Epson S5U13U11 Manual de usuario

SEIKO EPSON CORPORATION Rev. 1.1

S1D13U11 Display Controller

S5U13U11 Evaluation Board

User Manual

NOTICE

No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko

Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any lia-

bility of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or cir-

cuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as,

medical products. Moreover, no license to any intellectual property rights is granted by implication or otherwise, and there is

no representation or warranty that anything made in accordance with this material will be free from any patent or copyright

infringement of a third party. This material or portions thereof may contain technology or the subject relating to strategic

products under the control of the Foreign Exchange and Foreign Trade Law of Japan and may require an export license from

the Ministry of International Trade and Industry or other approval from another government agency.

All brands or product names mentioned herein are trademarks and/or registered trademarks of their respective companies

Evaluation board/kit and Development tool important notice

1. This evaluation board/kit or development tool is designed for use for engineering evaluation, demonstration, or develop-

ment purposes only. Do not use it for other purpose. It is not intended to meet the requirement of design for finished prod-

uct.

2. This evaluation board/kit or development tool is intended for use by an electronics engineer, and it is not the product for

consumer. The user should use this goods properly and safely. Seiko Epson dose not assume any responsibility and liabil-

ity of any kind of damage and/or fire coursed by usage of it. User should cease to use it when any abnormal issue occurs

even during proper and safe use.

3. The part used for this evaluation board/kit or development tool is changed without any notice.

S1D13U11 Display Controller

S5U13U11 Evaluation Board User Manual (Rev. 1.1) EPSON 3

Table of Contents

Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Chapter 2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Chapter 3 Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.1 Configuration Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Chapter 4 Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.1 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.1.1 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.1.2 Voltage Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.1.3 LED Backlight Voltage Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.1.4 LED Backlight Power Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.2 Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.3 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.4 Wake-up Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.5 Buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.6 Touch Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.7 Serial Flash ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.8 Host CPU Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.9 Generic LCD Panel Interface . . . . . . . . . . . . . . . . . . . . . . . . 15

4.10 Ortustech LCD Panel Interface . . . . . . . . . . . . . . . . . . . . . . . . 15

4.11 Peripheral Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Chapter 5 Parts Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Chapter 6 Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Chapter 7 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

7.1 Peripheral Expansion Board . . . . . . . . . . . . . . . . . . . . . . . . . 25

Chapter 8 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

8.1 Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

8.2 Document Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Chapter 9 Change Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

S1D13U11 Display Controller

4 EPSON S5U13U11 Evaluation Board User Manual (Rev. 1.1)

S1D13U11 Display Controller

S5U13U11 Evaluation Board User Manual (Rev. 1.1) EPSON 5

Chapter 1 Introduction

This manual describes the setup and operation of the S5U13U11 Evaluation Board. This evaluation board is

designed as an evaluation platform for the S1D13U11 Display Controller.

The S5U13U11 evaluation board can connect to a variety of embedded CPU boards and a personal computer via

USB 2.0. This evaluation board includes a touch screen controller, serial flash ROM and buzzer. This evaluation

board can connect to external devices such asLCD panel withtouch screen, key matrix circuit, and expansion serial

devices via connector.

This user manual is updated as appropriate. Please check the Epson Research and Development Website at

www.erd.epson.com for the latest revision of this document before beginning any development.

We appreciate your comments on our documentation. Please contact us via email at documentat[email protected]m.

This manual applies to the following evaluation boards.

• S5U13U11P00C100 (no LCD panel)

• S5U13U11P10C100 (with LCD panel)

S1D13U11 Display Controller

6 EPSON S5U13U11 Evaluation Board User Manual (Rev. 1.1)

Chapter 2 Features

The S5U13U11 Evaluation Board includes the following features:

• S1D13U11 Display Controller (144-pin QFP)

• Integrated Silicon Solution, Inc. IS42S16800E-7TLI 128M-bit SDRAM (54-pin TSOP)

• USB mini B connector for S1D13U11 USB2.0 High-speed device port

• Headers for S1D13U11 LCD interface pins

• Built-in Ortustech TFT panel with touch screen (S5U13U11P10C100 only)

• Header for S1D13U11 GPIO, SPI and I2C pins (need to add the connector)

• Resistive type touch screen controller with SPI interface

• 1Mbit serial flash ROM with SPI interface (for configuration data storage)

• Buzzer and Wake-up key

• 24MHz oscillator

• VBUS 5V power input or external DC5V power input can be selected

• Voltage regulator with 1.8V and 3.3V

• Voltage regulator with adjustable 6~24V output, 40mA max., to provide power for LED backlight of LCD

panels.

