Epson EMP-7500 Manual de usuario

Downloaded from: http://www.usersmanualguide.com/

Important Information About Your

EMP-7500/5500

Please read the following important information about your

EMP-7500/ 5500 projector.

Important Safety Information

Warning:

N ever look into the projector lens when the lamp is

switched on as the bright light can damage your eyes. N ever let

children look into the lens when it is on.

Warning:

N ever open any covers on the projector except the

lamp and filter covers. Dangerous electrical voltages inside

the projector can cause severe injury. Except as specifically

directed in this Owner’s Manual, do not attem pt to service

this product yourself. R efer all servicing to qualified service

personnel.

Warning:

K eep the plastic bags for the projector, accessories

and optional parts out of the reach of children. Children

covering their heads with bags may result in death by

suffocation. Be particularly careful around sm all children.

Caution:

When you replace the lamp, never touch the new

bulb with your bare hands. The invisible residue left by the oil

on your hands may be shorten the bulb life. Use a cloth or

gloves to handle the new bulb.

Downloaded from: http://www.usersmanualguide.com/

Button Function

Power Starts or stops projection.

Source Switches the input source to Computer or

Video.

Menu Displays or hides the menu.

Up, down arrows

(Sync+/Sync-) Synchronizes the computer’s graphic signal.

Use these buttons to adjust an overall image

that is fuzzy or streaked, or to select menu

items during menu operations.

Left, right

arrows(tracking-/

tracking+)

Matches the projector’s internal clock to

various computer graphic signals (tracking

adjustment).

Use these buttons to adjust an image with

vertical fuzzy lines, or to change numeric

settings during menu operations.

Enter key Registers a menu selection.

Resize Switches between Resizing screen and

Window screen (PC input).

AV/Mute Cuts off the screen and sound temporarily.

– Volume + Adjusts the volume.

Help Displays the help menu in various cases may

occur.

operation panel

operation indicator

zoom ring

focus ring

front foot

foot adjuster lever

speaker

remote

control

reciver

speaker

Operation Panel

EMP-7500/5500

U ICK

TART

Downloaded from: http://www.usersmanualguide.com/

Button Function

Menu Displays or hides the menu.

Source Switches the input source to Computer or

Video.

Effects buttons Use to display special effects 1 Pointer, 2

Box, 3 Line, 4 Maker, 5 Clear.

Top multi-purpose

button Acts as a right mouse click, registers a menu

selection, and selects other custom

functions.

Bottom multi-

purpose button Acts as a left mouse click, registers a menu

selection, and selects other custom

functions.

Help Displays the help menu in various cases may

occur.

Resize Switches between Resizing screen and

Window screen (PC input).

Custom Zooms a image by the Mouse Right/Left

buttons.

Freeze Keeps the current computer or video image

on the screen.

AV/Mute Cuts off the screen and sound temporarily.

– Volume + Adjusts the volume.

Power Starts or stops the projector.

Connecting to

a PC laptop computer

Connecting to

a Macintosh PowerBook

- Volume +

Power

Source

Effects

Resize

Help

Custom

Freeze

AV/Mute

Remote control

Computer cable Computer cable

MAC

desktop

adapter

Video

cable

adapter

EMP-7500/5500

U ICK

TART

Downloaded from: http://www.usersmanualguide.com/

DATA/V IDEO PROJ ECTOR

Owner’s Manual

Downloaded from: http://www.usersmanualguide.com/

retrieval system, or transmitted in any form or by any means, electronic,

mechanical, photocopying, recording, or otherwise, without the prior written

permission of SEIKO EPSO N CO RPO RATIO N . N o patent liability is

assumed with respect to the use of the information contained herein. Neither

is any liability assumed for damages resulting from the use of the information

contained herein.

N either SEIKO EPSO N CO RPO RATIO N nor its affiliates shall be liable to

the purchaser of this product or third parties for damages, losses, costs, or

expenses incurred by purchaser or third parties as a result of: accident, misuse,

or abuse of this product or unauthorized modifications, repairs, or alterations

to this product, or (excluding the U .S.) failure to strictly comply with SEIKO

EPSO N CO RPO RATIO N ’s operating and maintenance instructions.

SEIKO EPSO N C O RPO RATIO N shall not be liable against any damages or

problems arising from the use of any options or any consumable products

other than those designated as O riginal EPSO N Products or EPSO N

Approved Products by SEIKO EPSO N C O RPO RATIO N .

EPSO N is a registered trademark and PowerLite is a trademark of SEIKO

EPSO N CO RPO RATIO N .

General N otice:

The following trademarks and registered trademarks are the

property of their respective owners and are used in this publication for

identification purposes only.

• EPSO N/ Seiko Epson Corp.

• Macintosh, Macintosh O S System 7, PowerBook, Q uadra, Centris, Power

Mac/ Apple Computer Corp.

• IBM/ International Business Machines, Inc.

• Windows 3.x, Windows 95/ Microsoft Corp.

• SRS and the SRS symbol are registered trademarks of SRS

Labs, Inc. in the United States and selected foreign countries.

SRS technology is incorporated under license from SRS Labs, Inc. and is

protected under U nited States Patent Nos. 4,748,669 and 4,841, 572

with numerous additional issued and pending foreign patents.

Purchase of this product does not convey the right to sell recordings made

with SRS technology.

• SRS is an abbreviation for SO U ND RETRIEVAL SYSTEM.

O ther product names used herein are also for identification purposes only and

may be trademarks of their respective owners. EPSO N disclaims any and all

rights in those marks.

