Owner’s Manual

Model

6908760100

7212640100R00

IMPORTANT SAFETY INFORMATION: Always read this manual rst

before attempting to install or use this replace. For your safety, always

comply with all warnings and safety instructions contained in this manual

to prevent personal injury or property damage.

To view the full line of Dimplex products, please visit

www.dimplex.com

Note: Trim may vary.

2 www.dimplex.com

Table of Contents

Always use a qualied technician

or service agency to repair

this replace.

!NOTE: Procedures and

techniques that are considered

important enough to

emphasize.

CAUTION: Procedures and

techniques which, if not

carefully followed, will result in

damage to the equipment.

WARNING: Procedures

and techniques which, if not

carefully followed, will expose

the user to the risk of re,

serious injury, or death.

Welcome & Congratulations .................. 3

IMPORTANT INSTRUCTIONS .................4

Quick Reference Guide ...................... 7

Fireplace Installation ....................... 7

Wall Hanging Instructions ....................8

Media Installation ..........................10

Operation ................................ 12

Maintenance ............................. 14

Warranty ................................ 15

Replacement Parts ........................ 17

Welcome & Congratulations

Thank you and congratulations for choosing to purchase an electric

replace from Dimplex, the world leader in electric replaces.

Please carefully read and save these instructions.

CAUTION: Read all instructions and warnings carefully before

starting installation. Failure to follow these instructions may result in

a possible electric shock, re hazard and will void the warranty.

Please record your model and serial numbers below for future

reference: model and serial numbers can be found on the Model and

Serial Number Label of your replace.

NO NEED TO RETURN TO THE STORE

Questions with operation or assembly? Require Parts Information?

Product Under Manufacturer’s Warranty?

For Troubleshooting and Technical Support

OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)

Monday to Friday 8:00 a.m. to 4:30 p.m. EST

Please have your model number and product serial

number ready. (See above)

Serial Number Label

Model Number

4 www.dimplex.com

When using electrical appliances,

basic precautions should always

be followed to reduce the risk of

fire, electric shock, and injury to

persons, including the following:

① Read all instructions before

using the electric replace.

② This replace is hot when in

use. To avoid burns, do not let

bare skin touch hot surfaces.

The trim around the heater outlet

becomes hot during heater

operation.

③ Extreme caution is necessary

when any heater is used by or

near children or invalids and

whenever the unit is left operating

and unattended.

④ Always unplug the fireplace

when not in use.

⑤ Young children should be

supervised to ensure that they do

not play with the appliance.

⑥ The appliance is not intended

for use by young children

or inrmed persons without

supervision.

⑦ If the supply cord is damaged,

it must be replaced by the

manufacturer, or its service agent,

or a qualied person in order to

avoid a hazard.

IMPORTANT INSTRUCTIONS

⑧ Do not operate any unit with

a damaged cord or plug, or if

the heater has malfunctioned,

or if the electric replace has

been dropped or damaged in

any manner, contact Dimplex

Technical Service at

1-888-346-7539.

⑨Do not use outdoors.

⑩ This fireplace is not intended

for use in bathrooms, laundry

areas and similar indoor locations.

Never locate heater where it may

fall into a bathtub or other water

container.

⑪ High temperature, keep

electrical cords, drapery, and

other furnishings at least 3 feet

(0.9m) from the front of the heater

and away from the side and rear.

⑫ Do not run the cord under

carpeting. Do not cover cord with

throw rugs, runners, or the like.

Arrange cord away from trafc

area and where it will not be

tripped over.

⑬ Do not locate the unit

directly below a xed electrical

convenience outlet.

⑭ To disconnect the replace,

turn the controls off, then remove

the plug from the outlet.

SAVE THESE INSTRUCTIONS

⑮ Do not insert or allow foreign

objects to enter any ventilation

or exhaust opening as this may

cause an electric shock or re, or

damage to the heater.

⑯ Do not block air intake or

exhaust in any manner. Do not

use on soft surfaces, like a bed,

where openings may become

blocked.

⑰ All electrical heaters have

hot and arcing or sparking parts

inside. Do not use in areas where

gasoline, paint, or ammable

liquids are used or stored or

where the unit will be exposed to

ammable vapors.

⑱ Do not modify the electric

replace. Use it only as described

in this manual. Any other use

not recommended by the

manufacturer may cause re,

electric shock or injury to persons.

⑲ Always plug heaters directly

into a wall outlet/receptacle.

Never use with an extension cord

or relocatable power tap (outlet/

power strip).

⑳ Do not burn wood or other

materials in the electric replace.

㉑Do not strike the replace

glass.

㉒ Always use a certied

electrician should new circuits or

outlets be required.

