Efinix Titanium Ti60 F225 Manual de usuario

Titanium Ti60 F225

Development Kit User Guide

Ti60F225-DK-UG-v1.5

March 2022

www.efinixinc.com

trademarks and service marks are the property of their respective owners. All specifications subject to change without notice.

Titanium Ti60 F225 Development Kit User Guide

Contents

Introduction..................................................................................................................................... 4

What's in the Box?.................................................................................................................................... 4

Register Your Kit........................................................................................................................................4

Download the Efinity® Software.............................................................................................................. 5

Install the USB Driver (Linux)................................................................................................................... 5

Install USB Drivers (Windows)................................................................................................................. 5

Board Functional Description..........................................................................................................7

Features.......................................................................................................................................................7

Overview..................................................................................................................................................... 8

Power On..................................................................................................................................................10

Reset..........................................................................................................................................................10

Clock Sources.......................................................................................................................................... 11

Configuration........................................................................................................................................... 11

Headers.....................................................................................................................................................12

Headers P1, P2, and P3 (Multi-Purpose).................................................................................. 13

Header J1 (USB 3.0)....................................................................................................................15

Header J2 (Power Supply)..........................................................................................................15

Header J3 (VCC Selector).......................................................................................................... 16

Header J4 (VCCAUX Selector).................................................................................................. 16

Headers J5, J6, and J7 (TR, TL, and BR Voltage)....................................................................16

Headers J8, J9, J10, and J11 (3A, 3B, 4A, and 4B Voltage)................................................. 16

Header J12 (USB FTDI FT4232)................................................................................................ 16

Header J13 (SPI Flash Voltage Leveler)................................................................................... 17

Headers J14, J15, and J16 (USB 3.0 Boot Option)................................................................ 17

Header J18 (Supply Test Points)................................................................................................17

Test Points TP1, TP2, TP3, TP4 (Ground)..................................................................................17

SD1 (Micro-SD Card Slot)...........................................................................................................17

User Outputs............................................................................................................................................18

User Inputs............................................................................................................................................... 19

USB 3.0 Controller.................................................................................................................................. 20

Setting-up USB 3.0 Boot Option for Programming................................................................ 20

Program the USB 3.0 Controller................................................................................................20

MIPI and LVDS Expansion Daughter Card.................................................................................... 21

Features.....................................................................................................................................................21

Headers.....................................................................................................................................................21

Dual Raspberry Pi Camera Connector Daughter Card..................................................................24

Features.....................................................................................................................................................24

Headers.....................................................................................................................................................25

Headers FPC1 and FPC2 (Raspberry Pi FPC15 Connector).................................................. 25

Header J1 (Optional Camera Signals)......................................................................................26

Header J2 (Development Board Connector).......................................................................... 27

Dual MIPI to DSI Converter Daughter Card..................................................................................28

Features.....................................................................................................................................................28

Headers.....................................................................................................................................................28

Header J1 (Development Board Connector).......................................................................... 29

Headers J2 and J3 (Mini-DSI Panel Connector Daughter Card)...........................................30

Mini-DSI Panel Connector Daughter Card.................................................................................... 32

Features.....................................................................................................................................................32

www.efinixinc.com

Titanium Ti60 F225 Development Kit User Guide

Headers.....................................................................................................................................................33

Headers J2 (Mini-DSI Panel Connector Daughter Card)........................................................33

Headers J4 (Test Points)............................................................................................................. 34

Header J5 (Mini-DSI Display Panel).......................................................................................... 34

Setting up the Board.....................................................................................................................35

Installing Standoffs..................................................................................................................................35

Attaching the MIPI and LVDS Expansion Daughter Card..................................................................35

Attaching the Dual Raspberry Pi Camera Connector Daughter Card..............................................36

Attaching the Display and Daughter Cards........................................................................................ 37

Mini-DSI Panel Backlight Setup................................................................................................. 38

Titanium Ti60 F225 Development Board Example Design.......................................................... 39

Set Up the Hardware..............................................................................................................................40

Running the Example Design................................................................................................................42

Mini-DSI Panel.............................................................................................................................. 42

USB UVC....................................................................................................................................... 42

