Ebyte E104-BT12LSP-TB Manual de usuario

Chengdu Ebyte Electronic Technology Co.,Ltd E104-BT12LSP-TB User manual v1.0

E104-BT12LSP-TB

Chengdu Ebyte Electronic Technology Co.,Ltd E104-BT12LSP-TB User manual v1.0

1. Contents

Disclaimer....................................................................................................................................................................... 3

1 Introduction..................................................................................................................................................................4

1.1 Features............................................................................................................................................................. 4

1.2 Electrical parameters........................................................................................................................................ 4

2 Function brief...............................................................................................................................................................5

2.1 Pin definition.................................................................................................................................................... 6

2.2 Function test......................................................................................................................................................6

2.3 CH340 driver installation................................................................................................................................6

3 Customized cooperation.............................................................................................................................................. 7

4 About us....................................................................................................................................................................... 7

Chengdu Ebyte Electronic Technology Co.,Ltd E104-BT12LSP-TB User manual v1.0

Disclaimer

EBYTE reserves all rights to this document and the information

contained herein. Products, names, logos and designs described herein

may in whole or in part be subject to intellectual property rights.

Reproduction, use, modification or disclosure to third parties of this

document or any part thereof without the express permission of EBYTE

is strictly prohibited.

The information contained herein is provided “as is” and EBYTE

assumes no liability for the use of the information. No warranty, either

express or implied, is given, including but not limited, with respect to the

accuracy, correctness, reliability and fitness for a particular purpose of the

information. This document may be revised by EBYTE at any time. For

most recent documents, visit www.ebyte.com.

Chengdu Ebyte Electronic Technology Co.,Ltd E104-BT12LSP-TB User manual v1.0

E104-BT12LSP-TB User Manual V1.0

1. Introduction

1.1 Features

E104-BT12LSP-TB test adopts USB interface, which can be used to quickly test E104-BT12

Bluetooth related features and functions.

1.2 Electrical parameters

No.

parameter

name

Parameter value

Annotation

Support module

E104-BT12LSP

Mesh Networking module

Module size

46.5 * 26 mm

With USB connector

Production

Process

Lead-free process,

machine-mounted

Wireless products must be machine-mounted to

ensure batch consistency and reliability

Power supply

interface

USB

Communication

Interface

TTL

Operating

temperature

-40 ~ +85℃

Industrial grade

Working

humidity

10% ~ 90%

Relative humidity, non-condensing

Storage

temperature

-40 ~ +125℃

Industrial grade

Chengdu Ebyte Electronic Technology Co.,Ltd E104-BT12LSP-TB User manual v1.0

2. Function brief

2.1 Pin definition

Pin usage

Pin No.

Pin name

Pin direction

Pin usage

RST

Input

Module reset button

SW1

Input

retain

SW2

Input

retain

output

Serial output pin

Input

Serial input pin

VCC

The jumper cap selects whether it is USB powered or

battery powered

BAT

Battery power supply pin

+5V

External power supply pin (not powered by USB)

LED_R (PD2)

output

Pwm output

LED_G (PC1)

output

Pwm output

LED_B(PB5)

output

Pwm output

LED_B(PB4)

output

Network indicator

Note: Please refer to the user manual of E104-BT12 for specific function instructions.

Chengdu Ebyte Electronic Technology Co.,Ltd E104-BT12LSP-TB User manual v1.0

2.2 Function test

Test function

Description

Test receiving and

transmitting current

Connect the ammeter to the 6th pin, and then measure the sending and receiving

current

Data transmission

test

Refer to the Quick Start in the E104-BT12LSP datasheet for a series of tests.

Modification of

module parameters

Refer to E104-BT12LSP datasheet for parameter configuration, configuration

data

2.3 CH340 driver installation

If it is the first time to use the CH340 interface conversion module, the PC will prompt to install

the new device driver, which can be searched and downloaded online, or the driver wizard can

download the driver

Chengdu Ebyte Electronic Technology Co.,Ltd E104-BT12LSP-TB User manual v1.0

3. Customized cooperation

★If customers need product customization, please contact us.

★Ebyte has reached in-depth cooperation with many well-known companies.

4. About us

EBYTE is a company specializing in providing wireless data transmission solutions and products

◆Independently research and develop hundreds of models of products and software;

◆Wireless transparent transmission, WiFi, Bluetooth, Zigbee, PKE, digital radio and many other series

of wireless products;

◆With nearly a hundred employees, tens of thousands of customers, and cumulative sales of millions

of products;

◆Business covers more than 30 countries and regions around the world;

◆Passed the ISO 9001 quality management system and ISO 14001 environmental system certification;

◆It has a number of patents and software copyrights, and has passed international FCC/CE/ROHS and

other authoritative certifications.

Chengdu Ebyte Electronic Technology Co.,Ltd E104-BT12LSP-TB User manual v1.0

【Phone】028-61399028 【Tax】028-64146160

【Website】www.ebyte.com 1111111

【Technology Support】supp[email protected]m

【Address】B5 Mould Park, 199# Xiqu Ave, High-tech District, Sichuan, China
