DuraVision FDX1001T Manual de usuario
Important
Please read this User’s Manual carefully to familiarize yourself with safe and
effective usage. Please retain this manual for future reference.
重要事项
请仔细阅读用户手册，掌握如何安全、有效地使用本产品。请保留本手册，
以备日后参考。
Cover
2
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information condential
unless prior arrangements are made pursuant to EIZO NANAO CORPORATION’s receipt of said information.
Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.
Apple, ColorSync, eMac, iBook, iMac, iPad, Mac, MacBook, Macintosh, Mac OS, PowerBook, and QuickTime are registered trademarks
of Apple Inc.
Windows, Windows Media, Windows Vista, SQL Server, and Xbox 360 are registered trademarks of Microsoft Corporation in the United
States and other countries.
VESA is a registered trademark of Video Electronics Standards Association.
NEC is a registered trademark of NEC Corporation.
PC-9801 and PC-9821 are trademarks of NEC Corporation.
EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are
registered trademarks of EIZO NANAO CORPORATION in Japan and other countries.
All other company and product names are trademarks or registered trademarks of their respective owners.
SAFETY SYMBOLS
This manual and this product use the safety symbols below. They denote critical information. Please read them carefully.
WARNING
Failure to abide by the information in a WARNING may result in serious injury and can be life threatening.
CAUTION
Failure to abide by the information in a CAUTION may result in moderate injury and/or property or product damage.
Indicates an attention to be required.
Indicates a prohibited action.
Using the special functions, such as screen size change (ex. changing the horizontal and vertical ratio of images input)
for commercial purposes or for the purpose of showing in public may violate copyright laws.
This product has been adjusted specically for use in the region to which it was originally shipped. If operated outside
this region, the product may not perform as stated in the specications.
3
PRECAUTIONS
IMPORTANT
• This product is intended to be used with an industrial device designed to build industrial systems.
-Transportation systems (Ship, aircraft, train, automobile, etc.)
-Safety devices (Disaster prevention system, security control system, etc.)
-Equipment with direct effect on human life (Life support systems, Medical equipment or devices used in the
operating room, etc.)
-Nuclear energy control devices (Nuclear energy control systems, security control systems of nuclear facilities,
etc.)
-Main line devices (Operation control for transportation, control systems specic to aircrafts, etc.)
• To ensure personal safety and proper maintenance, please read this section.
WARNING
This product is intended to be housed in an enclosure. Do not use the bare monitor
separately.
Attempting to use a malfunctioning unit may result in electric shock, or equipment damage.
If the unit begins to emit smoke, smells like something is burning, or makes strange
noises, disconnect all power connections immediately and contact your dealer for
advice.
Attempting to use a malfunctioning unit may result in re, electric shock, or equipment damage.
Do not open the cabinet or modify the unit.
Opening the cabinet or modifying the unit may result in re, electric shock, or burn.
Refer all servicing to qualied service personnel.
Do not attempt to service this product yourself as opening or removing covers may result in re, electric
shock, or equipment damage.
Keep small objects or liquids away from the unit.
Small objects accidentally falling through the ventilation slots into the cabinet or spillage into the cabinet
may result in re, electric shock, or equipment damage. If an object or liquid falls/spills into the cabinet,
unplug the unit immediately. Have the unit checked by a qualied service engineer before using it again.
Use the unit in an appropriate location.
Not doing so may result in re, electric shock, or equipment damage.
• Do not place outdoors.
• Do not place in a transportation system (ship, aircraft, train, automobile, etc.) where it may be affected
by strong vibration or shock.
• Do not place in a dusty or humid environment.
• Do not place in a location where water is splashed on the screen (bathroom, kitchen, etc.).
• Do not place in a location where the steam comes directly on the screen.
• Do not place near heat generating devices or a humidier.
• Do not place in a location where the product is subject to direct sunlight.
• Do not place in an inammable gas environment.
4
WARNING
Use the enclose AC adapter.
The enclosed AC adapter is for use with this product only. Do not use the AC adapter with other
equipment. Connecting to power sources that do not match the power ratings of the AC adapter may
result in re or electric shock.
Make sure the power cord meets the following requirements.
This product does not include a power cord. Please provide separately a power cord which meets the
requirements. (For more information, please contact your dealer.)
• The power cord is compatible with the standards of the country and region in which
this product is to be used.
• The power cord has a rated value of at least 2.5A.
Power supply: 100-240Vac 50/60Hz
To disconnect the power cord, grasp the plug rmly and pull.
Tugging on the cord may damage and result in re or electric shock.
Use the correct voltage.
• The unit is designed for use with a specic voltage only. Connection to another voltage than specied
in this User’s Manual may cause re, electric shock, or equipment damage.
Power supply: 100-240Vac 50/60Hz
• Do not overload your power circuit, as this may result in re or electric shock.
Handle the power cord and AC adapter with care.
Do not place heavy objects on, pull or tie the power cord or the AC adapter. Use of a damaged cord or
AC adapter may result in re or electric shock.
