Emerson HD7088 Manual de usuario

MP3 PERSONAL CD PLAYER

with 45 SECOND DIGITAL

ANTI-SKIP PROTECTION

OWNER’S MANUAL

HD7088

Visit our web site at www.emersonradio.com

HD7088 O/M.QXD 4/12/02 3:24 PM Page 26

BEFORE WE BEGIN

SAFETY PRECAUTIONS

DANGEROUS VOLTAGE

The lightning ﬂash with arrowhead symbol, within an equilateral

triangle is intended to alert the user to the presence of uninsulated

dangerous voltage within the product’s enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

ATTENTION

The exclamation point within an equilateral triangle is intended to

alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature accompanying

the appliance.

DANGER:

This product utilizes a Class 1 laser to read Compact Discs. This

laser Compact Disk Player is equipped with safety switches to

avoid exposure when the CD door is open and the safety interlocks

are defeated. Invisible and hazardous laser radiation when open

and interlock failed or defeated. Avoid direct exposure to beam.

Please do not attempt to defeat or bypass the safety switches.

Thank you.............................................................

For purchasing this state-of-the-art Emerson personal CD player with MP3

decoder. In addition to normal audio CD's, this player will also read discs

that have been recorded in CD-R, CD-RW, and compressed MP3 formats.

It has an electronic anti-skip memory of 45 seconds for normal CD's and up

to 120 seconds for MP3 encoded CD's. Since MP3 CD's can hold up to 10

hours of recorded music, this player allows you to search an MP3 CD by

File, by Directory, or even by individual song title. The large, 2-line scrolling

text display, and alpha-numeric keypad make all operations clear and

simple. Digital quality, lightweight stereo headphones, and an AC adapter,

are included.

Please read this manual carefully and completely to make sure you get the

maximum enjoyment from all the features included in this high tech CD player

and keep this manual for future reference.

The serial number of your unit is located on the bottom cabinet. Please

record the serial number in the space below for future reference.

Model No. HD7088 Serial No.____________________

HD7088 O/M.QXD 4/12/02 3:24 PM Page 1

SAFETY PRECAUTIONS

INFORMATION

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in

accordance with instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

• Do not open the CD compartment while the CD is rotating.

• Always keep the CD compartment closed when not in use.

• Keep all foreign objects out of the CD compartment.

• Place the unit on a stable surface.

• Avoid installing the unit is locations described below:

• Places exposed to direct sunlight or close to heat radiating

appliances such as electric heaters.

• On top of other stereo equipment that radiates too much heat.

• Placed lacking ventilation or dusty places.

• Places subject to constant vibration.

• Humid or moist places.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

HD7088 O/M.QXD 4/12/02 3:24 PM Page 2

LOCATION OF CONTROLS

Welcome MP3

01 004 MP3

819

Many of the buttons have dual functions, meaning they

will perform one function in the Normal mode and a

different function in the Search mode. The descriptions

on the following page will indicate the function while in

the Normal mode, followed by the function in the File

Search mode (if applicable).

HD7088 O/M.QXD 4/12/02 3:24 PM Page 3

LOCATION OF CONTROLS (CONTINUED)

No. Name Normal Mode File Search

1 Display LCD Function Display

2 Battery Insert Batteries, see

Compartment page 5

3 FILE SEARCH Search for MP3 files ENTER

4 DISPLAY MP3 Display select 0, CLEAR

5 FILE/DIR. Locate MP3 file 9, “Space”

6 RESUME CD: Continues playback from 8,W,X,Y,Z

last track played.

MP3: Continues playback from

last position played.

7 ANTI-SKIP Electronic Anti Skip Protection 7,T,U,V

(ESP) ensures continuous playback.

8 PROGRAM Memorizes & reviews programs. 6,P,Q,R,S

9 OPEN Switch Slide to the right to open the CD

compartment.

10 DC4.5V Jack Use with external Power Supply.

11 PLAY/PAUSE Turns the unit on. Also starts 1,A,B,C

and pauses playback.

12 STOP Stops CD play, clears a 2,D,E,F

program. Also turns the unit off.

13 LINE OUT Jack Connect to an external amplifier,

such as a car stereo.

14 PHONES Jack Connect 3.5mm headphones.

15 VOLUME Adjusts the volume.

16 SKIP/SEARCH+ Press & release:Skip forward. 3,G,H,I

Press & Hold: Search forward.

17 SKIP/SEARCH– Press & release:Skip backward. 4,J,K,L

Press & Hold: Search backward.

