Essential Iron

1700 W

LX1700

Instruction Manual

Important safety instructions

• Only use the iron for its intended use—it is designed for household use only.

• To avoid the risk of electric shock, do not immerse the iron in water or other liquids.

• Always turn the iron OFF before plugging into or unplugging from the electrical outlet.

• Never pull on the cord to unplug; instead, grasp the plug and pull on it to remove from

outlet..

• Do not let the cord touch hot surfaces.

• Always disconnect iron from electrical outlet before lling iron with water, emptying

iron from water, or when iron is not in use.

• Do not use the iron if the cord or the appliance itself shows visible damage, or if the

appliance has been dropped or is leaking.

• If the iron seems damaged or malfunctions, take it to a qualied serviceman for

examination and repair. Do not disassemble yourself as incorrect reassembly may

result in a risk of electric shock.

• Burns can occur from touching hot metal parts, hot water or steam. Use caution

when turning the iron upside down—there may be hot water in the water tank.

• Never release steam facing people.

• To avoid a circuit overload, do not operate the iron on the same circuit with another

high wattage appliance.

• If it is absolutely necessary to use an extension cord, a cord with an ampere rating

equal to or greater than the maximum rating of the iron shall be used. Using a

cord rated for less amperage can result in a risk of re or electric shock due to

overheating. Care should be taken to arrange the cord so that it cannot be pulled on

or tripped over.

• The iron must be used and rested on a stable surface.

• The iron must not be left unattended while it is connected to the supply mains.

• Close supervision is required for any appliance used near children. Do not leave the

iron unattended while it is plugged into the outlet or when it is on an ironing board.

• Children should be supervised to ensure that they do not play with appliance. Parents

must warn children not to touch hot appliance parts.

• This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision and instructions concerning use of this appliance

by a person responsible for their safety.

Main components and accessories

Using

• Remove all labels and protective lms prior to use.

• Before ironing your clothes or fabric for the rst time, it is recommended that you heat

the iron and use it on a damp piece of cloth for a few minutes. This will ensure that any

residue left over from the manufacturing process is burnt o the ceramic soleplate and

won’t transfer to your clothes.

• You may notice a slight odor and some steam coming out of the iron when using it for

the rst time. This is normal and should disappear quickly.

1.Front cover

2.Nozzle

3.Water inlet cover

4.Steam burst

5.Spray button

6.Steam push button

7.Upper handle

8.Temperature

9.Conduit

10.Rear cover

11.Lower handle

12.Lamp

13.Water tank

14.Cleaning button

15.Decoration board

16.Skirt

17.soleplate

Instruction Manual LX1700

Before use, please read all the instructions carefully and retain for future reference.

Steam Ironing

1. To begin steam ironing, turn the steam knob on to , then ll the tank with water

using the water cup. Prevent water overow by keeping iron erect when lling and by not

exceeding the MAX line. It is best to use distilled water.

o position

max position

2. Put the plug into the outlet and adjust the temperature regulator to a suitable temperature

according to the fabric.

3. Wait until the lights turn o, push the steam knob, and then you may begin ironing.

4. Pay attention to the water in the water tank. When the water is almost running out you

must unplug the iron and rell the tank.

5. After you nish ironing, unplug the iron immediately. Turn the steam knob to setting,

empty the water tank and place the iron in an upright position.

6. Put the plug into the outlet again and power on for 5 minutes so that any remaining

water should evaporate. Power o and store away properly.

Steam Jet Function

• Turn o the steam knob rst.

• Turn the temperature regulator to MAX position (otherwise you may see water leakage).

• After the indicator goes o, press the steam jet button.

• Press the button once every second for a steam release.

Water Spray

• Ensure that the water tank has enough water in it.

• Push the water spray button four times to make the clothes wet. Spray function is used

for ironing thick cotton or hemp fabric.

• Water spray can remove wrinkles.

Auto Shut-o Feature

• The red light will be on while the iron is heating.

• Once iron is heated, the light will turn o.

• When the iron is in a horizontal position, it will power o automatically after 30 seconds

• When the iron is in a vertical position, it will power o automatically after 8 minutes

Note:

When ironing heat reactive fabrics, it is recommended to put a layer of cloth onto the clothing

you are about to iron to prevent clothes from damage.

Sort garments according to their suitable ironing temperatures. Start ironing lower temperature

clothing rst and adjust the temperature regulator as needed.

Synthetics/silk (low temperature)

Wool (medium temperature)

Cotton/linen (high temperature)

Cleaning

• Make sure the appliance is unplugged and the soleplate completely cool before cleaning.