㉓ Always use properly grounded,

fused and polarized outlets.

㉔ Disconnect all power supply

before performing any cleaning,

maintenance or relocation of the

unit.

㉕ When transporting or storing

the unit and cord, keep in a

dry place, free from excessive

vibration and store so as to avoid

damage.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NO USER-SERVICABLE PARTS INSIDE

IMPORTANT INSTRUCTIONS

6 www.dimplex.com

!NOTE: This equipment has been

tested and found to comply with

the limits for Class B digital device,

pursuant to part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses and

can radiate radio frequency energy

and, if not installed and used in

accordance with the instructions, may

cause harmful interference to radio

or television reception, which can be

determined by turning the equipment

off and on, the user is encouraged to

try to correct the interference by one or

more of the following measures:

· Increase the separation between

the equipment and the receiver.

· Connect the equipment into an

outlet on a circuit different from that

to which the receiver is connected.

· Consult the dealer or an

experienced radio/TV technician for

help.

Operation is subject to the following

two conditions: (1) this device may not

cause interference and (2) this device

must accept any interference, including

interference that may cause undesired

operation of the device.

IMPORTANT INSTRUCTIONS

WARNING: Remote control

contains small batteries. Keep away

from children. If swallowed, seek

medical attention immediately.

WARNING: Do not install battery

backwards, charge, put in re or mix

with used or other battery types - may

explode or leak causing injury.

!NOTE: Changes or modications

not expressly approved by the party

responsible for compliance could

void user's authority to operate the

equipment.

Quick Reference Guide

1. Before using the fireplace

verify:

• Are the circuit breakers

for the unit on?

2. If you have any technical

questions or concerns

regarding the operation

of your electric fireplace,

or require service contact

customer service.

3. The heater may emit a slight,

harmless odor when first

used. This odor is a normal

condition caused by the initial

heating of internal heater

parts.

Site Selection

!NOTE: A 15 Amp, 120

Volt circuit is required. A

dedicated circuit is preferred

but not essential in all cases.

A dedicated circuit will be

required if, after installation,

the circuit breaker trips or the

fuse blows on a regular basis

when the heater is operating.

Additional appliances on the

same circuit may exceed the

current rating of the circuit

breaker.

WARNING: Ensure the power

cord is not installed so that

it is pinched or against a

sharp edge and ensure that

Fireplace Installation

the power cord is stored or

secured to avoid tripping or

snagging to reduce the risk of

re, electric shock or injury to

persons.

Construction and electrical

outlet wiring must comply

with local building codes and

other applicable regulations to

reduce the risk of re, electric

shock and injury to persons.

Do not attempt to wire your

own new outlets or circuits. To

reduce the risk of re, electric

shock or injury to persons,

always use a licensed

electrician.

WARNING: The supplied

8 www.dimplex.com

Fireplace Installation

hanging components are

designed for use with Dimplex

replaces only. Improper use,

or use for purposes other than

intended, may cause damage

or injury.

Wall Hanging Instructions

WARNING: Failure to install

the replace as instructed

below may result in damage

to the equipment and or may

expose the user to the risk of

re, serious injury, illness or

death.

WARNING: The replace

requires the wall hanging

bracket screws to be installed

into a minimum of one wall

studs (Figure 1).

Tools Required

• #2 Phillips screwdriver

• Pencil

• Slot screwdriver

• Bubble level (supplied)

• Drill, and drill bits as required

Approximate time: 30 minutes

for installation

1. Remove the two screws that

secure the hanging bracket

to the back of the rebox.

(Figure 1)

2. Select an appropriate location

Figure 1

to mount the unit on a wall,

above an electrical outlet.

Access to the electrical outlet

must be maintained. Ensure

the installation meets the

national and state/provincial

electrical codes.

!NOTE: It is recommended

that the bottom of the unit

not be mounted higher than

1020mm (40") from the

Fireplace Installation ground

to maintain an optimized

viewing angle of the ame.

(Figure 2)

CAUTION: Ensure that the

top of the unit is at least

152mm (6") from the ceiling

or any object (i.e. Electrical

receptacles) that may

obstruct or be susceptible the

ow or temperature of air out

of the unit.

ABCD E F

40 in (1020 mm)

RECOMMENDED

6 in (152 mm)

MINIMUM

Figure 2

Figure 3

Fireplace Installation

CAUTION: High temperature,

keep electrical cords, drapery,

and other furnishings at least

3 feet (0.9m) from the front of

the heater and away from the

side and rear.

3. The replace must be

mounted at a minimum of

two (2) points, one of which

must be on a wall stud.

Some available hanging

combinations are A-G, B-F,

B-G, C-G, A-F, A-E, A-D and

Wall anchor

Screw

Wall

bracket

Figure 4

D-G. (Figure 3).

