ETC®Quick Guide

Source Four LED™Profile

Source Four LED Profile v1.3.0 Quick Guide Page 1 of 7 Electronic Theatre Controls, Inc.

Corporate Headquarters



3031 Pleasant View Road, P.O. Box 620979, Middleton, Wisconsin 53562-0979 USA



Tel +608 831 4116



Fax +608 836 1736

London, UK



Unit 26-28, Victoria Industrial Estate, Victoria Road, London W3 6UU, UK



Tel +44 (0)20 8896 1000



Fax +44 (0)20 8896 2000

Rome, IT



Via Pieve Torina, 48, 00156 Rome, Italy



Tel +39 (06) 32 111 683



Fax +44 (0) 20 8752 8486

Holzkirchen, DE



Ohmstrasse 3, 83607 Holzkirchen, Germany



Tel +49 (80 24) 47 00-0



Fax +49 (80 24) 47 00-3 00

Hong Kong



Rm 1801, 18/F, Tower 1 Phase 1, Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong



Tel +852 2799 1220



Fax +852 2799 9325

Service:

(Americas) [email protected]



(UK) service@etceurope.com



(DE) techserv-hoki@etcconnect.com



(Asia) [email protected]

Web:

www.etcconnect.com



Product information and specifications subject to change.

7460M1300-1.3.0



Rev B



Released 2012-04



ETC intends this document to be provided in its entirety.



US and international patents pending

Overview

For complete information and step-by-step instructions, see Source Four LED Profile v1.3.0 User

Manual.

Accessory

holder

Yoke

Accessory

retainer

Yoke

locking knob

Safety cable

loop

LCD

DMX Thru

DMX In

Keypad

Power In

Power Thru

Status

indicators

Light Bulb

Home

Back

Enter

Down

Power – Indicates AC power is On.

DMX – Indicates control signal is Active.

Error – Indicates data error, high temperature, or other unusual status.

ETC Source Four LED Quick Guide

Install Lens Tube

Source Four LED Profile v1.3.0 Quick Guide Page 2 of 7 Electronic Theatre Controls, Inc.

Install Lens Tube

Step 1: Slide lens tube into shutter barrel.

Step 2: Install the lens zoom knob.

Step 3: Install the Phillips screw in the top of the lens barrel.

Install Fixture

Step 1: Hang or mount the fixture.

Step 2: Attach safety cable.

Step 3: Insert additional accessories such as a top hat, etc.

WARNING:

Use only hardware rated for total weight of fixture and accessories.

A safety cable (or other approved safety device) must be securely attached

to the safety cable loop before loosening the clamp.

Low clearance position

General use position

ETC Source Four LED Quick Guide

Connect

Source Four LED Profile v1.3.0 Quick Guide Page 3 of 7 Electronic Theatre Controls, Inc.

Connect

Step 1: Attach power cable to Power In.

Step 2: Attach 5-pin XLR cable to DMX In (if using external control).

Step 3: Connect power cable to AC power.

Step 4: Plug XLR cable (if using) into data source.

Step 5: Link additional fixtures via Power Thru and DMX Thru connectors.

Focus

Step 1: Supply power and wait for the fixture to boot up.

Step 2: Press [Light Bulb] to open Presets & Sequences.

Step 3: Select Focus and press [Enter] to turn on LED array.

Step 4: Adjust fixture's position.

Step 5: Once focus is set, press [Enter] to turn off LED array and then [Home] to return to home

screen.

WARNING:

No more than nine Source Four LED fixtures per circuit (non-dimming, 100

to 240 VAC, 50/60 Hz)

Up to 32 device loads on the DMX daisy-chain.

Disconnect Power and DMX before all cleaning and maintenance.

Power In

Power Thru

DMX In

DMX Thru

ETC Source Four LED Quick Guide

Soft Focus Diffuser

Source Four LED Profile v1.3.0 Quick Guide Page 4 of 7 Electronic Theatre Controls, Inc.

Soft Focus Diffuser

Step 1: Install the diffuser into an A-Sized Pattern holder.

Step 2: Install a pattern in front of the diffuser, if needed.

Step 3: Insert the pattern holder and diffuser into the Pattern holder slot, making sure the

writing on the diffuser faces the front of the fixture.

Address

Step 1: From the home screen, press [Enter] to open Main Menu.

Step 2: On the Main Menu, scroll to DMX Start Address, press [Enter].

Step 3: Use [Up] or [Down] to scroll to desired address.

Step 4: Press [Enter] to select address number.

Step 5: Press [Home] to return to home screen.

* DMX address is not needed if using standalone or master/slave control.

Features Quick Setup

Step 1: On the Main Menu, scroll to Quick Setups.

Step 2: Press [Enter].

Step 3: Scroll to the desired setup and then press [Enter].

An asterisk (*) indicates which setup is active.

Step 4: Press [Home] to return to the home screen.

The top line of the home screen displays the name of the active setup.

Individual features and settings are adjustable under the Advanced menu. Consult the User Manual for

more information on advanced features of Source Four LED fixtures.