Downloaded from: http://www.usersmanualguide.com/

■

■ ■ ■ ■ ■

iii

contents

contents iii

Introduction vii

Getting the Most Out of Your Projector ................................ ix

Remote control ..........................................................................ix

Sleep mode.................................................................................ix

Control Panel.............................................................................ix

Optional Accessories....................................................................x

About This Manual................................................................ xi

Safety Instructions ................................................................ xii

Where to Get H elp .............................................................. xiv

World Wide Web site................................................................. xv

Transporting your projecotor ................................................ xv

Installation 1

U npacking the Projector .........................................................2

Additional Items......................................................................... 3

Setting U p the Projector .........................................................4

Connecting to a Computer .....................................................7

Connecting to a PC desktop computer ....................................... 8

Connecting to a PC laptop computer........................................ 10

Connecting to a Macintosh desktop computer .......................... 12

Connecting to a Macintosh PowerBook.................................... 14

Connecting to a Video Source .................................................. 16

Connecting to an External Speaker or PA System ..................18

Downloaded from: http://www.usersmanualguide.com/

contents

■ ■ ■ ■

Using the Projector 21

Turning the Equipment O n and O ff .....................................23

Turning the Projector O n and O ff ............................................ 23

Sleep Mode .............................................................................. 24

Focusing and Positioning the Screen Image ..........................25

Resize Button ........................................................................... 27

Controlling the Projector.......................................................... 28

Using the Remote Control ....................................................... 29

Using the Control Panel........................................................... 31

Projector Status Indicators....................................................33

Operation Indicator.................................................................. 33

Lamp Indicator......................................................................... 34

Temperature Indicator.............................................................. 34

Using the Projector Menus 35

Accessing the Main Menu .....................................................36

Changing a Menu Setting .....................................................36

Menu Options......................................................................39

Video Menu (Image source = Computer) ................................. 39

Video Menu (Image source = Video) ........................................ 42

Audio Menu ............................................................................. 43

Setting Menu ........................................................................... 44

User’s Logo Menu ................................................................... 46

Effect Menu ............................................................................. 48

About Menu............................................................................. 49

RESET ALL Menu................................................................... 49

Maintenance 51

Cleaning the Lens.................................................................52

Cleaning the Projector Case..................................................52

Cleaning the Air Filter ..........................................................53

Replacing the Lamp ..............................................................54

Troubleshooting 57

Problems with the Projector..................................................58

Downloaded from: http://www.usersmanualguide.com/

■ ■ ■ ■ ■

Problems with the Image or Sound .......................................60

Technical Specifications 63

Supported Monitor Displays (EMP-7500) ............................65

Supported Monitor Displays (EMP-5500) ............................66

Monitor and Computer connector pin assignments...............67

Glossary 69

Index 71

Downloaded from: http://www.usersmanualguide.com/

contents

■ ■ ■ ■

Downloaded from: http://www.usersmanualguide.com/

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Proyector de Epson

Epson

Epson EB-585Wi Manual de usuario

Epson

Epson PowerLite EB-L210SF Manual de usuario

Epson

Epson PowerLite 8300i/NL Hoja de especificaciones

Epson

Epson PowerLite 570 Manual de usuario

Epson

Epson EX90 Manual

Epson

Epson PowerLite 1716 Manual de usuario

Epson

Epson EMP-TS10 Manual de usuario

Epson

Epson 935W Instrucciones de instalación

Epson

Epson PowerLite 54c Manual de usuario

Epson

Epson EB-X31 Manual de operación y mantenimiento

Epson

Epson PowerLite Home Cinema 5020UBe Manual de operación y mantenimiento

Epson

Epson Pro Cinema LS12000 Manual de usuario

Epson

Epson V11H257220 - MovieMate 72 LCD Projector Manual de usuario

Epson

Epson 7700p - PowerLite XGA LCD Projector Dimensiones

Epson

Epson EMP-82 Manual de usuario

Epson

Epson PowerLite 85 Guía de referencia

Epson

Epson PowerLite 420 Hoja de especificaciones

Epson

Epson PowerLite home cinema 3010e Manual de usuario

Epson

Epson PowerLite 1835 Guía de referencia

Epson

Epson VS315W Instrucciones de funcionamiento y seguridad

Epson

Epson PowerLite S3 Manual de usuario

Epson

Epson Dreamio EH-DM2 Manual de usuario

Epson

Epson PowerLite 737c Dimensiones

Epson

Epson EH-LS650B Manual de usuario

Manuales populares de Proyector de otras marcas

iEmmet

iEmmet MP-312 Manual de usuario

Sony

Sony VPL-HS10 Marketing Specifications & Features Manual de usuario

Sony

Sony VPL-HW65ES Manual de servicio

Toshiba

Toshiba TLP-791U Manual de usuario

Philips

Philips LC1341 Guía de referencia

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manual de usuario

NEC

NEC NP600S EDU Manual de usuario

BenQ

BenQ SH753P Manual de usuario

Eiki

Eiki EK-623U series Manual de usuario

Christie

Christie LHD700 Manual de usuario

Navitar

Navitar FX Manual de usuario

InFocus

InFocus LitePro 560 Manual de usuario

Sony

Sony SRX-R815P Manual de usuario

Vivitar

Vivitar DP1500 X Manual de usuario

Acer

Acer C20 Series Manual de usuario

Asus

Asus ZenBeam Latte Manual de usuario

BOXLIGHT

BOXLIGHT CP-322i/CP-634i Manual de usuario

JVC

JVC 1108TTH-AO-AO Manual de usuario