• Do not use any rough or corrosive chemicals to wipe the soleplate.

• Any residue or specks can be wiped o using a cloth with vinegar or water.

• A needle or toothpick can be helpful to clean the steam holes on the soleplate.

• Avoid scratching the soleplate with hard objects.

Storage

• Ensure that the iron is completely cool and that the water tank is empty before storing.

• Keep the steam knob in the OFF position.

• Use the Velcro to wrap up the cord.

• Do not discard the cardboard in the box the iron was packaged in to prevent corrosion

• Heat resistant mat included to enable storing the iron while it is still warm.

Before use, please read the instruction carefully and store it properly.

Basic instructions

1. Fill the water to the "MAX" line and plug the iron into the mains.

2. There are total 4 temperature setting. Press Temperature up button or Temperature down

button to select suitable temperature according to the fabric.

When the temperature is going up, the selected temperature on screen will be blinking until

the solephate temperature reached the selected temperature.

3. Then you can use it to iron your clothes with steam by pressing the steam activation

trigger. The higher temperature setting, the larger steam output. The max steam output is

about 40g/min

If the temprature has not reached the selected temperature, press the steam trigger will be

no use, it can avoid the water drip.

4. Auto shut o function (if any)

It will swich the iron o automatically if it hasn't been used for a period of time - usually after

8 minutes idle in the upright position and 30 second when resting on the soleplate.

Move the iron slightly or press any button, it will return To the temperature that it had before

being switched o.

Using vertically - for garment and fabric steaming

1. If using the Textile Brush attachment carefully slide it over the tip of iron before turning on.

2. Once plugged in, set to a high temperature, either Cotton or Max settings.

3. Wait for the blinking to turn o. Pick up the iron and hold vertically, with the tip tilted slightly

forward.

4. Press the steam trigger and move the iron up and down the garment or fabric you want

to steam.

5. If the steam output declines, simply tilt the iron forward into a horizontal position and

then tilt back vertical to continue

DO NOT tilt the iron upside down while using vertically.

Instruction Manual

LX1700

After ironing

1. Allow to cool completely. Unplug and empty the Water Tank.

2. Clean the Ceramic Plate and the Cover Plate with a damp cloth, removing any residues.

3. Store vertically on a clean, dry, at surface, with the cable wrapped around the Iron.

Technical Informations

After each use

1. Pour out the residual water inside the water tank, turn on the steam switch, and spray the

water vapor inside the machine.

2. Turn o the steam switch and pull the power cord out of the outlet.

3. Place the machine on a at desktop and wait for the product to be properly accepted

after cooling.

Nursing, cleaning and storage

(1) Do not use rough or corrosive detergents or solvents. (2) Please do not immerse the

steam scalding machine in water or other liquids. (3) Don't drop, throw it or try to bend it.

(4) Please do not attempt to disassemble the decomposition products. (5) Empty the water

tank after each use. (6) Avoid storing products in damp places. (7) Do not close to the

heat source or let the sun shine directly on the product. (8) Always ensure that the steam

outlet hole is clean, scale-free and not blocked. (9) It is recommended to store the ironing

machine in a at position, such as in a drawer.

Power

Water Tank size

Wattage

Model

220-240V-50-60Hz

320ml

1700W

LX1700C

Warranty clause

When you need normal consultation, please contact us, and provide a warranty card or

electronic order number, we will provide services free of charge; reect the failure, tell the

accurate fault phenomenon, we will serve you as soon as possible.

We oer a one-year warranty for our products. The warranty period is calculated from the

date of purchase.

During the warranty period, we will replace the parts or the whole product according to

the situation. The accessories of products, such as accessories, packaging, etc. are not

covered by the warranty.

To apply for warranty, the product mainframe must be submitted to the designated

maintenance point together with the certicates that can prove the purchase date (e.g.

purchase certicate, invoice or network electronic order number, etc.).

The above warranty does not include the following:

(1) Any damage caused by improper use (e.g. incorrect use of current, voltage, insertion of

products into inappropriate sockets or man-made damage, etc.).

(2) Faults caused by natural disasters.

(3) Troubles caused by repairs by non-company maintenance personnel.

(4) The product aging and wear caused by normal use, but it has little eect on the use

function of the product.

(5) The warranty service will be terminated immediately after the product has been

repaired by unauthorized personnel or used parts not originally manufactured.

(6) Other non-product problems and faults caused by external factors.