ETC Source Four LED Quick Guide

Quick Setups

Source Four LED Profile v1.3.0 Quick Guide Page 5 of 7 Electronic Theatre Controls, Inc.

Quick Setups

Lustr+

Quick Setup Features Recommended For:

General Smooth dimming, good consistency, direct

color control, simple operation. General lighting, rentals.

Stage

Tungsten-like dimming, HSI color control with

Plus-7 fine tuning, fast color mixing and

consistency, console output snapshot to

record stand alone presets.

Theatrical lighting.

XT Arch Maximum consistency in extreme

applications, reduced brightness.

High-temperature environments, installations

with limited access.

High Impact Maximum brightness, quick response, RGB

color control, reduced consistency. Video-based control, effects lighting, concerts.

Studio

Three-point control—White Point (CCT),

Intensity and Tint, DMX, or standalone

operation.

Video and film lighting, white light-only

applications.

Parameter General Stage XT Arch High Impact Studio

DMX Settings

Profile Direct HSI HSI RGB Studio

Strobe Enabled Enabled Enabled Enabled Enabled

Data Loss

Setting Instant Instant HLL-4ever Instant N/A

Plus Seven N/A Enabled Disabled Disabled Disabled

Fan Control DMX DMX DMX DMX DMX

LED Settings

Output Setting Regulated Regulated Protected Boost Regulated

Dimming

Curve Standard Incandescent Standard Quick Linear

Red Shift N/A Disabled Disabled Disabled N/A

White Point N/A 3200 3200 5600 N/A

Local Settings

Status

Indicators On On On On On

Overtemp Dark Dark Visible Dark Visible

ETC Source Four LED Quick Guide

Quick Setups

Source Four LED Profile v1.3.0 Quick Guide Page 6 of 7 Electronic Theatre Controls, Inc.

Tungsten and Daylight

Quick Setup Features Recommended For:

Studio Linear dimming, simple standalone operation

via the UI.

Video or film lighting, installations without

DMX control.

Stage Tungsten-like dimming, stage-friendly

settings, DMX fan control.

Theatrical lighting, installations mixed with

tungsten.

Single

Channel

Standard dimming, automatic fan, only 1

DMX channel.

Architectural applications with streamlined

control.

Parameter Studio Stage Single Channel

DMX Settings

Profile Intensity Intensity Intensity

Strobe Enabled Enabled Disabled

Data Loss Setting N/A Instant Instant

Fan Control DMX DMX Automatic

LED Settings

Output Setting Regulated Regulated Regulated

Dimming Curve Linear Incandescent Standard

Local Settings

Status Indicators On On On

Overtemp Visible Dark Dark

ETC Source Four LED Quick Guide

DMX Profiles

Source Four LED Profile v1.3.0 Quick Guide Page 7 of 7 Electronic Theatre Controls, Inc.

DMX Profiles

Tungsten and Daylight

Lustr+

* When this feature is enabled.

Typical Power Consumption

Lustr+

Daylight

Tungsten

Channel Control

1Intensity

2Strobe*

3Fan control*

Channel HSI HSIC RGB Studio Direct

1Hue Hue Red Intensity Color 1

2Hue fine Hue fine Green Color temp Color 2

3Saturation Saturation Blue Tint Color 3

4Intensity Intensity N/A N/A Color 4

5Strobe* Strobe* Strobe* Strobe* Color 5

6Fan control*Fan control*Fan control*Fan control*Color 6

7N/A Color temp N/A N/A Color 7

8Plus7 on/off*Plus7 on/off*Plus7 on/off*Plus7 on/off*Intensity

9Plus7 - (1)*Plus7 - (1)*Plus7 - (1)*Plus7 - (1)*Strobe*

10 Plus7 - (2)*Plus7 - (2)*Plus7 - (2)*Plus7 - (2)*Fan control*

11 Plus7 - (3)*Plus7 - (3)*Plus7 - (3)*Plus7 - (3)*N/A

12 Plus7 - (4)*Plus7 - (4)*Plus7 - (4)*Plus7 - (4)*N/A

13 Plus7 - (5)*Plus7 - (5)*Plus7 - (5)*Plus7 - (5)*N/A

14 Plus7 - (6)*Plus7 - (6)*Plus7 - (6)*Plus7 - (6)*N/A

15 Plus7 - (7)*Plus7 - (7)*Plus7 - (7)*Plus7 - (7)*N/A

90V 120V 240V

Idle Power / Current 4.27W / 0.084A 4.38W / 0.079A 4.2W / 0.068A

100% Boost Power / Current 130.8W / 1.48A 129.9W / 1.11A 126.4W / 0.576A

90V 120V 240V

Idle Power / Current 4.3W / 0.083A 4.35W / 0.077A 4.04W / 0.066A

100% Boost Power / Current 165.2W / 1.87A 163.3W / 1.39A 160.3W / 0.718A

100V 120V 240V

Idle Power / Current 4.3W / 0.085A 4.35W / 0.078A 4.0W / 0.065A

100% Boost Power / Current 159.8W / 1.81A 157.4W / 1.35A 154.8W / 0.695A