!NOTE: Wall anchors must

be installed in the appropriate

wall locations to fasten the wall

bracket to drywall. (Figure 4)

4. Hold the wall hanging bracket

on the wall and mark the

location of ONE (1) of the

securing holes.

5. Place the bubble level onto

the top of the wall hanging

bracket.

6. Adjust the wall hanging

bracket so the bubble on the

level is centered between the

two black lines.

7. Mark the two (2) screw

locations, on the wall,

ensuring that the wall bracket

stays level.

8. Install the supplied wall

anchors on the drywall

marked locations by placing

10 www.dimplex.com

Fireplace Installation

Media Tray

Figure 6

a #2 Phillips screwdriver into

the recess of the anchor.

9. Press the anchor into the wall

in the desired marked position

while turning the anchor

clockwise until it is ush with

the wall.

10. Insert the wall anchor screws

through the wall bracket and

thread into the wall anchors.

Tighten the screw.

11. Install the remaining screw

through the bracket and into

the wall stud.

!NOTE: At least one of the

screws must be installed into a

wall stud.

12. Mount the unit on the wall,

so that the tabs on the wall

bracket have been inserted

into the slots on the back of

Figure 5

the rebox. (Figure 5)

13. Excess electrical cord can be

inserted back into the bottom

of the unit, into the cord

storage area.

Media Installation

Depending on the model, the

media may come installed in the

unit, packaged seperately or have

option of being interchanged.

Installed Media

• No additional steps are

required.

Media Seperately Packaged

• SolidMedia: Place media

piece on top of tray. (Figure 6)

• LooseMedia: Carefully pour

and evenly distribute the

media in the Media tray of the

rebox.

Otros manuales para 6908760100

Tabla de contenidos

Otros manuales de Chimenea de interior de Dimplex

Dimplex

Dimplex BLF7451-EU Manual de usuario

Dimplex

Dimplex DFP15-1134NG Manual de usuario

Dimplex

Dimplex DWOP20R Manual de usuario

Dimplex

Dimplex VEGA Manual de usuario

Dimplex

Dimplex DFR2551L Manual de usuario

Dimplex

Dimplex RWF-DG Manual de usuario

Dimplex

Dimplex DF2690 Manual de usuario

Dimplex

Dimplex VFA2927 Manual de usuario

Dimplex

Dimplex JUNEAU Manual de usuario

Dimplex

Dimplex WBK20 Manual de usuario

Dimplex

Dimplex LKD20-AU Manual de usuario

Dimplex

Dimplex SAHARA SHR12 Manual de usuario

Dimplex

Dimplex Crestmore CRS20 Manual de instrucciones

Dimplex

Dimplex contempra ef KDS6401E Guía de inicio rápido

Dimplex

Dimplex DFR2551G Manual de usuario

Dimplex

Dimplex contempra ef KDS6401E Guía de inicio rápido

Dimplex

Dimplex Revillusion RBF24DLX Manual de usuario

Dimplex

Dimplex DF2608 Manual de usuario

Dimplex

Dimplex Cavendish CSH20 Manual de usuario

Dimplex

Dimplex CAS20N-AU Manual de usuario

Dimplex

Dimplex DVF1200 Manual de usuario

Dimplex

Dimplex Cohesion DT1267BLK Manual de usuario

Dimplex

Dimplex 23" Insert Fireplace DFPI2311 Guía de inicio rápido

Dimplex

Dimplex BLF50 Manual de usuario

Manuales populares de Chimenea de interior de otras marcas

Brigantia

Brigantia 35-DVRS31N-2 Manual del propietario

Nordpeis

Nordpeis Bergen Manual de usuario

Superior

Superior BCT2536TMN Manual de usuario

Quadra-Fire

Quadra-Fire 5100I-GD-B Manual de usuario

Renaissance

Renaissance RUMFORD 1000 Manual de usuario

Lacunza

Lacunza IV-800 Manual de usuario

Baxi

Baxi 940 Instrucciones de uso

Dru

Dru Maestro 60/2 Tall RCH Manual de usuario

Diamond Fireglass

Diamond Fireglass SS-O22 Manual de usuario

HearthStone

HearthStone Windsor Bay 8830 Manual de programación

Napoleon

Napoleon ASCENT B42 Manual de usuario

Enviro

Enviro E33GI Manual de usuario

Smeg

Smeg L30 FABE Instrucciones de montaje

KEDDY

KEDDY K700 Manual de usuario

Godin

Godin 3451 Manual de usuario

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Manual de usuario

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Manual de usuario

Desa

Desa CCFPDFT Manual de operación
