SettingUpAircraftandBatteries

Thearmsoftheaircraftisfoldedonitsdelivery.Followtheinstructionsbelowtounfoldthearmsoftheaircraft.



SettingUpAircraft

1. Rotateanti‐clockwisetounfoldfrontarmstowardsthenoseoftheaircraft.



2. Rotateanti‐clockwisetounfoldreararmsoftheaircraft.



3. Unfoldallpropellerbladesandensureallbladesarealigned.



4. EnsuretheIntelligentFlightBatterysecurelyattachedtotheaircraft.TheIntelligentFlight

Batterymustbefullychargedonitsfirstuse.



SettingUpRemoteController

Unfoldthemobileholderclampsandadjustthepositionoftheantennas.

1. Insertthemobiledevicesintothespacebetweenthetwomobileholderclamps.



2. Pushthemobileholderclampsagainstthemobiledevicetosecureitsposition. 



3.ConnectyourmobiledevicewiththeaUSBcable.Youmayalsoconnectthemobiledeviceto

thechargingportoftheremotecontrollerwiththesuppliedmulti‐purposeUSBcable.



AircraftDiagram



1. GPS

2. ObstacleSensingSystem

3. Motor

4. Gimbal



5. FrontLEDIndicator

6. VisionPositioningSensors

7. AircraftStatusIndicator



8. ControlModeSwitch

9. CameraMicroSDCardSlot

10. LinkingButton



11. CameraMicroSDCardSlot

RemoteControllerDiagram



[1]Antennas

Relaysaircraftcontrolandvideosignal.



[2]PowerButton

Usedtopoweronorofftheremotecontroller



[3]ControlStick

Controlstheorientationandmovementoftheaircraft.



[4]AppButton

GainquickaccesstothefeatureintheDJIGOapp.



[5]MobileHolderClamp

Adjustitswidthtoaccommodatethemobiledevice.



[6]IntelligentFlightPauseButton

PressoncetoallowtheaircrafttoexitfromTapFly,ActiveTrackandAdvancedmode.



[7]ReturnHome(RTH)Button

PressandholdthebuttontoinitiateReturntoHome(RTH).



[8]RemoteControllerStatusScreen

Displaysystemstatusoftheremotecontroller.



[9]USBPort

ConnecttomobiledeviceforrunningtheDJIGOapp.



[10]C2Button



[11]CameraSettingsDial

Turnthedialtoadjustcamerasettings.(Onlyfunctionswhentheremotecontrollerisconnected

toamobiledevicerunningtheDJIGOapp.)



[12]ShutterButton

Presstotakeaphoto.Ifburstmodeisselected,thesetnumberofphotoswillbetakenwithone

press.



[13]VideoRecordingButton

Presstostartrecordingvideo.Pressagaintostoprecording.

[14]GimbalDial

Usethisdialtocontrolthetiltofthegimbal.



[15]C1Button

PressC1buttononcetolaunchtheDJIGOapponthemobiledevice.



[16]LanyardHole

Usedtosecurethepositionofyourlanyard.



[17]FlightModeSwitch

SwitchbetweenP‐mode,S‐mode



[18]ChargingPort

Connecttothesuppliedchargingcableforchargingthebattery.Connecttothesupplied

mulit‐purposeUSBcableforaccessingtomobiledevice.



UsingRemoteController

Remotecontrollercomeswitharechargeablebattery.Thebatterylevelisdisplayedonthe

remotecontrollersystemstatusscreen.Followthestepsbelowtopowerontheremote

controller:

1.Pressonceandreleasetocheckthecurrentbatterylevel.

2.PressandholdthePowerButtontoturnontheremotecontroller.

3.Theremotecontrollerwillbeepwhenitisturnedon,inaddition,thebatterylevelisdisplayed

ontheremotecontrollerstatusscreen.

4.RepeatStep2toturnofftheremotecontroller.



IntelligentFlightBattery

PoweronorofftheIntelligentFlightBattery

TurningOn:PressthePowerButtononce,thenpressagainandholdfor2secondstoturnon.

ThePowerLEDwillturnredandtheremotecontrollersystemstatusscreenwilldisplaythe

currentbatterylevel.

TurningOff:PressthePowerButtononce,thenpressagainandholdfor2secondstoturnoff.

Powerlevelindicatorsturnoffwhenitispowerdown.

Swith



Charging

1.ConnecttheBatteryChargertoapowersource(100‐240V50/60Hz).

2.ConnectoneendofthechargertotheIntelligentFlightBatterytotheBatteryCharger.Ifthe

batterylevelisabove95%,turnonthebatterybeforecharging.

3.TheBatteryLevelIndicatorwilldisplaythecurrentbatterylevelasitischarging.

4.TheIntelligentFlightBatteryisfullychargedwhentheBatteryLevelIndicatorsarealloff.

DisconnecttheIntelligentFlightBatteryfromtheBatteryCharger.

5.Air‐cooltheIntelligentFlightBatteryaftereachflight.Allowitstemperaturetodroptoroom

temperaturebeforestoringitforanextendedperiod.

6.Thechargerwillstopchargingthebatteryifthebatterycell’stemperatureisnotwithinthe

operatingrange(0°C~40°C).



PoweringontheAircraftandRemoteController

1. Unfoldthefrontandreararmsandpropellers.

2. PowerontheremotecontrollerfollowbytheIntelligentFlightBattery.



3. LaunchtheDJIGOappandenterthe“Camera”view.

StartingandStoppingtheMotors

StartingtheMotors

Pushbothstickstothebottominneroroutercornerstostartthemotors.Oncethemotorshavestartedspinning,releaseboth

stickssimultaneously.



StoppingtheMotors

Therearetwomethodstostopthemotors.Whentheaircrafthaslanded,pushthethrottledown①,thenconductthesame

CSCthatwasusedtostartthemotors,asdescribedabove.Motorswillstopimmediately.Releasebothsticksoncethemotors

stop.Method2:Whentheaircrafthaslanded,pushandholdthethrottledown.Themotorswillstopafter3seconds.







Using Mobile Device for Aircraft Control

YoumaychoosecontroltheaircraftviatheWiFiconnectionbelowthemobiledeviceandthe

aircraft.FollowthestepsbelowtolearnhowtousethemobiledevicestocontrolyourWM200

aircraft.
