Epson ActionLaser 1600 Manual de usuario

system, or transmitted in any form or by any means, mechanical, photocopying, recording,

or otherwise, without the prior written permission of Seiko Epson Corporation. No patent

liability is assumed with respect to the use of the information contained herein. Neither is

any liability assumed for damages resulting from the use of the information contained

herein.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this

product or third parties for damages, losses, costs, or expenses incurred by purchaser or

third parties as a result of: accident, misuse, or abuse of this product or unauthorized

modifications, repairs, or alterations to this product, or (excluding the US) failure to strictly

comply with Seiko Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation shall not be liable against any damages or problems arising from

the use of any options or any consumable products other than those designated as Original

EPSON Products or EPSON Approved Products by Seiko Epson Corporation.

EpsonScript Level 2 is a customized product based on PhoenixPage Level 2 developed by

Phoenix Technologies Ltd.

EPSON is a registered trademark of Seiko Epson Corporation.

ActionLaser and SelecType are trademarks and EPSON Connection is a service mark of

Epson America, inc.

Adobe and PostScript are registered trademarks of Adobe Systems, Inc.

Apple, Macintosh, LaserWriter, AppleTalk, TrueType, and LocalTalk are registered

trademarks of Apple Computer, Inc.

ITC Avant Garde, ITC Bookman, ITC Zapf Chancery, ITC Zapf Dingbats are registered

trademarks of International Typeface Corporation

Bookman and Century Schoolbook are registered trademarks of Kingsley-ATF Type

Corporation.

Helvetica Narrow and Palatino are registered trademarks of Linotype AG and/or its

related companies.

Swiss and Dutch are registered trademarks of Bitstream Inc.

General notice: Other product names used herein are for identification purposes only and

may be trademarks or registered trademarks of their respective owners. EPSON disclaims

any and all rights in those marks.

Contents

Introduction

About This Manual

.........................

Where to Get Help for U.S. and Canadian Users

........

System and Memory Requirements

................

Chapter 1 Setup

Installing Your Hardware ........................................................... 1-2

Removing the controller board .....................................

1-2

Installing the EpsonScript and LocalTalk boards .......

1-5

Reinserting the controller board .....................................

1-7

Printing a status sheet .......................................................

1-8

Chapter 2

Installing the Drivers and Utilities

Software Installation

........................

2-2

Installing the Macintosh Driver

..................

2-2

Running the EpsonScript Installer program

........

2-2

Selecting the EpsonScript driver

...............

2-5

Installing the Windows Driver

..................

2-6

Selecting a PostScript printer

.................

2-7

Running the EpsonScript Installer

..............

2-7

Selecting the default printer

.................

2-8

Chapter 3

Using EpsonScript in a Macintosh Environment

Changing the Emulation

......................

3-2

Selecting Fonts

............................

3-3

iii

Using the EpsonScript Macintosh Driver

.............

3-4

Saving PostScript-compatible files as binary and ASCII .. 3-5

Using precision bitmaps

....................

3-5

Using the MicroGray feature

.................

3-5

Printing an error sheet

.....................

3-6

Font Management

..........................

3-6

Adding fonts to a PPD file

...................

3-7

Substituting fonts

........................

3-7

Handling TrueType fonts

...................

3-8

Specifying which fonts to download

.............

3-8

Saving PostScript-Compatible Files

................

3-9

Using the EpsonScript Utility

....................

3-10

Managing fonts

.........................

3-12

Getting information about the printer

............

3-15

Sending files formatted for PostScript

............

3-15

Renaming the printer

.....................

3-16

Additional EpsonScript Utility features

...........

3-17

Chapter 4 Using EpsonScript in a windows Environment

Changing the Emulation

.......................

4-2

Selecting Fonts

............................

4-3

Using the EpsonScript Windows Driver

..............

4-4

Accessing EpsonScript driver settings

............

4-4

Advanced EpsonScript Settings

...................

4-6

Handling TrueType fonts

...................

4-6

Specifying memory usage

...................

4-7

Graphics settings

........................

4-7

Creating files that conform to Adobe DSC

..........

4-8

Printing EpsonScript error information

...........

