EF-CBD130 Conventional Reﬂective Beam Detector

Installation and operation manual

2INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com

Contents

DOCUMENT UPDATE NOTES....................................3

1. IMPORTANT PRODUCT SAFETY INFORMATION ..................3

1.1. Definitions and Symbols..........................................3

2. ABOUT THE EF-CBD130.......................................4

2.1. Feature and Benefits ............................................4

2.2. Technical Specifications ..........................................5

2.3. Product Appearance ............................................6

2.4. Principle of the Beam Detector ....................................6

3. INSTALLATION PROCEDURES .................................7

3.1. Mounting Details ...............................................7

3.2. LED Indicators .................................................7

3.3. Mounting Preparation ...........................................8

3.4. Mounting of the Beam Detector ...................................9

3.5. Mounting of the EF-CBD130-R Reflector.............................9

3.6. Cabling Details................................................10

4. PROGRAMMING SENSITIVITY AND SPAN ......................11

5. COMMISSIONING BEAM DETECTOR ..........................11

5.1. Commissioning Preparation ......................................12

5.2. Step 1: Entering Commissioning Method ...........................12

5.3. Step 2: Sightline Alignment Procedure .............................12

5.4. Step 3: Acceptable Adjustment Procedure ..........................12

5.5. Step 4: Finalizing Installation .....................................13

5.6. Step 5: Testing Fire Signal .......................................13

5.7. Step 6: Testing Fault Signal ......................................13

6. OTHER FUNCTIONS ........................................14

7. MAINTENANCE ............................................15

8. TROUBLESHOOTING GUIDE..................................15

9. SUPPLIED ACCESSORIES ....................................15

10. APPENDIX 1 ..............................................16

10.1. Limitation of Beam Detectors ...................................16

3INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com

DOCUMENT UPDATE NOTES

S.No. Release / Change Notes Date

AEaton update - first release July 2022

Eaton update - supplied accessories March 2023

1. IMPORTANT PRODUCT SAFETY INFORMATION

To prevent severe injury and loss of life or property, read the instruction carefully

before installing the beam detector to ensure proper and safe operation of

the system.

1.1. Definitions and Symbols

WARNING

Indicates a potentially hazardous situation which, if not avoided, can result in

serious injury or death.

CAUTION

Indicates a potentially hazardous situation which, if not avoided, can result in

minor to moderate injury, or serious damage to the product.

This product must only be disposed of in

accordance with the WEEE directive.

0832

DoP0506-UK

2831

DoP0506

EN54-12:2015

378aa/01

Eaton Electrical Products Ltd.

Llantarnam Park

Cwmbran

NP44 3AW

EF-CBD130 2831-CPR-F4717

EF-CBD130 0832-UKCA-CPR-F1371

EN54 Part 12 Compliance

EF-CBD130 Conventional Reflective Beam Detector

complies with the requirements of EN 54-12:2015.

C Eaton update

Eaton update - images and layout July 2022

4INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com

2. About the EF-CBD130

The EF-CBD130 reflective beam detector is for use with the Eaton range of

conventional fire systems. Alignment is made easy with a built in laser pointer and

digital display.

The laser pointer is used to mark the exact location where the reflector is to be

installed. Once the reflector is installed the digital display indicates the light intensity

between the detector and the reflector enabling the user to adjust for optimal

alignment

The EF-CBD130 has four adjustable operational ranges of between 8 to 20, 20 to 40,

40 to 70 and 70 to 100 meters beside with three adjustable sensitivity setting ranges

from 2.6dB, 3.8dB and 5.8dB to meet the specific environmental requirement. The

EF-CBD130 works on the principle of reflective infrared beam obscuration. Used in

conjunction with a reflector, it will notify the fire alarm panel when the infrared beam

is obscured by smoke.

The EF-CBD130 is ideal for use high ceiling and wide areas such as warehouses,

large stores, shopping malls, leisure centres, exhibition halls, hotel lobbies, printing

houses, garment factories, museums and prisons, as well as places where slight

smoke particles or corrosive gas exist.

