Emerson Rosemount 2051 Wireless Series Manual de usuario

Quick Start Guide

00825-0100-4107, Rev CA

May 2013

Rosemount 2051 Pressure Transmitter and

Rosemount 2051CF Series Flowmeters

with 4-20mA HART and 1-5Vdc Low Power HART

Protocol (Revision 5 and 7)

4107_QIG_RevCA.fm Page 1 Thursday, May 2, 2013 4:27 PM

May 2013

Quick Start Guide

Notices

NOTICE

This installation guide provides basic guidelines for Rosemount

2051 transmitters. It does not provide instructions for configuration, diagnostics,

maintenance, service, troubleshooting, Explosion-proof, Flameproof, or intrinsically safe

(I.S.) installations. Refer to the 2051 reference manual (document number

00809-0100-4107) for more instruction. This manual is also available electronically on

www.emersonprocess.com/rosemount.

Explosions could result in death or serious injury:

Installation of this transmitter in an explosive environment must be in accordance with the

appropriate local, national, and international standards, codes, and practices. Please review

the approvals section of the 2051 reference manual for any restrictions associated with a safe

installation.

Before connecting a HART-based communicator in an explosive atmosphere, make sure

the instruments in the loop are installed in accordance with intrinsically safe or

non-incendive field wiring practices.

In an Explosion-proof/Flameproof installation, do not remove the transmitter covers when

power is applied to the unit.

Process leaks may cause harm or result in death.

To avoid process leaks, only use the o-ring designed to seal with the corresponding flange

adapter.

Electrical shock can result in death or serious injury.

Avoid contact with the leads and the terminals. High voltage that may be present on leads

can cause electrical shock.

Conduit/Cable Entries

Unless marked, the conduit/cable entries in the transmitter housing use a 1/2-14 NPT

thread form. Only use plugs, adapters, glands or conduit with a compatible thread form

when closing these entries.

Contents

System Readiness . . . . . . . . . . . . . . . . . . . . . . 3

Confirm HART Revision Capability. . . . . . 3

Confirm Correct Device Driver . . . . . . . . . 3

Step 1: Mount the transmitter . . . . . . . . . . . 4

Pipe and Panel Mounting. . . . . . . . . . . . . . 5

Bolting considerations. . . . . . . . . . . . . . . . 5

Inline gage transmitter orientation . . . . . 7

Consider housing rotation. . . . . . . . . . . . . . . 8

Set the switches . . . . . . . . . . . . . . . . . . . . . . . 8

Connect the wiring and power up . . . . . . . . 9

Verify transmitter configuration . . . . . . . . 12

Trim the transmitter. . . . . . . . . . . . . . . . . . . 15

Safety Instrumented Systems. . . . . . . . . . . 17

Product certifications. . . . . . . . . . . . . . . . . . 17

4107_QIG_RevCA.fm Page 2 Thursday, May 2, 2013 4:27 PM

Quick Start Guide

May 2013

System Readiness

Confirm HART Revision Capability

If using HART based control or asset management systems, please confirm the

HART capability of those systems prior to transmitter installation. Not all

systems are capable of communicating with HART Revision 7 protocol. This

transmitter can be configured for either HART Revision 5 or 7.

For instructions on how to change the HART revision of your transmitter, see

page 15.

Confirm Correct Device Driver

Verify the latest Device Driver (DD/DTM) is loaded on your systems to ensure

proper communications.

Download the latest Device Driver files at www.emersonprocess.com or

www.hartcomm.org.

Rosemount 2051 Device Revisions and Drivers

Verify the latest Device Driver (DD/DTM) is loaded on your systems to ensure

proper communications.

1. Download the latest DD at www.emersonprocess.com or

www.hartcomm.org.

2. In the Browse by Member dropdown menu, select Rosemount business unit of

Emerson Process Management.

3. Select desired Product

a. Within Table 1, use the HART Universal Revision and Device Revision

numbers to find the correct Device Driver

Table 1. Rosemount 2051 Device Revisions and Files

Identify Device Find Device Driver Files Review

Instructions Review Functionality

Software

Release

Date

NAMUR

Software

Revision1

1.NAMUR Software Revision is located on the hardware tag of the device. HART Software Revision can be read using a HART

capable configuration tool.

HART

Software

Revision2

2. Device Driver file names us Device and DD Revision, e.g. 10_01. HART Protocol is designed to enable legacy device driver

revisions to continue to communicate with new HART devices. To access new functionality, the new Device Driver must

be downloaded. It is recommended to download new Device Driver files to ensure full functionality.

HART

Universal

Revision

Device

Revision2

Manual

Document

Number

Changes to

Software3

3.HART Revision 5 and 7 Selectable, Safety Certified. Local Operator Interface, Process Alerts, Scaled Variable, Configurable

Alarms, Expanded Engineering Units.

April

2012 1.0.0 01

710

AA See footnote 3 for

list of changes.

