Edimax ES-3116RL Manual de usuario

16 / 24 Ports

9”

”

FCC Certifications

This Equipment has been tested and found to comply with the limits for a

ClassAdigital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interferencewhen

the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause harmful

interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference

at his own expense.

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received;

including interference that may cause undesired operation.

CE Mark Warning

This equipment complies with the requirements relating to electromagnetic

compatibility, EN 55022 classAfor ITE, the essential protection requirement

of Council Directive 89/336/EEC on the approximation of the laws of the

Member States relating to electromagnetic compatibility.

Company has an on-going policy of upgrading its products and it may be

possible that information in this document is not up-to-date. Please check with

your local distributors for the latest information. No part of this document can

be copied or reproduced in any form without written consent from the

company.

Trademarks:All trade names and trademarks are the properties of their

respective companies.

English.

Introduction

This device is a powerful, high-performance Fast Ethernet

switch, with all ports capable of 10 or 100Mbps auto-negotiation

operation (NWay), which means this switch could automatically

negotiate with the connected partners on the network speed and

duplex mode. It is ideal for micro-segmenting large networks into

smaller, connected subnets for improved performance, enabling

the bandwidth demanding multimedia and imaging applications.

Moreover, the 10/100Mbps auto-sensing ability provides an

easy way to migrate 10Mbps to 100Mbps network with no pain.

Compared to the shared 10Mbps or 100Mbps networks, the

switch delivers a dedicated 10/100Mbps connection to every

attached client with no bandwidth congestion issue. This switch

also supports auto MDI / MDI-X function; each port could be

used to connect to another switch or hub with no crossover

RJ-45 cable.

Store-and-forward switching mode promises the low latency

plus eliminates all the network errors, including runt and CRC

error packets. To work under full-duplex mode, transmission and

reception of the frames can occur simultaneously without

causing collisions as well as double the network bandwidth.

The switch is plug-n-play without any software to configure and

also fully compliant with all kinds of network protocols. Moreover,

the rich diagnostic LEDs on the front-panel can provide the

operating status of individual port and whole system.

Before you start to install the switch, check the following

contents in this package：

zOne Rackmount Fast Ethernet Switch

zOne power cord and one user’s manual

zRack-mount brackets and screws

LED Definition

Please refer to the following table for LED definition

24 Ports example

LED Status Operation

Steady Green Power is on

Power Off Power is off

Steady Green The port is connected

Blinking Green The port is

transmitting/receiving data.

Link/Act

Off No connection

Stations Connection

Connect each station to the switch by twisted-pair cable. Plug

one RJ-45 connector into a RJ-45 port of the switch, and plug

the other RJ-45 connector into the station’s network adapter.

Power on the switch and then system is ready. For cable

selection, refer to the following table.

Switches Connection

In making a switch interconnection, you could use any port to

connect another switch with straight or crossover cable. As all

the ports support auto MDI / MDI-X function, using a straight

cable to make a switch-to-switch connection is allowed.

For cable selection, refer to the following table：

Network Speed Cable Type Max. Length

10Mbps Cat. 3, 4, 5 UTP/STP 100 meters

100Mbps Cat. 5 UTP/STP 100 meters

Rack-Mount

The switch may standalone, or may be mounted in a standard

19-inch equipment rack. Rack mounting produces an orderly

installation when you have a number of related network devices.

The switch is supplied with two optional rack mounting brackets

and screws. These are used for rack mounting the unit.

Specification

Standard

IEEE 802.3 10BASE-T

IEEE 802.3u 100BASE-TX

IEEE 802.3x full duplex operation and

flow control

Interface 16/ 24 * 10/100Mbps RJ-45 Fast

Ethernet Ports

Uplink Auto MDI/MDI-X(Auto crossover)

Network Speed 10/100Mbps & Full/Half duplex mode

auto detection

MAC Addr. Table 8K MAC entries

Memory 160Kbytes

Power Supply Internal Power supply

3.3V 4A (100-240V/ 50-60Hz)

EMI CE and FCC class A