Never touch the plug, AC adapter or power cord during a thunderstorm.
Touching them may result in electric shock.
Do not touch a damaged LCD panel directly with bare hands.
The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part
of the skin or body comes in direct contact with the panel, please wash thoroughly. If some physical
symptoms result, please consult your doctor.
5
CAUTION
Handle with care when carrying the unit.
Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is
dangerous. It may result in injury.
Do not install the unit in a closed space.
If the inerior becomes hot, it may result in re, electric shock or damage.
Do not touch the power plug or AC adapter with wet hands.
Doing so may result in electrical shock.
Use an easily accessible power outlet.
This will ensure that you can disconnect the power quickly in case of a problem.
Mind that the AC adapter becomes hot during use.
• Do not cover or place anything on top of the AC adapter. Do not place the AC adapter on top of things
that trap heat. Keep the AC adapter away from heat sources and direct sunlight.
Not doing so may result in re.
• Do not touch with bare hands. Doing so may result in burns.
The ambient temperature for using the AC adapter should not exceed 40 °C (104 °F).
Do not suspend the AC adapter in midair.
Using it while suspended in midair may result in re or electric shock.
Periodically clean the area around the plug.
Dust, water, or oil on the plug may result in re.
Unplug the unit before cleaning it.
Cleaning the unit while it is plugged into a power outlet may result in electric shock.
If you plan to leave the unit unused for an extended period, disconnect the power cord
from the wall socket after turning off the power for safety and power conservation.
6
Notice for this monitor
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is used
outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
Only use optional products manufactured or specied by us with this product.
As it takes about 30 minutes for the performance of electrical parts to stabilize, adjust the monitor 30 minutes or more
after the monitor power has been turned on.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and maintain a
stable display.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. (Refer to
“Cleaning” on the next page.)
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on
the LCD panel, this is not a malfunction. Percentage of effective dots: 99.99% or higher.
The backlight of the LCD panel has a xed lifetime. When the screen becomes dark or begins to icker, please contact
your local EIZO representative.
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt to
brush with tissues as this may scratch the panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may
occur on the interior and exterior surfaces of the monitor. In that case, do not turn the monitor on. Instead wait until the
dew condensation disappears, otherwise it may cause some damage to the monitor.
(Cautions for the Use of the Touch Panel)
• During touch operation
Be careful of the following points. Otherwise, damage may occur to the monitor.
- Do not strongly press, scratch, or poke the panel.
- Do not touch the panel with hard objects such as ballpoint pens or metals.
7
Cleaning
ATTENTION
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the panel, and
also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the panel.
• Do not allow liquid to enter the clearance between the panel and the panel frame.
NOTE
• The optional ScreenCleaner is recommended for cleaning the panel surface.
If necessary, the stains on the panel surface can be removed by moistening part of a soft cloth with water.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor
according to the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.
8CONTENTS
CONTENTS
Cover ............................................................ 1
PRECAUTIONS ................................................ 3
Notice for this monitor .............................................. 6
CONTENTS ............................................................ 8
Chapter 1 Introduction ......................................... 9
1-1. Features .............................................................. 9
1-2. Package Contents ............................................ 10
Chapter 2 Assembly ........................................... 11
Chapter 3 Settings and Adjustments ................ 14
3-1. Buttons .............................................................. 14
3-2. Basic Operation and Functions ...................... 15
Chapter 4 Troubleshooting ................................ 18
Chapter 5 Reference........................................... 20
5-1. Specications ................................................... 20
5-2. Glossary ............................................................ 24
5-3. Preset Timing .................................................... 25
LIMITED WARRANTY .......................................... 26
9
Chapter 1 Introduction
Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
• FDX1001T / FDV1001T: 10.4-inch screen, FDX1201T: 12.1-inch screen
• Resolution
- FDX1001T / FDX1201T: XGA (1024 × 768) display compliant
- FDV1001T: VGA (640 × 480) display compliant
• Maximum brightness
FDX1001T: 460 cd/m2, FDV1001T: 350 cd/m2, FDX1201T: 780 cd/m2
• LED backlight LCD panel
The LED backlight provides better power efficiency and reduced power consumption compared to existing
uorescent backlight LCD panels.
No mercury, a hazardous substance, is used.
• Analog signal support
PC signal: D-Sub mini 15 pin connector × 1
- FDX1001T / FDX1201T:
Horizontal scanning frequency 24 kHz - 50 kHz, Vertical scanning frequency 55 Hz - 75 Hz
- FDV1001T:
Horizontal scanning frequency 24 kHz - 32 kHz, Vertical scanning frequency 56 Hz - 70.5 Hz
Video signal: S-Video/ Video input connector × 1
- Applicable Format NTSC, PAL, SECAM
• Resistive technology touch panel function
Enables touch operation of the PC screen.
• Crosshair display function
Displays lines (Fine, Circle or Broken Line) as a reference for the position of the image displayed on the monitor.
(page 17)
• Video aspect function
Alters the display range of the input image (overscan). (page 17)
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
Otros manuales de Monitor de DuraVision