January

1998 N/A 178 5 3 N/A

4107_QIG_RevCA.fm Page 3 Thursday, May 2, 2013 4:27 PM

May 2013

Quick Start Guide

Step 1: Mount the transmitter

Liquid applications

1. Place taps to the side of the line.

2. Mount beside or below the taps.

3. Mount the transmitter so that the drain/vent valves are oriented upward.

Figure 2. Liquid applications

A. Coplanar

B. Inline

Gas applications

1. Place taps in the top or side of the line.

2. Mount beside or above the taps.

Figure 3. Gas applications

A. Coplanar

B. Inline

Steam applications

1. Place taps to the side of the line.

2. Mount beside or below the taps.

3. Fill impulse lines with water.

Figure 4. Steam applications

A. Coplanar

B. Inline

4107_QIG_RevCA.fm Page 4 Thursday, May 2, 2013 4:27 PM

Quick Start Guide

May 2013

Figure 5. Pipe and Panel Mounting

Bolting considerations

If the transmitter installation requires assembly of the process flanges, manifolds,

or flange adapters, follow these assembly guidelines to ensure a tight seal for

optimal performance characteristics of the transmitters. Use only bolts supplied

with the transmitter or sold by Emerson as spare parts. Figure 6 illustrates

common transmitter assemblies with the bolt length required for proper

transmitter assembly.

Rosemount 2051C

Panel Mount1

1.Panel bolts are customer supplied.

Pipe Mount

Coplanar Flange

Traditional Flange

Rosemount 2051T

4107_QIG_RevCA.fm Page 5 Thursday, May 2, 2013 4:27 PM

May 2013

Quick Start Guide

Figure 6. Common Transmitter Assemblies

A. Transmitter with Coplanar Flange

B. Transmitter with Coplanar Flange and optional Flange Adapters

C. Transmitter with Traditional Flange and optional Flange Adapters

D. Transmitter with Coplanar Flange and optional Manifold and Flange Adapters

Bolts are typically carbon steel or stainless steel. Confirm the material by viewing

the markings on the head of the bolt and referencing Table 2. If bolt material is

not shown in Table 2, contact the local Emerson Process Management

representative for more information.

Use the following bolt installation procedure:

1. Carbon steel bolts do not require lubrication and the stainless steel bolts are

coated with a lubricant to ease installation. However, no additional lubricant

should be applied when installing either type of bolt.

2. Finger-tighten the bolts.

3. Torque the bolts to the initial torque value using a crossing pattern. See

Figure 2 for initial torque value.

4. Torque the bolts to the final torque value using the same crossing pattern. See

Figure 2 for final torque value.

5. Verify that the flange bolts are protruding through the isolator plate before

applying pressure.

C. D.

4 x 1.75-in. (44 mm)

4 x 1.75-in.

(44 mm)

4 x 2.88-in. (73 mm)

4 x 1.75-in. (44 mm)

4 x 1.75-in.

(44 mm)

4 x 2.25-in.

(57 mm)

4107_QIG_RevCA.fm Page 6 Thursday, May 2, 2013 4:27 PM

Quick Start Guide

May 2013

Table 2. Torque values for the flange and flange adapter bolts

Inline gage transmitter orientation

The low side pressure port (atmospheric reference) on the inline gage transmitter

is located in the neck of the transmitter, behind the housing. The vent path is 360°

around the transmitter between the housing and sensor. (See Figure 7.)

Bolt Material Head Markings Initial Torque Final Torque

Carbon Steel (CS) 300 in.-lbs. 650 in.-lbs.

Stainless Steel (SST) 150 in.-lbs. 300 in.-lbs.

Failure to install proper flange adapter O-rings may cause process leaks, which can result in death or serious

injury. The two flange adapters are distinguished by unique O-ring grooves. Only use the O-ring that is designed

for its specific flange adapter, as shown below.

Keep the vent path free of any obstruction, including but not limited to paint, dust, and

lubrication by mounting the transmitter so that the contaminants can drain away.

B7M

316

STM

316

B8M

Rosemount 3051S / 3051 / 2051 / 3095

Rosemount 1151

Flange Adapter

O-ring

Flange Adapter

O-ring

PTFE Based

Elastomer

PTFE

Elastomer

4107_QIG_RevCA.fm Page 7 Thursday, May 2, 2013 4:27 PM

May 2013

Quick Start Guide

Figure 7. Inline Gage low side pressure port

A. Low Side pressure port (atmospheric reference)

Step 2: Consider housing rotation

To improve field access to wiring or to better view the optional LCD display:

Step 3: Set the switches

Set Alarm and Security switch configuration before installation as shown in

Figure 8.

The Alarm switch sets the analog output alarm to high or low.

- Default alarm is high.

The Security switch allows ( ) or prevents ( ) any configuration of the

transmitter.

- Default security is off ( ).

Use the following procedure to change the switch configuration:

1. If the transmitter is installed, secure the loop, and remove power.

2. Remove the housing cover opposite the field terminal side. Do not remove the

instrument cover in explosive atmospheres when the circuit is live.

3. Slide the security and alarm switches into the preferred position using a small

screwdriver.

4. Reattach the transmitter cover. The cover must be fully engaged to comply

with explosion-proof requirements.

