Part 2: Installation Cl. 8967

1. General Information

1.1 Machine Operation without Material . . . . . . . . . . . . . . . . . . . . 3

1.2 Table Tops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. Frame Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3. Table Top, Completing and Screwing on . . . . . . . . . . . . . . . . 7

4. Connecting the Sewing Drive to the Table Top

4.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4.2 Drive Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

4.3 Voltage Compensation Motor/ Machine Head . . . . . . . . . . . . . . . 8

4.4 Attaching the Pedal and Rod . . . . . . . . . . . . . . . . . . . . . . . . 9

4.5 Electrical Connection of the Motors . . . . . . . . . . . . . . . . . . . . . 9

5. Attaching the Machine Head

5.1 Mounting the Sewing Head, Establishing the Voltage Compensation

Positioning the V-belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5.2 Attaching the Belt Guard,

Mounting and Setting the Synchronizer . . . . . . . . . . . . . . . . . . 11

5.3. Connecting the Solenoid Valve Strip . . . . . . . . . . . . . . . . . . . . 12

6. Connecting the Compressed Air Maintenance Unit . . . . . . . . . . 13

7. Filling Oil and Readying the Machine for Operation . . . . . . . . . . 14

8. Conducting the Sewing Test . . . . . . . . . . . . . . . . . . . . . . . . 14

1. General Information

Attention!

The mains voltage and the nominal voltage listed on the

motor identification plate must be the same.

All work on the electronics is to be conducted only by au-

thorized personnel and with the mains plug disconnected.

Please observe all safety instructions!

Installation is to be conducted according to the following

instructions. All necessary parts are to be found in the en-

closed package.

1.1 Machine Operation without Material

Attention!

First arrest the pressure feet in the raised position and

set the shortest pressure foot stroke.

1.2 Table Tops The cutouts in self-made table tops must have the dimen-

sions shown in the sketches on pages 4 and 5.

The table tops must have the necessary load capacity

and firmness.

2. Frame Assembly

–Assemble the frame parts as shown and take care

that all feet touch the floor.

–Adjust the screws on the frame foot at the right back

accordingly for this.

3. Table Top, Completing and Screwing on

Underside of the Table Top:

- Screw on the cable duct 4 and the holder 5 for strain re-

liever

- Screw on main switch 2

- Screw on the sewing light transformer 1, if supplied

- Lay the electric wiring in the cable duct and to the motor

- Screw on the drawer 3 with mounting

- Screw on table top support plate 6 by frame MG56-2

- Screw the table top onto the frame with B8 x 35 wood

screws.

123

4. Connecting the Sewing Drive to the Table Top

4.1 General Different drive and connections packages are available

for the machine.

The drive package consists of:

Motor, motor protection switch with wiring, belt, belt pul-

ley.

The connectios package contains all wiring between the

motor and the sewing head.

The direct current drive available for this machine is ope-

rated by a "monophase alternating voltage". Therefore,

with multiple machines, the connections must be uniform-

ly distributed to the individual phases of the mains supply

(3 phase). Otherwise, this could lead to an overload of

the individual phases.

Attention!

If the electronics are not supplied by Dürkopp Adler, then

manufacture and testing is to be conducted to EN 60204-

3-1/JEC 204-3-1.

4.2 Drive Mounting

–Screw the drive with its base to the table top. Hereby

screw the 3 hex head M8 x 35 screws with washers

into the nuts in the table top.

–Fasten the V-belt pulley to the motor shaft

–Check the connections on the motor terminal board

and correct if necessary.

The arrangement must be appropriate to the mains

voltage.

4.3 Voltage Compensation Motor/ Machine Head

–Screw the green-yellow connecting cable found in

the enclosed package onto the motor base. It serves

to conduct the machine head static charge to ground

via the motor.

4.4 Attaching the Pedal and Rod.

For ergonomic reasons the lateral direction of the pedal is

to be aligned centered to the needle. Set the rod so that

the pedal has an incline of 10°.

4.5 Electrical Connections of the Motors

Please see the wiring diagrams enclosed in the drive

package for the necessary technical connections data.

5. Attaching the Machine Head

5.1 Mounting the Sewing Head, Establishing the Voltage

Compensation, Positioning the V-belt

–Mount the sewing head and fasten with three M8 x

95 Allan screws with washers and nuts.

–Establish the voltage compensation.

Screw the enclosed single-wire cable 1 to the sewing

head.

–Positioning the V-belt.

–Set the V-belt tension.

By swinging the motor, tension the V-belt so that it

can be pressed in at its center by about 10 mm

without great effort.

–Screw on the motor belt guard.

Set the cams so that the belt cannot slide out of the

V-belt pulley when the sewing machine is swung to

the back.
