Brief Operating Instructions

Levelflex FMP56, FMP57

HART

Guided wave radar

These Instructions are Brief Operating Instructions; they are

not a substitute for the Operating Instructions pertaining to

the device.

Detailed information about the device can be found in the

Operating Instructions and the other documentation:

Available for all device versions via:

• Internet: www.endress.com/deviceviewer

• Smart phone/tablet: Endress+Hauser Operations App

KA01061F/00/EN/19.22-00

71565966

2022-04-05

About this document Levelflex FMP56, FMP57 HART

2 Endress+Hauser

1 About this document

1.1 Symbols

1.1.1 Safety symbols

DANGER

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

WARNING

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

This symbol contains information on procedures and other facts which do not result in

personal injury.

1.1.2 Electrical symbols

Protective earth (PE)

Ground terminals that must be connected to ground prior to establishing any other

connections.

The ground terminals are located on the inside and outside of the device.

• Inner ground terminal; protective earth is connected to the mains supply.

• Outer ground terminal; device is connected to the plant grounding system.

1.1.3 Tool symbols

Flat-blade screwdriver

Allen key

Torx screwdriver

Open-ended wrench

1.1.4 Symbols for certain types of information and graphics

Permitted

Procedures, processes or actions that are permitted

Forbidden

Procedures, processes or actions that are forbidden

Levelflex FMP56, FMP57 HART Basic safety instructions

Endress+Hauser 3

Tip

Indicates additional information

Reference to documentation

Reference to graphic

Notice or individual step to be observed

Series of steps

Result of a step

Visual inspection

1, 2, 3, ...

Item numbers

A, B, C, ...

Views

1.1.5 Symbols on the device

Safety instructions

Observe the safety instructions contained in the associated Operating Instructions

Temperature resistance of the connection cables

Specifies the minimum value of the temperature resistance of the connection cables

2 Basic safety instructions

2.1 Requirements for personnel

The personnel must fulfill the following requirements for its tasks:

‣Trained, qualified specialists must have a relevant qualification for the specific function

and task

‣Are authorized by the plant owner/operator

‣Are familiar with federal/national regulations

‣Must have read and understood the instructions in the manual and supplementary

documentation

‣Follow instructions and comply with conditions

Basic safety instructions Levelflex FMP56, FMP57 HART

4 Endress+Hauser

2.2 Intended use

Application and media

The measuring device described in this manual is intended only for the level measurement of

bulk solids. Depending on the version ordered, the measuring device can also measure

potentially explosive, flammable, poisonous and oxidizing media.

If the limit values specified in the "Technical data" and the conditions listed in the manual and

additional documentation are observed, the measuring device may be used for the following

measurements only:

‣Measured process variables: level

‣Calculable process variables: volume or mass in any shape of vessel (calculated from the

level by the linearization functionality)

To ensure that the measuring device remains in proper condition for the operation time:

‣Use the measuring device only for media to which the process-wetted materials have an

adequate level of resistance.

‣Observe the limit values in the "Technical data".

Incorrect use

The manufacturer is not liable for damage caused by improper or non-intended use.

Verification for borderline cases:

‣For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in

verifying the corrosion resistance of fluid-wetted materials, but does not accept any

warranty or liability.

Residual risks

Due to heat transfer from the process as well as power loss in the electronics, the temperature

of the electronics housing and the assemblies contained therein (e.g. display module, main

electronics module and I/O electronics module) may rise up to 80 °C (176 °F). When in

operation, the sensor may reach a temperature close to the medium temperature.

Danger of burns from contact with surfaces!

‣In the event of high medium temperatures, ensure protection against contact to prevent

burns.

2.3 Workplace safety

When working on and with the device:

‣Wear the required personal protective equipment according to federal/national

regulations.

2.4 Operational safety

Risk of injury!

‣Operate the device only if it is in proper technical condition, free from errors and faults.

‣The operator is responsible for the interference-free operation of the device.

