EMPORIA TOUCH smart.2 Manual de usuario

English

Eveline Pupeter, emporia Telecom

www.emporia.eu

Thank you for purchasing an emporia product!

Please read this user guide before

attempting to use your phone.

TOUCH

smart.2

Wi-Fi

connection or

mobile data tariff

required

13 14

› YOUR MOBILE PHONE AT A GLANCE

1Loudspeaker

2Home screen

3Navigation ring

4Left function key

5Selection key

6Right function key

7Phone book key

8Camera key

9Green key

10 Chat app key

11 Red key

key (voicemail)

13 Camera lens and ash

14 Emergency button

(extra battery cover without

an emergency button)

15 Headset port

16 Torch button

17 Volume controls

and

18 Battery cover

19 Loudspeaker

20 Microphone

21 Port for USB charging cable

›Symbols on the external

display

Reception indicator

Battery

12:3012:30 Time

21.0821.08 Date

SunSun Day

Incoming call

Missed call

New SMS

New messaging

appmessage

›Other symbols on

the home screen

Vo LTE

Reception indicator

Wi-Fi

Alarm

Silent mode

Bluetooth

12 °C12 °C Temperature

› SYMBOLS AND OPERATING THE PHONE

ENGLISH–03

›How do I return a missed call?

1. Tap on the word Show on the screen below the notication

Missed call.

2. The call function will open and the number or name of

thecaller will be highlighted by a red bar.

›How do I access a new SMS message?

1. Tap on the word Show on the screen below the notication

New message.

2. The text message function will open.

3. The number or name of the sender will be highlighted by a bar.

4. Tap on the new SMS to read it.

›How do I access a new messaging app message?

• Tap on the chat app key to open the app.

›How do I remove indicators for missed calls,

SMS messages and messaging app notiﬁcations?

The symbols on the external display and along the top of the

screen will disappear as soon as you've read the SMS, opened

the messagingapp or had a look to see who the missed call

was from.

ENGLISH–04

› CONTENTS

› Your mobile phone at a

glance..................02

› Symbols and operating

thephone ..............03

1. Getting started .........06

1.1 Inserting a SIM card........06

1.2 Inserting and charging

thebattery................06

1.3 Turning on the phone......07

1.4 Entering a PIN code........07

1.5 Saving battery power......07

2. Setting up your phone...08

2.1 Setting up a

messaging app............08

2.2 Personalising the menu ....09

2.3 Updating your system

andapps..................09

3. Using the phone ........10

3.1 Using the home screen ....10

3.2 Dual-function keys ........10

3.3 Using the menu ...........11

3.4 Writing text ...............12

4. Calls ...................13

4.1 Accepting, rejecting or

ending a call ..............13

4.2 Calling someone ..........13

5. Contacts................14

5.1 Searching for a contact

in the phone book.........14

5.2 Adding a contact ..........14

5.3 Transferring contacts ......15

5.4 Opening and editing

acontact record ...........16

5.5 Contact options ...........17

6. Messages (SMS) .........18

6.1 Writing and sending

amessage ................18

6.2 Reading a message ........18

7. Messaging app..........19

7.1 Setting up a messaging app19

7.2 Using the messaging app ..19

7.3 Closing the messaging app 19

ENGLISH–05

8. Info centre .............20

8.1 Receiving a notiﬁcation ....20

8.2 Opening a notiﬁcation .....20

8.3 Deleting notiﬁcations......20

9. Camera.................21

9.1 Taking a photo or

recording a video..........21

9.2 Changing the camera

settings...................21

10. Photo album............22

10.1 Viewing a photo or video ..22

10.2 Sending or editing a photo 22

11. Settings ................24

11.1 Alarm.....................24

11.2 Silent mode ...............24

11.3 Wi-Fi......................25

11.4 Bluetooth .................25

11.5 Mobile data . . . . . . . . . . . . . . .26

11.6 Flight mode ...............26

11.7 Location (GPS).............26

11.8 Open to answer calls.......26

11.9 Voice assistant ............27

11.10 Wi-Fi hotspot ............27

11.11 Wallpaper ...............27

11.12 Messaging app ..........27

11.13 More settings............28

12. Internet ................29

13. Calendar ...............30

13.1 Entering a new event ......30

13.2 Opening an event

you've entered ............31

13.3 Searching for an event .....31

14. System updates.........32

15. Weather ................33

16. Emporia emergency call

function................34

17. Guarantee and service...36

ENGLISH–06

1. GETTING STARTED

1.1 Inserting a SIM card

1. Remove the battery cover (opening in the bottom left-hand corner).

2. Slide the SIM card into the SIM card holder with the gold

contacts facing down.