Read SD Card Information......................................................................................................... 43

Creating Your Own Design........................................................................................................... 43

Restoring the Demonstration Design........................................................................................... 44

Program the Development Board........................................................................................................ 44

Sapphire RISC-V SoC Application Binary............................................................................................ 45

Copy a User Binary to Flash (Efinity Programmer)..................................................................45

Copy a User Binary to Flash (2 Terminals)...............................................................................45

Revision History.............................................................................................................................47

www.efinixinc.com

Titanium Ti60 F225 Development Kit User Guide

Introduction

Thank you for choosing the Titanium Ti60 F225 Development Kit (part number:

Ti60F225-DK), which allows you to explore the features of the Ti60 FPGA.

Whether you are capturing video, aggregating sensor data, or designing for mobile or IoT

applications, the Titanium Ti60 F225 Development Kit provides everything you need to get

started quickly. Capture video with the included Raspberry Pi camera module, process it in

the Ti60 FPGA, and then stream the result to the provided mini-DSI display. The camera

and DSI converter daughter cards support up to 2 cameras or displays, respectively. The kit

also includes an I/O expansion daughter card so you can connect to other components more

easily.

Warning: The board can be damaged without proper anti-static handling.

What's in the Box?

The Titanium Ti60 F225 Development Kit includes:

•Titanium Ti60 F225 Development Board

•1 Mini-DSI Panel Connector Daughter Card

•1 Dual MIPI to DSI Converter Daughter Card

•1 MIPI and LVDS Expansion Daughter Card

•1 Dual Raspberry Pi Camera Connector Daughter Card

•1 Mini-DSI panel

•1 Raspberry Pi v2 camera module

•1 15-pin ﬂat cable

•1 30-pin ﬂat cable

•2 USB type-C cable

•18 jumpers

•10 standoﬀs, 10 screws, and 6 nuts

•Universal AC to DC power adapter

When you purchase an Eﬁnix development kit, you also receive a license for the Eﬁnity®

software plus one year of software upgrades and patches. The Eﬁnity® software is available

for download from the Support Center on the Eﬁnix web site.

To get access to our Support Center to download your software, register your development

kit at https://www.eﬁnixinc.com/register.

www.efinixinc.com 4

Titanium Ti60 F225 Development Kit User Guide

Download the Efinity® Software

To develop your own designs for the Ti60 device on the board, you must install the Eﬁnity®

software. You can obtain the software from the Eﬁnix Support Center under Eﬁnity

Software (www.eﬁnixinc.com/support/).

The Eﬁnity® software includes tools to program the device on the board. Refer to the

Eﬁnity® Software User Guide for information about how to program the device.

Learn more: Efinity® documentation is installed with the software (see Help > Documentation) and is also

available in the Support Center under Documentation (www.efinixinc.com/support/).

Install the USB Driver (Linux)

The following instructions explain how to install a USB driver for Linux operating systems.

1. Disconnect your board from your computer.

2. In a terminal, use these commands:

> sudo <installation directory>/bin/install_usb_driver.sh

> sudo udevadm control --reload-rules

Note: If your board was connected to your computer before you executed these

commands, you need to disconnect and re-connect it.

Install USB Drivers (Windows)

The Titanium Ti60 F225 Development Board development board has an FTDI FT4232H

chip to communicate with the USB port. This chip has separate channels that the board uses

for the JTAG and UART interfaces. You need to install a driver for each interface, and then

each interface appears as a unique FTDI device.

Note: If you install a composite driver, all of the interfaces appear as a composite device and you cannot

use them separately (which means you cannot use all of the features of the board).

Driver Options

The Zadig software includes a variety of drivers. When programming Eﬁnix FPGAs, use one

of these drivers:

•libusb-win32 (version)—This driver is more stable for unplug/plug events. This driver

does not work when debugging with OpenOCD.

•libusbK (version)—Use this driver if you plan to use OpenOCD to debug any Eﬁnix

RISC-V SoC.