Levelflex FMP56, FMP57 HART Basic safety instructions

Endress+Hauser 5

Modifications to the device

Unauthorized modifications to the device are not permitted and can lead to unforeseeable

dangers:

‣If modifications are nevertheless required, consult with the manufacturer.

Repair

To ensure continued operational safety and reliability:

‣Carry out repairs on the device only if they are expressly permitted.

‣Observe federal/national regulations pertaining to the repair of an electrical device.

‣Use only original spare parts and accessories from the manufacturer.

Hazardous area

To eliminate danger to persons or the installation when the device is used in the hazardous

area (e.g. explosion protection, pressure vessel safety):

‣Check the nameplate to verify whether the ordered device can be put to its intended use in

the hazardous area.

‣Observe the specifications in the separate supplementary documentation, which is an

integral part of this manual.

2.5 Product safety

This measuring device is designed in accordance with good engineering practice to meet state-

of-the-art safety requirements, has been tested, and left the factory in a condition in which it

is safe to operate. It meets the general safety standards and legal requirements.

NOTICE

Loss of degree of protection by opening of the device in humid environments

‣If the device is opened in a humid environment, the degree of protection indicated on the

nameplate is no longer valid. This may also impair the safe operation of the device.

2.5.1 CE mark

The measuring system meets the legal requirements of the applicable EU directives. These are

listed in the corresponding EU Declaration of Conformity together with the standards applied.

The manufacturer confirms successful testing of the device by affixing to it the CE mark.

2.5.2 EAC conformity

The measuring system meets the legal requirements of the applicable EAC guidelines. These

are listed in the corresponding EAC Declaration of Conformity along with the standards

applied.

The manufacturer confirms successful testing of the device by affixing to it the EAC mark.

Incoming acceptance and product identification Levelflex FMP56, FMP57 HART

6 Endress+Hauser

3 Incoming acceptance and product identification

3.1 Incoming acceptance

Check the following during incoming acceptance:

• Are the order codes on the delivery note and the product sticker identical?

• Are the goods undamaged?

• Do the nameplate data match the ordering information on the delivery note?

• If required (see nameplate): are the Safety Instructions (XA) provided?

If one of these conditions is not met, please contact your Endress+Hauser sales office.

3.2 Product identification

The device can be identified in the following ways:

• Nameplate specifications

• Extended order code with breakdown of the device features on the delivery note

‣Enter serial number from nameplates in W@M Device Viewer

(www.endress.com/deviceviewer)

 All of the information on the measuring device and on the scope of the technical

documentation pertaining to the device is displayed.

‣Enter the serial number from the nameplate in the Endress+Hauser Operations app or scan

the 2-D matrix code on the nameplate with the camera

 All of the information on the measuring device and on the scope of the technical

documentation pertaining to the device is displayed.

3.3 Storage and transport

3.3.1 Storage temperature

• Permitted storage temperature: –40 to +80 °C (–40 to +176 °F)

• Use original packaging.

3.3.2 Transporting the product to the measuring point

LWARNING

Housing or rod may become damaged or pull off.

Risk of injury!

‣Transport the measuring device to the measuring point in its original packaging or by the

process connection.

‣Always secure lifting equipment (slings, eyes, etc.) at the process connection and never lift

the device by the electronic housing or probe. Pay attention to the center of gravity of the

device so that it does not tilt or slip unintentionally.

‣Follow the safety instructions and transport conditions for devices weighing more than 18

kg (39.6 lbs) (IEC 61010).

Levelflex FMP56, FMP57 HART Incoming acceptance and product identification

Endress+Hauser 7

A0043233

Mounting Levelflex FMP56, FMP57 HART

8 Endress+Hauser

4 Mounting

4.1 Mounting requirements

4.1.1 Suitable mounting position

1 32

A0021468

 1 Installation conditions for Levelflex

Levelflex FMP56, FMP57 HART Mounting

Endress+Hauser 9

Spacing requirements when mounting

• Distance (A) between the vessel wall and rod and rope probes:

• For smooth metallic walls: > 50 mm (2 in)

• For plastic walls: > 300 mm (12 in) to metallic parts outside the vessel

• For concrete walls: > 500 mm (20 in), otherwise the permitted measuring range may be

reduced.

