Edelbrock 6700 Manual de usuario

Catalog #6700

Page 1 of 2 Brochure #63-6700

Rev. 5/06 - DA/mc

Dodge Viper Heat Shields

For 1992-1999 Roadster & 1996-1999 Coupe

Catalog #6700

INSTALLATION INSTRUCTIONS

Please study these instructions carefully before installing your new heat shield. If you have any questions, please contact

our Technical Hotline at : 1-800-416-8628 from 7 am – 5 pm, Monday through Friday, Pacific Standard Time or e-mail

us at [email protected]. Please fill out and mail your warranty card.

INSTALLATION INSTRUCTIONS

WHEN BEING INSTALLED ON VEHICLES WITH

EDELBROCK T.E.S. #66062:

RIGHT SIDE:

1. Remove top of heater blower box from lower heater

box assembly in engine compartment.

2. Remove the bolts from the coolant reservoir so it can

be moved around.

3. Disconnect spark plug wires from spark plugs and

move out of the way.

4. Loosen the 2nd and 4th upper header flange bolts

for mounting bracket installation.

5. Install one mounting bracket on each of the two

header flange bolts loosened in Step 4. Position the

brackets so that the slot on the end is straight down

under the bolt and bracket is flat on top. These

brackets will angle forward and down slightly when

installed properly.

NOTE: Before attempting to install the heat shield

onto the brackets, first measure the distance

between the threaded holes in the mounting

brackets. You should have 9 1/8” from center to

center of holes. If you don’t, you can bend the

brackets with a pair of pliers or a small hammer.

Doing this will make heat shield installation much

easier.

6. Install the right side heat shield by angling the front

edge of the heat shield down toward the front half of

the header and slipping it forward between the

header and the coolant reservoir and hose. Once it

is down on top of the brackets, slide it toward the

rear of the car, align holes and install supplied bolts

and lock washers.

NOTE: We recommend you use a small amount of

high heat silicone R.T.V. on the top surface of the

mounting bracket to help to keep the shield from

rattling against the mounting brackets.

7. After you have tightened the heat shield to the

mounting brackets, tap on the shield to see if you

have rattles. To eliminate rattles, you can: (1) adjust

the shield at the mounting points “slotted holes”, (2)

bend the heat shield as needed for clearance, (3)

bend mounting brackets slightly for a better fit on

your vehicle.

8. Re-install plug wires onto spark plug.

NOTE: Spark plug boots, wires and hose should not

contact the sharp edges of the heat shield as they

can be damaged.

9. Re-install bolts for coolant reservoir bottle. Use

plastic ties and hose holder provided in kit as

needed to hold coolant hose away from sharp edges

of heat shield.

10. Re-install top half of heater blower box.

LEFT SIDE:

1. Disconnect spark plug wires from spark plugs and

move out of the way.

2. Loosen the 2nd and 4th upper header flange bolts

for mounting bracket installation.

Catalog #6700

Page 2 of 2 Brochure #63-6700

Rev. 5/06 - DA/mc

Edelbrock Corporation, 2700 California St., Torrance, CA 90503

Tech Line: 1-800-416-8628

E-Mail: [email protected]

3. Install one mounting bracket on each of the two

header flange bolts loosened in Step 2. Position the

brackets so that the slot on the end is straight down

under the bolt and the bracket is flat on top. These

brackets will angle back and down slightly when

installed properly. Re-tighten flange bolts with

brackets in place.

NOTE: Before attempting to install the heat shield

onto the brackets, first measure the distance

between the threaded holes in the mounting

brackets. You should have 9 1/8” from center to

center of holes. If you don’t, you can bend the

brackets with a pair of pliers or a small hammer.

Doing this will make heat shield installation much

easier.

4. Install the left side heat shield by positioning the rear

edge down toward the center of the header, then

while moving it down and back, slip it past the valve

cover and foot well sheet metal and into position.

NOTE: We recommend you use a small dab of high

heat silicone R.T.V. on the top surface of the

mounting bracket to help keep the shield from

rattling against the mounting bracket. Align the

shield with the brackets and install bolts and lock

washers supplied in kit.

5. After you have tightened the heat shield to the

mounting brackets, tap on the shield to see if you

have rattles. To eliminate rattles, you can: (1) adjust

the shield at the slotted mounting holes of the shield;

(2) bend the heat shield as needed for clearance; (3)

bend the mounting brackets slightly for a better fit

on your vehicle.

6. Re-install plug wires onto spark plugs.

NOTE: Spark plug boots and wire should not contact

the sharp edges of the heat shield as they may be

damaged.

BOTH SIDES FINAL CHECK: Make sure you have re-

secured all bolts, screw, etc. Make sure all hoses, wires

and plug boots have adequate clearance around sharp

edges of heat shields.

Start vehicle and let idle. If heat shields rattle, refer to

Step 5 (Left Side) or Step 7 (Right Side). When the

vehicle is idling, the heat shields will look like they shake

a lot, but if installed and adjusted properly should not

rattle.

FOR INSTALLING ON VEHICLE WITH OTHER THAN

EDELBROCK T.E.S.

These heat shields are designed to work primarily with

Edelbrock T.E.S. but can be adapted to be used with

other manufacturer’s headers.

It may be necessary to fabricate additional or different

mounting brackets, trim shield if necessary if the

brackets supplied will not work for the brand of headers

you have.

Installations on vehicles with other than Edelbrock T.E.S.

should be done by a skilled fabricator for custom

installation.
