Contents

eMachines Notebook Series

Quick Guide

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

eMachines Notebook Series Quick Guide

Original Issue: 03/2011

English

First things first

We would like to thank you for making an eMachines notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your eMachines notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your computer.

The eMachines Generic User Guide contains useful information applying to all

models in the eMachines product range. It covers basic topics such as system

recovery, using the keyboard, audio, etc. Please understand that due to its nature,

the eMachines Generic User Guide will occasionally refer to functions or features

which are only contained in certain models, but not necessarily in the model you

have purchased. Such instances are marked in the text with language such as "only

for certain models".

This Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the eMachines Generic User Guide,which contains detailed

information on such subjects as system utilities, data recovery, expansion options

and troubleshooting. In addition it contains warranty information and the general

regulations and safety notices for your notebook. It is available in Portable

Document Format (PDF) and comes preloaded on your notebook. Follow these

steps to access it:

1 Click on Start > All Programs > eMachines Documentation.

2 Click on eMachines Generic User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on eMachines Generic User

Guide will run the Adobe Reader setup program first. Follow the

instructions on the screen to complete the installation. For instructions

on how to use Adobe Reader, access the Help and Support menu.

English

Your eMachines notebook tour

After setting up your computer as illustrated in the setup poster, let us show you

around your new eMachines notebook.

Top view

#Icon Item Description

1 Integrated webcam Web camera for video communication.

2 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output (configuration may

vary by model).

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other key in

the hotkey combination.

3 Power button Turns the computer on and off.

4 Keyboard For entering data into your computer.

5 Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

6 Click buttons (left

and right)

The left and right buttons function like the

left and right mouse buttons.

7 Microphone Internal microphone for sound recording.

8 Power indicator Indicates the computer's power status.

Battery indicator Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

9 Speakers Deliver stereo audio output.

Hotkey Icon Function Description

<Fn> + <F3> Communication Enables/disables the computer’s

communication devices.

<Fn> + <F4> Sleep Puts the computer in Sleep mode.

<Fn> + <F5> Display toggle Switches display output between the

display screen, external monitor (if

connected) and both.

<Fn> + <F6> Screen blank Turns the display screen backlight off

to save power. Press any key to

return.

<Fn> + <F7> Touchpad toggle Turns the internal touchpad on and off.

#Icon Item Description

English

Closed front view

<Fn> + <F8> Speaker toggle Turns the speakers on and off.

<Fn> + < > Brightness up Increases the screen brightness.

<Fn> + < > Brightness down Decreases the screen brightness.

<Fn> + < > Volume up Increases the sound volume.

<Fn> + < > Volume down Decreases the sound volume.

<Fn> +

<Home>

Play/Pause Play or pause a selected media file.

<Fn> +

<Pg Up>

Stop Stop playing the selected media file.

<Fn> +

<Pg Dn>

Previous Return to the previous media file.

<Fn> +

<End>

Next Jump to the next media file.

#Icon Item Description

1Microphone jack Accepts inputs from external

microphones.

Headphones/speaker

jack

Connects to audio devices

(e.g., speakers, headphones).

2 2-in-1 card reader Accepts Secure Digital (SD),

MultiMediaCard (MMC).

Note: Push to remove/install the card.

Only one card can operate at any time.

Hotkey Icon Function Description

English

Left view

#Icon Item Description

1 Kensington lock slot Connects to a Kensington-compatible

computer security lock.

Note: Wrap the computer security lock

cable around an immovable object such as

a table or handle of a locked drawer. Insert

the lock into the notch and turn the key to

secure the lock. Some keyless models are

also available.

2 DC-in jack Connects to an AC adapter.

3 External display (VGA)

port

Connects to a display device (e.g., external

monitor, LCD projector).

4 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-

based network.

5 USB 2.0 port Connects to USB 2.0 devices (e.g., USB

mouse, USB camera).

21345

English

Right view

#Icon Item Description

1 USB 2.0 ports Connect to USB 2.0 devices (e.g., USB

mouse, USB camera).

2 Optical drive Internal optical drive; accepts CDs or

DVDs.

3 Optical disk access

indicator

Lights up when the optical drive is

active.

4 Optical drive eject

button

Ejects the optical disk from the drive.

5 Emergency eject hole Ejects the optical drive tray when the

computer is turned off.

Note: Insert a paper clip to the

emergency eject hole to eject the optical

drive tray when the computer is off.

21345
