DRIFT Ghost XL Manual de usuario
1
Thank you for purchasing the Drift Ghost XL
CUSTOMER SUPPORT
Check our official website for firmware updates, customer
support, and info on all our products.
https://driftinnovation.com/
If you have any suggestions, comments or concerns; please
contact our customer support team at:
WARRANTY
Warranty does not apply if the product is damaged due to
physical abuse, mishandling, accident, fire, frostbite, water
damage, negligence or failure to follow the supplied operating
instructions. For more information on warranty, see:
https://driftinnovation.com/warranty
2
CONTENTS
3-4 PACKAGE CONTENTS | ABOUT YOUR CAMERA
5-6 INITIAL SETUP | GETTING STARTED
7-10 MODE SELECTION & SETTINGS
11 MOUNTING THE CAMERA
12-17 FEATURE OVERVIEW
18-19 ACCESSORY GUIDE
20 Wi-Fi & FIRMWARE
21 CONNECTING YOUR CAMERA
22-23 SPECIFICATIONS
24-26 DISCLOSURES
3PACKAGE CONTENTS
A Ghost XL
BUniversal Clip
CCurved Adhesive Mount
DFlat Adhesive Mount
ETRS-Audio Adaptor Cable
FTRS-Power Cable
GUSB Cable B
C
D
A
E
F
G
4
ABOUT YOUR CAMERA
ARear Button
BMiddle Button
CFront Button
DStatus LED
ERear Screen
FMicrophone
G5 PIN Micro USB Port
HMicro SD Card Slot
I External Mic/Power
Connector
JExternal Mic/Power
Cover
KRotating Lens
LMemory Card and
USB Door
GHOST XL
A B C D
E
K
F
J
I
HG
L
5INITIAL SETUP
1.Open the Memory Card and USB door.
2.Insert a Class 10 or higher microSD/HC/XC card (up to 128GB).
Format before first usage!
3.Connect the camera via a micro USB cable to a powered USB
port, and charge the battery for 5 hours before first use.
4.Close the Memory card and USB door, and ensure that the
latch is secured. You are ready to go!
6
GETTING STARTED
POWER ON/OFF
1.Press and hold the button to power on.
2.The Rear Screen will power on, showing the welcome display.
3.The camera is now ready to record video or take photos.
4.Current camera mode is indicated by the colour of the Status
LED and Rear Screen, along with the icon in the top left of the
Rear Screen.
5.To power off, press and hold the button for 3 seconds.
MODE NAVIGATION
To change the current camera recording mode, press the
button; changing between Video, Photo, Timelapse, Photoburst,
and General Settings modes.
2 4
Mode Icon
7MODE SELECTION & SETTINGS
MODE SETTINGS
To change the settings of
the current mode press the
button, this will move the
highlight block from the mode
icon onto each setting in turn.
VIDEO MODE
(Green LED) Press the
button to start recording. The
Status LED and LCD backlight
will flash red to indicate
recording. Press the button
again to stop recording.
VIDEO SETTINGS
●Resolution
●Frame Rate
PHOTO MODE
(Yellow LED) The camera will
capture still images when the
button is pressed, and the
status LED and LCD screen will
flash red each time a photo is
captured.
PHOTO SETTINGS
●Resolution
TIMELAPSE MODE
(Purple LED) Press the
button to capture a series
of still images at a specified
rate. The Status LED and LCD
screen will flash red each time
an image is captured. To stop
recording, press the button
once more.
8
MODE SELECTION & SETTINGS
TIMELAPSE SETTINGS
●Resolution
●Timelapse Interval
PHOTOBURST MODE
(Cyan LED) The camera will capture a burst of still images for an
allotted duration and at a specified rate, when the button is
pressed. For best results, use a memory card with the highest
possible data rate.
PHOTOBURST SETTINGS
●Resolution
●Burst Duration
●Capture Rate
GENERAL SETTINGS
(Red LED) Press the button to scroll through the available
settings, press and hold the button to scroll backwards
the Settings. and press to cycle through the options of a
highlighted setting.
9
●Dash Cam ON/OFF
●Dash Cam Interval 10s/30s/1min/2mins/5mins
●Event Detection ON/OFF
●Video Tagging ON/OFF
●Tagging Interval 10s/30s/1min/2mins/5mins/10mins
●Wi-Fi ON/OFF
●RC Paired/Unpaired
●FOV 140/115/90
●Exposure +2/+1/0/-1/-2
●Self Timer OFF/3s/5s/10s
●Bit Rate High/Mid/Low
●Filter Normal/Vivid/Low Light
●ISO Auto/100/200/400/800
●Mic Sensitivity 0/1/2/3/4/5
●Speaker Volume OFF/Low/Mid/High
●Indicator LED ON/OFF
●Vibrate Indication
ON/OFF
●Default Startup Mode
Resume/Video/Photo/Timelapse/
Burst
MODE SELECTION & SETTINGS
10
●Camera Off Never/2mins/5mins/10mins/20mins
●THM Files ON/OFF
●Time and Date
●Date Stamp ON/OFF
●Instant On ON/OFF
●Clone Mode ON/OFF
●Clone Group 0/1/2/3/4/5
●Video-Lapse ON/OFF
●Video-Lapse Interval 0.5s/1s/2s/5s/10s/30s
●Language EN/DE/FR/IT/ES/CN
●Restore Default
●Format SD Card
●Serial Number
●Firmware Version
MODE SELECTION & SETTINGS