1. Loosen the housing rotation set screw.

2. First rotate the housing clockwise to the desired

location. If the desired location cannot be

achieved due to thread limit, rotate the housing

counter clockwise to the desired location (up to

360° from thread limit).

3. Re-tighten the housing rotation set screw.

Housing Rotation Set

Screw (5/64-inch)

4107_QIG_RevCA.fm Page 8 Thursday, May 2, 2013 4:27 PM

Quick Start Guide

May 2013

Figure 8. Transmitter electronics board

A. Alarm

B. Security

Step 4: Connect the wiring and power up

Shielded twisted pair cable should be used for best results. Use 24 AWG or larger

wire that does not exceed 5,000 feet (1500 meters) in length. If applicable, install

wiring with a drip loop. Arrange the drip loop so the bottom is lower than the

conduit connections and the transmitter housing.

Figure 9. Wiring the Transmitter (4-20 mA HART)

A. Vdc supply

B. RL250 (necessary for HART communication only)

Without LCD Meter With LCD/LOI Display

4107_QIG_RevCA.fm Page 9 Thursday, May 2, 2013 4:27 PM

May 2013

Quick Start Guide

Figure 10. Wiring the Transmitter (1-5 Vdc Low Power)

Use the following steps to wire the transmitter:

1. Remove the housing cover on the FIELD TERMINALS side.

2. Connect the Leads and shown in Figure 9 on page 9 or Figure 10.

3. Ground housing to fulfill local grounding regulations.

4. Ensure proper grounding. It is important that the instrument cable shield:

a. Be trimmed close and insulated from touching the transmitter housing.

b. Be connected to the next shield if cable is routed through a junction box.

c. Be connected to a good earth ground at the power supply end.

5. If transient protection is needed, refer to section “Grounding for Transient

Terminal Block” for grounding instructions.

6. Plug and seal unused conduit connections.

7. Replace the housing cover.

Installation of the transient protection terminal block does not provide transient protection

unless the 2051 case is properly grounded.

Do not run signal wiring in conduit or open trays with power wiring, or near heavy electrical

equipment.

Do not connect the powered signal wiring to the test terminals. Power could damage the test

diode in the terminal block.

Power

Supply

Voltmeter

4107_QIG_RevCA.fm Page 10 Thursday, May 2, 2013 4:27 PM

Otros manuales para Rosemount 2051 Wireless Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Transmisor de Emerson

Emerson

Emerson Rosemount 2051 Wireless Series Manual de usuario

Emerson

Emerson PT5-30L-FLR Manual de usuario

Emerson

Emerson Rosemount 2051HT Manual de usuario

Emerson

Emerson Rosemount 2051 Manual de usuario

Emerson

Emerson Rosemount 648 Manual de usuario

Emerson

Emerson Rosemount 8712C Guía de configuración

Emerson

Emerson Rosemount 702 Manual de usuario

Emerson

Emerson Rosemount 708 Manual de usuario

Emerson

Emerson Micro Motion 4200 Manual de usuario

Emerson

Emerson Rosemount MultiVariable 3051SMV Manual de usuario

Emerson

Emerson Rosemount 4088B MultiVariable Manual de usuario

Emerson

Emerson Rosemount 705 Manual de usuario

Emerson

Emerson Rosemount 3051 CF Series Manual de usuario

Emerson

Emerson Rosemount MCL-220 Manual de usuario

Emerson

Emerson Rosemount 5600 Series Manual operacional

Emerson

Emerson Rosemount 2051CF series Manual de usuario

Emerson

Emerson Rosemount 3051 Manual de usuario

Emerson

Emerson Fisher C1 Manual de usuario

Emerson

Emerson Rosemount 3144P Manual de usuario

Emerson

Emerson Rosemount 644 HART Manual de usuario

Emerson

Emerson Rosemount 648 Manual de usuario

Emerson

Emerson Rosemount 3300 Series Manual de usuario

Emerson

Emerson Rosemount 3051 Manual de usuario

Emerson

Emerson Micro Motion 5700 Guía rápida

Manuales populares de Transmisor de otras marcas

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manual del propietario

Honeywell

Honeywell 5816WMBR Manual de usuario

Kamstrup

Kamstrup READy MTU Instrucciones de funcionamiento

Omega

Omega ZW Series Manual de usuario

ABB

ABB Field 264H Guía

Alinco

Alinco DJ-V17T Manual de usuario

Dejero

Dejero EnGo 3x Manual de usuario

Rosemount

Rosemount 4600 Manual de usuario

Speaka Professional

Speaka Professional 2342740 Manual de usuario

trubomat

trubomat GAB 1000 Manual de usuario

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manual de usuario

Rondish

Rondish UT-11 Manual de usuario

MG 10JRE Manual de usuario

Burkert

Burkert 8177 Manual de usuario

Firetide

Firetide HotPort 3203 Manual

Tele Radio

Tele Radio T9-02 Manual de usuario

Rotronic

Rotronic HygroFlex HF3 Series Manual de usuario

Jamara

Jamara FCX6 Pro Tel Manual de usuario
