Instruction manual

0449 505 101 GB 20230412 Valid for: serial no. 126-xxx-xxxx

LAF 1251 / LAF 1251M

TABLE OF CONTENTS

0449 505 101 © ESAB AB 2023

1SAFETY ....................................................................................................... 4

1.1 Meaning of symbols ............................................................................... 4

1.2 Safety precautions ................................................................................. 4

2INTRODUCTION.......................................................................................... 8

3TECHNICAL DATA ...................................................................................... 9

4INSTALLATION............................................................................................ 10

4.1 Location................................................................................................... 10

4.2 Connections............................................................................................ 11

5OPERATION ................................................................................................ 12

5.1 Controls................................................................................................... 12

6MAINTENANCE........................................................................................... 13

6.1 Cleaning .................................................................................................. 13

6.1.1 Welding power source.......................................................................... 13

6.1.2 Contactor.............................................................................................. 13

7ORDERING SPARE PARTS ........................................................................ 14

DIAGRAM ............................................................................................................ 15

CONNECTION INSTRUCTION............................................................................ 19

ORDERING NUMBERS....................................................................................... 21

Rights reserved to alter specifications without notice.

1 SAFETY

0449 505 101 -4- © ESAB AB 2023

1 SAFETY

1.1 Meaning of symbols

As used throughout this manual: Means Attention! Be Alert!

DANGER!

Means immediate hazards which, if not avoided, will result in immediate,

serious personal injury or loss of life.

WARNING!

Means potential hazards which could result in personal injury or loss of life.

CAUTION!

Means hazards which could result in minor personal injury.

WARNING!

Before use, read and understand the instruction manual

and follow all labels, employer´s safety practices and

Safety Data Sheets (SDSs).

1.2 Safety precautions

Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who

works on or near the equipment observes all the relevant safety precautions. Safety

precautions must meet the requirements that apply to this type of equipment. The following

recommendations should be observed in addition to the standard regulations that apply to

the workplace.

All work must be carried out by trained personnel well-acquainted with the operation of the

equipment. Incorrect operation of the equipment may lead to hazardous situations which can

result in injury to the operator and damage to the equipment.

1. Anyone who uses the equipment must be familiar with:

○ its operation

○ location of emergency stops

○ its function

○ relevant safety precautions

○ welding and cutting or other applicable operation of the equipment

2. The operator must ensure that:

○ no unauthorised person is stationed within the working area of the equipment

when it is started up

○ no-one is unprotected when the arc is struck or work is started with the

equipment

3. The workplace must:

○ be suitable for the purpose

○ be free from drafts

1 SAFETY

0449 505 101 -5- © ESAB AB 2023

4. Personal safety equipment:

○ Always wear recommended personal safety equipment, such as safety glasses,

flame-proof clothing, safety gloves

○ Do not wear loose-fitting items, such as scarves, bracelets, rings, etc., which

could become trapped or cause burns

5. General precautions:

○ Make sure the return cable is connected securely

○ Work on high voltage equipment may only be carried out by a qualified

electrician

○ Appropriate fire extinguishing equipment must be clearly marked and close at

hand

○ Lubrication and maintenance must not be carried out on the equipment during

operation

WARNING!

Arc welding and cutting can be injurious to yourself and others. Take precautions

when welding and cutting.

ELECTRIC SHOCK - Can kill

• Install and ground the unit in accordance with instruction manual.

• Do not touch live electrical parts or electrodes with bare skin, wet gloves or

wet clothing.

• Insulate yourself from work and ground.

• Ensure your working position is safe

ELECTRIC AND MAGNETIC FIELDS - Can be dangerous to health

• Welders having pacemakers should consult their physician before welding.

EMF may interfere with some pacemakers.

• Exposure to EMF may have other health effects which are unknown.

• Welders should use the following procedures to minimize exposure to

EMF:

○ Route the electrode and work cables together on the same side of

your body. Secure them with tape when possible. Do not place your

body between the torch and work cables. Never coil the torch or work

cable around your body. Keep welding power source and cables as

far away from your body as possible.

