Dimplex MULTIFIRE DF3215 Guía de inicio rápido

PARTS & SERVICE MANUAL

FOR THE 32” MULTIFIRE™

FIREPLACE

MODEL NUMBER:

DF3215

TABLE OF CONTENTS

OPERATION PAGE1

PARTS DRAWING PAGE 5

PARTSLIST PAGE6

WIRING DIAGRAM PAGE 7

LIGHT BULB REPLACEMENT PAGE 8

FILTER REPLACEMENT PAGE 10

REMOTE CONTROL SWITCH BOARD REPLACEMENT PAGE 11

REMOTE CONTROL RECEIVER REPLACEMENT PAGE 12

FLAME MOTOR/FLAME ROD REPLACEMENT PAGE 13

MAIN ON/OFF SWITCH REPLACEMENT PAGE 15

HEATER ASSEMBLY REPLACEMENT PAGE 16

POWER CORD REPLACEMENT PAGE 17

DF3215

OPERATION

ELECTRIC FIREPLACE MANUAL CONTROL

The manual controls for the fireplace are located in the upper right hand corner.

A. Main On/Off Switch

Supplies power to the 3 position manual control switch.

B. 3 Position Manual Control Switch

Position 1 (left position): The unit is operated with the remote control.

Position 2 (center position): The flame effect is turned ON.

Position 3 (right position): The flame effect and heater are turned ON simultaneously.

When the manual control is in Position 3 the heater does not run on the remote

operated thermostat. When the heater is ON the red indicator light is activated on the

firebox and the fan and heater are running on low.

NOTE

When the manual control is in positions 2 and 3, the fireplace unit will not operate with

the remote control.

RESETTING THE TEMPERATURE CUTOFF SWITCH

Should the heater overheat, an automatic switch will turn the heater off and it will not

come back on without being reset. The temperature cutoff switch can be reset by

unplugging the unit, waiting 5 minutes and plugging the unit back in.

CAUTION

If you need to continuously reset the heater, unplug the unit and call Dimplex North

America Limited at 1-800-668-6663 and press 4 for technical support.

FIGURE 1

Indicator

Light

Initialization

Button

3 Position

Manual

Control

Main

On/Off

Switch

SERIAL No.

XXX XX

DF3215

REMOTE CONTROL

The remote control has a range of approximately 50 ft. (15.25m), it does not have to be

pointed at the fireplace and can pass through most obstacles (including walls). It is

supplied with 243 independent frequencies to prevent interference with other units.

BATTERY INSTALLATION

1. Depress tab on the battery cover on the back of the remote transmitter and

remove battery cover.

2. Install 3 AAA batteries into the remote control (included).

3. Replace the battery cover.

NOTE

The remote transmitter has a battery backup time of 24 hours. The batteries can be

removed for up to 24 hours before the transmitter will require re-initialization.

NOTE

When the Low Battery icon is present on the remote control it is recommended to

replace the batteries promptly, to maintain full functionality of the remote/fireplace

(FIGURE 5).

INITIALIZING THE REMOTE CONTROL

1. Plug cord into 120 volt wall outlet.

2. Turn ON the electrical power at the circuit breaker.

3. Ensure the Main On/Off switch located inside the fireplace in the upper right hand

corner is in the ON position.

4. Set the 3 position manual control to Position 1 (left position).

5. Press and hold the initialization button on the unit.

6. While holding the initialization button, press the flame/heat ON/OFF button or

the Purifire™ ON/OFF button on the remote control transmitter.

7. Release the initialization button on the unit. The remote control is now ready for

operation.

Batteries

Indicator

Light

Initialization

Button

3 Position

Manual

Control

FIGURE 2

FIGURE 3

Main

On/Off

Switch

SERIAL No.

XXX XX

DF3215

FREQUENCY INTERFERENCE

If the fireplace does not respond properly to the remote control, the remote operating

frequency may have to be reset. The remote control can send another frequency code

to the circuit board to eliminate interference.

1. Press the ENTER button on the remote control, the middle display flashes.

2. Use the direction buttons on the hand held remote to move the cursor to and

press ENTER.

3. Press and hold the initialization button on the unit.

4. Press and hold left direction button on the remote control.

5. A descending bar graph will appear on the screen.

6. The green indicator light will flash on the unit when the new frequency code has

been stored.

7. Release left direction button on the remote control.

8. Release the initialization button on the unit.

9. Press ENTER to return to the main menu.

Indicator

Light

Initialization

Button

3 Position

Manual

Control

Main

On/Off

Switch

SERIAL No.

