ERNITEC K111DX Manual de instrucciones
Keyboard X
K111DX
Installation
User
Manual
Version 2.3
2851-00005
SYS EM
U
se
r
Operation
In addition to the normal keys, the Keyboard X also uses so-called 'Soft Keys'. The function of
the 'Soft Keys' depends on what selections the operator has made. The 'Soft Key symbols' in
the keyboard LCD display, changes according to the selections made by the operator.
0001001 0000
--
Soft Keys
Soft Key symbols
Alarm active
Numeric Status
Selected Camera/DVR
Selected Monitor
LonBox in controlSelected Site
The Escape key can be used to step back through the 'Soft Key symbols'.
ESCAPE
When operating a keyboard for the first time, the user will have to log on with User ID and
Password, and then select a monitor and a camera as the first operation.
User Log-on
Enter 'User ID' and 'Password'.
Ö
'Password'
ÖÖ
'User ID'
Ö
Select Monitor
Selects Monitor 3
MONITOR
Ö
3
Select Camera
Selects Camera 1 on the selected monitor
CAMERA
Ö
1
2851-00005 Page 11
SYS EM
Next/Previous Camera
(Disabled if a DVR camera is selected).
Next CameraPrevious Camera
Display Text
Toggles on/off Status Text, Camera Text
and Time/Date, on the selected monitor.
Options:
All text OFF.
Only Camera text ON.
Camera text and Time/Date ON.
All text ON.
TEXT
Select Remote Site (Soft Key)
The first camera on the Remote Site, will be displayed on
the selected monitor.
Selects Remote Site 3
Ö
3
Select Local Site (Soft Key)
The first camera on the Local Site, will
be displayed on the selected monitor.
Selects Local Site
SYS EM
Page 12 2851-00005
PTZ operation
PTZ Control
Using the joystick, or pressing one of the zoom/focus/iris keys,
will also enable PTZ control.
Enables/disables PTZ control for the selected camera
CONTROL
Zoom
WideTele
ÖÖ
ZOOM
Focus
NearFar
ÖÖ
FOCUS
Auto Focus
Enables Auto Focus.
FOCUS
Ö
AUTO
Iris
CloseOpen
ÖÖ
IRIS
Auto Iris
Enables Auto Iris.
IRIS
Ö
AUTO
2851-00005 Page 13
SYS EM
Pan/Tilt
When controlling a variable speed Pan/Tilt,
pushing the joystick towards its extremes will increase speed
Auto panning (Soft Key)
Starts Auto Panning at predefined speed.
Starts Auto Panning at e.g. 25% of maximum Pan Speed.
Actual speed depends on Pan/Tilt used.
Ö
25
Call Preset (Soft Key)
Calls preset 1, on the selected PTZ camera.
Ö
1
Preset Tour
Starts Preset Tour 1, on the selected PTZ camera
TOUR
Ö
1
SYS EM
Page 14 2851-00005
Auxiliary Function (Soft Key)
Activate/Deactivate AUX relay 1, on the selected PTZ camera
Ö
1
Direct Auxiliary Functions (Soft Keys)
Activate/De-activate the AUX relay
Ö
Backlight Compensation (Soft Key)
Toggle BLC on/off, on the selected PTZ camera
Define Preset (Soft Keys)
Defines Preset number 1
Maximum number of Presets depends on the
Telemetry Receiver used
Ö
1
Ö
Set Auto Panning Limits (Soft Keys)
Set ri
g
ht limi
t
Set left limit
ÖÖ
2851-00005 Page 15
SYS EM
Camera Sequence
Start Sequence
Starts Sequence 1 on the selected monitor
SEQUENCE
Ö
1
Hold Sequence
Pauses the sequence on the selected monitor.
Pressing HOLD again, resumes the sequence.
HOLD
Alarm Operation
Clear Alarm
Clears the alarm currently active on the
selected alarm monitor.
ALARM
Step Through Active Alarms
Switches to the selected
alarm.
Steps through the alarm
texts for the active alarms
on the alarm monitor.
ALARM
+
SHIFT
Ö
SYS EM
Page 16 2851-00005
Alarm Enable/Disable
From the keyboard, the operator can enable/disable specific alarm inputs.
The NodeManager software can generate a list, with the required alarm inforation.
Select alarm enable/disable menu.
Ö
Select Site
Select the site number where the alarm is connected.
Ö
1
Select Alarm Type
Select the Alarm Type. 0=Normal alarm, 5=Tamper alarm.
Ö
0
Select Alarm Box Number
Select the Alarm Box number.
Ö
1
Select Alarm Input Pin
Select the Input pin for the selected alarm box.
Ö
3
Enable/disable Alarm
Enable (ON) or Disable (OFF) the selected alarm.
or
Alarm status
Displays status for the selected alarm.
2851-00005 Page 17
SYS EM
Holiday Setup
Up to 30 Holidays can be programmed 1 year ahead.
Alarms activated on a Holiday will be handled according to the Alarm Zone setup in the
NodeManager software.
Select Holiday setup menu.
Ö
Set Holiday
Set June 20, as Holiday.
Ö
2006
Clear Holiday
Clear June 20, as Holiday.
Ö
2006
Holiday Status
Display Holiday status for June.
Ö
6
SYS EM
Page 18 2851-00005
DVR operation
When selecting a camera input, that has a DVR connected, the camera symbol will
automatically change to a DVR control symbol.
Take DVR control
Enables/disables DVR control of the selected DVR.
CONTROL
DVR Monitors (Soft Keys)
Select between DVR monitor outputs.
Spot monitor 2Spot monitor 1Main monitor
Select Camera
Selects Camera 1 on the selected DVR monitor
CAMERA
Ö
1
Digital Zoom
Hold zoom key until function activates.
Use joystick to "pan/tilt" while zoomed in.
WideTele
ÖÖ
ZOOM
Split Screen Modes (Soft Key)
Toggles between split screen modes.
2851-00005 Page 19
SYS EM