3. To add more storage, insert a memory card into the memory

card holder with the gold contacts facing down.

1.2 Inserting and charging the battery

1. Insert the battery, making sure that the battery contacts touch

the phone's gold contacts.

2. Place the battery cover over the battery and click it into place.

3. Plug the charging cable into the USB port of the phone and

the power plug into a mains outlet.

Charge the battery for at least four hours before the rst time you

use it. Only use batteries and chargers that are permitted for use

with this specic model.

ENGLISH–07

1.3 Turning on the phone

• Press and hold the key for at least two seconds until

the emporia logo appears. It will take a few seconds for the

homescreen to be displayed.

• To turn the phone o, press and hold the key

for 2seconds again.

1.4 Entering a PIN code

• Enter the four-digit PIN code for your SIM card when asked

todo so and conrm the entry.

• You can change or turn o the PIN code in Menu _Settings

_More settings _SIM card lock.

You have a maximum of three attempts to enter the correct

number. If you enter the wrong number three times in a row, you

will only be able to unblock the SIM card with the PUK code. You

will nd your original PIN code and PUK code in the documents

supplied with your SIM card by your network operator.

1.5 Saving battery power

After a few seconds of inactivity, the display will turn o to

save battery power. In the event of an incoming call or you

pressing any key, the screen will automatically light up again.

ENGLISH–08

2. SETTING UP YOUR PHONE

When you use a new SIM card for the rst time, you need to set

the language, date, time and any data connections. You can also

congure and change these later in Menu _Settings if you wish

(See »11. Settings« on page 24).

If you use the phone's mobile data facility, your network tari

must include mobile data. Ask your retailer or network provider for

more information.

2.1 Setting up a messaging app

1. When on the home screen, press the chat app key and

select YES to conrm your answer to the security question.

2. Select the messaging app you want to install.

You can choose from Signal, Telegram and WhatsApp.

3. Pressing the chat app key again now will open

themessaging app you've selected straight away.

More information on setting up a messaging app is available in

the messaging app manual, which is supplied separately.

ENGLISH–09

2.2 Personalising the menu

• The menu has been preset to display the following functions:

Contacts, Messages, Chat app, Calendar, Camera,

Photo album, Settings and Applications.

• The placement of each of these functions can be altered

individually, apart from that of the unmovable Applications

button.

• To replace a function with another one, tap and hold one of

the buttons for approx. 3seconds and select your chosen

function from the list that appears.

2.3 Updating your system and apps

Updates are not performed automatically on the

emporiaTOUCHsmart. When a system update is available,

youwill receive a notice in the info centre.

Always carry out these updates.

(See »14. System updates« on page 32)

If the notice Update app appears when you're opening your

messaging app, proceed as follows:

4. Tap on Download and grant permission to any requests.

5. Go to the info centre and tap on the downloaded document.

6. Allow Install unknown apps and answer the

securityquestions.

7. The new version of your messaging app will be installed.

ENGLISH–10

3. USING THE PHONE

This phone can be controlled both via its touchscreen and via its

numeric keypad and navigation ring. In the following, operating

the phone using the keys has been prioritised.

3.1 Using the home screen

• Left function key : opens the menu

• Right function key :opens the info centre

(can be made visible for present notications)

• Phone book : opens Contacts

• Camera :opens the photo function

• key: opens your call history

• Chat app key: opens the messaging app installed

3.2 Dual-function keys

Some keys have additional functions if they are pressed and

held down for a few seconds:

•

key: allows you to listen to your voicemail

Changing your voicemail settings:

Menu _Contacts _Settings _Voicemail _Setup

_Voicemail number

• key: + for country code, e.g. +49 for Germany

• key: turns the torch on continuously
