Model 3051 Transmitter With

FOUNDATION™fieldbus protocol

00809-0100-4774

English

Rev. BA

Device Revision 7

Product

Manual

Model 3051 Transmitter with

FOUNDATION™fieldbus

Fisher-Rosemount

satisfies all obligations

coming from legislation

to harmonise product

requirements in the

European Union.

Rosmeount Inc.

8200 Market Boulevard

Chanhassen, MN 55317

USA

Tel 1-800-999-9307

Fax (952) 949-7001

Product documentation available at...

www.rosemount.com

¢00809-0100-4774q¤

00809-0100-4774 Rev. BA 11/00

Patents and trademarks here.

COVER PHOTO: (ILLUSTRATION REFERENCE)

NOTICE

Read this manual before working with the product. For personal and system safety, and

for optimum product performance, make sure you thoroughly understand the contents

before installing, using, or maintaining this product.

Within the United States, Rosemount Inc. has two toll-free assistance numbers:

Customer Central

Technical support, quoting, and order-related questions.

1-800-999-9307 (7:00 am to 7:00 pm CST)

North American Response Center

Equipment service needs.

1-800-654-7768 (24 hours—includes Canada)

Outside of the United States, contact your local Rosemount representative.

The products described in this document are NOT designed for nuclear-qualified

applications. Using non-nuclear qualified products in applications that require nuclear-

qualified hardware or products may cause inaccurate readings.

For information on Rosemount nuclear-qualified products, contact your local Rosemount

Sales Representative.

Rosemount Model 3051 Transmitter with FOUNDATIONTM fieldbus Protocol

Section

1-1

1Introduction

OVERVIEW The sections in this manual provide information on installing,

operating, and maintaining the Rosemount Model 3051 Transmitter

with FOUNDATION™fieldbus with Revision 7 software. The sections are

organized as follows:

Section 2 Installation

• Mechanical and electrical installation instructions

Section 3 Configuration

• Basic transmitter operation

• Software functionality

• Provides basic configuration procedures

Section 4 Operation and Maintenance

• Provides general maintenance information and procedures

Appendix A Specifications and Reference Data

• Specification data for all model 3051 transmitters with

FOUNDATION fieldbus

Appendix B Approvals

• Intrinsic safety approval drawings

• European ATEX directive information

Appendix C Block Information

• Transducer Block operation and parameters

• Resource Block operation and parameters

• Advanced Diagnostic block information

• LCD block information

Rosemount Model 3051 Transmitter with FOUNDATIONTM fieldbus Protocol

1-2

Section

2-1

2Installation

OVERVIEW This section contains specific information pertaining to the installation

of the Model 3051 Transmitter with FOUNDATION fieldbus.

SAFETY MESSAGES Instructions and procedures in this section may require special

precautions to ensure the safety of the personnel performing the

operations. Information that raises potential safety issues is indicated

by a warning symbol ( ). Please refer to the following safety messages

before performing an operation preceded by this symbol.

Warnings

Explosions can result in death or serious injury.

• Do not remove the transmitter covers in explosive environments when the

circuit is live.

• Both transmitter covers must be fully engaged to meet

explosionproof requirements.

• Verify that the operating atmosphere of the transmitter is consistent with the

appropriate hazardous locations certifications.

Electrical shock can result in death or serious injury.

• Avoid contact with the leads and terminals.

Process leaks could result in death or serious injury.

• Install and tighten all four flange bolts before applying pressure.

• Do not attempt to loosen or remove flange bolts while the transmitter is

in service.

Replacement equipment or spare parts not approved by Rosemount Inc. for use

as spare parts could reduce the pressure retaining capabilities of the transmitter

and may render the instrument dangerous.

• Use only bolts supplied with the Model 3051 or sold by Rosemount Inc. as

spare parts for the Model 3051.

Rosemount Model 3051 Transmitter with FOUNDATIONTM fieldbus Protocol

2-2

GENERAL

CONSIDERATIONS Measurement accuracy depends upon proper installation of the

transmitter and impulse piping. Mount the transmitter close to the

process and use a minimum of piping to achieve best accuracy. Keep in

mind the need for easy access, personnel safety, practical field

calibration, and a suitable transmitter environment. Install the

transmitter to minimize vibration, shock, and temperature fluctuation.