Warning: Do not choose the WinUSB driver.

www.efinixinc.com 5

Titanium Ti60 F225 Development Kit User Guide

Install Drivers

To install the interface drivers in Windows:

1. Connect the FTDI USB (J12) on the board to your computer with a USB type-C cable.

2. Download the Zadig software from zadig.akeo.ie. (You do not need to install it; simply

run the downloaded executable.)

3. Run the Zadig software.

Note: To ensure that the USB driver is persistent across user sessions, run the

Zadig software as administrator.

4. Choose Options > List All Devices.

5. Repeat the following steps for each interface. The interface names end with (Interface N),

where N is the channel number.

•Select libusb-win32 or libusbK in the Driver drop-down list. (Do not choose

WinUSB.)

•Click Replace Driver.

6. Close the Zadig software.

Important: Install drivers for interfaces 0 and 1 only. You do not need to install drivers for interfaces 2

and 3 because when you connect the Titanium Ti60 F225 Development Board to your computer, Windows

automatically installs a driver for them.

www.efinixinc.com 6

Titanium Ti60 F225 Development Kit User Guide

Board Functional Description

The Titanium Ti60 F225 Development Board contains a variety of components to help you

build designs for the Titanium Ti60 device.

Figure 1: Titanium Ti60 F225 Development Board Block Diagram

4 User Pushbuttons

2 RGB LEDs

USB Type-C

Connector

USB Type-C

Connector

NOR

Flash

FTDI

FT4232

USB 3.0

Controller

MIPI RX/TX, LVDS, GPIO

Header

MIPI RX/TX, LVDS, GPIO

Header

MIPI RX/TX, LVDS, GPIO

Header

8 Data, 2 Clock,

6 GPIOs

8 Data, 2 Clock,

6 GPIOs

8 Data, 2 Clock,

6 GPIOs

25 MHz, 33.3333 MHz, 74.25 MHz

Oscillators

2 User DIP Switches

HyperRAM X16,

256 Mbit

Ti60 FPGA

Micro SD Card Slot

Features

•Eﬁnix Ti60F225C4 device in an 225-ball FineLine BGA package

•HyperRAM x16 bits memory:

—256 Mb

—1.8 V power supply

—200 MHz maximum clock rate

—Up to 400 Mbps double-data rate

—Supports single ended clock (CK) and diﬀerential clock (CK/CK#)

•128 Mbit SPI NOR ﬂash memory

•Three MIPI, LVDS, and GPIO high-speed connectors to attach the daughter cards

included in the kit or your own custom daughter cards

•Micro-SD card slot

•USB v3.0 interface and type-C connector

•USB Type-C connector for programming the ﬂash or Ti60 FPGA using the Eﬁnity®

software

•25, 33.3333, and 74.25 MHz oscillators for Ti60F225C4 PLL input

•User LEDs and switches:

—2 RGB LEDs on Ti60F225C4 banks 3B

—4 pushbutton switches (connected to bank 3B, TL and BR I/O pins)

—2 DIP switches (connected to bank 1B I/O pins)

•Power:

—12.0 V power supply connector

www.efinixinc.com 7

Titanium Ti60 F225 Development Kit User Guide

—On-board regulator sources: 0.95 V (5A), 1.2 V (5A), 1.5 V (0.5A), 1.8 V (5A),

3.3 V (5A)

—Fixed 1.8 V VCCIO for I/O banks 1A, 1B, 2A, and 2B

—Fixed 3.3 V VCCIO for I/O bank BL

—User selectable voltages from 1.8 V and 3.3 V for I/O banks TR, TL, and BR

—User selectable voltages from 1.2 V, 1.5 V, and 1.8 V I/O banks 3A, 3B, 4A, and 4B

•Power good and Ti60F225C4 conﬁguration done LEDs

Overview

The board features the Eﬁnix Ti60 programmable device in a 225-ball FBGA package, which

is fabricated using Eﬁnix Quantum™ technology. The Quantum™-accelerated programmable

logic and routing fabric is wrapped with an I/O interface in a small footprint package. Ti60

devices also include embedded memory blocks and DSP blocks. You create designs for the

Ti60 device in the Eﬁnity® software, and then download the resulting conﬁguration bitstream

to the board using the USB connection.

Learn more: For more information on Ti60 FPGAs, refer to the Ti60 Data Sheet.

