1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged 8 years
and above and by persons with reduced capabilities
provided that they have been given instruction and/or
supervision regarding the safe use of the appliance
and understand the potential hazards involved.
•Do not let children play with the appliance.
•Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance door
when it is open.
•If the appliance has a child safety device, this should
be activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•Do not exceed the maximum load of 7 kg (refer to the
"Programme chart" chapter).
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
•The ventilation opening in the base (if applicable) must
not be covered by a carpet, mat, or any floor covering.
ENGLISH 3
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging and the
transit bolts.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in
future they must be reattached to lock
the drum to prevent internal damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• The floor area where the appliance is
to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Adjust the feet to have the necessary
space between the appliance and the
flooring.
• Do not install the appliance where the
appliance door cannot be fully
opened.
2.2 Electrical connection
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
www.electrolux.com4
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• This appliance complies with the
E.E.C. Directives.
2.3 Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
2.4 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• This appliance is for household use
only.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Make sure that all metal objects are
removed from the laundry.
• Do not put a container to collect
possible water leakage under the
appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
• Do not touch the glass door while a
programme is in operation. The glass
can get hot.
2.5 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
3. PRODUCT DESCRIPTION
3.1 Appliance overview
7 8 9
10
1 2
3
4
5
6
ENGLISH 5
1Detergent dispenser
2Control panel
3Door handle
4Rating plate
5Drain pump filter
6Feet for levelling the appliance
7Water drain hose
8Mains cable
9Water inlet hose connection
10 Feet for levelling the appliance
3.2 How to activate the child
safety device
This device prevents children or pets
from being closed in the drum.
Turn the device clockwise, until the
groove is horizontal.
You cannot close the door.
To close the door, turn the device
anticlockwise until the groove is vertical.
4. CONTROL PANEL
4.1 Control panel description
1 2 34 5 76 8 9 10
1Programme knob
2Temperature button
• Cold position
3Spin button
• Night Cycle function
• Rinse Hold function
4Easy Iron button
5Extra Rinse button
6Delay Start button
7Display
8Time Manager buttons
9Door locked indicator
10 Start/Pause button
www.electrolux.com6
4.2 Display The display shows the following
information:
ASoil degree indicators:
Intensive
Normal
Daily
Light
Quick
Quick
Refresh
Super Refresh
When you select a programme, the display shows the indicator of the soil de‐
gree automatically proposed by the appliance.
BChild safety lock (see «Settings» chapter).
ENGLISH 7
A B C
DE
CDigit
area:
•Duration of the selected programme
After you select a programme, the duration is displayed in hours and
minutes (e. g. ). The duration is calculated automatically on
the basis of the maximum recommended load for each type of fabric.
After the programme start, the time remaining is updated every mi‐
nute.
•Delayed start
The selected delay appears for a few seconds, then the display
shows the duration of the selected programme again.
•Alarm codes
In the event of operating problems, some alarm codes can be dis‐
played, e. g. (see chapter «Troubleshooting»).
•Incorrect option selection
If you set an option not compatible with the selected wash pro‐
gramme, the message shows up for a few seconds and the
red indicator of button Start/Pause starts flashing.
•End of programme
When the programme has finished, three flashing zeros are
displayed and the indicator of button Start/Pause goes out.
If the indicator goes off, you can open the door.
DWashing programme phase indicators:
Wash
Rinses
Drain
Spin
By selecting the wash programme, the washing programme indicators corre‐
sponding to the various phases making up the programme are shown.
After you have pressed the Start/Pause button, only the indicator of the running
phase stays on.
EDuring the washing cycle the display shows a temperature icon indicat‐
ing that the appliance has started the heating phase of the water in the
tub.
www.electrolux.com8
5. PROGRAMMES
5.1 Programme Chart
Programme
Temperature range
Maximum
load
Reduced
load1)
Maximum
spin speed
Programme description
(Type of load and soil level)
Cottons
90°C - (Cold)
7 kg
3.5 kg
1400 rpm
White cotton and coloured cotton. Normal soil
and light soil.
+ Prewash
+ Prewash
90°C - (Cold)
7 kg
3.5 kg
1400 rpm
White cotton and coloured cotton. Heavy soil
and normal soil.
Synthetics
60°C - (Cold)
3 kg
1.5 kg
900 rpm
Synthetic items or mixed fabric items. Normal
soil.
+ Prewash
+ Prewash
60°C - (Cold)
3 kg
1.5 kg
900 rpm
Synthetic items or mixed fabric items. Heavy
soil and normal soil.
