Brief Operating Instructions
Levelflex FMP56, FMP57
HART
Guided wave radar
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
– Internet: www.endress.com/deviceviewer
– Smart phone/tablet: Endress+Hauser Operations App
KA01061F/00/EN/16.15
71282384
Levelflex FMP56, FMP57 HART
2 Endress+Hauser
TAG No.: XXX000
Ser. No.: X000X000000
Order code 00X00-XXXX0XX0XXX
www.endress.com/deviceviewer Endress+Hauser Operations App
Serial number
A0023555
Levelflex FMP56, FMP57 HART Table of contents
Endress+Hauser 3
Table of contents
1 Important document information ................................................ 4
1.1 Symbols ............................................................................ 4
2 Basic safety instructions ......................................................... 6
2.1 Requirements for the personnel ........................................................... 6
2.2 Designated use ....................................................................... 6
2.3 Workplace safety ...................................................................... 7
2.4 Operational safety ..................................................................... 7
2.5 Product safety ........................................................................ 7
3 Product description .............................................................. 8
3.1 Product design ....................................................................... 8
4 Incoming acceptance and product identification .................................. 9
4.1 Incoming acceptance ................................................................... 9
4.2 Product identification .................................................................. 9
5 Storage, Transport .............................................................. 11
5.1 Storage conditions .................................................................... 11
5.2 Transport product to the measuring point ................................................... 11
6 Mounting ....................................................................... 12
6.1 Mounting requirements ................................................................ 12
6.2 Mounting the device .................................................................. 17
6.3 Post-installation check ................................................................. 25
7 Electrical connection ............................................................ 26
7.1 Connection conditions ................................................................. 26
7.2 Connecting the device ................................................................. 39
7.3 Post-connection check ................................................................. 42
8 Commissioning via wizard ...................................................... 43
9 Commissioning (via operating menu) ........................................... 44
9.1 Display and operating module ........................................................... 44
9.2 Operating menu ..................................................................... 47
9.3 Unlock the device .................................................................... 48
9.4 Setting the operating language .......................................................... 48
9.5 Configuration of a level measurement ..................................................... 49
9.6 User-specific applications ............................................................... 50
Important document information Levelflex FMP56, FMP57 HART
4 Endress+Hauser
1 Important document information
1.1 Symbols
1.1.1 Safety symbols
Symbol Meaning
DANGER
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
WARNING
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
CAUTION
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
NOTICE
NOTE!
This symbol contains information on procedures and other facts which do not result in personal
injury.
1.1.2 Electrical symbols
Symbol Meaning Symbol Meaning
Direct current Alternating current
Direct current and alternating current Ground connection
A grounded terminal which, as far as
the operator is concerned, is grounded
via a grounding system.
Protective ground connection
A terminal which must be connected to
ground prior to establishing any other
connections.
Equipotential connection
A connection that has to be connected
to the plant grounding system: This
may be a potential equalization line or
a star grounding system depending on
national or company codes of practice.
1.1.3 Tool symbols
A0011219 A0011220 A0013442 A0011221 A0011222
Cross-head
screwdriver
Flat blade
screwdriver Torx screwdriver Allen key Hexagon wrench
Levelflex FMP56, FMP57 HART Important document information
Endress+Hauser 5
1.1.4 Symbols for certain types of information
Symbol Meaning Symbol Meaning
Permitted
Procedures, processes or actions that
are permitted.
Preferred
Procedures, processes or actions that
are preferred.
Forbidden
Procedures, processes or actions that
are forbidden.
Tip
Indicates additional information.
Reference to documentation Reference to page
Reference to graphic
,…
,
Series of steps
Result of a sequence of actions Visual inspection
1.1.5 Symbols in graphics
Symbol Meaning
1, 2, 3 ... Item numbers
,…
,
Series of steps
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
-
Hazardous area
Indicates a hazardous area.
.
Safe area (non-hazardous area)
Indicates the non-hazardous area.
1.1.6 Symbols at the device
Symbol Meaning
Safety instructions
Observe the safety instructions contained in the associated Operating Instructions.
Temperature resistance of the connection cables
Specifies the minimum value of the temperature resistance of the connection cables.
Basic safety instructions Levelflex FMP56, FMP57 HART
6 Endress+Hauser
2 Basic safety instructions
2.1 Requirements for the personnel
The personnel must fulfill the following requirements for its tasks:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task
‣Are authorized by the plant owner/operator
‣Are familiar with federal/national regulations
‣Before beginning work, the specialist staff must have read and understood the instructions
in the Operating Instructions and supplementary documentation as well as in the
certificates (depending on the application)
‣Following instructions and basic conditions
2.2 Designated use
Application and measured materials
The measuring device described in these Operating Instructions is intended only for level
measurement of bulk solids. Depending on the version ordered the device can also measure
potentially explosive, flammable, poisonous and oxidizing materials.
Observing the limit values specified in the "Technical data" and listed in the Operating
Instructions and supplementary documentation, the measuring device may be used for the
following measurements only:
‣Measured process variables: level
‣Calculated process variables: Volume or mass in arbitrarily shaped vessels (calculated from
the level by the linearization functionality)
To ensure that the measuring device remains in proper condition for the operation time:
‣Use the measuring device only for measured materials against which the process-wetted
materials are adequately resistant.
‣Observe the limit values in "Technical data".
Incorrect use
The manufacturer is not liable for damage caused by improper or non-designated use.
Verification for borderline cases:
‣For special measured materials and cleaning agents, Endress+Hauser is glad to provide
assistance in verifying the corrosion resistance of wetted materials, but does not accept any
warranty or liability.
