Edision EDI-Rx Manual de usuario

User’s Guide

EDI-Rx

IR over COAX

CONTENTS

►INTRODUCTION .............................................................................4

►INSTALLATION EXAMPLE..............................................................4

►FEATURES ......................................................................................5

►TECHNICAL SPECIFICATIONS ......................................................5

►CONNECTIΟΝ & OPERATION .......................................................6

►PACKAGE INCLUDES ....................................................................6

►TROUBLESHOOTING.....................................................................7

► INTRODUCTION

The Extension IR Receiver over Coax EDI-Rx offers the

ability to control the connected audio/video source,

from another room TV point, through the existing coaxi-

al cable connection using your existing remote control.*

*Note that the HDMI Modulator Xtend is required to be installed as well

ROOM

USB PORT

ANT IN

TV SOCKET,

RF SPLITTERS,

TAPS,EXISTING RF

NETWORK,etc...

SMATV

COAXIAL CABLE

COAXIAL

CABLE

COAXIAL CABLE

USB to DC CABLE

IR CONTROL

SYSTEM EDI-Rx

JACK to IR Rx

CABLE

RF IN

RF OUTDC 5V

IR OUT

► FEATURES

• IR control over coaxial

• Ports - Connections: RF IN, RF OUT, IR OUT, DC 5V

• Power over DC to USB cable

• IR Signal LED

• Low Power Consumption

► TECHNICAL SPECIFICATIONS

Modulation Type ASK

Frequency bandwidth VHF III (174-230 MHZ)

& UHF (470-862 MHZ)

RF IN Input 1 x Female IEC-type

RF OUT Output 1 x Male IEC-type

IR Receiver OUT Stereo Jack 3,5mm (Jack to IR EDI-Rx)

DC OUT 5V/500mA (DC to USB cable)

IR Signal LED IR status indication

► CONNECTIΟΝ & OPERATION

1. Connect the RF OUT of the existing RF network to the RF

IN of the IR EDI-Rx (A).

2. From the RF OUT of the EDI-Rx (D), connect to the ANT

IN of the TV.

3. Connect the Jack to IR Rx cable from the IR Control Sys-

tem EDI-Rx (B) in front of the TV IR reception point, so as

to control it via IR.

4. Connect the DC5V input of the IR Control System EDI-Rx

ΑB C D

Jack to IR Rx

cable

USB to DC

(5V) cable

► PACKAGE INCLUDES

1. IR Control System EDI-Rx

2. Jack to IR Rx cable

3. USB to DC (5V) cable

4. User Manual EN/DE/GR

► TROUBLESHOOTING

The IR control at the other TV point does not work

• Make sure that the Jack to IR Tx cable is close to the

audio/video source device.

• Make sure that there is a clear field between the IR

remote control and the Jack to IR Rx cable and the

distance between them is up to ~6 meters.

• In case the LED indication of the IR Control System

EDI-Rx is always ON, this may be caused by inter-

ference. Please relocate the device.

• Check the DC 5V power supply of the IR Control Sys-

tem EDI-Rx.

• Make sure that the IR signal coaxial cable path

does not include active devices such as amplifiers,

multiswitches etc.

For more queries or advanced troubleshooting,

please contact our technical support at [email protected]

The CE certificate of the product is available on our webpage,

by visiting this link: https://www.edision.gr/en/support

www.edision.gr

EDISION HELLAS LTD • FARMAKEIKA - 57001 N. RΙSIO • THESSALONIKI - GREECE