2.1. Feature and Benefits

1. EN54-12 Compliance

2. Intuitive alignment with built in laser pointer and digital display

3. Employ single-ended design through reflector

4. Four ranges wide monitoring from 8-100 meters via encoder

5. Three users programing sensitivity adjustment

6. Built-in microprocessor

7. Self-diagnosis function can monitor for internal faults

8. Automatic compensation for factors weakening received signals, such as

dust contamination, positional movement and ageing of the transmitter

9. Fire and Fault interfacing relays

10. Aesthectically pleasing

5INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com

2. About the EF-CBD130

2.2. Technical Specifications

Part Number EF-CBD130

Standard

Listed LPCB Certification

Compliance EN 54-12:2015

Fire Detection and Alarm Systems BS 5839 Part 1:2017

Specification

Operating Voltage 20 V to 28 V DC

Current Parameters Standby: 23mA Commission: 56mA Alarm: 33mA

Beam Sensor Sensitivity [via Encoder] Level 1: 2.6 dB High Sensitivity

Level 2: 3.8 dB Medium Sensitivity

Level 3: 5.8 dB Low Sensitivity

Beam Pathway Length [via Encoder] Span 1: 8 to 20 meters Limited Path

Span 2: 20 to 40 meters Short Path

Span 3: 40 to 70 meters Normal Path

Span 4: 70 to 100 meters Long Path

Beam Path Angle ±0.4º Directional (This data takes the average of the left and right

deflection angles.)

Alignment Guide Laser Beam Pointer

Digital Display Guide Nixie Tube

LED Indicator Guide Red: Fire ; Yellow: Fault ; Green: Alignment

Reset Time Less than 2 Second

Relay Capacity [Fire & Fault] Normally Open & Close/ 2.0 A; 30 VDC

Physical

Material / Colour ABS / White

Dimension / Weight L:190.87 x W:126.87 x H:91.96 mm / 440 gm

Weight 0.130 Kg with base

Environmental

Operating Temperature -10°C to +50°C

Ingress Protection Rating IP30 [IP66 glue seal-For permanent fixing, Not EN54-12 approved]

Humidity 0 to 95% Relative Humidity, Non condensing

6INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com

2. About the EF-CBD130

2.3. Product Appearance

2.4. Principle of the Beam Detector

In a fire, when smoke enters the path of the beam detector, some of the light

is absorbed or scattered by the smoke particles. This decreases the received

signal, leading to an increase in optical obscuration. This unit decodes the received

signals and compares to the pre-programmed algorithm stored on the processor.

Through this algorithm the detector will take appropriate action and activate the

corresponding relays and LED indicators.”

To avoid false alarms the detector and reflector should be mounted on a solid

structure, care should be taken to avoid obstructing the path of the beam. Refer to

Figure 1.

In operation mode, the unit continually emits light, care should be taken that the

activities in the space do not obstruct the beam or move the device to avoid false

operation of the detector. Refer to Figure 1.

Smoke

Fire Status

Beam

Detector

Mounting

Bracket

Reector Beam

Detector

Mounting

Bracket

Normal Status

Reector

Figure 1. Beam detector principle 2 Installation Procedures

2. About the EF-CBD130

7INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com

3. Installation Procedures

3.1. Mounting Details

79mm

85mm

158.5mm

AlignmentFault

Fire

39.54mm

30.53mm

AlignmentFault

Fire

71.8mm 5.89mm

Figure 2. Detector Diagram

3.2. LED Indicators

LED Indicators Colour Function

Fire Red Illuminates when at least one fire alarm event occurs

Fault Yellow Illuminates when at least one fault alarm event occurs in the detector

Alignment Green Illuminates during commissioning

8INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com

2. About the EF-CBD130

3.3. Mounting Preparation

This beam detector must be installed, commissioned and maintained by competent

personnel. The installation should comply with all local standards and/or codes of

practice in the region.

Note - to avoid damage to critical components such as the reed switch it is advisable

to use the magnetic tool when needed.

If the ceiling height is less than 8 meters, the beam detector should be

installed between 0.5 meters to 1 meter below the ceiling level. Refer to Figure 3.

If the ceiling height is more than 8 meters, the beam detector should be

installed at least 0.5 meters below the ceiling. Refer to Figure 3.

The chosen location should be clean and dry and not subject to shock,

vibration, electro-statistic discharge, and free from glass walls, direct sunlight and

any reflective barriers.

Make sure that the beam path is free from obscuration caused by moving

items.

