DURKOPP ADLER 906 Manual de funcionamiento
906
Additional Instructions
Attaching the Bar Code Scanner
All rights reserved.
Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents,
including extracts, is prohibited without the prior written approval of Dürkopp Adler AG.
Copyright © Dürkopp Adler AG - 2014
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Table of contents
Additional Instructions 906 - 00.0 - 11/2014 1
1 Scope of delivery........................................................................3
2 Bar code types............................................................................4
3 Fitting the parts set ....................................................................5
3.1 Removing the covers....................................................................5
3.2 Fitting and connecting the power supply......................................7
3.3 Laying and connecting supply lines..............................................8
3.4 Fitting the holder and bar code scanner.....................................11
3.5 Connecting the bar code scanner...............................................12
3.6 Sticking the bar code..................................................................12
3.7 Activating the bar code scanner.................................................13
3.8 Assigning the ID .........................................................................14
3.9 Aligning the bar code scanner....................................................14
3.10 Fitting the covers ........................................................................16
4 Bar codes ..................................................................................18
Additional Instructions 906 - 00.0 - 11/2014
2
Scope of delivery
Additional Instructions 906 - 00.0 - 11/2014 3
1 Scope of delivery
Check whether the scope of delivery of the parts set 0911 597804 is
correct prior to the attachment.
Components of the parts set
Part no. Quantity Description
0791 906702 1Additional instructions
0911 494030 1Holder
0911 494040 1Holder
9202 002877 1Cylinder-head bolt M6x10
9203 003737 3Cylinder-head bolt M4x25
9204 201647 1Pan-head screw M4x6
9223 000930 2Cylinder-head bolt M1.6x5
9830 501025 3Spacer sleeve
9840 121001 10 Cable tie
9850 911004 1Level converter
9850 911005 1Circuit board
9850 911006 1Bar code scanner
9870 906006 1Cable set
Bar code types
Additional Instructions 906 - 00.0 - 11/2014
4
2 Bar code types
The following bar code types can be read by the bar code scanner:
• Code 128
• Code 39
These bar code types can be created with freeware software. Observe
that the bar code must consist of 3 to 10 characters (incl. spaces).
However, you can also use the bar codes provided on the last page.
Fitting the parts set
Additional Instructions 906 - 00.0 - 11/2014 5
3 Fitting the parts set
Requirements:
• Switch off the machine.
• Unplug the power plug.
3.1 Removing the covers
1. Loosen the screws (2).
Fig. 1: Right cover, front view
2. Remove the cover (1).
3. Loosen the screws (5).
Danger of electric shock due to live parts!
Serious injuries to life and limb.
The bar code scanner may be attached only by
qualified technicians.
Switch off the machine and pull the power plug.
Make sure the power plug cannot be accidentally
plugged back in.
DANGER
(1) - Right cover (2) - Screws
①
②
Fitting the parts set
Additional Instructions 906 - 00.0 - 11/2014
6
Fig. 2: Left cover, rear view
4. Remove the cover (4).
5. Loosen the screws (6).
Fig. 3: Rear cover
6. Remove the rear cover (3).
You can begin with the installation and the connection of the circuit board.
(3) - Rear cover
(4) - Cover (5) - Screws
⑤
③④
(6) - Screw
⑥
Fitting the parts set
Additional Instructions 906 - 00.0 - 11/2014 7
3.2 Fitting and connecting the power supply
Fig. 4: Side without power unit
1. Fit the circuit board with power supply (1) with spacer sleeves (2)
and M4x25 cylinder-head bolts (3).
Fig. 5: Side with power supply
2. Connect the cable (0.2 m) (8) from the cable set with the 3-pin plug
connection (6) of the power supply.
3. Connect the cable (8) to the 10-pin flat plug of the circuit board:
White core (7) to 8 (+24 V-1)
Brown core (5) to 9 (Y9)
Green core (4) to 10 (GND)
(1) - Power pack
(2) - Spacer sleeve (3) - Cylinder-head bolt
①
②③
Fitting the parts set
Additional Instructions 906 - 00.0 - 11/2014
8
Fig. 6: Connecting the cable
3.3 Laying and connecting supply lines
1. Lay the supply lines from the cable set on the side cover to the side
cover parallel to the cable harness to allow supply line A (1.2 m) (1) to
be connected with the white and brown core to the power supply and
supply line B (2.2 m) (2) to the controller (page 9.).
2. Fastenthesupplylineswithcableties (3)tothecableharnessattherear.
Fig. 7: Laying supply lines, rear view
3. Laysupplylineswitha6-pinpinstrip (4) to thepointwherethebar code
scanner is to be fitted.
4. Fasten the supply lines (6) with cable ties (5) to the cable harness on
the right.
(4) - Green core
(5) - Brown core (6) - 3-pin plug connection
(7) - White core
(8) - Cable
④
⑤⑥
⑧
⑦
(1) - Supply line A
(2) - Supply line B (3) - Cable tie
②
①③
②