Within the scope of the law, the right of nal interpretation of the above clauses belongs to

our company.

Product warranty card

Main technical parameters

Product model: LX1700 Water tank capacity: 320 ml Steam volume: 10-40g/min

Quality

Sustainability

Your new Electrolux garment care supertool

is designed with sustainability in mind.

Visit https://www.electroluxgroup.com/en/ to learn more about our

Shape living for the better initiative

Concept

Our key design philosophy is to achieve top performance

with the lowest energy demand.

Carefully calibrated power generates more steam with less

electricity, which saves on runtime, yields smoother clothing

in fewer passes, delivers a longer-lasting press, rejuvenates

clothing to retain newness, and ultimately keeps energy and

garments from waste.

Components

You only get out what you put in, so we insist on parts made

with more sustainable materials and processes.

In line with the SDGs created by the UN, we use innovative

materials that help both performance and planet, such as

post-consumer rubber cords, repurposed plastics, and

recyclable ceramicized soleplates that oer even edge-to-

edge heating.

Package

This box is for keeps. Made of the nest recycled materials,

it features an original, reusable design.

An exclusive, heat-resistant inner pad enables you to safely

store your garment care tool even while it’s hot. And the

striking, inkless box turns into a valuable, décor-friendly

storage container you will enjoy keeping in your home,

and out of landfills.

Questions comments?

Contact Smartekusa at 1-877-678-6232

12 Hinsdale Street

Brooklyn NY 11207

Electrolux is a registered trademark used under license from AB Electrolux (publ.)

A box worth keeping in the family

Tabla de contenidos

Otros manuales de Hierro de Electrolux

Electrolux

Electrolux SSI 7020 INOX Manual de usuario

Electrolux

Electrolux EDB1720 Manual de usuario

Electrolux

Electrolux Zanussi Professional N 700 Manual de usuario

Electrolux

Electrolux 4SafetyPRECISION EDB61XX Manual de usuario

Electrolux

Electrolux FIT1 Manual de programación

Electrolux

Electrolux IC6 48 FFS Series Manual de usuario

Electrolux

Electrolux Perfect Set Gas Range Manual de usuario

Electrolux

Electrolux EDB1730 Manual de usuario

Electrolux

Electrolux IC44832 LF Manual de usuario

Electrolux

Electrolux ESI700 Series Manual de usuario

Electrolux

Electrolux ESI6157 Manual de usuario

Electrolux

Electrolux ESS4105 Manual de usuario

Electrolux

Electrolux Refine 700 Manual de usuario

Electrolux

Electrolux UltraSteam ESI6123 Manual de usuario

Electrolux

Electrolux EasyLine ESI4005 Manual de usuario

Electrolux

Electrolux EDB16 Series Manual de usuario

Electrolux

Electrolux AEG DB 75 Series Manual de usuario

Electrolux

Electrolux Refine 700 E7SI1-4WB Manual de usuario

Electrolux

Electrolux EasyLine EDI1004 Manual de usuario

Electrolux

Electrolux MOTION EDBT800 Manual de usuario

Electrolux

Electrolux ESI 61 Series Manual de usuario

Electrolux

Electrolux MOTION EDBT800 Manual de usuario

Electrolux

Electrolux PERFECTGLIDE ELFI18K7MB Manual de usuario

Electrolux

Electrolux EasyLine ESI4007 Manual de usuario

Manuales populares de Hierro de otras marcas

Clatronic

Clatronic DB 3703 Manual de usuario

TEFAL

TEFAL FV4093Z0 Manual de usuario

Gorenje

Gorenje SIH 2200 BS Manual de usuario

Philips

Philips GC6012 Manual de usuario

Bosch

Bosch 2 Series Manual de usuario

Riffel

Riffel Catena KB-819 Manual de usuario

Texi

Texi Hestia Manual de usuario

Maxwell

Maxwell MW-3010 Manual de usuario

TREVIDEA

TREVIDEA Girmi ST60 Manual de usuario

Philips

Philips HI5914/30 Manual de usuario

Primula

Primula Vapormat Manual de usuario

Magio

Magio MG-541 Manual de usuario

Scarlett

Scarlett SC-1334S Manual de usuario

Bosch

Bosch Sensixx B22L Manual de usuario

Philips

Philips GC651 Manual de usuario

Vitek

Vitek VT-1247 VT Manual de usuario

Cleanmaxx

Cleanmaxx 3397 Manual de usuario

Philips

Philips GC800 Manual de usuario