0.5m min to 1m max

Beam

Detector

Beam

Detector

0.5m min

Below 8 meters ceiling height Above 8 meters ceiling height

Figure 3. Installation Details

9INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com

2. About the EF-CBD130

3.4. Mounting of the Beam Detector

1. Using the supplied bracket, mark the position of the fixing holes.

2. Fit the mounting bracket using appropriate fixings for the surface, ensure

that the bracket is secure and free from movement. Refer to Figure 4

3. Fix the detector base onto the bracket using two M4x12x10 standard screws.

79mm

85mm

158.5mm

Figure 4. Mounting Bracket Figure 5. Beam Detector

3.5. Mounting of the EF-CBD130-R Reflector

1. For distances between 8m and 40m one reflector is required, for distances

between 40m and 100m four reflectors are required

2. Mark the position of the fixing holes

3. Fit the reflector with suitable fixings. Refer to Figure 6.

10 INSTALLATION AND OPERATION MANUAL 25-17603-C March 2023 www.eaton.com

2. About the EF-CBD130

Beam

Detector

Line-of-Sight Distance

8 to 40m (1 x reector)

Reector 1 x Reector

122mm

100mm

244mm

200mm

4 x Reector

40m to 100m (4 x reector)

Figure 6. Mounting of EF-CBD130-R Reflector Reflector

3.6. Cabling Details

Cables should be brought into the detector using the supplied cable gland.

The maximum size of the cable which can be terminated is 1.5mm².

Observe the polarity. Refer to Figure 7.

1. Terminal D1 (+) and D2 (-) for connecting Power supply [24VDC]

2. Terminals S1(+) and S2(-) to be linked to D1 (+) and D2 (-)

3. Terminal HJ1 and HJ2 for connecting Fire signal relay output

[Normally Open]

4. Terminal GZ1 and GZ2 for connecting Fault signal relay output

[Normally Close]

Figure 7. Wiring Terminals

Tabla de contenidos

Otros manuales de Sensor de seguridad de Eaton

Eaton

Eaton CWGA-0 Series Manual

Eaton

Eaton xComfort CBMA-02/01 Manual

Eaton

Eaton CEAG EURO X LED Manual de servicio

Eaton

Eaton MEM Watchman 180 Manual de usuario

Eaton

Eaton CWGA-0 Series Manual

Eaton

Eaton All-Pro MS180BT Manual de usuario

Eaton

Eaton Sure-Lites 2C Manual de usuario

Eaton

Eaton CEAG Style 22011 CG-S Manual de servicio

Eaton

Eaton All-Pro MS180 Manual de usuario

Eaton

Eaton Crouse-hinds series Manual de usuario

Eaton

Eaton xComfort CSEZ-01/06 Manual de usuario

Eaton

Eaton HaloHome MST20C18W Manual de usuario

Eaton

Eaton URTDII Manual

Eaton

Eaton CEAG 6811 LED CGLine+ Manual de servicio

Eaton

Eaton HALO MS180 Manual de usuario

Eaton

Eaton Velos Manual de usuario

Eaton

Eaton Powerware Series Manual de usuario

Eaton

Eaton ALL-PRO MS185DW Manual de usuario

Eaton

Eaton NexiTech Series Manual de usuario

Eaton

Eaton 1450-CSA Manual

Eaton

Eaton PPD-C-230V Manual de usuario

Eaton

Eaton All-Pro MS245RW Manual de usuario

Eaton

Eaton Sure-Lites UX6 Manual de usuario

Eaton

Eaton MAP820 Manual de instrucciones

Manuales populares de Sensor de seguridad de otras marcas

THORLABS

THORLABS PDA10JT Manual de usuario

Waeco

Waeco UV-DETECT Manual de usuario

Intermatic

Intermatic IOS-DSIMF Manual de usuario

urmet domus

urmet domus 1083 Manual de usuario

Siemens

Siemens AZL66 Series Manual de usuario

BTI

BTI Profiline Multi Finder Manual de usuario

Challenger

Challenger SL01 Manual de usuario

DMP Electronics

DMP Electronics 1122INT Manual de usuario

Rielta

Rielta Ladoga MK-RK Manual de usuario

Mirion Technologies

Mirion Technologies ACCURAD PRD Manual de usuario

Bosch

Bosch DS835 Manual de usuario

DBI SALA

DBI SALA EZ Stop Manual del operador

Lamptime

Lamptime ST05C Manual de usuario

Ubiquiti

Ubiquiti MFI-MSC Manual de usuario

Subsite

Subsite 910R Instrucciones de instalación

Satel

Satel OPAL Pro Manual de usuario

Aleph

Aleph XC-1XTEU Manual de usuario

Pima

Pima LARIS QUAD Manual de usuario
