top of

the radio and sleep for about 10 more minutes.

SOUND 110 OWNER’S MANUAL

THE ALARM ON/OFF BUZZER BUTTON

THE SNOOZE BUTTON

SETTING THE CLOCK continued

SETTING THE ALARM

Pressing this button turns the bass on or off.

Pressing this button selects FLAT, ROCK, JAZZ, CLASSIC and POP

equalization. Use the one whose sound you like best.

Selects sleep time of 00-90 minutes. The radio plays for the amount

of minutes selected and then turns off. Use with the radio turned on.

Pressing the remote’s mute button mutes the radio. Press it again

to un-mute it or press one of the tuning buttons.

Pressing the remote’s STEREO/MONO button during FM radio play

enables selection of stereo or mono play.

Use this input on the back of the radio (3.5 mm, 1.8 inch stereo) to

route a signal input into this radio.

Use this output on the back of the radio (3.5 mm, 1/8 inch stereo) to

route the signal to external, amplied speakers.

SLEEP BUTTON

SOUND 110 OWNER’S MANUAL

BASS BUTTON

EQ BUTTON

THE MUTE BUTTON

STEREO/MONO BUTTON

AUX INPUT

SPEAKER OUTPUT

• FM Frequency 87.5 – 108MHz

• AM Frequency 530 – 1710 KHz

• Speaker Output Power 5 Watts RMS x 2

• Power Supply: input 110 VAC, 60 Hz; output 14 VAC, 2500 mA.

• Specication and the design are subject to possible modications

without notice due to improvement.

NOTE: In case of malfunction due to electrostatic discharge, reset

the product to resume normal operation. To reset the product,

unplug AC from the back of the unit, wait 30 seconds, then plug it

back in.

To ensure full warranty coverage or product updates, registration of

your product should be completed as soon as possible after purchase

or receipt. You may use one of the following options to register your

product:

1. By visiting our website at http://www.etoncorp.com.

2. Mail in enclosed warranty card.

3. Mail your registration card or information to the following address;

include your name, full mailing address, phone number, email ad-

dress, model purchased, date purchased, retail vendor:

Etón Corporation

1015 Corporation Way

Palo Alto, CA 94303 USA

WARRANTY REGISTRATION

SOUND 110 OWNER’S MANUAL

SPECIFICATIONS
