Emerson TOUCH SCREEN EMP588-4 Manual de usuario

User Guide EMP588-4

Touch Screen

IN THE BOX

MP3 Music and Video Player

USB 2.0 Cable

(for battery charging

and high speed data transfer)

CD Quick Start Guide

Stereo Headphones

4 GB

Quick Start and Media Transfer

EMP588-4

record

music

ebook

video

browser

settings

photos

record

music

ebook

video

browser

settings

photos

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications

Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

● Re-orient or relocate the receiving antenna.

● Increase the separation between the equipment and receiver.

● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the

equipment.

FCC INFORMATION

Congratulations on purchasing the Emerson MP3 Music & Video Player.

Before using the player, read this manual thoroughly and keep it for future reference.

This manual contains important safety information and correct operation instructions.

Trademarks and trade names used in this instruction manual are owned by their respective

companies or organizations.

Unauthorized duplication of any recordings whether downloaded from the internet or made from audio

CDs is a violation of copyright laws and international treaties.

The making of unauthorized copies of copy-protected material, may be an infringement of copyrights

and constitute a criminal offence. This equipment should not be used for such purposes.

INTRODUCTION

Always follow these basic safety precautions when using your player. This will reduce the risk of product damage and personal injury.

Do not disassemble, repair or modify the player by yourself. Refer servicing to qualified personnel.

This device contains a built- in battery, do not dispose of in fire.

In the event that the battery is leaking, do not handle the device with your bare hands. Contact the service center for help since the liquid may

remain in the player. If your body or clothes had contact with the battery liquid, wash it off thoroughly with water. Also, if some liquid gets into

your eyes, do not rub your eyes but immediately wash them with clean water, and consult a doctor.

Keep the player away from direct sunlight and any direct heat source.

Do not expose the unit to rain or moisture.

Do not use the player in dry environments to avoid static.

Never apply heavy impact on the player, or place it on a magnet.

Route the USB cable so that people and pets are not likely to trip over it.

Disconnect the USB cable from the computer when you do not use the player for a long time.

Clean only with a dry cloth. Make sure the player is turned off before cleaning. Do not use a liquid cleanser.

Be sure to back up your files to avoid data loss.

Precautions in using the headphones

Do not use the headphones while driving an automobile or riding a bicycle. It is dangerous, and against the

law. To avoid an accident, do not turn up the volume of the headphones too high while walking.

It is not recommended that you use the headphones at a high volume for an extended time, as this may

cause hearing damage.

IMPORTANT SAFETY PRECAUTIONS

4 GB internal memory

2.8” Touch screen

USB 2.0 high speed connection

Stores and plays music, video, and pictures

Text reading (txt format)

Digital voice recording (built-in microphone)



Built-in stereo speaker



Mini SD card slot (add up to 8 GB additional memory, mini SD card not included)

Folder navigation

Li-ion rechargeable battery

Supports MP3 / WMA / WAV music formats

MPEG - 4 (AVI) movie / video files

JPEG format picture browsing

FEATURES

Headphone jack

2. [ POWER ] - Power ON/Off switch / lock

3. Mini-USB jack

4. Speaker (listen to music or video without headphones)

10.

Touch Screen display

9. [+] -Volume up

Reset hole

6. [ M ] - Select an option / Return / Menu

7. [−]-Volume down

8. Mini SD card slot

LOCATIONS OF CONTROLS

System requirements

You computer system must meet the following specifications:

Pentium 200MHz or above

Microsoft Windows 2000/ME/XP/Vista

USB port supported

CONNECTING TO A COMPUTER

PC USB High Speed Connection Cable MP3 Player

PC connection

In orderto enjoy the multimedia capabilities of your MP3 Player, you have to first copy yourfavorite files from your PC to it’s internal memory.

Connect your MP3 Player to the computer using the included USB 2.0 cable. The device will be detected automatically without installing any driver.

Once detected, you can read/write to the device’s memory just as if you where using a regular disk drive.

Important: To avoid any data loss, always perform a safe USB device extraction before disconnecting the USB cable from the PC.

In Windows XP, forexample, you can find the safe extraction icon in the task barnext to the system clock.

Makesure yourcomputer is powered on, and followthe steps belowto connect the playerto yourcomputer.

1. Plugthelarger USB connector of the USB cable intothe USB port on thecomputer.

2. Plugtheotherend (small) of the USB cable to theplayer.

3. The computer system detects “New hardware” and starts to install the driver automatically. Wait for the system tofinish the installation.

When it hasfinished, “Emerson MP3” will be created in “My Computer”.

record

music

ebook

video

browser

settings

photos

Disconnectingthe USB cable

After completing the file transfer, please disconnect the USB cable the following way:

1. Double click the green arrow “Safely Remove Hardware” in the task bar on the bottom right of the window.

2. Select “USB Device” and click “Stop”.

3. When the “Stop a Hardware device” appears, click “OK” to disconnect the USB mass storage device, and unplug the player safely.

Your MP3 Playerhas an integrated rechargeable Li-ion battery. It is recommended to fully charge the playerbefore using it forthe first time.

Recharge the battery by connecting the player to a computer using the included USB 2.0 cable.

Charging time is between 3-5 hours, depending if the player is powered off or working. To keep the battery in good condition, we recommend not

charging it for more than 8 hours.

Battery level indication:

Important:

● Fully charge it before you use the player for the first time or when you haven’t used it for a long time.

● Charge the player immediately when the “Low battery” message is displayed.

● Do not over charge or discharge the player. Over charging or discharging will shorten the battery life.

● The battery could be over discharged if the player is not used for a long time (over three months). To avoid over discharge, fully charge the player

every three months and always keep the voltage of the battery above 50 %.

CHARGING THE BATTERY

MINI SD

Full Two-thirds full Half full Low Empty

The player supports MINI SD cards which enable you to add up to 8 GB of additional memory to your player

(mini SD card not included).

1. Insert the MINI SD card into the card slot with the metallic contacts facing towards the back of the player, and gently push it in

until it clicks.

2. To access the MINI SD card, select “browser” > mini SD.

3. Touch a file or folder to select it, and press the [ M] or button.

4. Press and HOLD the or [ M] button to get back to the main menu.

5. To remove the card, gently push it in until it pops out.

Note: ● Do not use force while inserting the memory card

● Do not remove the card during data transfers

INSERT MINI SD CARD

record

music

ebook

video

browser

settings

photos

Enter

Return
