Owner’s Manual

Model

CDFI400RH/DFI400RH (6909051142)

CDFI400CH/DFI400CH (6909051143)

DFI600RH (6909051162)

DFI600CH (6909051163)

7213810100R02

IMPORTANT SAFETY INFORMATION: Always read this manual

rst before attempting to install or use the Optimyst® cassette. For

your safety, always comply with all warnings and safety instructions

contained in this manual to prevent personal injury or property

damage.

To view the full line of Dimplex products, please visit

www.dimplex.com

2 www.dimplex.com

Table of Contents

Always use a qualied technician

or service agency to repair

this cassette.

!NOTE: Procedures and

techniques that are considered

important enough to

emphasize.

CAUTION: Procedures and

techniques which, if not

carefully followed, will result in

damage to the equipment.

WARNING: Procedures

and techniques which, if not

carefully followed, will expose

the user to the risk of re,

serious injury, or death.

Welcome & Congratulations....................3

IMPORTANT SAFETY INSTRUCTIONS ..........4

Installation..................................6

Assembly...................................9

Operation..................................11

Maintenance...............................13

Warranty .................................15

Replacement Parts ..........................17

Welcome & Congratulations

Thank you and congratulations for choosing to purchase an Optimyst®

cassette from Dimplex, the world leader in electric replaces.

Please carefully read and save these instructions.

CAUTION: Read all instructions and warnings carefully before

starting installation. Failure to follow these instructions may result in a

possible electric shock, re hazard and will void the warranty.

Please record your model and serial numbers below for future

reference: model and serial numbers can be found on the Model and

Serial Number Label of your cassette.

NO NEED TO RETURN TO THE STORE

Questions with operation or assembly? Require Parts Information?

Product Under Manufacturer’s Warranty?

For Troubleshooting and Technical Support

OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)

Monday to Friday 8:00 a.m. to 4:30 p.m. EST

Please have your model number and product serial

number ready. (See above)

Model Number

Serial Number

4 www.dimplex.com

IMPORTANT SAFETY INSTRUCTIONS

THE ELECTRICAL RATING FOR

THESE MODELS IS

120VAC, 60 HZ, 12 AMP.

When using an electrical furnishing,

basic precautions should always be

followed, including the following:

Read all instructions before using

(this furnishing).

DANGER: To reduce the risk

of electric shock always unplug

this furnishing from the electri-

cal outlet before cleaning.

WARNING: To reduce the risk

of burns, re, electric shock, or

injury to persons:

① Unplug from outlet before putting

on or taking off parts.

② Close supervision is necessary

when this furnishing is used by, or

near children, invalids, or disabled

persons.

③ Use this furnishing only for its

intended use as described in these

instructions. Do not use attach-

ments not recommended by the

manufacturer.

④ Never operate this furnishing if it

has a damaged cord or plug, if it is

not working properly, if it has been

dropped or damaged, or dropped

into water. Contact Dimplex Techni-

cal Service at 1-888-346-7539 for

replacement parts.

⑤ Keep the cord away from heated

surfaces.

⑥ Never operate the furnishing with

the air openings blocked. Keep the

air openings free of lint, hair, and

the like.

⑦ Never drop or insert any object

into any opening.

⑧ Do not use outdoors.

⑨ Do not operate where aerosol

(spray) products are being used

or where oxygen is being adminis-

tered.

⑩ To disconnect, turn all controls to

the off position, then remove plug

from outlet.

WARNING: Risk of Electric

Shock – Connect this furnishing

to a properly grounded outlet

only. See Grounding Instruc-

tions.

⑪ This electrical appliance has hot

and arcing or sparking parts inside.

Do not use in areas where gaso-

line, paint, or ammable liquids are

used or stored.

⑫ Do not modify the unit. Use it

only as described in this manual.

Any other use not recommended by

the manufacturer may cause re,

SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

electric shock or injury to persons.

⑬ To reduce the risk of electric

shock, this appliance has a three

pronged plug. This plug will t in a

grounded outlet only one way. If the

plug does not t, contact a quali-

ed electrician to install the proper

outlet. Do not change the plug in

any way. Always plug this appliance

directly into a wall outlet/receptacle.

Never use with an extension cord

or relocatable power tap (outlet/

power strip).

⑭ Keep away from curtains, drap-

eries and similar materials.

⑮ Always use a certied electrician

should new circuits or outlets be

required.

⑯ Always use properly grounded,

fused and polarized outlets.

⑰ When transporting or storing the

unit and cord, keep in a dry place,

free from excessive vibration and

store so as to avoid damage.

⑱ This furnishing has not been

evaluated for ammability or ciga-

rette ignition resistance.

⑲ Do not submerse.

