Brief Operating Instructions

Liquiline System CA80TN

Colorimetric analyzer for total nitrogen

These instructions are Brief Operating Instructions; they are

not a substitute for the Operating Instructions pertaining to

the device.

Detailed information on the device can be found in the

Operating Instructions and in the other documentation

available at:

• www.endress.com/device-viewer

• Smart phone/tablet: Endress+Hauser Operations App

KA01440C/07/EN/01.21

71519646

2021-01-31

Liquiline System CA80TN

2 Endress+Hauser

Order code:

Ext. ord. cd.:

Ser. no.:

www.endress.com/deviceviewer Endress+Hauser

Operations App

XXXXXXXXXXXX

XXXXX-XXXXXX

XXX.XXXX.XX

Serial number

A0023555

Liquiline System CA80TN Table of contents

Endress+Hauser 3

Table of contents

1 About this document .............................................................. 4

1.1 Warnings ............................................................................ 4

1.2 Symbols ............................................................................. 4

1.3 Symbols on the device ................................................................... 4

1.4 Documentation ........................................................................ 5

2 Basic safety instructions .......................................................... 6

2.1 Requirements for personnel .............................................................. 6

2.2 Designated use ........................................................................ 6

2.3 Workplace safety ...................................................................... 6

2.4 Operational safety ......................................................................6

2.5 Product safety ......................................................................... 7

3 Incoming acceptance and product identification ................................... 8

3.1 Incoming acceptance .................................................................... 8

3.2 Product identification ................................................................... 8

3.3 Scope of delivery ....................................................................... 9

3.4 Certificates and approvals ................................................................ 9

4 Installation ...................................................................... 10

4.1 Installation conditions .................................................................. 10

4.2 Mounting the analyzer ................................................................. 15

4.3 Post-installation check ................................................................. 19

5 Electrical connection ............................................................ 19

5.1 Connection conditions .................................................................. 19

5.2 Connecting the analyzer ................................................................ 19

5.3 Ensuring the degree of protection ......................................................... 22

5.4 Post-connection check ..................................................................22

6 Operation options ............................................................... 23

6.1 Structure and function of the operating menu ................................................ 23

7 Commissioning .................................................................. 23

7.1 Preparatory steps ..................................................................... 23

7.2 Function check ....................................................................... 26

7.3 Switching on the measuring device ........................................................ 27

7.4 Access to the configuration (only versions CA80TN-HR) ......................................... 27

7.5 Setting the operating language ........................................................... 27

7.6 Configuring the measuring device ......................................................... 28

About this document Liquiline System CA80TN

4 Endress+Hauser

1 About this document

1.1 Warnings

Structure of information Meaning

LDANGER

Causes (/consequences)

If necessary, Consequences of non-

compliance (if applicable)

‣Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid the dangerous situation will result in a fatal or serious injury.

LWARNING

Causes (/consequences)

If necessary, Consequences of non-

compliance (if applicable)

‣Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid the dangerous situation can result in a fatal or serious injury.

LCAUTION

Causes (/consequences)

If necessary, Consequences of non-

compliance (if applicable)

‣Corrective action

This symbol alerts you to a dangerous situation.

Failure to avoid this situation can result in minor or more serious injuries.

NOTICE

Cause/situation

If necessary, Consequences of non-

compliance (if applicable)

‣Action/note

This symbol alerts you to situations which may result in damage to property.

1.2 Symbols

Additional information, tips

Permitted or recommended

Not permitted or not recommended

Reference to device documentation

Reference to page

Reference to graphic

 Result of a step

1.3 Symbols on the device

Reference to device documentation

Caution: Hazardous voltage

Warning: Health hazard

Warning: Oxidizing

Liquiline System CA80TN About this document

Endress+Hauser 5

Warning: Corrosive

Warning: Hazardous to the aquatic environment

Do not dispose of products bearing this marking as unsorted municipal waste. Instead, return them to the

manufacturer for disposal under the applicable conditions.

