Draytek VigorSwitch P1080 Manual de usuario

-P

Quick Start Guide

European Community Declarations

Manufacturer: DrayTek Corp.

Address: No. 26, Fu Shing Road, HuKou Township, HsinChu Industrial Park, Hsin-Chu, Taiwan 303

Product: VigorSwitch P1080

DrayTek Corp. declares that VigorSwitch P1080 is in compliance with the following essential requirements and other relevant

provisions of 2004/108/EC.

The product conforms to the requirements of Electro-Magnetic Compatibility (EMC) Directive 2004/108/EC by complying with

the requirements set forth in EN55022/Class A and EN55024/Class A.

The product conforms to the requirements of Low Voltage (LVD) Directive 2006/95/EC by complying with the requirements

set forth in EN60950-1.

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following

measures:

zReorient or relocate the receiving antenna.

zIncrease the separation between the equipment and receiver.

zConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.

zConsult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device may accept any interference received, including interference that may cause undesired operation.

Version: 1.01

Date: 15/03/2011

nPackage Content

This switch provides 8 10/100M PoE ports. It was designed for easy

installation and high performance in an environment where PoE devices

might need to be connected to the network.

The switch consists of 8 PSE/PoE ports. Providing power to devices via PoE

can offer a solution where power outlet availability is limited and offer the

system designer a flexible solution to locate the network device anywhere.

This is particularly useful for wall-mounted devices such as IP Cameras

where the ideal location to position the device is not nearby a power outlet.

The compact rigid desktop size was specifically designed for small to

medium workgroups. It can be installed where space is limited; moreover, it

provides smooth network migration and an easy way to upgrade to network

capacity.

Quick Start Guide UK-type power cord EU-type power cord

Note: If any of these items is found missing or damaged, please contact

your local supplier for replacement.

oDescriptions of Panel

LED Status Explanation

On The device is powered on.PWR Off The device is powered off.

On A normal connection is through its corresponding

port.

Off LAN is disconnected.

ACT

Blinking Data is transmitting (sending/receiving).

On Connect to a Power Device.PoE Off No Power Device is connected.

Interface Description

Power inlet for AC input (100~240V/AC, 50~60Hz).

Installing Your Switch

Power Device to This Switch and Getting 48V Power Source through

Cat. 5 Cables

Use a Cat. 5 twisted-pair cable to connect a PoE device to the port (1~8) of this

switch. This switch will supply 48V power to PoE Device over Cat. 5

twisted-pair cable. Please note that Power Device must comply with IEEE

802.3af.

PC/Other Devices to This 8-Port PoE Ethernet Switch

Other PCs, servers and network devices can be connected to the switch using a

standard ‘straight through’ twisted pair cable.
