Elo TouchSystems 0702L Manual de usuario

Revision A

P/N E915161

www.elotouch.com

Quick Installation Guide

0702L Touchmonitor

The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Afﬁliates (collectively “Elo”) makes no

representations or warranties with respect to the contents herein, and speciﬁcally disclaims any implied warranties of merchantability or ﬁtness for a

particular purpose. Elo reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation

of Elo to notify any person of such revisions or changes.

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer

language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior

written permission of Elo Touch Solutions, Inc.

Elo and the Elo logo are either trademarks or registered trademarks of Elo Touch Solutions, Inc..

North America

800-ELO-TOUCH

Tel +1 408 597 8000

Fax +1 408 597 8050

[email protected]

Europe

Tel +32 (0)16 70 45 00

Fax +32 (0)16 70 45 49

[email protected]

Asia-Paciﬁc

Tel +86 (21) 3329 1385

Fax +86 (21) 3329 1400

[email protected]

Latin America

Tel +52 55 2281-6958

EloSales.LAT[email protected]

Elo Touch Solutions Technical Support

Online self-help: www.elotouch.com/support

Power Button Micro USB connection Serial Number

75mm mounting interface

Download and install the latest DisplayLink

drivers at www.elotouch.com/support.

Note: DisplayLink driver installation requires

another display to be functioning during

driver installation because the 0702L will not

function without the drivers installed.

Connect the micro USB cable. Ensure the

rubber gasket (red) is all the way inside the

cable cover area.

3Install the cable cover by installing the top

side rst and rotating it down. Secure the door

with the M3 screw included.

Monitor can be mounted to any standard

75mm x 75mm VESA mounting bracket

using four M4x8mm screws.

Connect the Data Connector of the Y-Cable to the host PC USB port.

Note: Some computers also require connecting the AUX Power

connector to the host PC.

AUX Power Connector

75mm

Data Connector

Go to www.elotouch.com/support to download user manual.