• LED backlight circuit with PWM control

S1D13U11 Display Controller

S5U13U11 Evaluation Board User Manual (Rev. 1.1) EPSON 7

Chapter 3 Installation and Configuration

The S5U13U11 evaluation board incorporates jumpers and 0 ohm resistors which allow it to be used in a variety of

different configurations.

3.1 Configuration Jumpers

The S5U13U11 has 15 jumpers which configure various board settings. The jumper positions for each function are

shown below. JP5, JP6, JP7, JP8, JP9, JP10, JP11, JP14 and JP15 are solder bridges to reduce power noise. To

change the jumper position remove the solder.

JP1 - Current Measurement of the S5U13U11 Evaluation Board

JP1 can be used to measure the current consumption of the S5U13U11 power supply.

When the jumper is at position 1-2, normal operation is selected.

When no jumper is installed, the current consumption for power supply can be measured by connecting an ammeter

between pins 1 and 2 of the jumper.

Jumper Function Position 1-2 Position 2-3 No Jumper

JP1 Board current measurement Normal —Current measurement

JP2 Board power supply VBUS 5V input External DC5V —

JP3 VBUS input signal VBUS 5V input External DC5V —

JP4 Power-on reset source VBUS 5V input External DC5V —

JP5 COREVDD current measurement Normal —Current measurement

JP6 PLLVDD current measurement Normal —Current measurement

JP7 PIOVDD current measurement Normal —Current measurement

JP8 USBVDD current measurement Normal —Current measurement

JP9 MIOVDD current measurement Normal —Current measurement

JP10 Touch screen power 5V 3.3V (Position 1-3) —

JP11 External 3.3V current measurement Normal —Current measurement

JP12 LED Backlight 12V power control ON —OFF

JP13 Ortustech panel control ON/OFF control Always ON —

JP14 3.3V regulator current measurement Normal —Current measurement

JP15 1.8V regulator current measurement Normal —Current measurement

= Default setting

S1D13U11 Display Controller

8 EPSON S5U13U11 Evaluation Board User Manual (Rev. 1.1)

JP2 - Power Supply Select for the S5U13U11 Evaluation Board

JP2 can be used to select the S5U13U11 power supply.

When the jumper is at position 1-2, VBUS 5V input is selected. The external power supply is not needed.

When the jumper is at position 2-3, external DC5V input is selected. The external power supply is needed.

The supply current of VBUS is specified as a maximum 500mA in the USB specification.

JP3 - VBUS Input Signal Select

JP3 can be used to select the signal of the S1U13U11 VBUS input pin.

When the jumper is at position 1-2, VBUS input is selected.

When the jumper is at position 2-3, external DC5V input is selected.

JP4 - Power-on Reset Source Select

JP4 can be used to select the source of the power-on reset circuit.

When the jumper is at position 1-2, VBUS input is selected.

When the jumper is at position 2-3, external DC5V input is selected.

Figure 3-1: Configuration Jumper Locations (JP1, JP2, JP3, JP4)

S1D13U11 Display Controller

S5U13U11 Evaluation Board User Manual (Rev. 1.1) EPSON 9

JP5, JP6, JP7, JP8, JP9 - Current Measurement of the S1D13U11 Power Supplies

JP5, JP6, JP7, JP8, JP9 can be used to measure the current consumption of the S1D13U11 power supplies.

When the jumper is at position 1-2, normal operation is selected.

When no jumper is installed, the current consumption for each power supplies can be measured by connecting an

ammeter between pins 1 and 2 of the jumper.

The jumper associated with each power supply is as follows:

JP5 for COREVDD

JP6 for PLLVDD

JP7 for PIOVDD

JP8 for USBVDD

JP9 for MIOVDD

Figure 3-2: Configuration Jumper Locations (JP5, JP6, JP7, JP8, JP9)

S1D13U11 Display Controller

10 EPSON S5U13U11 Evaluation Board User Manual (Rev. 1.1)

JP11, JP14, JP15 - Current Measurement of the On-board Power Supplies

JP11, JP14, JP15 can be used to measure the current consumption of on-board power supplies.

When the jumper is at position 1-2, normal operation is selected.

When no jumper is installed, the current consumption for each power supplies can be measured by connecting an

ammeter between pins 1 and 2 of the jumper.

The jumper associated with each power supply is as follows:

JP11 for external 3.3V power

JP14 for 3.3V regulator

JP15 for 1.8V regulator

Figure 3-3: Configuration Jumper Locations (JP11, JP14, JP15)
