PARTS AND SERVICE MANUAL

FOR

DIMPLEX 26” OUTDOOR

ELECTRIC FIREPLACE

Model DFO2607

TABLE OF CONTENTS

OPERATION PAGE 2

PARTS DRAWING PAGE 3

PARTS LIST PAGE 4

WIRING DIAGRAM PAGE 5

FRONT GLASS REMOVAL PAGE 6

UPPER LIGHT REPLACEMENT PAGE 7

LOWER LIGHT REPLACEMENT PAGE 8

MAIN ON/OFF/FLAME CONTROL REPLACEMENT PAGE 9

FLAME ROD AND MOTOR REPLACEMENT PAGE 10

CIRCUIT BOARD REPLACEMENT PAGE 11

AUDIO BOARD REPLACEMENT PAGE 12

DFO2607

OPERATION

ELECTRIC FIREPLACE MANUAL CONTROL

The manual controls for the firebox are located in the upper right hand corner behind

the access panel. To access the controls, open the upper access panel by pulling

forward and down.

To locate controls refer to Figure 3.

NOTE: The main on/off switch/flame action and flame brightness controls are

always illuminated as long as the unit is plugged in.

A. Main On/Off Switch

The ON/OFF SWITCH supplies power to the flames and over head lights.

B. Flame Action Control

Press the up or down arrow to adjust the flame speed to the desired level.

C. Flame Brightness Control

Press the up or down arrow to increase or decrease the brightness of the over head

lights.

D. Storage Compartment

A convenient location to place your CD’s or MP3 player.

E. Audio Input Plug

Using the audio cord included, a CD or MP3 player may be connected to the firebox.

NOTE: This unit does not have a heat option

Figure 3

Main

On/Off

Switch

Flame Brightness

Flame ActionAudio Input Plug Storage Compartment

DFO2607

REPLACEMENT PARTS

FIREBOX, 26” – Dimplex

CATALOGUE NO. DFO2607

PART NO. 6903100200

REPLACEMENT PART

1. MOTOR, ASSEMBLY 3000240200RP

2. LED LIGHT, TOP 3700060200RP

3. SWITCHBOARD 3000560100RP

4. CIRCUIT BOARD 3000520200RP

5. MIRROR 5900750200RP

6. GLASS FRONT 5900710200RP

7. LED LIGHT, BOTTOM 3700060200RP

8. TRANSFORMER 2100200200RP

9. FLAME ROD 5900080600RP

10.BUSHING 8500000400RP

11. LOGSET 0437960600RP

12.AUDIO BOARD 3000530100RP

YELLOW WIREOF CABLE

TO LINE UP WITH SQUARE

SOLDER PAD OF CONNECTOR BOARD.

LIGHT WIRE HARNESS

REFER TO DWG#

2500420000

INCLUDED IN

LIGHT WIRE HARNESS

INCLUDE DIN

LIGHT WIRE HARNESS

MAIN PC BBOARD

(BACK SIDE VIEW)

BLACK WIRE OF CABLE

TO LINE UP WITH SQUARE

SOLDER PAD OF CONNECTOR BOARD.

1 WATT LED

FLAME LIGHT 1 WATT LED

FLAME LIGHT

3 WATT LED

FLAME LIGHT

1 WATT LED

TOP LIGHT

CONNECTOR, WIRE

TWISTER

"B" TERMINAL

TYP.

FLICKER MOTOR

P/N 300240200

(HARNESSINCLUDED)

AUDIO BOARD

(BACK SIDE VIEW)

SWITCHBOARD

P/N 3000500100

(HARNESS INCLUDED)

CONNECTOR, FEMALE

P/N 4300430100

(HARNESS INCLUDED)

4X"A"TERMINAL

SPEAKER TERMINAL

4X "C" TERMINAL

2 X "A" TERMINAL

4 X "A" TERMINAL

SQUARE

SOLDER PAD

WIRING DIAGRAM

DFO2607

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

Lights need to be replaced when you notice a dark section of the flame. There are

three lights under the log set which generate the flames and embers located under the

emberbed.

It is a good idea to replace all of the lights at one time if they are close to the end of their

rated life. Group replacement will reduce the number of times you need to open the unit

to replace the lights.

FRONT GLASS REMOVAL

1. Remove top from mantel.

2. Lift firebox out of mantel.

3. Lay firebox on it’s back.

4. Remove screws from the left and right side of the front glass lower support.

5. Insert the tip of a slot screwdriver between the glass edge on either the left or right

side trim.

6. Using the screwdriver as a lever, apply pressure in a downward motion forcing the

edge of the glass up.

DFO2607

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

Lights need to be replaced when you notice a dark section of the flame. There are

three lights under the log set which generate the flames and embers located under the

emberbed.

It is a good idea to replace all of the lights at one time if they are close to the end of their

rated life. Group replacement will reduce the number of times you need to open the unit

to replace the lights.

UPPER LIGHT REPLACEMENT

1. Remove the front glass as shown on page 6 of this manual.

2. Remove the top trim piece by removing the 3 retaining screws.

3. Remove the 10 retaining screws and lift the top off of the unit.

4. Unplug the light wiring harness from the circuit board.

5. Remove the 3 screws and remove the light from the unit.

6. Reassemble in the reverse order.

LIGHT BULB REQUIREMENTS

Quantity of 2 clear chandelier or candelabra bulbs with an E-12 (small) socket base,

60 watt rating.

DFO2607

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

Lights need to be replaced when you notice a dark section of the flame. There are

three lights under the log set which generate the flames and embers located under the

emberbed.

It is a good idea to replace all of the lights at one time if they are close to the end of their

rated life. Group replacement will reduce the number of times you need to open the unit

to replace the lights.

LOWER LIGHT REPLACEMENT

1. Remove the front glass as shown on page 6 of this manual.

2. Remove the top trim piece by removing the 3 retaining screws.

3. Remove the 10 retaining screws and lift the top off of the unit.

4. Unplug the lower light wiring harness from the circuit board.

5. Remove the flame rod.

6. Remove the 3 screws holding each light and remove the light assembly from the

unit.

7. Reassemble in the reverse order.

DFO2607

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

MAIN ON/OFF SWITCH REPLACEMENT

1. Remove the front glass as shown on page 6 of this manual.

2. Remove the top trim piece by removing the 3 retaining screws.

3. Remove the 10 retaining screws and lift the top off of the unit.

4. Locate the main on/off/flame control mounted on the top panel and disconnect the

wiring plug noting it’s original location.

5. Remove the 4 mounting screws on the front of the top panel and remove the control

from the unit.

6. Reassemble in the reverse order.