18 DBBS Turns BASS enhancement on/off.

19 PLAY MODE Cycles between RANDOM, 5,M,N,O

INTRO,REPEAT A,REPEAT1.

HD7088 O/M.QXD 4/12/02 3:24 PM Page 4

INSTALLATION

This CD player can be powered by either 2 “AA” batteries or the

provided AC adapter.

AC Operation

To operate the unit using AC power, connect the AC adapter

(included) to the DC4.5V jack on the rear of the CD Player and to

a wall outlet having 120V, 60Hz AC only. The batteries are

automatically disconnected when the AC adapter is used.

CAUTION: Use only the AC adapter provided with this unit.

Disconnect the adapter when not in use.

Battery Installation

Batteries need to be replaced when “LOW

BATTERY” appears in the display. Fresh Alkaline

batteries will last approximately 7 hours with Anti-

Skip off, and 6 Hours with Anti-Skip on.

1. Open the battery compartment door on the

bottom of the unit by sliding it out and then

lifting it. To prevent the possibility of

losing the cover, it cannot be removed.

2. Insert two (2) “AA” batteries (not included)

according to the polarity diagram. Alkaline

batteries are recommended for longer

playing time.

–

BATTERY PRECAUTIONS

Follow these precautions when using batteries in this device:

1. Do not mix different types of batteries together (e.g. Alkaline and

Carbon-zinc) or old batteries with fresh ones.

2. If the device is not to be used for a long period of time, remove the

batteries to prevent damage or injury from possible battery leakage.

3. Do not try to recharge batteries not intended to be recharged; they

can overheat and rupture. (Follow battery manufacturer’s directions.)

HD7088 O/M.QXD 4/12/02 3:24 PM Page 5

INSTALLATION (CONTINUED)

Playback Through a Home Audio System:

By using a home audio connection cable, superb CD sound

can be heard through your home audio system. Before

making any connections, turn off the power to all equipment.

Plug a connection cable (not included) between the LINE

OUT jack on the side of the CD player and the ampliﬁer’s CD

or AUX input jacks. (Do not connect it to the ampliﬁer’s

PHONO jacks.)

NOTE: If the CD player interferes with TV or radio reception,

move the CD player away from the TV or radio or turn off the

power to the CD player.

Headphones:

Connect the supplied headphones into the green PHONES

(Headphones) jack.

Use your common Sense when using headphones:

• Hearing Safety: Do not play your unit at high volume.

Hearing experts advise against continuous extended play.

If you experience a ringing in your ears, reduce the

volume or discontinue use.

• Traffic Safety: Do not use while operating a motor vehicle.

It may create a traffic hazard and it is illegal in many

areas. You should use extreme caution or temporarily

discontinue use in potentially hazardous situations. Even

if your headset is an open-air type designed to let you

hear outside sounds, do not turn up the volume so high

that you can’t hear what’s around you.

HD7088 O/M.QXD 4/12/02 3:24 PM Page 6

OPERATION

Press the PLAY/PAUSE button

❶

to turn the unit on.

Open the CD compartment lid by

sliding the OPEN switch

❷

Gently press a disc, label side up,

onto the spindle until it locks in

place.Close the CD compartment

lid; the total tracks and playing

time (and folders, if using MP3)

will appear in the display.

Adjust the VOLUME control ❶

and DBBS switch ❷ as

desired.

ESP

CD 01 00:15

When the disc is through playing,

it will stop. Press the STOP

button to stop the disc before it is

finished. Press the STOP button

again to turn the unit off.

Press the PLAY/PAUSE

button to begin playback; the

current track and elapsed

playing time (and folder, if

using MP3) will appear in the

display.

CD 01 00:12

ESP

TO INSERT AND PLAY A CD

This CD player is designed to play all kinds of Audio Discs and

MP3 CD ROMS, such as CD recordables and rewritables. Do

not try to play CDI, CDV, DVD or computer CDs.

HD7088 O/M.QXD 4/12/02 3:24 PM Page 7

OPERATION (CONTINUED)

CD PLAYBACK NOTES:

• See page 15 for more information on MP3’s.

• When recording (“burning”) CDs, make sure the session is “finalized”,

or simply record (“burn” only one session). You can find more

information on “finalizing” in your CD recorder’s manual.

• This unit is capable of playing standard CDs or 3” singles; no adapter

is required.

• If a disc is inserted incorrectly, dirty, damaged or not present at all,

“no disc” will appear in the display.

• If a disc is not recorded properly, “disc error” will appear in the

display.

• Playback will stop when you open the CD compartment, but it is not

recommended to open the compartment before the STOP button is

pressed.