1.4 Documentation

The following instructions complement these Brief Operating Instructions and are available on

the product pages on the Internet:

• Operating Instructions Liquiline System CA80TN

• Device description

• Commissioning

• Operation

• Software description (excluding sensor menus; these are described in a separate manual -

see below)

• Device-specific diagnostics and troubleshooting

• Maintenance

• Repair and spare parts

• Accessories

• Technical data

• Operating Instructions Memosens, BA01245C

• Software description for Memosens inputs

• Calibration of Memosens sensors

• Sensor-specific diagnostics and troubleshooting

• Guidelines for communication via fieldbus and web server

• PROFIBUS, SD01188C

• Modbus, SD01189C

• Web server, SD01190C

• EtherNet/IP, SD01293C

• Special documentation on reagents:

CY80TN, SD02686C

Basic safety instructions Liquiline System CA80TN

6 Endress+Hauser

2 Basic safety instructions

2.1 Requirements for personnel

• Installation, commissioning, operation and maintenance of the measuring system may be

carried out only by specially trained technical personnel.

• The technical personnel must be authorized by the plant operator to carry out the specified

activities.

• The electrical connection may be performed only by an electrical technician.

• The technical personnel must have read and understood these Operating Instructions and

must follow the instructions contained therein.

• Faults at the measuring point may only be rectified by authorized and specially trained

personnel.

Repairs not described in the Operating Instructions provided must be carried out only

directly at the manufacturer's site or by the service organization.

2.2 Designated use

The Liquiline System CA80TN is a wet-chemical analyzer for the almost continuous

determination of the concentration of total nitrogen in liquid media.

The analyzer is designed for use in the following applications:

• Monitoring of the wastewater treatment plant outlet

• Control of the water quality of surface waters

• Monitoring of industrial wastewater

• Control of industrial wastewater treatment

Use of the device for any purpose other than that described poses a threat to the safety of

people and of the entire measuring system, and is therefore not permitted. The manufacturer

is not liable for damage caused by improper or non-designated use.

2.3 Workplace safety

As the user, you are responsible for complying with the following safety conditions:

• Installation guidelines

• Local standards and regulations

• Regulations for explosion protection

Electromagnetic compatibility

• The product has been tested for electromagnetic compatibility in accordance with the

applicable international standards for industrial applications.

• The electromagnetic compatibility indicated applies only to a product that has been

connected in accordance with these Operating Instructions.

2.4 Operational safety

Before commissioning the entire measuring point:

1. Verify that all connections are correct.

2. Ensure that electrical cables and hose connections are undamaged.

Liquiline System CA80TN Basic safety instructions

Endress+Hauser 7

3. Do not operate damaged products, and protect them against unintentional operation.

4. Label damaged products as defective.

During operation:

‣If faults cannot be rectified:

products must be taken out of service and protected against unintentional operation.

LCAUTION

Activities while the analyzer is in operation

Risk of injury and infection from medium!

‣Before you release any hoses, make sure that no actions, such as the pumping of sample,

are currently running or are due to start shortly.

‣Wear protective clothing, goggles and gloves or take other suitable measures to protect

yourself.

‣Wipe up any spilt reagent with a disposable tissue and rinse with clear water. Then dry the

cleaned areas with a cloth.

LCAUTION

Risk of injury from door stop mechanism

‣Always open the door fully to ensure the door stop engages properly.

2.5 Product safety

2.5.1 State-of-the-art technology

The product is designed to meet state-of-the-art safety requirements, has been tested, and

left the factory in a condition in which it is safe to operate. The relevant regulations and

international standards have been observed.

Devices connected to the analyzer must comply with the applicable safety standards.

2.5.2 IT security

We only provide a warranty if the device is installed and used as described in the Operating

Instructions. The device is equipped with security mechanisms to protect it against any

inadvertent changes to the device settings.

IT security measures in line with operators' security standards and designed to provide

additional protection for the device and device data transfer must be implemented by the

operators themselves.

Incoming acceptance and product identification Liquiline System CA80TN

8 Endress+Hauser

3 Incoming acceptance and product identification

3.1 Incoming acceptance

1. Verify that the packaging is undamaged.

 Notify the supplier of any damage to the packaging.

Keep the damaged packaging until the issue has been resolved.

2. Verify that the contents are undamaged.

 Notify the supplier of any damage to the delivery contents.

Keep the damaged goods until the issue has been resolved.

3. Check that the delivery is complete and nothing is missing.

 Compare the shipping documents with your order.

4. Pack the product for storage and transportation in such a way that it is protected

against impact and moisture.

 The original packaging offers the best protection.

Make sure to comply with the permitted ambient conditions.

If you have any questions, please contact your supplier or your local Sales Center.

NOTICE

Incorrect transportation can damage the analyzer

‣Always use a lifting truck or a fork-lift to transport the analyzer.

