Brief Operating Instructions

Deltabar PMD55B

Differential pressure measurement

HART

These Instructions are Brief Operating Instructions; they are

not a substitute for the Operating Instructions pertaining to

the device.

Detailed information about the device can be found in the

Operating Instructions and the other documentation:

Available for all device versions via:

• Internet: www.endress.com/deviceviewer

• Smart phone/tablet: Endress+Hauser Operations App

KA01466P/00/EN/04.22-00

71582831

2022-08-31

Associated documentation Deltabar PMD55B HART

2 Endress+Hauser

1 Associated documentation

Order code:

Ext. ord. cd.:

Ser. no.:

www.endress.com/deviceviewer Endress+Hauser

Operations App

XXXXXXXXXXXX

XXXXX-XXXXXX

XXX.XXXX.XX

Serial number

A0023555

2 About this document

2.1 Document function

The Brief Operating Instructions contain all the essential information from incoming

acceptance to initial commissioning.

2.2 Symbols

2.2.1 Safety symbols

DANGER

Deltabar PMD55B HART About this document

Endress+Hauser 3

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

WARNING

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

This symbol contains information on procedures and other facts which do not result in

personal injury.

2.2.2 Electrical symbols

Ground connection:

Terminal for connection to the grounding system.

2.2.3 Symbols for certain types of information

Permitted:

Procedures, processes or actions that are permitted.

Forbidden:

Procedures, processes or actions that are forbidden.

Additional information:

Reference to documentation:

Reference to page:

Series of steps:

Result of an individual step:

2.2.4 Symbols in graphics

Item numbers: 1, 2, 3 ...

Series of steps:

Views: A, B, C, ...

2.2.5 Symbols on the device

Safety instructions:

Observe the safety instructions contained in the associated Operating Instructions.

Basic safety instructions Deltabar PMD55B HART

4 Endress+Hauser

2.2.6 Communication symbols

2.3 Registered trademarks

HART®

Registered trademark of the FieldComm Group, Austin, Texas, USA

Bluetooth®

The Bluetooth® wordmark and logos are registered trademarks of Bluetooth SIG, Inc. and any

use of these trademarks by Endress+Hauser is licensed. Other trademarks and trade names

are those of their respective owners.

Apple®

Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the

U.S. and other countries. App Store is a service mark of Apple Inc.

Android®

Android, Google Play and the Google Play logo are trademarks of Google Inc.

3 Basic safety instructions

3.1 Requirements for the personnel

The personnel for installation, commissioning, diagnostics and maintenance must fulfill the

following requirements:

‣Trained, qualified specialists must have a relevant qualification for this specific function

and task

‣Are authorized by the plant owner/operator

‣Are familiar with federal/national regulations

‣Before beginning work, the specialist staff must have read and understood the instructions

in the Operating Instructions and supplementary documentation as well as in the

certificates (depending on the application)

‣Follow instructions and comply with conditions

The operating personnel must fulfill the following requirements:

‣Being instructed and authorized according to the requirements of the task by the facility's

owner-operator

‣Following the instructions in these Operating Instructions

3.2 Intended use

The Deltabar is a differential pressure transmitter for measuring pressure, flow, level and

differential pressure.

3.2.1 Incorrect use

The manufacturer is not liable for damage caused by improper or non-intended use.

Deltabar PMD55B HART Basic safety instructions

Endress+Hauser 5

Verification for borderline cases:

‣For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in

verifying the corrosion resistance of fluid-wetted materials, but does not accept any

warranty or liability.

3.3 Workplace safety

When working on and with the device:

‣Wear the required personal protective equipment according to federal/national

regulations.

‣Switch off the supply voltage before connecting the device.

3.4 Operational safety

Risk of injury!

‣Operate the device only if it is in proper technical condition, free from errors and faults.

‣The operator is responsible for the interference-free operation of the device.

Modifications to the device

Unauthorized modifications to the device are not permitted and can lead to unforeseeable

dangers:

‣If, despite this, modifications are required, consult with Endress+Hauser.

Repair

To ensure continued operational safety and reliability:

‣Carry out repairs on the device only if they are expressly permitted.

‣Observe federal/national regulations pertaining to the repair of an electrical device.

‣Use original spare parts and accessories from Endress+Hauser only.

Hazardous area

To eliminate the risk of danger to persons or the facility when the device is used in the

approval-related area (e.g. explosion protection, pressure equipment safety):

‣Check the nameplate to verify if the device ordered can be put to its intended use in the

approval-related area.

‣Observe the specifications in the separate supplementary documentation that is an integral

part of these Instructions.

3.5 Product safety

This device is designed in accordance with good engineering practice to meet state-of-the-art

safety requirements, has been tested, and left the factory in a condition in which it is safe to

operate.

It meets general safety standards and legal requirements. It also complies with the EC

directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms

this by affixing the CE mark to the device.

Incoming acceptance and product identification Deltabar PMD55B HART

6 Endress+Hauser

3.6 Functional Safety SIL (optional)

The Functional Safety Manual must be strictly observed for devices that are used in functional

safety applications.

3.7 IT security

Endress+Hauser can only provide a warranty if the device is installed and used as described in

the Operating Instructions. The device is equipped with security mechanisms to protect it

against any inadvertent changes to the device settings. IT security measures in line with

operators' security standards and designed to provide additional protection for the device and

device data transfer must be implemented by the operators themselves.

3.8 Device-specific IT security

The device offers specific functions to support protective measures by the operator. These

functions can be configured by the user and guarantee greater in-operation safety if used

correctly. An overview of the most important functions is provided in the following section:

• Write protection via hardware write protection switch

• Access code to change the user role (applies for operation via Bluetooth, FieldCare,

DeviceCare, Asset Management Tools (e.g. AMS, PDM)

4 Incoming acceptance and product identification

4.1 Incoming acceptance

DELIVERY NOTE

1 = 2

A0016870

• Is the order code on the delivery note (1) identical to the order code on the product sticker

(2)?

• Are the goods undamaged?

• Do the data on the nameplate correspond to the order specifications and the delivery note?

• Is the documentation available?

• If required (see nameplate): are the Safety Instructions (XA) provided?

If you can answer "no" to any of these questions, please contact Endress+Hauser.

Deltabar PMD55B HART Mounting

Endress+Hauser 7

4.2 Storage and transport

4.2.1 Storage conditions

• Use the original packaging

• Store the device in clean and dry conditions and protect from damage caused by shocks

Storage temperature range

See Technical Information.

4.2.2 Transporting the product to the measuring point

LWARNING

Incorrect transport!

Housing and membrane may become damaged, and there is a risk of injury!

‣Transport the device to the measuring point in the original packaging.

5 Mounting

NOTICE

The device can be damaged if handled incorrectly!

‣The removal of the screws with item number (1) is not permissible under any

circumstances and will void the warranty.

A0025336

5.1 Mounting requirements

5.1.1 General instructions

• Do not clean or touch the membrane with hard and/or pointed objects.

• Do not remove the protection on the membrane until just before installation.

Always firmly tighten the housing cover and the cable entries.

1. Counter-tighten the cable entries.

2. Tighten the coupling nut.

Mounting Deltabar PMD55B HART

8 Endress+Hauser

5.1.2 Installation instructions

• To ensure optimal readability of the local display, adjust the housing and local display

• Endress+Hauser offers a mounting bracket to mount the device on pipes or walls

• When measuring in media containing solids (e.g. dirty liquids), installing separators and

drain valves is useful for capturing and removing sediment

• Using a valve manifold allows for easy commissioning, installation and maintenance

without interrupting the process

• When mounting the device, establishing the electrical connection and during operation:

prevent the penetration of moisture into the housing

• Point the cable and plug downwards as much as possible to prevent moisture from entering

(e.g. rainwater or condensation)

5.1.3 Installing pressure piping

• For recommendations for routing pressure piping, refer to DIN 19210 "Differential pressure

piping for flow measurement devices" or the corresponding national or international

standards

• When routing the pressure piping outdoors, ensure sufficient anti-freeze protection, e.g. by

using pipe heat tracing

• Install the pressure piping with a monotonic gradient of at least 10%

5.2 Mounting the device

5.2.1 Flow measurement

Flow measurement in gases

Mount the device above the measuring point so that condensate can drain into the process

pipe.

Flow measurement in vapors

• Mount the device below the measuring point

• Mount the condensate traps at the same height as the tapping points and at the same

distance to the device

• Prior to commissioning, fill the piping to the height of the condensate traps

Flow measurement in liquids

• Mount the device below the measuring point so that the piping is always filled with liquid

and gas bubbles can run back into the process pipe

• When measuring in media with solid parts, such as dirty liquids, installing separators and

drain valves is useful for capturing and removing sediment

Deltabar PMD55B HART Mounting

Endress+Hauser 9

5.2.2 Level measurement

Level measurement in open vessels

• Mount the device below the lower measuring connection so that the piping is always filled

with liquid

• The low-pressure side is open to atmospheric pressure

• When measuring in media with solid parts, such as dirty liquids, installing separators and

drain valves is useful for capturing and removing sediment

Level measurement in a closed vessel

• Mount the device below the lower measuring connection so that the piping is always filled

with liquid

• Always connect the low-pressure side above the maximum level

• When measuring in media with solid parts, such as dirty liquids, installing separators and

drain valves is useful for capturing and removing sediment

Level measurement in a closed vessel with superimposed vapor

• Mount the device below the lower measuring connection so that the piping is always filled

with liquid

• Always connect the low-pressure side above the maximum level

• The condensate trap ensures constant pressure on the low-pressure side

• When measuring in media with solid parts, such as dirty liquids, installing separators and

drain valves is useful for capturing and removing sediment

5.2.3 Pressure measurement

Pressure measurement with 160 bar (2 400 psi) and 250 bar (3 750 psi) measuring cell

• Mount the device above the measuring point so that the condensate can drain into the

process pipe

• The negative side is open to atmospheric pressure via the screwed-in reference air filter of

the side flange on the low-pressure side

5.2.4 Differential pressure measurement

Differential pressure measurement in gases and vapors

Mount the device above the measuring point so that condensate can drain into the process

pipe.

Differential pressure measurement in liquids

• Mount the device below the measuring point so that the piping is always filled with liquid

and gas bubbles can run back into the process pipe

• When measuring in media with solid parts, such as dirty liquids, installing separators and

drain valves is useful for capturing and removing sediment

Electrical connection Deltabar PMD55B HART

10 Endress+Hauser

5.2.5 Closing the housing cover

NOTICE

Thread and housing cover damaged from dirt and fouling!

‣Remove fouling (e.g. sand.) on the thread of the cover and housing.

‣If you continue to encounter resistance when closing the cover, check the thread again for

fouling.

Housing thread

The thread of the electronics and connection compartment is coated with lubricant

varnish.

Avoid additional lubrication.

6 Electrical connection

6.1 Connecting requirements

6.1.1 Potential equalization

The protective ground on the device must not be connected. If necessary, the potential

matching line can be connected to the outer ground terminal of the device before the device is

connected.

A0045411

1 Ground terminal for connecting the potential matching line

LWARNING

Explosion Hazard!

‣Please refer to the separate documentation on applications in hazardous areas for the

safety instructions.

For optimum electromagnetic compatibility:

• Keep the potential matching line as short as possible

• Maintain a cross-section of at least 2.5 mm2 (14 AWG)

Otros manuales para Deltabar PMD55B

Tabla de contenidos

Otros manuales de Instrumento de medición de Endress+Hauser

Endress+Hauser

Endress+Hauser Levelflex FMP55 Manual

Endress+Hauser

Endress+Hauser Liquiline System CA80PH Manual de usuario

Endress+Hauser

Endress+Hauser EngyCal RH33 Especificaciones técnicas

Endress+Hauser

Endress+Hauser CNGmass DCI Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promass 83 Manual de usuario

Endress+Hauser

Endress+Hauser TOCII CA72TOC Manual de usuario

Endress+Hauser

Endress+Hauser Promag 300 Manual de usuario

Endress+Hauser

Endress+Hauser SpectraSensors SS2100i-1 Manual de instrucciones

Endress+Hauser

Endress+Hauser QG2000 Manual

Endress+Hauser

Endress+Hauser Proline t-mass 65 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Cerabar S PMC71 Manual de usuario

Endress+Hauser

Endress+Hauser Cerabar S PMP71 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Proline Promag H 200 Manual

Endress+Hauser

Endress+Hauser Viomax CAS51D Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual de usuario

Endress+Hauser

Endress+Hauser RIA14 Especificaciones técnicas

Endress+Hauser

Endress+Hauser CleanFit P CPA 472 Manual de usuario

Endress+Hauser

Endress+Hauser COM280 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Prosonic Flow 93 Manual de lista de piezas

Endress+Hauser

Endress+Hauser RID14 Manual de usuario

Endress+Hauser

Endress+Hauser Levelflex FMP55 Manual de usuario

Endress+Hauser

Endress+Hauser Levelflex FMP53 Manual de usuario

Endress+Hauser

Endress+Hauser Promass 84F Manual

Endress+Hauser

Endress+Hauser Micropilot FMR56 Manual

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario

Acterna

Acterna MS1400 Manual de usuario

R&S

R&S ZPH Manual de usuario