4-9

Appendix A

Index

Introduction

EpsonScript Level 2 for the ActionLaser™ 1600 adds PostScript®

compatibility to your ActionLaser 1400 so you can print files

formatted for PostScript. The printed output is equivalent to

the output of an Apple® LaserWriter® II NTX.

EpsonScript includes a set of 35 PostScript-compatible fonts

that include the following: Fixed Pitch 810 Courier, Dutch® 801

Roman, Swiss® 721, Geometric ITC Avant Garde® Revival 711

ITC Bookman,® Swiss 721 Narrow, Century 702 Century

Schoolbook,® Zapf Calligraphic 801, ITC Zapf Chancery®

Medium Italic, ITC Zapf Dingbats,® and Symbol. Matching

screen fonts are also included to ensure that what you see on

the screen matches the final printed output.

The quality of grayscale images is enhanced when you use the

MicroGray feature, which allows EpsonScript to achieve the

quality of a 1200-dpi typesetter to produce smoother graphic

output than is available with standard PostScript.

The EpsonScript kit consists of an EpsonScript interface board

and two sets of disks, one for the PC and one for the Apple

Macintosh.® Your kit might also include the Local Talk®

interface board, which allows you to connect the printer to

your Macintosh or to an AppleTalk® network.

About This Manual

This manual is intended both for Macintosh and PC users. It is

divided up into the following chapters:

Chapter 1, “Setup,” describes how to install the EpsonScript

and the LocalTalk interface boards. If these boards are already

installed on your printer, skip this chapter. Note that the

LocalTalk board needs to be installed only if you have a

Macintosh.

Introduction 1

Chapter 2, "Installing the Drivers and Utilities,” describes how

to install the EpsonScript software.

Chapter 3, “Using EpsonScript in a Macintosh Environment,”

provides detailed information about using EpsonScript if your

printer is connected to an Apple Macintosh computer.

Chapter 4, “Using EpsonScript in a Windows” Environment,”

provides detailed information about using EpsonScript if you

are running Microsoft® Windows on your PC.

Appendix A, “Changes to SelecType,“’ describes how the

printer’s SelecType menus are expanded to include settings

specific to EpsonScript. Because the default settings are

designed for most computer environments, you should not

normally have to consult this appendix.

Where to Get Help for U.S. and Canadian Users

Epson America provides local customer support and service

through a nationwide network of authorized EPSON dealers

and Service Centers.

EPSON also provides the support services listed below through

EPSON Connections” U.S. users can call (800) 922-8911;

Canadian users can call (800) GO-EPSON.

Assistance in locating your nearest Authorized EPSON

Reseller or Service Center

Technical assistance with the installation, configuration,

and operation of EPSON products

EPSON technical information library fax service

Product literature with technical specifications on EPSON’s

current and new products

Customer Relations.

2 Introduction

You can purchase supplies, parts, documentation, and

accessories by calling EPSON Accessories at (800) 873-7766

(U.S. sales only). In Canada, call (800) GO-EPSON for sales

locations.

When you call for technical assistance, be ready to identify

your system and its configuration, and describe any error

conditions to the support staff.

If you need help with any software program you are using, see

the documentation that came with that program for technical

support information

System and Memory Requirements

To install and use EpsonScript in a Macintosh environment,

your Macintosh must berunning System 7.0 or later and have

at least 2MB of RAM.

Caution:

Installing EpsonScript on a Macintosh that is running System

6.x or earlier can corrupt the system file on your Macintosh.

If you are installing EpsonScript in a Windows environment,

your PC must be

running Windows 3.0 or later.

The 2MB of memory that comes with the printer is sufficient

for using EpsonScript for most print jobs. However, if you

regularly print pages that contain complex layouts or a lot of

large or complicated graphics, you may need to install more

memory on your printer. See your printer manual for more

information.

Note:

LaserTalk™ and SmartArt™ are not compatible with EpsonScript.

Introduction 3

Chapter 1

Setup

Installing Your Hardware

.....................

1-2

Removing the controller board

................

1-2

Installing the EpsonScript and LocalTalk boards

......