○ Connect the work cable to the workpiece as close as possible to the

area being welded.

FUMES AND GASES - Can be dangerous to health

• Keep your head out of the fumes.

• Use ventilation, extraction at the arc, or both, to take fumes and gases

away from your breathing zone and the general area.

ARC RAYS - Can injure eyes and burn skin

• Protect your eyes and body. Use the correct welding screen and filter lens

and wear protective clothing.

• Protect bystanders with suitable screens or curtains.

NOISE - Excessive noise can damage hearing

Protect your ears. Use earmuffs or other hearing protection.

1 SAFETY

0449 505 101 -6- © ESAB AB 2023

MOVING PARTS - Can cause injuries

• Keep all doors, panels and covers closed and securely in place. Have only

qualified people remove covers for maintenance and troubleshooting as

necessary. Reinstall panels or covers and close doors when service is

finished and before starting engine.

• Stop engine before installing or connecting unit.

• Keep hands, hair, loose clothing and tools away from moving parts.

FIRE HAZARD

• Sparks (spatter) can cause fire. Make sure that there are no inflammable

materials nearby.

• Do not use on closed containers.

HOT SURFACE - Parts can burn

• Do not touch parts bare handed.

• Allow cooling period before working on equipment.

• To handle hot parts, use proper tools and/or insulated welding gloves to

prevent burns.

MALFUNCTION - Call for expert assistance in the event of malfunction.

PROTECT YOURSELF AND OTHERS!

CAUTION!

This product is solely intended for arc welding.

WARNING!

Do not use the power source for thawing frozen pipes.

CAUTION!

Class A equipment is not intended for use in residential

locations where the electrical power is provided by the

public low-voltage supply system. There may be

potential difficulties in ensuring electromagnetic

compatibility of class A equipment in those locations,

due to conducted as well as radiated disturbances.

1 SAFETY

0449 505 101 -7- © ESAB AB 2023

NOTE!

Dispose of electronic equipment at the recycling

facility!

In observance of European Directive 2012/19/EC on

Waste Electrical and Electronic Equipment and its

implementation in accordance with national law,

electrical and/or electronic equipment that has reached

the end of its life must be disposed of at a recycling

facility.

As the person responsible for the equipment, it is your

responsibility to obtain information on approved

collection stations.

For further information contact the nearest ESAB dealer.

ESAB has an assortment of welding accessories and personal protection equipment

for purchase. For ordering information contact your local ESAB dealer or visit us on

our website.

2 INTRODUCTION

0449 505 101 -8- © ESAB AB 2023

2 INTRODUCTION

LAF 1251 / LAF 1251M are remote-controlled 3-phase welding power sources designed for

high-efficiency mechanical submerged-arc welding (SAW).

The welding power sources are fan-cooled and are monitored by a thermal cutout against

overload. When the thermal cutout is deployed the yellow lamp on the front panel illuminates

automatically. The reset is carried out automatically when the temperature has decreased to

a permitted level.

3 TECHNICAL DATA

0449 505 101 -9- © ESAB AB 2023

3 TECHNICAL DATA

LAF 1251 LAF 1251M

Mains connection 380/400/415/500 V, 3~50 Hz 220/230/400/415/500 V, 3~50 Hz

440/550 V, 3~60 Hz 230/400/440/550 V, 3~60 Hz

Primary current Imax 104 A Imax 171 A

Permissible load at:

100 % duty cycle 1250 A / 44 V 1250 A / 44 V

Setting range 100-1250 A / 24-44 V 100-1250 A / 24-44 V

No-load voltage 53 V 53 V

No-load power 210 W 210 W

Efficiency at max current 89 % 88 %

Power factor at max

current 0.89 0,94

Apparent power at max

current 69 kVA

Active power at max

current 61.7 kW

Operating temperature -10 to +40 °C

Continual sound pressure

at no-load <70 dB(A)

Weight 490 kg 490 kg

Dimensions L × W × H 774 × 598 × 1430 mm 774 × 598 × 1430 mm

Insulation class

(transformer) H H

Enclosure class IP 23 IP 23

Application class

Enclosure class

The IP code indicates the enclosure class, i.e. the degree of protection against penetration

by solid objects or water.

