Quick Start Guide

FX Wall Mounted Fan Heaters QS015

This guide is for quick reference only. Refer to the FX installation and operating instructions for further information

FX20V

Dimplex UK Ltd, Millbrook House, Hedge End, Southampton, SO30 2DF. For further assistance please contact Dimplex customer services on 0845 600 5111. Web-site: www.dimplex.co.uk

On/Off indicator

Indicator will glow red when heating

Pull cord switch

Pull the cord to switch the heater ON and pull the cord

again to switch the heater OFF

FX20VE (runback timer)

On/Off indicator

Indicator will glow red when heating.

Pull cord switch

Pull the cord to switch the heater ON and the heater will

run for 15 minutes* and then automatically switch off. To

restart the heater for a further 15 minutes pull the cord

twice.

To switch the heater off before the timer

expires pull the cord once.

*Timer is factory preset at 15 minutes but can be adjusted to run for any

time period from 5 – 155mins, please refer to installation and operating

instructions for further details

FX20VL

Thermostat

Turn thermostat dial to appropriate position to

give comfort level required. Heater will switch on

and off as necessary, and a higher setting will

make the room warmer.

On/Off indicator

Indicator will glow red when heating

WARNING: A clearance of at least 250mm must be maintained from either side of the heater, 280mm from the top of the heater to the ceiling

and must be installed 1800mm from the floor DO NOT COVER or obstruct the air inlet or outlet grilles.

PLEASE REFER TO THE OPERATING AND INSTALLATION INSTRUCTIONS FOR FURTHER SAFETY ADVICE.