• Distance (B) between rod probes and internal fittings (3): > 300 mm (12 in)

• When using more than one Levelflex:

Minimum distance between the sensor axes: 100 mm (3.94 in)

• Distance (C) from the end of the probe to the bottom of the vessel:

• Rope probe: > 150 mm (6 in)

• Rod probe: > 10 mm (0.4 in)

4.1.2 Securing the probe

Securing rope probes

A0012609

A Rope sag: ≥ 10 mm/(1 m probe length) [0.12 in/(1 ft probe length)]

B Reliably grounded end of probe

C Reliably insulated end of probe

1 Fastener in female thread of probe end weight

2 Insulated fastening kit

Mounting Levelflex FMP56, FMP57 HART

10 Endress+Hauser

• The end of the rope probe must be secured (fixed down) under the following conditions:

• If the probe would otherwise temporarily come into contact with the vessel wall, the cone,

internal fittings/beams or another part of the installation

• If the probe comes closer than 0.5 m (1.6 ft) to a concrete wall.

• A female thread is provided in the probe weight to secure the end of the probe:

• Rope 4 mm (1/6"), 316: M 14

• Rope 6 mm (1/4"), 316: M 20

• Rope 6 mm (1/4"), PA>steel: M14

• Rope 8mm (1/3"), PA>steel: M20

• Far higher tensile loads occur on the probe when it is secured (fixed down). Therefore,

preferably use the 6 mm (1/4") rope probe.

• When fixed down, the end of the probe must be either reliably grounded or reliably

insulated. Use an insulated fastening kit if it is not otherwise possible to secure the probe

with a reliably insulated connection.

• To prevent an extremely high tensile load (e.g. due to thermal expansion) and the risk of

the rope breaking, the rope must be slack. Required sag: ≥ 10 mm/(1 m rope length) [ 0.12

in/(1 ft rope length)].

Pay attention to the tensile loading capacity of rope probes.

Securing rod probes

• In the case of WHG approval: a support is required for probe lengths ≥ 3 m (10 ft).

• In general, rod probes must be secured in the event of horizontal flow (e.g. from an

agitator) or strong vibrations.

• Only secure rod probes directly at the end of the probe.

Otros manuales para Levelflex FMP56

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de Endress+Hauser

Endress+Hauser

Endress+Hauser prowirl 70 Manual

Endress+Hauser

Endress+Hauser silopilot FMM 460 Manual de usuario

Endress+Hauser

Endress+Hauser TH15 Instrucciones de instalación

Endress+Hauser

Endress+Hauser Turbimax CUS50D Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 55S Manual

Endress+Hauser

Endress+Hauser Analytik Jena multi EA 5000 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar PMD78B Manual de usuario

Endress+Hauser

Endress+Hauser Dosimag Manual de usuario

Endress+Hauser

Endress+Hauser RIA46 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Proline Prowirl F 200 Manual de usuario

Endress+Hauser

Endress+Hauser Proline 500 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Stamosens CSM750 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag H 200 Manual de usuario

Endress+Hauser

Endress+Hauser nivotester FTC 420 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Prowirl D 200 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Thermocouples TH51 Manual

Endress+Hauser

Endress+Hauser Proline Prowirl 73 Manual de usuario

Endress+Hauser

Endress+Hauser RID14 Especificaciones técnicas

Endress+Hauser

Endress+Hauser SpectraSensors OXY5500 Manual de usuario

Endress+Hauser

Endress+Hauser TOCII CA72TOC Manual de usuario

Endress+Hauser

Endress+Hauser Cerabar S Series Manual de usuario

Endress+Hauser

Endress+Hauser prowirl 70 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50H Manual

Endress+Hauser

Endress+Hauser Soliwave FDR56 Especificaciones técnicas

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario

Acterna

Acterna MS1400 Manual de usuario

R&S

R&S ZPH Manual de usuario