Equipment marked IP23 is intended for indoor and outdoor use.

Application class

The symbol indicates that the power source is designed for use in areas with increased

electrical hazard.

4 INSTALLATION

0449 505 101 - 10 - © ESAB AB 2023

4 INSTALLATION

The installation must be carried out by a professional.

NOTE!

Mains supply requirements

High power equipment may, due to the primary current drawn from the mains

supply, influence the power quality of the grid. Therefore connection restrictions or

requirements regarding the maximum permissible mains impedance or the required

minimum supply capacity at the interface point to the public grid may apply for some

types of equipment (see "TECHNICAL DATA" chapter). In this case it is the

responsibility of the installer or user of the equipment to ensure, by consultation with

the distrubution network operator if necessary, that the equipment may be

connected.

4.1 Location

WARNING!

Secure the equipment - particularly if the ground is uneven or sloping.

• Place the welding power source on a level foundation.

• Make sure there is nothing to prevent the cooling.

Lifting instructions

Otros manuales para LAF 1251

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de soldadura de ESAB

ESAB

ESAB Miggytrac 1001 Manual de usuario

ESAB

ESAB A22 POB Instrucciones de uso

ESAB

ESAB AristoMig 320 Manual de usuario

ESAB

ESAB Migmaster 280 Pro Manual de usuario

ESAB

ESAB Origo M11 Feed 302 Manual de usuario

ESAB

ESAB LHF 405 PIPEWELD Manual de usuario

ESAB

ESAB SCT-1500 SERIES Manual de usuario

ESAB

ESAB Firepower MST-200 Manual de usuario

ESAB

ESAB ST-16 Manual de usuario

ESAB

ESAB m3 Plasma EPP-202 Manual de usuario

ESAB

ESAB A6S Compact 300 Manual de usuario

ESAB

ESAB EMP 205ic AC/DC Actualización de firmware

ESAB

ESAB Origo Arc 650c Manual de usuario

ESAB

ESAB Buddy Arc 200 Manual de usuario

ESAB

ESAB LTR 160 Manual de usuario

ESAB

ESAB TAF 1251 Manual de usuario

ESAB

ESAB Multimaster-260 Manual del propietario

ESAB

ESAB ET 300i Manual de usuario

ESAB

ESAB Retrofit Aristo Mig 4004i WeldCloud Manual de usuario

ESAB

ESAB Caddy Mig C200i Manual de usuario

ESAB

ESAB AristoFeed 30 4 Series Manual de usuario

ESAB

ESAB HandyPlasma 250 Manual de usuario

ESAB

ESAB PowerCut 1600 Manual de usuario

ESAB

ESAB ESABMig 400t Manual de usuario

Manuales populares de Sistema de soldadura de otras marcas

Berner

Berner PLASMACUT 54 Manual de usuario

Pro Spot

Pro Spot PR-155 Manual de usuario

Forney

Forney 210 Manual de usuario

Thermal Arc

Thermal Arc 400S Manual de usuario

Lincoln Electric

Lincoln Electric HANDYMIG 170I Manual de usuario

GYS

GYS PROTIG 201 AC/DC Manual de usuario

TAFA

TAFA 30*8B35 Manual de usuario

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Manual de usuario

CIGWELD

CIGWELD 636804 Guía rápida

Red-D-Arc

Red-D-Arc DC-400 Manual de usuario

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manual de usuario

Elettro

Elettro HI-MIG 3000 SYNERGIC Manual de usuario

WIA

WIA Weldmatic 270 CP132-2 Manual de usuario

Sonics

Sonics H520T Manual de usuario

Miller

Miller Big Blue 400D Manual de usuario

NewArc

NewArc RT2000 Guía de inicio rápido

Hypertherm

Hypertherm powermax1000 Manual de usuario

Lincoln Electric

Lincoln Electric POWER WAVE I400 Manual de usuario