⑳ Light bulb requirement: 45W,

12VAC halogen bulbs type MR 16.

Contact Dimplex Technical Service

at 1-888-346-7539 for replacement

bulbs.

㉑ The electric fireplace shall be

installed in an enclosure no smaller

than that indicated. (See Figure 2)

CAUTION: The receptacle

cord is intended for use only with

the Dimplex heater 6909070159,

120VAC, 60Hz., 1000W.

!NOTE: Changes or modica-

tions not expressly approved by the

party responsible for compliance

could void user's authority to oper-

ate the equipment.

WARNING: Remote control con-

tains small batteries. Keep away

from children. If swallowed, seek

medical attention immediately.

WARNING: Do not install bat-

tery backwards, charge, put in re

or mix with used or other battery

types - may explode or leak caus-

ing injury.

6 www.dimplex.com

Installation

WARNING: Ensure the power

cord is not installed so that it is

pinched or against a sharp edge

and ensure that the power cord is

stored or secured to avoid tripping

or snagging to reduce the risk

of re, electric shock or injury to

persons.

Grounding Instructions

This product must be grounded.

If it should malfunction or break-

down, grounding provides a path

of least resistance for electric

current to reduce the risk of

electric shock. This product is

equipped with a cord having an

equipment-grounding conductor

and a grounding plug. The plug

must be plugged into an appropri-

ate outlet that is properly installed

and grounded in accordance with

all local codes and ordinances.

DANGER: Improper connec-

tion of the equipment-grounding

conductor can result in a risk

of electric shock. Check with a

qualied electrician or serviceman

if you are in doubt as to whether

the product is properly grounded.

Do not modify the plug provided

with the product – if it will not t

the outlet, have a proper outlet

installed by a qualied electrician.

This product is for use on a

nominal 120-volt circuit and has

a grounding plug that looks like

the plug in Figure 1. Make sure

that the product is connected to

an outlet having the same con-

guration as the plug. No adapter

should be used with this product.

CAUTION: Risk of Electric

Shock. This product has two

cords. Unplug both cords before

moving or servicing this furnishing.

!NOTE: A 15 Amp, 120 Volt cir-

cuit is required. A dedicated circuit

is preferred but not essential in

all cases. A dedicated circuit will

be required if, after installation,

the circuit breaker trips or fuse

blows on a regular basis when the

cassette is operating. Additional

appliances on the same circuit

may exceed the current rating of

the circuit breaker.

Mantel Installation

Install the replace into the

mantel (refer to mantel assembly

instructions).

Figure 1

Installation

Figure 2

New Construction

1. Mark the desired location on

the oor and store the replace

in a safe, dry and dust free

location.

2. Use studs to frame an enclo-

sure with the following mini-

mum internal/opening dimen-

sions (Figure 2).

!NOTE: An air inlet is required

for optimum mist production, see

Figure 2 for minimum dimen-

sions.

!NOTE: For optimal perfor-

mance, the following minimum

clearances between the instal-

lation surface and any surface

above should be maintained:

• Cassette Only: 12 in. (305 mm)

• Cassette with Dimplex heater:

19 in. (483 mm)

Figure 3

3. Secure unit through the two

holes in the bottom of the unit

into supports to prevent the

unit from hanging from the top

ange, see gure 3 for dimen-

sions.

4. The unit is equipped with a

power supply plug and a fused

receptacle (Figure 4), the plug

should be plugged directly into

a 15 A, 120 V outlet.

CAUTION: During operation

8.5 in.

(216mm)

6.7 in.

(170mm)

Air Inlet

DFI400: 100cm2

DFI600: 150cm2

Supports: 0.75 in (19 mm) high

Exit for Cord

DFI400: 15.75 in. (400mm)

DFI600: 22.05 in. (560mm)

Installation

Surface

FRONT

1.2 in.

(30.0 mm)

3.5 in.

(90.0 mm)

3.1 in.

(80.0 mm)

4.8 in.

(122.0 mm)

5.4 in.

(137.0 mm)

1.2 in.

(30.0mm)

8 www.dimplex.com

ensure that the receptacle cord is

positioned so that the face is per-

pendicular to the oor as in Figure

CAUTION: For continued pro-

tection against risk of re, replace

only with same type and rating of

fuse, 10 amp fuse maximum.

5. The receptacle is intended for

plugging in a Dimplex heater

(supplied with the mantel),

which will allow the heater to

be controlled with the provided

remote. (Figure 4)

CAUTION: The receptacle

cord is intended for use only with

the Dimplex heater 6909070159.

If this receptacle is used with any

other product, Dimplex will not be

liable for any damage or issues

that may arise.