1-5

Reinserting the controller board

................

1-7

Printing a status sheet

.....................

1-8

Setup 1-1

Installing Your Hardware

EpsonScript for the ActionLaser 1600 comes with two interface

boards: the EpsonScript board and the LocalTalk interface

board.

In a PC environment, you need to install the EpsonScript board

only. In a Macintosh environment, you need to install both the

EpsonScript and LocalTalk interface boards.

If your ActionLaser 1600 is already equipped with EpsonScript

and LocalTalk (if needed), you can skip this chapter.

Removing the controller board

The EpsonScript and LocalTalk interface boards attach to

connectors on the printer’s controller board. Therefore, you

first need to remove the controller board.

Warning:

High voltages are present inside the printer when the power is

on. Do not attempt to remove the controller board unless the

printer is turned off and the power cord is unplugged. Also, do

not touch the contacts on the board because many of the

components

can

be damaged by static electricity.

Turn off the printer and unplug the power cable from the

electrical outlet.

Remove any optional font cartridges and the lower paper

cassette, if installed.

Disconnect all interface cables from the interface connectors.

Turn the printer so that its left side is facing you.

1-2 Setup

Otros manuales para ActionLaser 1600

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Accesorios de impresora de Epson

Epson

Epson T605B00 Instrucciones de funcionamiento y mantenimiento

Epson

Epson PJMB100 Instrucciones de funcionamiento y seguridad

Epson

Epson R300 - Stylus Photo Color Inkjet Printer Manual de usuario

Epson

Epson Stylus Photo 790 Manual de usuario

Epson

Epson T603100 Instrucciones de funcionamiento y mantenimiento

Epson

Epson T098120 Manual de funcionamiento

Epson

Epson T499201 Instrucciones de funcionamiento y mantenimiento

Epson

Epson T6245 Manual de funcionamiento

Epson

Epson Printer Interface Cartridge Manual de usuario

Epson

Epson T544200 Instrucciones de funcionamiento y mantenimiento

Epson

Epson T606600 Instrucciones de funcionamiento y mantenimiento

Epson

Epson T549500 Instrucciones de funcionamiento y mantenimiento

Epson

Epson T069420 Manual de funcionamiento

Epson

Epson 802.11g Manual de usuario

Epson

Epson Stylus Photo 820 Manual de usuario

Epson

Epson T564300 Instrucciones de funcionamiento y mantenimiento

Epson

Epson Ink Cartridge T048520 for use with Epson Stylus Photo R300, R300N, and... Manual de usuario

Epson

Epson S020193 Manual de funcionamiento

Epson

Epson S050033 Guía

Epson

Epson DP-505 Manual de usuario

Epson

Epson T603400 Instrucciones de funcionamiento y mantenimiento

Epson

Epson EP4749CB Manual de usuario

Epson

Epson T041020 Manual de funcionamiento

Epson

Epson STYLUS Stylus C41 Manual de operación y mantenimiento

Manuales populares de Accesorios de impresora de otras marcas

Star Micronics

Star Micronics TSP800 Series Manual de usuario

REA

REA JET HR pro 2K Manual de usuario

HP Laserjet,Color Laserjet 4si Manual de usuario

oliser

oliser MS 45 Manual de usuario

Roland

Roland DU2-64 Instrucciones y recetas

Xerox

Xerox EFI EXP6000 Manual de usuario

Canon

Canon Finisher-T1 Manual de usuario

Sharp

Sharp FO-1MK Manual de usuario

Labelmate

Labelmate PM-300 Manual de usuario

Canon

Canon TonerRobot EP-27 Manual de usuario

Ricoh

Ricoh LCIT RT5100 Guía de inicio rápido

GBC

GBC 16 Series Manual de usuario

Canon

Canon INNER 2-WAY TRAY-E1 Manual de operación y mantenimiento

Develop

Develop SD-509 Manual de usuario

Kyocera

Kyocera KM-6230 Manual

Triumph Adler

Triumph Adler DF-710 Manual

Citizen

Citizen CBM-202PC Series Manual de usuario

Canon

Canon Color imageCLASS MF8170c Manual de usuario