XXX XX

FIGURE 4

Remote display

Up direction

button

Left direction button

Flame/Heat ON/OFF

button

DF3215

REMOTE CONTROL FUNCTIONS

FLAME/HEAT ON/OFF BUTTON

Press the Flame/Heat On/Off button to turn the Flame/Heat function ON. When the

heater function is ON, the icon is displayed on the remote control in the upper left

hand corner. When this icon is displayed, the red indicator light is activated on the

firebox. The default temperature setting is 72°F (22°C). Press the Flame/Heat On/Off

button to turn the Flame/Heat function OFF.

NOTE

When using the remote control the heater runs on a thermostat. Press the or

direction keys to adjust the set temperature. Once the desired set temperature is

reached the heater will turn OFF. The heater will cycle ON and OFF to maintain the

desired set temperature.

PURIFIRE ON/OFF BUTTON

Press the Purifire™ On/Off button to turn the Purifire™ function ON. When the

Purifire™ function is ON and the Heater icon is NOT displayed on the remote control,

the green indicator light is activated on the firebox. The default setting for the Purifire™

is set at low speed. Press the Purifire™ On/Off button to turn the Purifire™ function

OFF.

NOTE

To turn the Flame/Heat and Purifire™ ON or OFF at the same time, press both

control buttons simultaneously.

*For detailed instructions on any of the functions, consult the User’s Guide*

Right

direction

button

Down

direction

button

Sleep timer

Purifire™ ON/OFF button

Enter button

Occupancy

Sensor

Set temperature

Day of week

Room temperature Time of da

Ambient Light

Sensor

Batteries

FIGURE 5

Low

Battery

Indicator

DF3215

REPLACEMENT PARTS

FIREBOX, 32" - DIMPLEX - MULTIFIRE –

CATALOGUE NO. DF3215

PART NO. 6902520159

MOD LEVEL: NONE

MADE IN: CHINA

REPLACEMENT PART REPLACEMENT PART NO.

1. 30” URETHANE LOG SET ASSEMBLY 0439070100RP

2. HEATER ASSEMBLY 2200490500RP

3. UPPER & LOWER LIGHT ASSEMBLY 2500200200RP

4. WIRE HARNESS – RECEIVER TO BLOWER 2500390100RP

5. WIRE HARNESS – RECEIVER TO LOGSET 2500380100RP

6. FLAME MOTOR 3000240200KIT

7. REMOTE CONTROL – SENDER 3000320100RP

8. REMOTE CONTROL RECEIVER 3000320200RP

9. REMOTE CONTROL SWITCH BOARD 3000320300RP

10.CORD SET 4100040400RP

11.REFLECTOR ROD 5900080700RP

12.MIRROR, SEMI-SILVERED 5900160700RP

13.FOOT 8800090100RP

14.STEEL CURTAIN 8800240603RP

15.STEEL CURTAIN ROD 8800250400RP

16.BIFOLD DOORS 6902560100RP

17.FILTER 0439060100RP

18.MAIN ON/OFF SWITCH 2800070700RP

DF3215

WIRING DIAGRAM

DF3215

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

Light bulbs need to be replaced when you notice a dark section of the flame. There are

four bulbs under the log set which generate the flames and embers.

It is a good idea to replace all of the light bulbs at one time if they are close to the end of

their rated life. Group replacement will reduce the number of times you need to open

the unit to replace the light bulbs.

LOWER BULB REPLACEMENT

1. Open the bi-fold doors.

2. Pull the front edge of the plastic ember bed or plastic grate up and forward until the

rear tab releases from the ledge located at the bottom of the mirror.

IMPORTANT

ONLY handle the logset by the emberbed.

NOTE

Logset fits tightly into firebox, some force

may be necessary to remove.

3. Set logset in front of firebox.

4. Disconnect the logset LED wire

harness from unit.

5. Lift the left side of the flame rod out of

the mounting bracket.

6. Examine the bulbs to determine which

bulbs require replacement.

7. Unscrew bulbs counter clockwise.

8. Insert new bulbs.

9. Install the left side of the flame rod to

the mounting bracket.

10.Reconnect the logset LED wire harness.

11.Replace the logset by inserting the front of

the emberbed under the front edge of the

fireplace and push down on the rear edge of

the emberbed until it snaps into place.

NOTE

Ensure the logset is installed tightly under the back ledge

to prevent light leakage.

12.Close the bi-fold doors.

LOWER LIGHT BULB REQUIREMENTS

Quantity of 4 clear chandelier or candelabra bulbs with an

E-12 (small) socket base, 60 watt rating.

Example: GE 60BC or Philips 60 CTC.

LED Wire

Harness

Logset

Light Bulb