Installation

15A 120V

Plug

10A 120V

Receptacle

Figure 4

Transducer

Rock

Media

Removable Rell

Container

Light Bulbs

Assembly

Figure 5

1. Carefully unpack all of the

components from the box.

(Figure 5)

2. Remove top cover by turning

the retaining tabs on both ends

of the water reservoir. (Figure

3. Install the light bulbs by

aligning the pins on the bulbs

and the xture and pressing

down until they are fully

inserted. (Figure 7)

4. Install the transducer so that

it is sitting level in the circular

holding area in the reservoir.

5. Orient transducer wire so that

it does not sit directly above

the emitter and the wire passes

through the slot in the side of

the tank. (Figure 6)

6. Reinstall the top cover and

ensure both retaining tabs have

been turned so that they are

pointing inwards.

7. Fill and install the Rell

Container.

!NOTE: Normal tap water can

be used in the Optimyst® as long

as the tap water is not considered

to be hard water. In the event your

tap water is hard, you may use soft-

ened water or distilled water with

1/8 tsp of salt (0.5 mL) added to the

water reservoir. (The addition of

additional salt should only be used

when you notice that the unit is not

producing mist as expected.)

!NOTE: During initial installation,

the Rell Container should be

relled after the Reservoir has lled

to ensure the maximum operating

time.

Remote

Control

Curved Tray

Housing

Media

Tray

10 www.dimplex.com

Figure 6

Top

Cover

Transducer

Emitter

Wire Slot

Assembly

8. Install the media on top, media

tray and media (if applicable),

so that the opening is not

blocked (Figure 7).

CAUTION: Do not arrange the

media while the unit is running,

since the media and/or tray may be

hot.

9. Make sure the On/Off switch

is switched to Off (refer to

Operating Instruction section).

10. Plug the unit into a 15 Amp/

120 volt outlet.

Retaining

Tab

Figure 7

!NOTE: Rock media shown, install

other medias in the same way.

Fan

Housing

Water Tank

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Chimenea de interior de Dimplex

Dimplex

Dimplex EF2570G-IR Manual de usuario

Dimplex

Dimplex Figaro FGA15 Manual de usuario

Dimplex

Dimplex RBF Manual de usuario

Dimplex

Dimplex BELLINI BLN15W Manual de usuario

Dimplex

Dimplex DF2608 Manual de usuario

Dimplex

Dimplex DNV20CH Manual

Dimplex

Dimplex ROTHESAY RSY20 Manual de usuario

Dimplex

Dimplex VIVALDI DE LUXE Manual de usuario

Dimplex

Dimplex EF3003 Guía de inicio rápido

Dimplex

Dimplex Opti-myst Manual de usuario

Dimplex

Dimplex Revillusion RBF24DLX Manual de usuario

Dimplex

Dimplex CHT20LE Manual de usuario

Dimplex

Dimplex Vivente Plus V V T75 Manual

Dimplex

Dimplex RILEY RLY20-AU Manual de usuario

Dimplex

Dimplex BURNHAM BRN20 Manual de usuario

Dimplex

Dimplex Canterbury CAB20F Manual de usuario

Dimplex

Dimplex DF2608-AU Manual de usuario

Dimplex

Dimplex GDS33HG-1310RG Manual de usuario

Dimplex

Dimplex Charlotte CRT20AB Manual de usuario

Dimplex

Dimplex COMPACT FIREPLACE Manual de usuario

Dimplex

Dimplex EWM-COPPER Guía de inicio rápido

Dimplex

Dimplex 7207380100REV00 Manual de usuario

Dimplex

Dimplex BF8000ST Manual de usuario

Dimplex

Dimplex Juneau JUN Manual de usuario

Manuales populares de Chimenea de interior de otras marcas

Brigantia

Brigantia 35-DVRS31N-2 Manual del propietario

Nordpeis

Nordpeis Bergen Manual de usuario

Superior

Superior BCT2536TMN Manual de usuario

Quadra-Fire

Quadra-Fire 5100I-GD-B Manual de usuario

Renaissance

Renaissance RUMFORD 1000 Manual de usuario

Lacunza

Lacunza IV-800 Manual de usuario

Baxi

Baxi 940 Instrucciones de uso

Dru

Dru Maestro 60/2 Tall RCH Manual de usuario

Diamond Fireglass

Diamond Fireglass SS-O22 Manual de usuario

HearthStone

HearthStone Windsor Bay 8830 Manual de programación

Napoleon

Napoleon ASCENT B42 Manual de usuario

Enviro

Enviro E33GI Manual de usuario

Smeg

Smeg L30 FABE Instrucciones de montaje

KEDDY

KEDDY K700 Manual de usuario

Godin

Godin 3451 Manual de usuario

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Manual de usuario

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Manual de usuario

Desa

Desa CCFPDFT Manual de operación
