Elari FixiTime Manual de usuario
FIXITIME SMARTWATCH/MOBILE PHONE
WITH GPS/LBSTRACKING
USER MANUAL
Product description
1. Screen
Displays hour, date, level of the battery charge, intensity of the
signal of the mobile network.
2. Key1
Click once to accept the incoming call.
During the conversation click it to increase the volume. Hold
down this button for 3 seconds to call a particular contact.
3. The power button
On/o: press and hold during 2 seconds.
Theendof conversation:pressthebuttonduringtheconvers
ation
Rejectacall:pressthebuttonduringthe call
Displaydate/time:pressthebutton 1 time
Displaythesignalof the mobilenetworkandthebatterylevel:
double press
Display GPSsignallevel:press 3 times
4. Hotkey2
Press1timetoaccept theincomingcall.
Duringacall,pressthebutton
todecreasethevolume.
Press andholdfor3seconds tocall
a particular contact.
5. SOS key
Press andhold for3seconds
tosendanalarmsignalto family mem-
bers(set up via Wherecomapplication).
6. SlotforaSIMcard
7. MicroUSBport
UseonlytheUSBcableprovidedin the
package forchargingofthewatch.
Quick Start Guide
Insert the SIM card (microSIM)
Type of the SIM card: microSIM, GSM 900/1800/850/1900, with
GPRS internet access.
Insert the SIM card with the chip facing upwards, as shown
on the picture. Restart the watch after installing the SIM card
and make there is cellular signal. If you see the sign «x»
intheupperleftcornerofthe screen,inserttheSIMcardagain.
Downloading and installing Wherecom
Method 1. Scan the QR code:
Method 2.
For iOS: nd the Wherecom application in App Store
For Android: nd the Wherecom application in Google Play
For iOS For Android
Opening Wherecom on your smartphone and signing up
To run the application for the rst time you need to create an
account. To do this, click on «Registration», enter your e-mail
address and click «Get the code». Wait until you receive the
conrmation code on the specied e-mail address. Enter
the code in the «Conrmation code» eld, create and enter
a password (6 characters minimum) and press «Save». On
subsequent runs of the application, you will be able to log in
using the e-mail address you provided during the registration
and the password.
Adding a tracker
After registration, you will be asked to add a tracker («Add a
tracker») or check the interface and the functionality of the
application («Demo»). Click «Add a tracker» to start the relevant
procedure.To add a tracker you must specify the IMEI code of the
watch and the telephone number of the SIM card installed in it.
The easiest way to obtain the IMEI code is to scan the barcode on
the watch storage box. To scan a barcode, place the code image
in a viewnder of your smartphone.
After reading the barcode successfully, the phone will transfer
you to a text input screen for entering your phone number (the
eld with the IMEI code will be lled in). You can also enter the
IMEI code manually. To do this, click «Add manually». To nd out
the IMEI number, turn on the watch, press the power button for
the signal and the battery levels to appear on the screen, and
then quickly click the power button 3 times in a row. Software
version together with the code will be displayed on the screen
as a scrolling text.
Enter the code number in the relevant eld on the phone display,
then enter the phone number of the SIM-card installed inside
the watch and click «Next». The phone will send a text message
with the command on your watch. Within 30 to 60 seconds a
four-digit conrmation code will appear on the watch display.
Enter the code in the relevant eld of your phone application.
If the code you entered is correct, the tracker will be added suc-
cessfully and you will be automatically transferred to the prole
editing page enabling you to change user information (name,
date of birth, weight, height, prole photo, etc). Thus, your rst
tracker has been added and you can track its current location on
the map as well as exploit other features.
Conguring the list of family contacts
To protect the child against attackers the watch tracker can be
called on only from the phone numbers listed as family. To add
a number to the list, open the side panel and click «Family mem-
bers». You will see a list of phone numbers the watch can receive
calls from. To add a new number, press «+» in the upper right cor-
ner of the screen, type the name of the new family member, his
phone number and click «Add».The new number will then appear
in the list.
There are two shortcut keys on the watch tracker that can be used
to call numbers congured for each key. For example, the rst key
is congured to call mom and the second key – to call dad. Speed
dial numbers for the watch can be congured in the phone ap-
plication (see the «Family members» section). To link a number to
a speed dial key, click the relevant number in the list and choose
«Reset as contact 1» or «Reset as contact 2» for keys «1» and «2»
respectively. To delete a number from the contact list, click on the
relevant number and choose «Delete» in the opened menu.
Tracker conguration
You can congure dierent work options for the watch tracker.
To open tracker settings, click «Details» under the tracker name
to the right of the user photo. The tracker can transmit its lo-
cation data with dierent frequencies. To adjust the frequency,
click «Frequency» and select one of the available modes. NB:
the higher the frequency is (i.e. the location data is sent to the
server more frequently), the higher the battery consumption of
the watch.
Click on «Tracker data» to see a QR code with information re-
garding the SIM-card number installed and IMEI code of the
watch that can be given to your family member for a scan au-
thorising him to add the tracker in his phone application. There
is a «Delete» button at the bottom to remove the tracker (NB:
after you have deleted the tracker you will not be able to track
its location anymore).
In «Information» you can view and edit user prole data and au-
thorise other people to track his location (see below).