3.2 Product identification

3.2.1 Nameplate

Nameplates can be found:

• On the inside of the door on the bottom right, or on the front in the bottom right-hand

corner

• On the packaging (adhesive label, portrait format)

The nameplate provides you with the following information on your device:

• Manufacturer identification

• Order code

• Extended order code

• Serial number

• Firmware version

• Ambient and process conditions

• Input and output values

• Measuring range

• Activation codes

• Safety information and warnings

• Certificate information

• Approvals as per order version

‣Compare the information on the nameplate with the order.

Liquiline System CA80TN Incoming acceptance and product identification

Endress+Hauser 9

3.2.2 Product identification

Interpreting the order code

The order code and serial number of your product can be found in the following locations:

• On the nameplate

• In the delivery papers

Obtaining information on the product

1. Go to www.endress.com.

2. Call up the site search (magnifying glass).

3. Enter a valid serial number.

4. Search.

 The product structure is displayed in a popup window.

5. Click on the product image in the popup window.

 A new window (Device Viewer) opens. All of the information relating to your

device is displayed in this window as well as the product documentation.

3.2.3 Manufacturer address

Endress+Hauser Conducta GmbH+Co. KG

Dieselstraße 24

D-70839 Gerlingen

3.3 Scope of delivery

The scope of delivery comprises:

• 1 analyzer in the version ordered with optional hardware

• 1 x Brief Operating Instructions (hard copy)

• 1 x Maintenance Manual

• Optional accessories

‣If you have any queries:

Please contact your supplier or local sales center.

3.4 Certificates and approvals

The product meets the requirements of the harmonized European standards. As such, it

complies with the legal specifications of the EU directives. The manufacturer confirms

successful testing of the product by affixing to it the  mark.

Installation Liquiline System CA80TN

10 Endress+Hauser

4 Installation

LCAUTION

Incorrect transportation can cause injury and damage the device

‣Always use a lifting truck or a fork-lift to transport the analyzer. Two people are needed for

the installation.

‣Lift the device by the recessed grips.

4.1 Installation conditions

The device can be installed in the following ways:

• Mounted on a wall

• Mounted on a base

4.1.1 Dimensions

530 (20.87)463 (18.23)

793 (31.22)

A0028820

 1 Liquiline System CA80 closed version, dimensions in mm (in)

Otros manuales para Liquiline System CA80TN

Tabla de contenidos

Otros manuales de Instrumento de medición de Endress+Hauser

Endress+Hauser

Endress+Hauser IO-Link Liquipoint FTW23 Manual de usuario

Endress+Hauser

Endress+Hauser Hart Proline Promag P 500 Manual de usuario

Endress+Hauser

Endress+Hauser Hart Micropilot FMR60B Manual de usuario

Endress+Hauser

Endress+Hauser StamoLys CA 71 CU Manual de usuario

Endress+Hauser

Endress+Hauser 2-Pack TDLAS Actualización de firmware

Endress+Hauser

Endress+Hauser Liquiline System CA80AL Especificaciones técnicas

Endress+Hauser

Endress+Hauser Proline Promass E TB2 HART Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar S FMD77 Manual de usuario

Endress+Hauser

Endress+Hauser Liquiphant M FTL51C Manual

Endress+Hauser

Endress+Hauser Levelflex M FMP45 Manual de usuario

Endress+Hauser

Endress+Hauser Teqwave H Manual de usuario

Endress+Hauser

Endress+Hauser Solimotion FTR20 Manual de usuario

Endress+Hauser

Endress+Hauser Levelflex FMP53 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 55 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag W 800 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Levelflex FMP50 Manual

Endress+Hauser

Endress+Hauser Proline t-mass B 150 HART Manual de usuario

Endress+Hauser

Endress+Hauser airtrol CPC 200 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 10D Manual

Endress+Hauser

Endress+Hauser Proline Promass S 300 Manual de usuario

Endress+Hauser

Endress+Hauser EngyCal RH33 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Liquiphant M/S with electronic Insert FEL56 Manual del operador

Endress+Hauser

Endress+Hauser Liquiphant S FTL70-**********L Series Manual

Endress+Hauser

Endress+Hauser Proline Promass 84 MODBUS RS485 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario

Acterna

Acterna MS1400 Manual de usuario

R&S

R&S ZPH Manual de usuario
