Dimplex DHCH20H Manual de usuario

For domestic household use only.

INSTRUCTION MANUAL

2kW Ceramic Tower Heater

Model: DHCH20H

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND

RETAINED FOR FUTURE REFERENCE.

Note also the information presented on the appliance

CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/

OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY

Please read the operating instructions carefully before using your product for

the first time and keep them in a safe place.

• When using electrical appliances, basic precautions should always be followed

to reduce the risk of fire, electrical shock and injury to persons, including the

following:

• If the appliance is damaged, check with the supplier before installation and

operation.

- Do not use outdoors.

- Do not use in the immediate surroundings of a bath, shower or a

swimming pool.

- Do not use this heater if it has been dropped.

- Do not use if there are visible signs of damage to the heater.

- Use this heater on a horizontal and stable surface, or fix it to the

wall, as applicable.

• Do not locate the appliance immediately below a fixed socket outlet or

connection box.

• This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the

appliance.

• Do not use this appliance in series with a thermal control, a program controller,

a timer or any other device that switches on the heat automatically, since a

fire risk exists when the appliance is accidentally covered or displaced.

• In the event of a fault, unplug the appliance.

• Unplug the appliance when not required for long periods.

• This product is intended for INDOOR RESIDENTIAL applications only.

• DO NOT cover cord with carpeting, throw rugs, runners, or similar coverings.

• DO NOT route cord under furniture or appliances. Take care to position the

cord away from traffic areas and where it will not be a tripping hazard.

• This appliance must not be used in a bathroom.

• The appliance must be positioned so that the plug is accessible.

• Although this appliance complies with safety standards, we do not recommend

its use on deep pile carpets or on long hair type of rugs.

• The appliance must be positioned so that the plug is accessible.

• If the supply cord is damaged it must be replaced by the manufacturer or

service agent or a similarly qualified person in order to avoid a hazard.

• Keep the supply cord away from the front of the appliance.

• Do not use this heater in small rooms when they are occupied by persons

not capable of leaving the room on their own, unless constant supervision is

provided.

• To reduce the risk of fire, keep textiles, curtains and or flammable material a

minimum distance of 1m from the air outlet.

• In order to avoid overheating, DO NOT COVER the appliance. Do not place

material or garments on the appliance, or obstruct the air circulation around

the appliance, for instance by curtains or furniture, as this could cause

overheating and a fire risk.

• This Heater carries the warning symbol indicating that it must not

be covered.

• In order to avoid a hazard due to inadvertent resetting of the thermal cut-out,

this appliance must not be supplied through an external switching device,

such as a timer, or connected to a circuit that is regularly switched on and off

by the utility.

• CAUTION: Some parts of this product can become very hot and cause burns.

Particular attention has to be given where children and vulnerable people are

present.

• Do not use this appliance with an extension lead or power board.

• Do not use this appliance in series with a thermal control, a program controller,

a timer or any other device that switches on the heat automatically, since a

fire risk exists when the appliance is accidentally covered or dis-placed.

Exposed to the

weather outdoors

Near water If the power cable

wires are frayed or cut

Where small children

may be left unattended

No extension leads or

power boards

Where there is risk

of fire or close to

a naked flame

Where the power

cable may be

damaged

On a slope or

uneven surface

Where it may be

damaged by

chemicals

If there is a risk

of water falling on

the unit

Where there is a risk

of interference by

foreign objects

This product is not

made for DIY repair

Model no. DHCH20H

Power supply

220-240V~, 50Hz

Rated power

2000W

Heat settings

Adjustable Thermostat Y

Oscillation Y

Weight (net) 2kg

Dimensions (w x d x h) 170 x 165 x 516mm

Specifications

For greater precision, please always refer to the rating label placed on the product.

Parts

Handle

Thermostat

Switch

Grille

Base

Power Indicator Light

Control Panel

Thermostat Switch

AMin

BMax

1Off

2Fan Only

3Low Heat

4High Heat

5Off

6Fan & Oscillation

7Oscillation - Low Heat

8Oscillation - High Heat

Fig 1

Fig 2

Operation

1. Turn the THERMOSTAT switch clockwise, from MIN to MAX.

2. To use the heater without oscillation, turn the SWITCH to the FAN ONLY icon

2. For low heat, position the switch to icon 3 and for high heat, switch to icon

3. To enable oscillation, turn the SWITCH to the FAN & OSCILLATION icon 6.

For low heat, position the switch to icon 7 and for high heat, switch to icon 8.

4. To turn the device off, position the switch to one of the OFF icons 1or 5.

Note: For best results, use this heater in a room with a maximum ceiling height

of 2.5m.

Cleaning

Over time, dust can accumulate on the heater which can effect performance.

It is recommended to clean the unit at least once a month.

1. Turn the unit OFF and disconnect the appliance from the power supply.

2. Remove any dust build up with a soft brush.

3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can be

used for any stubborn marks.

IMPORTANT

The control panel and other parts must not come into contact with water or

any other liquids.

Storage

If not using the unit for an extended period of time. After cleaning please:

• Ensure control switch is OFF and remove plug from the power outlet.

• Cover the unit and store it upright in a location where it will not receive direct

sunlight. NB- Prolonged exposure to direct sunlight will discolour the unit.

If the unit fails to operate efficiently, is broken or other problems arise, unplug

and do not operate. Ask for advice by calling your local after sales service

agent or the Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824

(NZ).

Maintenance

Warranty

Please refer to the warranty card in the box for warranty information. For any

troubleshooting advice, please contact the relative Customer Care Centre below.

Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd

8 Lakeview Drive, 38 Harris Road, East Tamaki,

Scoresby 3179, Victoria Auckland 2013

Australia New Zealand

Ph: 1300 556 816 Ph: 0800 666 2824

Recycling: Do not dispose of electrical appliances as unsorted

municipal waste. Use separate collection facilities. Contact your

local government for information regarding the collection systems

available. If electrical appliances are disposed of in landfills or dumps,

hazardous substances can leak into the ground water, polluting the

food chain and damaging health and well-being.