Figure 2: Titanium Ti60 F225 Development Board Components (Top)

Multi-Purpose

Connector

Multi-Purpose

Connector

Multi-Purpose

Connector

USB 3.0

Boot Options

USB Type-C

(USB 3.0)

USB Type-C

(FT4232)

User

Pushbuttons

Power Supply

Select

12 V Power

Supply

On/Off

Switch

FT4232 Reset/

User Pushbutton

USB 3.0 Reset

VCC Selector

VCCAUX

Selector

Ti60

Reset

Ti60 F225

RGB LEDs

Power Supply

Test Points

www.efinixinc.com 8

Titanium Ti60 F225 Development Kit User Guide

Figure 3: Titanium Ti60 F225 Development Board Components (Bottom)

Micro-SD

Card Slot

Dipswitches

Figure 4: Titanium Ti60 F225 Development Board Header and LED Definition

Ti60

J16

J15

J14

1 2 3 4 5 6

J13

USB

3.0

Power

Input

USB

FT4232 J5

D15

(CDONE)

D16

D17

J10

J11

J18

D22

(Power Good)

D20

(NSTATUS)

www.efinixinc.com 9

Titanium Ti60 F225 Development Kit User Guide

The Titanium Ti60 F225 Development Board provides three multi-purpose 0.8 mm high-

speed ground plane sockets. These sockets can be used for GPIO, MIPI CSI-2 TX/RX, and

LVDS TX/RX. The board includes two USB type-C ports, one for USB 3.0 interface and the

other for the FTDI interface.

The FTDI FT4232H module has four channels to support the following interfaces:

•SPI—FTDI interface 0

•FPGA JTAG—FTDI interface 1

•FPGA UART—FTDI interface 2

•USB 3.0 chip UART—FTDI interface 3

The FTDI module receives the Ti60 conﬁguration bitstream from a USB host and writes to

the Ti60 FPGA in SPI passive conﬁguration. You can write a conﬁguration bitstream to the

on-board SPI NOR ﬂash memory through JTAG with the JTAG SPI Flash Loader Core.

Additionally, it supports a UART interface to the Ti60 and the USB 3.0 chip.

The SPI NOR ﬂash memory stores the conﬁguration bitstream. The Ti60 device accesses this

conﬁguration bitstream when it is in active conﬁguration mode (default).

Learn more: Refer to the Titanium Ti60 F225 Development Board Schematics and BOM for more

information about the components used in the Titanium Ti60 F225 Development Board.

Power On

To turn on the development board, turn on switch SW4. The 12 V DC power is input to

the on-board regulators to generate the required 3.3 V, 2.5 V, 1.8 V, 1.5 V, and 1.2 V for

components on the board. When these voltages are up and stable, the power-good LED, D22

illuminates, giving you a visual conﬁrmation of the status.

Reset

The Ti60F225C4 device is typically brought out of reset with the CRESET signal. Upon

power up, the Ti60F225C4 device is held in reset until CRESET toggles high-low-high.

Note: You can manually assert the high-low-high transition with pushbutton switch SW3.

CRESET has a pull-up resistor. When you press SW3, the board drives CRESET low; when

you release SW3, the board drives CRESET high. Thus, a single press of SW3 provides the

required high-low-high transition.

After toggling CRESET, the Ti60F225C4 device goes into conﬁguration mode and reads

the device conﬁguration bitstream from the ﬂash memory. When conﬁguration completes

successfully, the device drives the CDONE signal high. CDONE is connected to a green LED

(D15), which turns on when the Ti60F225C4 device enters user mode.

www.efinixinc.com 10

Tabla de contenidos

Otros manuales de Microcontrolador de Efinix

Efinix

Efinix Titanium Manual de usuario

Efinix

Efinix Titanium Ti180 M484 Manual de usuario

Efinix

Efinix Trion T8 BGA81 Manual de usuario

Efinix

Efinix Trion8 BGA81 Manual de usuario

Efinix

Efinix Titanium Ti180 J484 Manual de usuario

Efinix

Efinix Trion T20 BGA256 Manual de usuario

Efinix

Efinix Trion T120 BGA324 Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario
