EMPORIA TOUCHsmart Manual de usuario
English
Eveline Pupeter, emporia Telecom
www.emporiatelecom.co.uk / www.emporiatelecom.ie
Thank you for purchasing an emporia product!
Please read this user guide before attempting to use your phone.
TOUCH
smart
Wi-Fi
connection or
mobile data tariff
required
V188i_GuideBook_V5_55710-ENG.indd 1 05.12.19 13:03
2
1
4
16
7
9
12
11
3
13 14
20
18
19
5
10
YOUR MOBILE PHONE AT A GLANCE
1Loudspeaker
2Screen (in picture showing
standby mode)
3Navigation ring
4Left function key
5Selection key
6Right-hand function key
7Phone book key
8Camera key
9Green key
10 WhatsApp key
11 Red key
12
1
key (voicemail)
13 Camera lens and ash
14 Emergency button
(extra battery cover without
an emergency button)
15 Headset port
16 Torch button
17 Volume controls
and
18 Battery cover
19 Microphone
20 Port for USB charging cable
6
15
17
8
SYMBOLS ON THE
EXTERNAL DISPLAY
Reception indicator
Battery
12:30 Time
21.08 Date
Sun Day
Missed call
Symbols in standby mode
Battery
Wi-Fi
Alarm
Silent mode
Bluetooth
Reception indicator
12° C Temperature
New WhatsApp
message
Missed call
New SMS
V188i_GuideBook_V5_55710-ENG.indd 2 05.12.19 13:03
SYMBOLS AND OPERATING THE PHONE
ENGLISH–03
How can I return a missed call?
1. Tap on the word See on the screen below
the notication Missed call.
2. The call function will open and the number or
name of the caller highlighted by a red bar.
How do I access a new message?
1. Tap on the word See on the screen below
the notication New message.
2. The SMS message function will open.
3. The number or name of the sender will be highlighted
by a red bar.
4. Tap on the new SMS to read it.
How do I access a new WhatsApp message?
• Tap on the WhatsApp button to open the app.
How do I remove indicators for missed calls,
SMS messages and WhatsApp notifications?
The symbols on the external display and along the top of the
screen will disappear as soon as you've read the SMS, opened
WhatsApp or had a look to see who the missed call was from.
V188i_GuideBook_V5_55710-ENG.indd 3 05.12.19 13:03
ENGLISH–04
1. GETTING STARTED
Inserting a SIM card
• Remove the battery cover (opening in the bottom left-hand
corner).
• Slide the SIM card into the SIM card holder
with the gold contacts facing down.
• To add more storage, insert an SD card into the card holder
with the gold contacts facing down.
Inserting and charging the battery
• Insert the battery, making sure that the battery contacts
touch the phone's gold contacts.
• Place the battery cover over the battery and press it down
until it clicks into place.
• Plug the charging cable into the USB port on the bottom of
thephone.
Charge the battery for at least four hours before the rst time you
use it. While charging, the phone will be switched on automatically.
V188i_GuideBook_V5_55710-ENG.indd 4 05.12.19 13:03
ENGLISH–05
Turning on the phone
• Press and hold the key for at least 2 seconds until the
emporia logo appears. It will take a few seconds for the
standby mode to be displayed.
• To turn the phone o, press the key
for two seconds again.
Entering a PIN code
Enter the four-digit PIN code for your SIM card when asked to
do so and conrm the code.
You can change or turn o the PIN code in Menu _Settings
_More settings _SIM card lock.
The PIN code is a four-digit number that is intended to prevent
somebody else from being able to switch on your mobile phone.
You have a maximum of three attempts to enter the correct
number. If you enter the wrong number three times in a row, you
will only be able to unblock the SIM card with the PUK code. You
will nd the original PIN code and PUK code in the package and
documents that came with your SIM card.
Saving energy
After a few seconds of inactivity, the display will turn o to
save battery power. In the event of an incoming call or you
pressing any key, the screen will automatically light up again.
V188i_GuideBook_V5_55710-ENG.indd 5 05.12.19 13:03
ENGLISH–06
2. SETTING UP YOUR PHONE
When you use a new SIM card for the rst time, you need to select
a number of settings. You will need to set the language, date, time
and any necessary data connections. You can also congure these
later in Menu and Settings if you wish.
2.1 Language, date and time
Menu _Settings _More settings
_Language and input and Date and time.
2.2 Wi-Fi
Menu_Settings _Wi-Fi
1. Set indicator button to ON
2. Select Wi-Fi network
3. Enter password
You can read more about this in the chapter »11.4 Wi-Fi« on
page25.
2.3 Mobile data connection
Menu _Settings _Mobile data
Set indicator button to ON
If you use the phone's mobile data facility, your network tari
must include mobile data. Ask your retailer or network provider for
more information.
V188i_GuideBook_V5_55710-ENG.indd 6 05.12.19 13:03
ENGLISH–07
2.4 WhatsApp
1. When the phone is on standby, press the WhatsApp key .
2. Tap on AGREE AND CONTINUE to accept the WhatsApp
privacy policy and terms of service.
3. Enter your phone number and then conrm it
by tapping on NEXT.
4. Tap on OK to conrm verication of your number.
5. You will receive an SMS to activate WhatsApp.
To make this automatic, grant permission for SMS messages,
otherwise enter the code you have received by SMS.
6. Provide your own prole information. This includes the name
and photo that will appear to others when you use WhatsApp.
You can now delete the SMS you received from WhatsApp.
2.5 Menu screen
The phone has been preset to display the following
functions on the menu screen: Contacts, Messages,
WhatsApp, Calendar, Camera, Photo album, Settings and
Applications. The placement of each of these functions can
be altered individually, apart from that of the unmovable
Applications button.
How to alter the menu screen:
Tap and hold one of the buttons for approx. 3seconds and
select your chosen function from the list that appears.
V188i_GuideBook_V5_55710-ENG.indd 7 05.12.19 13:03
ENGLISH–08
If you would like to set up the device for a relative or friend, it is
best if you familiarise them with the functions and adjust the
necessary settings. For example, in the Weather app, a location
has to be specied.
2.6 Memory usage: recommendations to help your
phone run smoothly
This device is a feature phone that has been enhanced by
the WhatsApp function. It doesn't oer all the functions of a
smartphone, because its storage space doesn't allow that.
We recommend doing the following:
• Switch o the device once a day or enable the Automatic
switch-on / switch-off function to help performance.
• Regularly delete photos you have taken yourself from the
device and/or save them elsewhere to free up storage space
on your phone.
• Regularly delete photos and videos you have taken and sent
to contacts via WhatsApp. (Recording and sending videos that
are too large can prevent the device from running smoothly.)
V188i_GuideBook_V5_55710-ENG.indd 8 05.12.19 13:03
ENGLISH–09
3. USING THE PHONE
This phone can be controlled both via its touchscreen and via its
numeric keypad and navigation ring. In the following, operating
the phone using the keys has been prioritised.
After starting, the phone is in standby mode.
In standby mode the phone is on, but is not running any
applications (calls, SMS messages, etc.).
3.1 Using the phone in standby mode
• Phone book: opens Contacts
• Camera: opens the photo function
• WhatsApp: opens WhatsApp
• Left function key: opens the menu
Some keys have additional functions if they are pressed and
held down for a few seconds:
•
1
key: Listen to your voicemail
Changing your voicemail settings when the phone is on
standby: key _Options _Settings _Voicemail
_Setup _Voicemail number
• key: switches phone on/o
V188i_GuideBook_V5_55710-ENG.indd 9 05.12.19 13:03
ENGLISH–10
3.2 Using the menu
Menu items: Contacts, Messages, WhatsApp, Calendar,
Camera, Photo album, Settings and Applications
• Navigate through the menu items with the navigation ring.
Your current selection will be highlighted by a blue border.
• Press the selection key to open the selected menu item.
• Options which you can select with the function keys will be
shown at the bottom of the screen.
The left function key is normally the OK button, while
the right function key is normally for BACK. Note the terms
displayed along the bottom of the screen and match these
with the function keys below them.
• To return to standby mode,
press the red key.
3.3 Writing text
Use the
aA1
key to toggle between numeric and text input.
• To input text, press a number key multiple times
(e.g. 2x
4ghi
, 1x
2abc
, 3x
5jkl
, 3x
5jkl
and 3x
6
mno
for Hallo).
• Special characters: In text mode,
press the key several times.
• The symbols available vary according to which language you
are using.
V188i_GuideBook_V5_55710-ENG.indd 10 05.12.19 13:03