• If there is no activity for 60 seconds, the unit will turn itself off to save

the batteries.

• It may take 10 to 30 seconds for the player to read an MP3 CD and

begin playback, depending on the number of tracks burned on the CD.

During CD playback, if you

wish to pause the disc

momentarily, press the

PLAY/PAUSE button

. Playback

stops but the disc continues to

spin and the elapsed time

flashes in the Display.

CD 01 00:12

ESP

Press the

PLAY/PAUSE

button

again to release Pause

and resume playback. The

sound returns and the

elapsed time in the Display

stops flashing.

CD 01 00:12

ESP

CD PAUSE CONTROL

HD7088 O/M.QXD 4/12/02 3:24 PM Page 8

OPERATION (CONTINUED)

TO BEGIN PLAYBACK FROM A SPECIFIC TRACK

FORWARD/REVERSE SKIP TRACK

After you insert the disc into

the CD player and the total

number of tracks appear on

the display, you may press

either the SKIP/SEARCH + or

– buttons to select a specific

track for playback.

Welcome CD

CD 03 61:34

When the desired track

number (and file number if

using MP3) appears in the

display, press the PLAY/

PAUSE button. Playback will

begin with the track (or file)

you selected.

CD 03 00:10

ESP

During playback, press and

release the SKIP/SEARCH +

button once to advance the player

to the beginning of the next track.

Press the SKIP/SEARCH +

button repeatedly to advance the

player to higher number tracks.

CD 05 00:00

ESP

During playback, press and release

the SKIP/SEARCH – button once to

move the player back to the

beginning of the currently playing

track. Press the SKIP/SEARCH –

button repeatedly to move the player

back to lower numbered tracks.

CD 02 00:00

ESP

HD7088 O/M.QXD 4/12/02 3:24 PM Page 9

Tabla de contenidos

Otros manuales de Reproductor de MP3 de Emerson

Emerson

Emerson HD7288 Manual de usuario

Emerson

Emerson MP200 Manual de usuario

Emerson

Emerson Barbie Petal BAR900 Manual de usuario

Emerson

Emerson EMP4163-1 Manual de usuario

Emerson

Emerson EMP413-2 Manual de usuario

Emerson

Emerson EMP414-4 Manual de usuario

Emerson

Emerson Research MP530 Manual de usuario

Emerson

Emerson EMP3550-4 Manual de usuario

Emerson

Emerson Research MP120 Manual de usuario

Emerson

Emerson EMP312-2 Manual de usuario

Emerson

Emerson EMP312-1 Manual de usuario

Emerson

Emerson MP100 Manual de usuario

Emerson

Emerson MP3 MUSIC & VIDEO PLAYER EMP517-2 Manual de usuario

Emerson

Emerson MP120 Manual de usuario

Emerson

Emerson MP205 Manual de usuario

Emerson

Emerson EMP3550-4 Manual de usuario

Emerson

Emerson Research MP250 Manual de usuario

Emerson

Emerson EMP312-1 Manual de usuario

Emerson

Emerson PD3689 Manual de usuario

Emerson

Emerson EMP513-4 Manual de usuario

Emerson

Emerson EMP312-2 Manual de usuario

Emerson

Emerson EMP516-2 Manual de usuario

Emerson

Emerson EMP415-2 Manual de usuario

Emerson

Emerson EMP180C-4 Manual de usuario

Manuales populares de Reproductor de MP3 de otras marcas

Blaupunkt

Blaupunkt Compact Drive MP3 Manual de usuario

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manual de usuario

Meizu Electronic Technology

Meizu Electronic Technology E5 Manual de usuario

Naxa

Naxa NMV-173NX Manual de usuario

Philips

Philips PSA250 Manual de usuario

Zipy

Zipy go! Waving Manual de usuario

Sylvania

Sylvania SMPK4068 Manual de usuario

Sony

Sony NW-MS7 - Memory Stick Walkman Manual de usuario

Irradio

Irradio RF-42UC Manual de usuario

NABAIJI

NABAIJI SWIM MUSIC 100 Manual de usuario

Laser

Laser MP3-A9-4GB Manual de usuario

Samsung

Samsung YP-T7F Manual de usuario

Savant

Savant SMS-1001-00 Guía de referencia rápida

Trevi

Trevi XP 71 BT Manual de usuario

AGPtek

AGPtek C2 Manual de usuario

MobiBlu

MobiBlu DAH-1500i Manual de usuario

Denver

Denver MPS-201 Manual de usuario

Steren

Steren MP3-002 Manual de usuario
