EnGenius EOC-2610 Manual de usuario

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 7/23/2008

Long Range Wireless Access Point / Client Bridge EOC-2610

2.4GHz 54Mbps 802.11b/g Multi-Function AP

EOC-2610 is a long range outdoor wireless Access Point and Client

Bridge that operates seamlessly in the 2.4GHz frequency spectrum.

It features high transmitted output power and high receivable

sensitivity along with antenna diversity. High output power and high

sensitivity can extend range and coverage to reduce the roaming

between Access Points to get a more stable wireless connection. It

also reduces the expense of equipment in the same environment.

It supports distance control by 1km to 30km; antenna diversity function

and RSSI indicator which enables the best transmit and receive signals

for traffic communication. This product comes with PoE injector for

building in outdoor environment easily.

To protect your wireless connectivity, it can encrypt all wireless

transmissions through 64/128-bit WEP data encryption and also

supports WPA/WPA2. The MAC address filter lets you select

exactly which stations should have access to your network. In

addition, the User Isolation function can protect the private network

between client users.

The attractive design, high performance, and array of features

make EOC-2610 a suitable wireless solution for your residence or

office.

Package Content

¾1* 802.11b/g Long range AP/CB (EOC-2610)

¾1* PoE injector (EPE-1212)

¾1* Power Adaptor

¾1* CD-ROM with User’s Manual

¾1* QIG

¾1* Metal strap

¾1* Special screw set

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 7/23/2008

Features

Wireless

- 2.4GHz It works in 2.4GHz frequency spectrum

- High output power Transmit output power programmable for different country selections

- High Data Rate High speed physical transmitting rate up to 54Mbps with 11g, support large

payload such as MEPG video streaming

- Multifunction application Access Point/Client Bridge

- Long range transmitting Transmit power control and distance control (ACK timeout)

- Signal Strength LED indicators have the best transmit and receive signal for traffic

communication

- Antenna Diversity Two internal panel antennas and also could switch to external antenna for

applications

Networking

- Public wireless solution An AP interface that is especially useful in public areas such as

hotspots and enterprise

- Signal Strength Display RF signal strength status shown LEDs of 3 colors, making network

build-up easier

- QoS(WMM) Enhance performance and density (Phase 2)

- MSSID

Security

- 802.11i WEP, WPA, WPA2 (Encryption support TKIP/AES)

- 802.1x IEEE 802.1x Supplicant support in CB mode

- MAC address functions MAC address filter (AP mode)

- L2 isolation

- Station isolation

Management

- Firmware Upgrade Upgrading firmware via web browser, setting are reserved after upgrade

- Reset & Backup Reset to factory default. User can export all setting into a file via WEB

- MIB MIB I, MIB II(RFC1213)

- SNMP V1, V2c

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 7/23/2008

Technical Specifications

Hardware Specification

MCU/RF Atheros AR2315 Single chip

Memory 32MB SDRAM

Flash 8MB

Physical Interface One 10/100 Fast Ethernet RJ-45

Reset Button

One SMA Connector

One switch (external and internal antenna switching)

LED indicators Power/ Status

LAN (10/100Mbps)

WLAN (Wireless is up)

3* Link Quality (Client Bridge mode)

¾Green: Good Quality

¾Yellow: Marginally Acceptable Quality

¾Red: Bad Quality

Power Requirements Active Ethernet (Power over Ethernet, IEEE802.3af) 12 V DC/1A

Proprietary PoE design

Regulation Certifications FCC Part 15/UL, ETSI 300/328/CE

RF Specification

Frequency Band 802.11b/g

2.412~2.472GHz

Modulation Technology OFDM = BPSK, QPSK, 16-QAM, 64-QAM

DSSS = DBPSK, DQPSK, CCK

Operating Channels 802.11b/g

11 for North America, 14 for Japan, 13 for Europe

Receive Sensitivity

(Typical)

802.11g

-92 dBm @ 6Mbps,

-74 dBm @ 54Mbp

802.11b

-97 dBm @ 1Mbps

-89 dBm @ 11Mbps

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 7/23/2008

Available transmit power

(Average power)

FCC ETSI

Frequency Power Frequency Power

2.412~2.462

GHz

IEEE802.11g

26dBm@6~24Mbps

25dBm@36Mbps

23dBm@48Mbps

22dBm@54Mbps

2.412~2.472

GHz

IEEE802.11g

26dBm@6~24Mbps

25dBm@36Mbps

23dBm@48Mbps

22dBm@54Mbps

2.412~2.462

GHz

IEEE802.11b 27dBm@1~11Mbps 2.412~2.472

GHz

IEEE802.11b 27dBm@1~11Mbps

Tolerance +/-1 dBm Tolerance +/- 1 dBm

Internal Antenna Embedded 10dBi Panel antenna (Antenna diversity)

External Antenna 1* SMA connector

Software Features

General

Topology Infrastructure

Protocol / Standard IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet)

IEEE 802.11b/g (2.4GHz WLAN)

Operation Mode 802.11 11b/g

Access Point

Client Bridge

LAN DHCP Client

Wireless Channel Selection (Setting varies by countries)

Transmission Rate

11 b/g：54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 in Mbps

Long distance transmission : 1km to 30km

Transmit power table

Signal Strength indication using LEDs

Security WEP Encryption-64/128/152 bit

WPA/WPA2 Personal (WPA-PSK using TKIP or AES)

WPA/WPA2 Enterprise (WPA-EAP using TKIP)

802.1x Authenticator/supplicant

Hide SSID in beacons

802.1Q VLAN

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 7/23/2008

L2 isolation(AP mode)

Wireless STA (Client) connected list

Multiple SSID

QoS WMM (Phase 2)

Management

Configuration Web-based configuration (HTTP)

Firmware Upgrade •Upgrade firmware via web-browser

•Keep latest setting when f/w update

Administrator Setting •Administrator password change

Reset Setting •Reboot (Press 1 second)

•Reset to Factory Default (Press 5 seconds)

System monitoring Status, Event Log

SNMP V1, V2c (Phase 2)

MIB MIB I, MIB II (RFC1213) and Private MIB (Phase 2)

Backup & Restore Settings through Web

Time setting NTP (Auto-setting of time)

Time setting manually

Environment & Mechanical

Temperature Range Operating -20°C~70°C

Storage -30°C to 80°C

Humidity

(non-condensing) 0%～90% typical

Dimensions 260mm (L) x 84mm (W) x 55mm (H)

Weight 300g

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 7/23/2008

Application

Access Point + Client Bridge scenario

Long Range Transmitting

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 7/23/2008

Product ID & Mounting Base

Front Rea

Standard Mounting Kits

Pole mount

Optional mounting kits

Wall

mount

Window

mount