IMPORTANT

Install the enclosed pipe plug in unused conduit openings with a

minimum of five threads engaged to comply with explosionproof

requirements. The transmitter is shipped with the plug installed on the

transmitters ordered with CSA explosionproof approval.

MECHANICAL

CONSIDERATIONS Figures 2-1 through 2-5 on pages 2-3 through 2-6 show dimensional

drawings of Model 3051 transmitters. Figure 2-8 on page 2-10 shows

installation examples. Figures 2-9 through 2-12 on pages 2-14 through

2-17 show dimensional drawings of mounting brackets.

NOTE

For Model 3051CD0 and 3051CD1, mount the transmitter solidly to

prevent tilting. A tilt in the physical transmitter may cause a zero shift

in the transmitter output.

NOTE

For steam service, do not blow down impulse piping through the

transmitter. Flush the lines with the blocking valves closed and refill

the lines with water before resuming measurement.

NOTE

When the transmitter is mounted on its side, position the Coplanar

flange to ensure proper venting or draining. Mount the flange as shown

in Figure 2-8 on page 2-10, keeping drain/vent connections on the

bottom for gas service and on the top for liquid service.

NOTE

The Model 3051 transmitter incorporates two independent seals

between the process connection and the conduit connection.

2-3

Installation

Figure 2-1. Model 3051CD

Dimensional Drawings

Figure 2-2. Model 3051CG and

3051CA Dimensional Drawings

0.75 (20)

Clearance for

Cover Removal

Transmitter

Circuitry

Nameplate

Drain/Vent Valve

1/2–14 NPT on Optional Flange

Adapters. Adapters Can Be Rotated

to Give Connection Centers of 2.00

(51), 2.125 (54), or 2.25 (57).

6.4

(163)

5.0

(127)

0.75 (20)

Clearance for

Cover Removal

Terminal

Connections

1/2–14 NPT Conduit

Connection (Two Places,

Other Sizes Available)

Certification

Label

4.1 (105)

Housing Rotation

Set Screw

7.1

(180) 8.2

(208)

1/4–18 NPT on Coplanar Flange for

Pressure Connection Without the

Use of Flange Adapters

3051-3031A06A, B06A

OTE: Dimensions are in inches (millimeters)

1/2–14 NPT on

Optional

Flange Adapter

OTE: Dimensions are in inches (millimeters)

5.0

(127)

0.75 (20) Clearance

for Cover Removal

Transmitter

Connections

0.75 (20)

Clearance for

Cover Removal

Transmitter

Circuitry

Nameplate

5.2

(132)

1/2–14 NPT Conduit

Connection (Two Places,

Other Sizes Available) 4.1

(105)

Certification

Label

Housing Rotation

Set Screw

1/4–18 NPT on Coplanar Flange for Pressure

Connection Without the Use of Flange Adapters

7.1

(180) 8.2

(208)

3051-3031A06C, B06A

Rosemount Model 3051 Transmitter with FOUNDATIONTM fieldbus Protocol

2-4

Figure 2-3. Model 3051C (Traditional

Flange) Dimensional Drawings

Figure 2-4. Model 3051T Dimensional

Drawings

.75

(

20) Clearance

or Cover

emoval

5.0

(127)

Terminal

Connections

Housing Rotation

Set Screw

0.75 (20)

Clearance for

Cover Removal

1/2–14 NPT Conduit

Connection (Two

Places, Other Sizes

Available)

Nameplate 1.7

(43)

2.2

(56)

1/4–18 NPT on Traditional Flange for

Pressure Connection Without the Use

of Flange Adapters

Certification Label

4.1

(105)

7.9

(201)

1.1

(28)

3.4

(87)

1.1

(28)

1/2–14 NPT on Optional Flange

Adapters. Adaptors Can Be Rotated

to Give Connection Centers of 2.00

(51), 2.125 (54), or 2.25 (57)

Drain/Vent

Valve

305-3031D30A, E30A

OTE: Dimensions are in inches (millimeters).

0.75 (20)

Clearance for

Cover Removal

Transmitter

Circuitry

Nameplate

5.0

(127)

0.75 (20)

Clearance for

Cover Removal

Terminal

Connections

–14 NPT

Conduit

Connection

(Two Places,

Other Sizes

Available)

Certificatio

Label

4.1

(105)

7.2

(183)

Housing Rotation

Set Screw

NOTE:

Dimensions are

in inches

(millimeters)

3051-3051TA6B, TB6A