Delicates
40°C - (Cold)
3 kg
1.5 kg
700 rpm
Delicate fabrics such as acrylics, viscose,
polyester items. Normal soil.
Spin
7 kg
1400 rpm
To spin the laundry and to drain the water in the
drum. All fabrics, except woollens and deli‐
cate fabrics.
Drain
7 kg To drain the water in the drum. All fabrics.
Rinse
7 kg
1400 rpm
To rinse and spin the laundry. All fabrics, ex‐
cept woollens and very delicate fabrics. Reduce
the spin speed accordingly to the type of laun‐
dry.
Mix 20°
20°C
3 kg
900 rpm
Special programme for cotton, synthetic and
mixed fabrics lightly soiled. Select this pro‐
gramme to reduce the energy consumption.
Make sure that the detergent is suitable for low
temperatures in order to have good washing re‐
sults2).
ENGLISH 9
Programme
Temperature range
Maximum
load
Reduced
load1)
Maximum
spin speed
Programme description
(Type of load and soil level)
Silk
30°C - (Cold)
1 kg
700 rpm
Special programme for silk and mixed synthet‐
ic items.
Handwash
40°C - (Cold)
2 kg
900 rpm
Machine washable wool, hand washable
wool and delicate fabrics with «hand washing»
care symbol.3)
Wool/Handwash
40°C - (Cold)
2 kg
900 rpm
Machine washable wool, hand washable
wool and delicate fabrics with «hand washing»
care symbol.3)
Cottons+Prewash
90°C - 40°C
7 kg
1400 rpm
White cotton and fast-coloured cotton. Nor‐
mal soil with stains. The energy consumption
decreases and the time of the washing pro‐
gramme is extended.
Cottons Eco4)
90°C - 40°C
7 kg
1400 rpm
White cotton and fast-coloured cotton. Nor‐
mal soil. The energy consumption decreases
and the time of the washing programme is ex‐
tended.
1) If you select the Super Quick, Refresh and Super Refresh option by pressing buttons
Time Manager, we recommend that you reduce the maximum load as indicated in the pro‐
grammes for cottons, synthetics and delicates. Full loading is possible however with some‐
what reduced cleaning results.
2) The appliance performs the short heating phase if the water temperature is below 20°C.
The appliance can show the temperature setting as “cold”.
3) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the
drum doesn't rotate or doesn't rotate properly, but this is normal for this programme.
4) Standard programmes for the Energy Label consumption values. According to regu‐
lation 1061/2010, these programmes with temperature selected 60°C and with temperature
selected 40°C are respectively the «Standard 60°C cotton programme» and the «Standard
40°C cotton programme». They are the most efficient programmes in terms of combined en‐
ergy and water consumption for washing normally soiled cotton laundry.
The water temperature of the washing phase may differ from the temperature
declared for the selected programme.
Programme options compatibility
Programme
■ ■ ■ ■ ■ ■ ■
www.electrolux.com10
Otros manuales para EWG 147410 W
1
Tabla de contenidos
Otros manuales de Arandela de Electrolux
Electrolux
Electrolux EW 502 F Manual de usuario
Electrolux
Electrolux EWF1408B1WA Manual de usuario
Electrolux
Electrolux EIFLW55HIW - 27" Front-Load Washer Manual de usuario
Electrolux
Electrolux EWF12853 Manual de usuario
Electrolux
Electrolux EWF 890 Manual de usuario
Electrolux
Electrolux EWT 1215 Manual de usuario
Electrolux
Electrolux W455H Manual de usuario
Electrolux
Electrolux EWF 1210 Manual de usuario
Electrolux
Electrolux EW6T5621AF Manual de usuario
Electrolux
Electrolux EWS 31256 EDU Manual de usuario
Electrolux
Electrolux WE170P Manual de usuario
Electrolux
Electrolux EW6S347SI Manual de usuario
Electrolux
Electrolux EWF 1649 Manual de usuario
Electrolux
Electrolux EW 1026F Manual de usuario
Electrolux
Electrolux EW6F5549E4 Manual de usuario
Electrolux
Electrolux WH1128 Manual de instrucciones
Electrolux
Electrolux EWT 106411 W Manual de usuario
Electrolux
Electrolux WASL2E202 Manual de usuario
Electrolux
Electrolux EW6FN528WU Manual de usuario
Electrolux
Electrolux EW7F248S Manual de usuario