Residual risk
The electronics housing and its built-in components such as display module, main electronics
module and I/O electronics module may heat to 80 °C (176 °F) during operation through heat
transfer from the process as well as power dissipation within the electronics. During operation
the sensor may assume a temperature near the temperature of the measured material.
Danger of burns due to heated surfaces!
‣For high process temperatures: Install protection against contact in order to prevent burns.
Levelflex FMP56, FMP57 HART Basic safety instructions
Endress+Hauser 7
2.3 Workplace safety
For work on and with the device:
‣Wear the required personal protective equipment according to federal/national
regulations.
2.4 Operational safety
Risk of injury.
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
Conversions to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers.
‣If, despite this, modifications are required, consult with the manufacturer.
Repair
To ensure continued operational safety and reliability,
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to repair of an electrical device.
‣Use original spare parts and accessories from the manufacturer only.
Hazardous area
To eliminate a danger for persons or for the facility when the device is used in the hazardous
area (e.g. explosion protection, pressure vessel safety):
‣Based on the nameplate, check whether the ordered device is permitted for the intended
use in the hazardous area.
‣Observe the specifications in the separate supplementary documentation that is an integral
part of these Instructions.
2.5 Product safety
This measuring device is designed in accordance with good engineering practice to meet state-
of-the-art safety requirements, has been tested, and left the factory in a condition in which
they are safe to operate.
It meets general safety standards and legal requirements. It also complies with the EC
directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms
this by affixing the CE mark to the device.
Product description Levelflex FMP56, FMP57 HART
8 Endress+Hauser
3 Product description
3.1 Product design
3.1.1 Levelflex FMP56/FMP57
1
2
5
3
4
A0012470
1 Design of the Levelflex
1 Electronics housing
2 Process connection (here as an example: flange)
3 Rope probe
4 End-of-probe weight
5 Rod probe
Levelflex FMP56, FMP57 HART Incoming acceptance and product identification
Endress+Hauser 9
4 Incoming acceptance and product identification
4.1 Incoming acceptance
Upon receipt of the goods check the following:
• Are the order codes on the delivery note and the product sticker identical?
• Are the goods undamaged?
• Do the nameplate data match the ordering information on the delivery note?
• Is the DVD with the operating tool present?
If required (see nameplate): Are the Safety Instructions (XA) present?
If one of these conditions is not satisfied, contact your Endress+Hauser Sales Center.
4.2 Product identification
The following options are available for identification of the measuring device:
• Nameplate specifications
• Order code with breakdown of the device features on the delivery note
• Enter serial numbers from nameplates in W@M Device Viewer
( www.endress.com/deviceviewer ): All information about the measuring device is
displayed.
• Enter the serial number from the nameplates into the Endress+Hauser Operations App or
scan the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser Operations
App: all the information for the measuring device is displayed.
Incoming acceptance and product identification Levelflex FMP56, FMP57 HART
10 Endress+Hauser
4.2.1 Nameplate
Order code:
Ext. ord. cd.:
Ser. no.:
Order code:
Ext. ord. cd.:
Ser. no.:
1
2
3
4
A0021952
2 Example of a nameplate
1 Order code
2 Serial number (Ser. no.)
3 Extended order code (Ext. ord. cd.)
4 2-D matrix code (QR code)
For detailed information about interpreting the nameplate specifications, refer to the
Operating Instructions for the device.
Only 33 digits of the extended order code can be indicated on the nameplate. If the
extended order code exceeds 33 digits, the rest will not be shown. However, the complete
extended order code can be viewed in the operating menu of the device in the Extended
order code 1 to 3 parameter.
Otros manuales para Levelflex FMP56
12
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Radar de Endress+Hauser
Endress+Hauser
Endress+Hauser Levelflex FMP56 Especificaciones técnicas
Endress+Hauser
Endress+Hauser Micropilot FMR50 Especificaciones técnicas
Endress+Hauser
Endress+Hauser FOUNDATION Fieldbus Micropilot FMR50 Especificaciones técnicas
Endress+Hauser
Endress+Hauser FOUNDATION Fieldbus Micropilot FMR56 Especificaciones técnicas
Endress+Hauser
Endress+Hauser Levelflex FMP55 Manual de usuario
Endress+Hauser
Endress+Hauser Micropilot FMR67B Manual de usuario
Endress+Hauser
Endress+Hauser micropilot M FMR 231 Manual de usuario
Endress+Hauser
Endress+Hauser FOUNDATION Fieldbus Levelflex FMP51 Especificaciones técnicas
Endress+Hauser
Endress+Hauser FOUNDATION Fieldbus Micropilot FMR51 Especificaciones técnicas
Endress+Hauser
Endress+Hauser Micropilot FMR56 Especificaciones técnicas
Endress+Hauser
Endress+Hauser Micropilot S FMR540 Manual de usuario
Endress+Hauser
Endress+Hauser Micropilot FWR30 Manual de usuario
Endress+Hauser
Endress+Hauser Micropilot M FMR250 Especificaciones técnicas
Endress+Hauser
Endress+Hauser Micropilot FMR20 Especificaciones técnicas
Endress+Hauser
Endress+Hauser Micropilot FMR63B PROFIBUS PA Manual de usuario
Endress+Hauser
Endress+Hauser micropilot M FMR 230 Manual de usuario
Endress+Hauser
Endress+Hauser Levelflex FMP53 FOUNDATION Fieldbus Especificaciones técnicas
Endress+Hauser
Endress+Hauser Micropilot FMR66B PROFINET with Ethernet-APL Especificaciones técnicas
Endress+Hauser
Endress+Hauser Micropilot M FMR245 Manual de usuario
Endress+Hauser
Endress+Hauser Micropilot FMR62B Especificaciones técnicas
